Protease Inhibitors
J ournal of Medicinal Chemistry, 2000, Vol. 43, No. 9 1805
Szabo, G.; J uhasz, A.; Tomori, E.; Szilagyi, G. Highly active and
selective anticoagulants. D-Phe-Pro-Arg-H, a free tripeptide
aldehyde prone to spontaneous inactivation, and its stable
N-methyl derivative D-Me-Phe-Pro-Arg-H. J . Med. Chem. 1990,
33, 1729-1735.
XNHC6H4SO2), 149.1 (s, NHCONH), 175.1 (s, SO2NdC). Anal.
(C25H27N5O7S2, 573.65) C, H, N, S.
p Ka Deter m in a tion . The half-neutralization point was
measured by titrating the organic acids/bases with 0.05 N
NaOH and 0.05 N HCl in EtOH-water (30%, v/v), using a
glass electrode, as described by Bell and Roblin56 for the
structurally related antibacterial sulfonamides.
(8) Krishnan, R.; Zhang, E.; Hakansson, K.; Arni, R. K.; Tulinsky,
A.; Lim-Wilby, M. S.; Levy, O. E., Semple, J . E., Brunck, T. K.
Highly selective mechanism-based thrombin inhibitors: struc-
tures of thrombin and trypsin inhibited with rigid peptidyl
aldehydes. Biochemistry 1998, 37, 12094-13103.
(9) Claeson, G.; Philipp, M.; Agner, E.; Scully, M. F.; Metternich,
R.; Kakkar, V. V.; DeSoyza, T.; Niu, L. H. Benzyloxycarbonyl-
D-Phe-Pro-methoxypropylboroglycine: a novel inhibitor of throm-
bin with high selectivity containing a neutral side chain at the
P1 position. Biochem. J . 1993, 290, 309-312.
(10) (a) Stu¨rzebecher, J .; Vieweg, H.; Wikstrom, P.; Turk, D.; Bode,
W., Interaction of thrombin with benzamidine-based inhibitors.
Biol. Chem. Hoppe-Seyler 1992, 373, 491-496. (b) Stu¨rzebecher,
J .; Prasa, D.; Bretschneider, E.; Bode, W.; Bauer, M.; Brand-
stetter, H.; Wikstrom, P.; Vieweg, H. New developments in the
field of benzamidine-derived thrombin inhibitors. In DIC -
Pathogenesis, Diagnosis, and Therapy of Disseminated Intra-
vascular Fibrin Formation; Muller-Berghaus, G., Madlener, K.,
Blomback, M., ten Cate, J . W., Eds.; Excerpta Medica: Amster-
dam, London, New York, Tokyo, 1993; pp 183-190.
(11) (a) Adang, A. E.; Lucas, H.; de Man, A. P.; Engh, R. A.;
Grootenhuis, P. D. Novel acylguanidine containing thrombin
inhibitors with reduced basicity at the P1 moiety. Bioorg. Med.
Chem. Lett. 1998, 8, 3603-3608. (b) Lumma, W. C.; Witherup,
K. M.; Tucker, T. J .; Brady, S. F.; Sisko, J . T.; Naylor-Olsen, A.
M.; Lewis, S. D.; Lucas. B. J .; Vacca, J . P. Design of novel, potent,
noncovalent inhibitors of thrombin with nonbasic P-1 substruc-
tures: rapid structure-activity studies by solid-phase synthesis.
J . Med. Chem. 1998, 41, 1011-1013. (c) Reers, M.; Koschinsky,
R.; Dickneite, G.; Hoffmann, D.; Czech, J .; Stuber, W. Synthesis
and characterisation of novel thrombin inhibitors based on
4-amidinophenylalanine. J . Enzyme Inhib. 1995, 9, 61-72.
(12) (a) Levy, O. E.; Semple, J . E.; Lim, M. L.; Reiner, J .; Rote, W.
E.; Dempsey, E.; Richard, B. M.; Zhang, E.; Tulinsky, A.; Ripka,
W. C.; Nutt, R. F. Potent and selective thrombin inhibitors
incorporating the constrained arginine mimic L-3-piperidyl(N-
guanidino)alanine at P1. J . Med. Chem. 1996, 39, 4527-4530.
(b) Semple, J . E.; Rowley, D. C.; Brunck, T. K.; Ha-Uong, T.;
Minami, N. K.; Owens, T. D.; Tamura, S. Y.; Goldman, E. A.;
Siev, D. V.; Ardecky, R. J .; Carpenter, S. H.; Ge, Y.; Richard, B.
M.; Nolan, T. G.; Hakanson, K.; Tulinsky, A.; Nutt, R. F.; Ripka,
W. C. Design, synthesis, and evolution of a novel selective, and
orally bioavailable class of thrombin inhibitors: P1-argininal
derivatives incorporating P3-P4 lactam sulfonamide moieties.
J . Med. Chem. 1996, 39, 4531-4536.
(13) Sixma, J . J .; de Groot, P. G. The ideal antithrombotic drug.
Thromb. Res. 1992, 68, 507-512.
(14) Okamoto, S.; Kinjo, K.; Hijikata, A.; Kikumoto, R.; Tamao, Y.;
Ohkubo, K.; Tonomura, S. Thrombin inhibitors. 1. Ester deriva-
tives of NR-(arylsulfonyl)-L-arginine. J . Med. Chem. 1980, 23,
827-830.
(15) (a) Stu¨rzebecher, J .; Markwardt, F.; Voigt, B.; Wagner, G.;
Walsmann, P. Cyclic amides of NR-arylsulfonylamino acylated
4-amidinophenylalanine - tight binding of thrombin. Thromb.
Res. 1983, 29, 635-642. (b) Stu¨rzebecher, J .; Markwardt, F.;
Voigt, B.; Wagner, G. Inhibition of bovine and human thrombins
by derivatives of benzamidines. Thromb. Res. 1984, 36, 457-
467.
(16) Groutas, W. C.; Kuang, R.; Venkataraman, R.; Epp, J . B.; Ruan,
S.; Prakash, O. Structure-based design of mechanism-based
inhibitors of the serine proteinases employing a novel amino
acid-derived heterocyclic scaffold. Biochemistry 1997, 36, 4739-
4750.
(17) (a) Supuran, C. T.; Briganti, F.; Scozzafava, A. Sulfenamido-
sulfonamides as inhibitors of carbonic anhydrase isozymes I, II
and IV. J . Enzyme Inhib. 1997, 12, 175-190. (b) Briganti, F.;
Pierattelli, R.; Scozzafava, A.; Supuran, C. T. Carbonic anhy-
drase inhibitors Part 37. Novel classes of isozyme I and II
inhibitors and their mechanism of action. Kinetic and spectro-
scopic investigations on native and cobalt-substituted enzymes.
Eur. J . Med. Chem. 1996, 31, 1001-1010.
(18) (a) Supuran, C. T.; Ilies, M. A.; Scozzafava, A. Carbonic anhy-
drase inhibitors Part 29. Interaction of isozymes I, II and IV
with benzolamide-like derivatives. Eur. J . Med. Chem. 1998, 33,
739-752. (b) Mincione, F.; Menabuoni, L.; Briganti, F.; Mincione,
G.; Scozzafava, A.; Supuran, C. T. Carbonic anhydrase inhibi-
tors: Inhibition of isozymes I, II and IV with N-hydroxysulfona-
mides - A novel class of intraocular pressure lowering agents.
J . Enyme Inhib. 1998, 13, 267-284.
En zym e Assa ys: KI Deter m in a tion s. Human thrombin
and human trypsin were purchased from Sigma Chemical Co.
(St. Louis, MO); their concentrations were determined from
the absorbance at 280 nm and the extinction coefficients
furnished by the supplier. The activity of such preparations
was in the range of 2500-3000 NIH units/mg. The potency of
standard and newly obtained inhibitors was determined from
the inhibition of the enzymatic (amidolytic) activity of these
serine proteases, at 21 °C, using Ts-Gly-Pro-Arg-pNA (Chro-
mozym TH) from Sigma as substrate, by the method of
Lottenberg et al.23 The substrate was reconstituted as 4 mM
stock in ultrapure water and brought to pH 4 with hydrochloric
acid. Substrate concentrations were determined from absor-
bance at the isosbestic wavelength for the peptide-p-nitro-
anilide-p-nitroaniline mixtures. Extinction coefficients of 8270
L‚mol-1‚cm-1 in the used buffer (0.01 M Hepes-0.01 M Tris-
0.1 M NaCl-0.1% poly(ethylene glycol) 6000) were employed.
The rate of p-nitroanilide hydrolysis was determined from the
change in absorbance at 405 nm using an extinction coefficient
for p-nitroaniline of 9920 L‚mol-1‚cm-1 for the above-men-
tioned reaction buffer. Measurements were made using a Cart
3 spectrophotometer interfaced with a PC. Initial velocities
were thus estimated using the direct linear plot-based proce-
dure as reported by Lottenberg et al.23 KI’s were then deter-
mined according to Dixon, using a linear regression program.57
The KI values determined are the means of at least three
determinations.
Ack n ow led gm en t. This research was financed in
part by the EU Grant ERB CIPDCT 940051.
Su p p or tin g In for m a tion Ava ila ble: Tables S1-S6 giv-
ing the calculated descriptors for the 99 drugs considered in
the QSAR section. This material is available free of charge
Refer en ces
(1) Shafer, J . A. Cardiovascular chemotherapy: anticoagulants.
Curr. Opin. Chem. Biol. 1998, 2, 458-465.
(2) (a) Stu¨rzebecher, J .; Meier, J . Synthetic low-molecular weight
thrombin inhibitors: The ideal antithrombotic drug? J . Enzyme
Inhib. 1995, 9, 1-2. (b) Stu¨rzebecher, J .; Prasa, D.; Hauptmann,
J ., Vieweg, H.; Wikstrom, P. Synthesis and structure-activity
relationships of potent thrombin inhibitors: Piperazides of
3-amidinophenylalanine. J . Med. Chem. 1997, 40, 3091-3099.
(3) (a) Pavone, V.; De Simone, G.; Nastri, F.; Galdiero, S.; Staiano,
N.; Lombardi, A.; Pedone, C. Multiple binding mode of reversible
synthetic thrombin inhibitors. A comparative structural analysis.
Biol. Chem. 1998, 379, 987-1006. (b) De Simone, G.; Lombardi,
A.; Galdiero, S.; Della Morte, R.; Staiano, N.; Pedone, C.;
Bolognesi, M.; Pavone, V. Hirunorms are true hirudin mimet-
ics: the crystal structure of human R-thrombin: hirunorm V
complex. Protein Sci. 1998, 7, 243-253.
(4) (a) Stubbs, M. T.; Bode, W. A player of many parts: the spotlight
falls on thrombin’s structure. Thromb. Res. 1993, 69, 1-58. (b)
Engh, R. A.; Brandstetter, H.; Sucher, G.; Eichinger, A.; Bau-
mann, U.; Bode, W.; Huber, R.; Poll, T.; Rudolph, R.; von der
Saal, W. Enzyme flexibility and “weak” interactions characterize
thrombin-ligand interactions: implications for drug design.
Structure 1996, 4, 1353-1362.
(5) (a) Babine, R. E.; Bender, S. L. Molecular recognition of protein-
ligand complexes: Application to drug design. Chem. Rev. 1997,
97, 1359-1472. (b) Salemme, F. R.; Spurlino, J .; Bone, R.
Serendipity meets precision: the integration of structure-based
drug design and combinatorial chemistry for efficient drug
discovery. Structure 1997, 5, 319-324.
(6) Eriksson, U. G.; Renberg, L.; Bredberg, U.; Teger-Nilsson, A.
C.; Regardh, C. G. Animal pharmacokinetics of inogatran, a low-
molecular-weight thrombin inhibitor with potential use as an
antithrombotic drug. Biopharm. Drug Dispos. 1998, 19, 55-64.
(7) (a) Bajusz, S.; Barbas, E.; Tolnay, P.; Szell, E.; Bagdy, D.
Inhibition of thrombin and trypsin by tripeptide aldehydes. Int.
J . Pept. Protein Res. 1978, 12, 217-221. (b) Bajusz, S.; Szell,
E.; Bagdy, D.; Barbas, E.; Horvath, G.; Dioszegi, M.; Fittler, Z.;
(19) Winnek, P. S.; Anderson, G. W.; Marson, H. W.; Faith, E.; Roblin,
R. O., J r. Studies in chemotherapy. V. Sulfanilylcyanamide and
related compounds. J . Am. Chem. Soc. 1942, 64, 1682-1685.
