ARTICLE
Journal Name
The reusability of A-Hp-Br catalyst was also investigated in processing and the catalyst displays outstanding recyclability
flow condition and the results are summarized in Figure 8. and reusability. Further application of PANF-QAS in organic
After each run, 10 mL of ethyl acetate was pumped into the synthesis is on-going in this group.
system at 0.1 mL/min to regenerate the fiber catalyst. After
fifteen recycles, A-Hp-Br catalyst was still as active as the
Acknowledgements
original catalyst (Figure 8). Compared with commonly used
PTCs, the PANF-QAS catalyst has advantages of simple work-up
procedure for recovery and excellent reusability.
This work was supported by the National Natural Science
Foundation of China ( No. 21572156), (No. 21306133), Tianjin
Research Program of Application Foundation and Advanced
Technology (No. 14JCYBJC22600), National Basic Research
Program of China (2015CB856500), and Scientific Research
Fund Project of Yunnan Provincial Department of Education (No.
2014Y535).
Experimental
Typical procedure for PANF-QAS catalyzed reduction
Corresponding aldehydes, ketones, aryl azides, or benzyl
halides (4 mmol), NaBH4 (2 mmol) and A-Hp-Br (10 mol%)
were added to 15 mL of pH = 12 aqueous solution. The
solution was stirred at appropriate temperature and
monitored by TLC. After completion, the reaction was
quenched by 10% HCl aqueous solution to pH = 7 and filtered
to recycle catalyst A-Hp-Br, which was washed with ethyl
acetate (5 mL×2) and directly used for the next run. The eluted
ethyl acetate was used to extract aqueous phase of the
reaction mixture and dried over Na2SO4. Then the solvent was
evaporated (recycled) to give the products (most ones have
high purity, a few products with low purities were simply
purified through silica gel column).
Notes and references
1
(a) C.-J. Li, Acc. Chem. Res., 2010, 43, 581-590; (b) S.
Kobayashi and K. Manabe, Acc. Chem. Res., 2002, 35, 209-
217; (c) F. Zhou and C.-J. Li, Nat. commun., 2014, 5, 1-6; (d)
A. Gordillo, M. A. Ortuño, C. López-Mardomingo, A. Lledós,
G. Ujaque and E. de Jesús, J. Am. Chem. Soc., 2013, 135,
13749-13763; (e) Z. Jia, F. Zhou, M. Liu, X. Li, A. S. Chan and
C.-J. Li, Angew. Chem. Int. Ed., 2013, 52, 11871-11874; (f) X.
Zhou, X. Li, L. Jiao, H. Huo and R. Li, Catal. Lett., 2015, 145
,
1591-1599; (g) N. M. Patil and B. M. Bhanage, Catal. Today.,
2015, 247, 182-189. (h) Z. Mandegani, M. Asadi, Z. Asadi, A.
Mohajeri, N. Iranpoor and A. Omidvar, Green Chem., 2015,
17, 3326-3337; i) P. Kleman, P. Barbaro and A. Pizzano, Green
Chem., 2015, 17, 3826-3836; (j) C.-J. Wu, J.-J. Zhong, Q.-Y.
Meng, T. Lei, X.-W. Gao, C.-H. Tung and L.-Z. Wu, Org. Lett.,
2015, 17, 884-887; (k) Q. Liang, P. Xing, Z. Huang, J. Dong, K.
B. Sharpless, X. Li and B. Jiang, Org. Lett., 2015, 17, 1942-
1945; (l) J. Pinto, V. L. M. Silva, A. M. G. Silva, L. M. N. B. F.
Santos and A. M. S. Silva, J. Org. Chem., 2015, 80, 6649-6659;
(m) J. M. de los Santos, R. Ignacio, Z. Es Sbai, D. Aparicio and
F. Palacios, J. Org. Chem., 2014, 79, 7607-7615.
Typical procedure for continuous flow process
Silicone column was filled with 370 mg of catalyst A-Hp-Br ( c =
1.08 mmol/g) between flask and peristaltic pump. The catalytic
column was kept 25oC while a solution of the NaBH4 (2 mmol)
in 20 mL water (pH = 12) and 1-naphthaldehyde (4 mmol) in 1
mL of ethyl acetate were pumped into the system at 0.5
mL/min. Notably, the water and 1-naphthaldehyde were
stirred by magnetic stirrer in flask to ensure the mixture is
emulsion. After completion, the reaction was pumped into 10
mL of 10% HCl aqueous solution at 0.1 mL/min to quench the
reaction, then ethyl acetate (5 mL×2) was pumped in to system
at 0.1 mL/min to regenerate the catalyst and directly used for
the next run. The eluted ethyl acetate was used to extract
aqueous phase of the reaction mixture and dried over Na2SO4.
Then the solvent was evaporated (recycled) to give the
products with high purity without further purification.
2
(a) A. F. Trindade, P. M. P. Gois and C. A. M. Afonso, Chem.
Rev., 2009, 109, 418-514; (b) M. Benaglia, A. Puglisi and F.
Cozzi, Chem. Rev., 2003, 103, 3401-3430; (c) R. P. Jumde, C.
Evangelisti, A. Mandoli, N. Scotti and R. Psaro, J. Catal., 2015,
324, 25-31; (d) M. Alonzi, M. P. Bracciale, A. Broggi, D. Lanari,
A. Marrocchi, M. L. Santarelli and L. Vaccaro, J. Catal., 2014,
309, 260-267; (e) T. Kropp, J. Paier and J. Sauer, J. Am. Chem.
Soc., 2014, 136, 14616-14625; (f) P. Liu, E. J. M. Hensen, J.
Am. Chem. Soc., 2013, 135, 14032-14035; (g) C. Bianchini, D.
G. Burnaby, J. Evans, P. Frediani, A. Meli, W. Oberhauser, R.
Psaro, L. Sordelli and F. Vizza, J. Am. Chem. Soc., 1999, 121
,
5961-5971; (h) Y. Chen, E. Callens, E. Abou-Hamad, N. Merle,
A. J. P. White, M. Taoufik, C. Copéret, E. Le Roux and J.-M.
Basset, Angew. Chem. Int. Ed., 2012, 51, 11886-11889; (i) E.
Le Roux, M. Taoufik, C. Copéret, A. de Mallmann, J.
Thivolle
‐Cazat, J. M. Basset, B. M. Maunders and G. J.
Conclusions
Sunley, Angew. Chem. Int. Ed., 2005, 44, 6755-6758; (j) B.
Tamami and S. Ghasemi, Appl. Catal. A-Gen., 2011, 393, 242-
250;
A series of quaternary ammonium salts were integrated onto
polyacrylonitrile fibers and the structure/loading-activity
relationships were investigated which showed that the
catalysts containing quaternary ammonium salts with longer
alkyl chains, bigger cationic radii, and lipophilic functional
groups lead to higher reduction rates. These fiber supported
catalysts showed excellent catalytic activities (91%-99%) for a
wide scope of substrates including aldehydes, ketones, aryl
azides, and benzyl halides. The reduction of 1-naphthaldehyde
by the optimized catalyst was performed in continuous flow
3
(a) M. E. Sergeev, F. Morgia, M. Lazari, C. Wang and R. M.
van Dam, J. Am. Chem. Soc., 2015, 137, 5686-5694; (b) L.
Woźniak, J. J. Murphy and P. Melchiorre, J. Am. Chem. Soc.,
2015, 137, 5678-5681; (c) S. E. Denmark, R. C. Weintraub and
N. D. Gould, J. Am. Chem. Soc., 2012, 134, 13415-13429; (d)
Y. Liu, S. Jin, L. Huang and Y. Hu, Org. Lett., 2015, 17, 2134-
2137; (e) R. Mirabdolbaghi, T. Dudding and T. Stamatatos,
Org. Lett., 2014, 16, 2790-2793; (f) M. Ando, M. Sasaki, I.
Miyashita and K. Takeda, J. Org. Chem., 2015, 80, 247-255; (g)
B. Li and C. Li, J. Org. Chem., 2014, 79, 2242-2254; (h) J.-A.
