FULL PAPER
10.50 major (s, 1 H, anti-cis-CH); 0.81–1.88 (m, 45 H, major and
Acknowledgments
minor adamantyl protons; ov. 3 H, allyl-CH3; ov. minor 1 H, anti-
cis-CH; ov. major 1 H, syn-cis-CH); 2.13 minor (s, 1 H, syn-cis-
CH); 2.42 major (d, JP,H = 17.2 Hz, 1 H, anti-trans-CH); 3.0 minor
(d, JP,H = 16.4 Hz, 1 H, anti-trans-CH); 3.82 major (d, JP,H = Hz12
1 H, syn-trans-CH); 4.03 minor (d, JP,H = 10.4 Hz, 1 H, syn-trans-
CH); 6.85–7.90 (m, 36 H, Ar) ppm. 13C{1H} NMR (100.6 MHz,
CDCl3): δ = 122.6 major (s, allyl-CH3); 30.8, 36.0 43.3 (s, C3, C4,
C2 Ad); 58.9 major (s, cis-CH2); 77.2 major (trans-CH2 ov. CDCl3);
78.5 (s, C1O Ad); 120.1–133.8 (C and CH Naph); 147.6 (s, COP);
151.9 (s, CO Ad) ppm. C94H88ClO6PPd: calcd. C 75.95, H 5.97;
found C 72.64, H 6.24. HR-MS/ESI: m/z calcd. 1449.5353 [M –
Cl]+; found 1449.5376.
The authors are thankful for the financial support from the Portug-
uese Fundação para a Ciência e a Tecnologia (FCT) (FCT/QREN/
FEDER/COMPETE - Programa Operacional Fatores de Competi-
tividade, grant number PTDC/QUI-QUI/112913/2009 and PhD
grant SFRH/BD/60499/2009, to R. M. B. C.) and from the Spanish
Ministerio de Economía y Competitividad (MINECO), grant
number CTQ2010-15292/BQU.
[1] a) C. S. Slone, D. A. Weinberger, C. A. Mirkin, in: The Transi-
tion Metal Coordination Chemistry of Hemilabile Ligands,
Progr. Inorg. Chem. (Ed.: K. D. Karlin), Wiley, 1999, vol. 48,
p. 233–350; b) P. Braunstein, F. Naud, Angew. Chem. 2001, 113,
702; Angew. Chem. Int. Ed. 2001, 40, 680–699; c) R. Lindner,
B. Van den Bosch, M. Lutz, J. N. H. Reek, J. I. van der Vlugt,
Organometallics 2011, 30, 499–510; d) M. V. Jiménez, M. I.
Bartolomé, J. J. Pérez-Torrente, F. J. Lahoz, L. A. Oro, Chem-
CatChem 2012, 4, 1298–1310.
Chloro(η3-2-Me-allyl){tris[(R)-2Ј-(1-adamantyl ester)-1,1Ј-bi-
naphthyl-2-yl]phosphite}palladium(II) (Pd5): The procedure was the
same as described above. From [{PdCl(η3-2-Me-allyl)}2] (19.7 mg,
0.05 mmol) and 5 (144 mg, 0.105 mmol), the title product was ob-
tained as a white solid, yield 109 mg (70%). Isomer ratio observed
in solution 2.5:1. 31P{1H} NMR (121 MHz, CDCl3): δ = 1118.0
[2] J. Joseph, T. V. RajanBabu, E. D. Jemmis, Organometallics
2009, 28, 3552–3556.
1
(major), 118.86 (minor) ppm. H NMR (400.1 MHz, CDCl3): δ =
10.85 major (s, 1 H, anti-cis CH); 1.14 major (s, 3 H, allyl-CH3);
1.23–1.78 (m, 45 H, major and minor adamantyl protons; ov.
minor 1 H, anti-cis CH; ov. minor 3 H, allyl-CH3; ov. major and
minor 1 H, syn-cis CH); 1.87 major (d, JP,H = 16 Hz, 1 H, anti-
trans-CH); 3.13 minor (d, JP,H = 16 Hz, 1 H, anti-trans-CH); 3.86
major (d, JP,H = 12.0 Hz, 1 H, syn-trans-CH); 4.29 minor (d, JP,H
= 12.0 Hz, 1 H, syn-trans-CH); 6.73–7.90 (m, 36 H, Ar) ppm.
13C{1H} NMR (100.5 MHz, CDCl3): δ = 122.7 major (s, allyl-
CH3); 27.6, 36.1, 37.9, 40.5 (s, C3, C4, C2, C1 Ad); 57.4 major (s,
cis-CH2); 80.7 major (d, JP,C = 50 Hz, trans-CH2); 118.8–133.4 (s,
C and CH Binaph); 146.9 (s, COP); 147.0 (s, CO Ad); 175.6 (s,
COO) ppm. C97H88ClO9PPd: calcd. C 74.18, H 5.65; found C
74.19, H 6.50. HR-MS/ESI: m/z calcd. 1533.5201 [M – Cl]+; found
1533.5214.
[3] M. Nandi, J. Jin, T. V. RajanBabu, J. Am. Chem. Soc. 1999,
121, 9899–9900.
[4] A. Zhang, T. V. RajanBabu, Org. Lett. 2004, 6, 1515–1517.
[5] A. Börner, Eur. J. Inorg. Chem. 2001, 327–337.
[6] H. Huang, Z. Zheng, H. Luo, C. Bai, X. Hu, H. Chen, J. Org.
Chem. 2004, 69, 2355–2361.
[7] J. Meeuwissen, R. J. Detz, A. J. Sandee, B. de Bruin, J. N. H.
Reek, Dalton Trans. 2010, 39, 1929–1931.
[8] J. Mazuela, P.-O. Norrby, P. G. Andersson, O. Pàmies, M. Dié-
guez, J. Am. Chem. Soc. 2011, 133, 13634–13645.
[9] K. A. Vallianatou, D. J. Frank, G. Antonopoulo, S. Georgako-
poulos, E. Siapi, M. Zervou, I. D. Kostas, Tetrahedron Lett.
2013, 54, 397–401.
[10] S. Borns, R. Kadyrov, D. Heller, W. Baumann, A. Spannen-
berg, R. Kempe, J. Holz, A. Börner, Eur. J. Inorg. Chem. 1998,
1291–1295.
General Procedure for Asymmetric Hydrovinylation: Hydrovinyl-
ation reactions were carried out in a stainless-steel autoclave fitted
with an external jacket connected to an ethanol bath and tempera-
ture controlled using a thermostat to Ϯ0.5 °C. The internal tem-
perature was controlled with a thermocouple. The suitable amounts
of the chosen neutral complex Pd1–Pd5, styrene (20 mmol) and
AgBF4 (1.1 molar equiv.) with respect to the amount of Pd were
dissolved in dichloromethane (15 mL) and stirred for 10 min shel-
tered from light. After removing the formed AgCl by filtration, the
solution was placed by syringe into the autoclave, which had been
purged by successive vacuum/nitrogen cycles and thermostatted to
25 °C. Ethylene was admitted until a pressure of 16 bar was
reached. After the selected time, the autoclave was slowly de-
pressurised and a 10% aqueous NH4Cl solution (10 mL) was
added. The mixture was stirred for 10 min to quench the catalyst.
The organic layer was separated, dried with Na2SO4, filtered
through a plug of SiO2 and subjected to GC analysis to determine
the distribution of the products and the enantiomeric excess with
30 m Agilent HP 5 and Astec Chiraldex DM columns.
[11] D. Rageot, A. Pfaltz, Helv. Chim. Acta 2012, 95, 2176–2193.
[12] N. D. Schley, G. E. Dobereiner, R. H. Crabtree, Organometal-
lics 2011, 30, 4174–4179.
[13] D. B. Grotjahn, Chem. Lett. 2010, 39, 908–914.
[14] D. B. Grotjahn, Dalton Trans. 2008, 6497–6508.
[15] Z. E. Clarke, P. T. Maragh, T. P. Dasgupta, D. G. Gusev, A. J.
Lough, K. Abdur-Rashid, Organometallics 2006, 25, 4113–
4117.
[16] a) R. M. Ceder, A. Grabulosa, G. Muller, M. Rocamora, Catal.
Sci. Technol. 2013, 3, 1446–1464; b) V. Saini, B. J. Stokes, M. S.
Sigman, Angew. Chem. Int. Ed. 2013, 52, 11206–11220.
[17] T. V. RajanBabu, Synlett 2009, 853–885.
[18] G. Hilt, Eur. J. Org. Chem. 2012, 4441–4451.
[19] T. V. RajanBabu, Chem. Rev. 2003, 103, 2845–2860.
[20] C. R. Smith, T. V. RajanBabu, Org. Lett. 2008, 10, 1657–1659.
[21] C. R. Smith, T. V. RajanBabu, J. Org. Chem. 2009, 74, 3066–
3072.
[22] W. Shi, J. Xie, S. Zhu, G. Hou, Q. Zhou, J. Am. Chem. Soc.
2006, 128, 2780–2781.
[23] A. Zhang, T. V. RajanBabu, J. Am. Chem. Soc. 2006, 128,
5620–5621.
General Procedure for Asymmetric Hydrogenation: A solution of
[Rh(cod)2]BF4 or [Rh(cod)2]OTf (0.015 mmol) and the mono-
phosphite (0.03 mmol) in dry CH2Cl2 (4 mL) was introduced into a
stainless-steel autoclave and stirred for 10 min. Dimethyl itaconate
(1.5 mmol) was added with a cannula and the autoclave was then
filled with the desired hydrogen pressure. After 24 h (or 48 h), the
autoclave was opened and the reaction mixture was concentrated
to dryness, dissolved in n-hexane and passed over a silica gel pad.
Samples were analysed with a gas chromatograph equipped with a
chiral column.
[24] C. R. Smith, H. J. Lim, A. Zhang, T. V. RajanBabu, Synthesis
2009, 2089–2100.
[25] a) M. M. P. Grutters, C. Müller, D. Vogt, J. Am. Chem. Soc.
2006, 128, 7414–7415; b) D. Vogt, Angew. Chem. 2010, 122,
7323; Angew. Chem. Int. Ed. 2010, 49, 7166–7168; c) M. M. P.
Grutters, J. I. van der Vlugt, Y. Pei, A. M. Mills, M. Lutz, A. L.
Spek, C. Müller, C. Moberg, D. Vogt, Adv. Synth. Catal. 2009,
351, 2199–2208.
[26] R. K. Sharma, T. V. RajanBabu, J. Am. Chem. Soc. 2010, 132,
3295–3297.
[27] G. Jiang, B. List, Chem. Commun. 2011, 47, 10022–10024.
Eur. J. Inorg. Chem. 2014, 1034–1041
1040
© 2014 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
