11574 J. Phys. Chem. A, Vol. 114, No. 43, 2010
Deniz et al.
and 532 nm (30 mJ) and the emission intensity was measured
at 580 nm with and without a long-pass filter (>490 nm) in
between laser and sample.
Acknowledgment. We thank the the NSF (CAREER Award
CHE-0237578 and CHE-0749840) and MIUR (PRIN 2008) for
financial support.
Supporting Information Available: Experimental proce-
dures for the syntheses of 3a, 4a, 5a, 22a, and 25 and their
precursors; steady-state absorption and emission spectra of 19a
and 22a; redox potentials of 20, 21, 29, and 30; steady-state
emission spectra of 23-25; absorbance evolution upon excita-
tion of 3a and 5a; determination of the quantum yield for the
photochromic transformations. This material is available free
References and Notes
(1) Pawley, J. B., Ed.; Handbook of Biological Confocal Microscopy;
Springer: New York, 2006.
(2) Haugland, R. P. The Handbook: A Guide to Fluorescent Probes
and Labeling Technologies; Molecular Probes: Eugene, OR, 2005.
(3) Born, M.; Wolf, E. Principles of Optics; Cambridge University
Press: Cambridge, 2002.
(4) (a) Hell, S. W. Nat. Biotechnol. 2003, 21, 1347–1355. (b) Hell,
S. W.; Dyba, M.; Jakobs, S. Curr. Opin. Neurobiol. 2004, 14, 599–609. (c)
Hell, S. W. Phys. Lett. A 2004, 326, 140–145. (d) Hell, S. W.; Kastrup, L.
Nachr. Chem. 2007, 55, 47–50. (e) Hell, S. W. Science 2007, 316, 1153–
1158. (f) Hell, S. W. Nat. Methods 2009, 6, 24–32. (g) Hell, S. W.; Schmidt,
R.; Egner, A. Nat. Photonics 2009, 3, 381–387.
(5) (a) Bates, M.; Huang, B.; Zhuang, X. Curr. Opin. Chem. Biol. 2008,
12, 505–514. (b) Huang, B.; Bates, M.; Zhuang, X. Annu. ReV. Biochem.
2009, 78, 993–1016. (c) Zhuang, X. Nat. Photonics 2009, 3, 365–367.
(6) Ji, N.; Shroff, H.; Zhong, H.; Betzig, E. Curr. Opin. Neurobiol.
2008, 18, 605–616.
(7) Gustafsson, M. G. L. Nat. Methods 2008, 5, 385–387.
(8) Ferna´ndez-Sua´rez, M.; Ting, A. Y. Nat. ReV. Mol. Cell. Biol. 2008,
9, 929–943.
Figure 11. Emission intensity at 580 nm of solutions (0.01-0.03 mM,
MeCN, 20 °C) of 3a (a), 5a (b), 20 (c), and 21 (d) recorded by turning
on and off an exciting beam at λOFF (355 nm, 10 mJ, 6 ns), while
illuminating the sample at λON (532 nm, 30 mJ, 6 ns).
(9) Heilemann, M.; Dedecker, P.; Hofkens, J.; Sauer, M. Laser Photon
ReV. 2009, 3, 180–202.
Mass Lab Trio-2 spectrometer in a 3-nitrobenzyl alcohol matrix.
High-resolution electrospray ionization mass spectra
(HRESIMS) were recorded with an Agilent LCTOF spectrom-
eter. Nuclear magnetic resonance (NMR) spectra were recorded
with Bruker Avance 400 and 500 spectrometers. Steady-state
absorption spectra were recorded with a Varian Cary 100 Bio
spectrometer, using quartz cells with a path length of 0.5 cm.
Steady-state emission spectra were recorded with a Varian Cary
Eclipse spectrometer in aerated solutions. Fluorescence quantum
yields were determined with a fluorescein standard, following
a literature protocol.27 Cyclic voltammograms were recorded
with a CH Instruments 660 workstation in degassed MeCN
solutions of Bu4NPF6 (0.1 M) under an atmosphere of Ar, using
a glassy-carbon working electrode, a platinum counter electrode,
and a Ag/AgCl reference electrode. Time-resolved absorption
spectra and emission traces were recorded with a Luzchem
Research mLFP-111 spectrometer in aerated solutions by
illuminating orthogonally the sample with a Continuum Surelite
II-10 Nd:YAG pulsed laser [pulse width ) 6 ns (fwhm)]. The
laser pulse was probed with a fiber that synchronized the mLFP
system with a Tektronix TDS 3032 digitizer operating in
pretrigger mode. The signals from a compact Hamamatsu
photomultiplier were initially captured by the digitizer and then
transferred to a personal computer that controlled the experiment
with Luzchem software developed in the LabView 5.1 environ-
ment from National Instruments. For absorption measurements,
the laser was operated at 355 nm (10 mJ) and the transmittance
was measured in the 350-700 nm spectral range. The monitor-
ing beam was supplied by a ceramic xenon lamp and delivered
through quartz fiber optical cables. For fluorescence measure-
ments, the laser was operated simultaneously at 355 (10 mJ)
(10) (a) Lippincott-Schwartz, J.; Manley, S. Nat. Methods 2009, 6, 21–
23. (b) Lippincott-Schwartz, J.; Patterson, G. H. Trends Cell Biol. 2009,
19, 555–565.
(11) Hess, S. T. Nat. Methods 2009, 6, 124–125.
(12) Dorion, G. H.; Wiebe, A. F. Photochromism; Focal Press: New
York, 1970.
(13) In Photochromism; Brown, G. H., Ed.; Wiley: New York, 1971.
(14) In Organic Photochromes; El’tsov, A. V., Ed.; Consultants Bureau:
New York, 1990.
(15) In Photochromism: Molecules and Systems; Bouas-Laurent, H.,
Du¨rr, H., Eds.; Elsevier: Amsterdam, 1990.
(16) In Organic Photochromic and Thermochromic Compounds; Crano,
J. C., Guglielmetti, R., Eds.; Plenum Press: New York, 1999.
(17) Irie, M. Chem. ReV. 2000, 100, 1683–1890.
(18) Kuz’min, M. G.; Koz’menko, M. V. In Luminescence of Photo-
chromic Compounds in Organic Photochromes; El’tsov, A. V., Ed.;
Consultants Bureau: New York, 1990, pp 245-265.
(19) (a) Raymo, F. M.; Tomasulo, M. Chem. Soc. ReV. 2005, 34, 327–
336. (b) Raymo, F. M.; Tomasulo, M. J. Phys. Chem. A 2005, 109, 7343–
7352. (c) Cusido, J.; Deniz, E.; Raymo, F. M. Eur. J. Org. Chem. 2009,
2031–2045. (d) Yildiz, I.; Deniz, E.; Raymo, F. M. Chem. Soc. ReV. 2009,
38, 1859–1867.
(20) (a) Hofmann, M.; Eggeling, C.; Jakobs, S.; Hell, S. W. Proc. Natl.
Acad. Sci. U.S.A. 2005, 102, 17565–17569. (b) Bossi, M.; Belov, V.;
Polyakova, S.; Hell, S. W. Angew. Chem., Int. Ed. 2006, 45, 7462–7465.
(c) Bossi, M.; Fo¨lling, J.; Dyba, M.; Westphal, V.; Hell, S. W. New J.
Phys. 2006, 8, 275–284. (d) Schwentker, M. A.; Bock, H.; Hofmann, M.;
Jakobs, S.; Bewersdorf, J.; Eggeling, C.; Hell, S. W. Microsc. Res. Technol.
2007, 70, 269–280. (e) Fo¨lling, J.; Polyakova, S.; Belov, V.; van Blaaderen,
A.; Bossi, M. L.; Hell, S. W. Small 2008, 4, 134–142.
(21) (a) Tomasulo, M.; Deniz, E.; Alvarado, R. J.; Raymo, F. M. J.
Phys. Chem. C 2008, 112, 8038–8045. (b) Deniz, E.; Tomasulo, M.;
DeFazio, R. A.; Watson, B. D.; Raymo, F. M. Phys. Chem. Chem. Phys.
2010, 12, 11630-11634.
(22) Deniz, E.; Tomasulo, M.; Sortino, S.; Raymo, F. M. J. Phys. Chem.
C 2009, 113, 8491–8497.
(23) Deniz, E.; Sortino, S.; Raymo, F. M. J. Phys. Chem. Lett. 2010, 1,
1690–1693.
