Biaryl Coupling Reactions Catalyzed by Diazadecalins
SCHEME 1
SCHEME 2 a
a
Reagents and conditions: (a) (7f) BnBr, KOH, MeOH, reflux,
4 h, 50%. (7g) o-MeOPhCH2Br, KOH, MeOH, reflux, 1 d, 29%.
(7g f 7h ) BBr3, 1 d, 29%.
al.9c,d demonstrated that catalytic coupling of 3-car-
boalkoxy-2-naphthols with good enantioselectivity is pos-
sible using prolyldiamine (3) or sparteine (5) derived
copper oxidants (Scheme 1). In a further advance, we
have found that 1,5-diaza-cis-decalin 6 copper catalysts
are highly selective in this reaction (eq 1).13 By imple-
menting several modifications, a variety of novel 3,3′-
disubstituted BINOL derivatives can be synthesized. In
this paper, we disclose the full results of these studies.
Ch ir a l Dia m in es. Few significantly different chiral
diamines have found general utility in asymmetric
synthesis. The most widely used versions (1-5) are
shown in Scheme 1.14,15 We identified scaffold 6 as a
potential lead from our efforts in the computer-aided
identification of novel ligands.16 We have demonstrated
that diaza-cis-decalins 617 are moderately effective in
asymmetric lithiation-substitution18 and highly effective
in the enantioselective oxidative biaryl coupling of sub-
stituted 2-naphthol derivatives.13a Here, the development
of the diaza-cis-decalin copper catalysts for the enantio-
selective oxidative coupling of a variety of functionalized
2-naphthols is presented.
Resu lts a n d Discu ssion
Meta l a n d Liga n d Su r vey. Enantiomerically pure
(S,S)-1,5-diaza-cis-decalin 7a and its antipode (R,R)-7a
are readily synthesized from commercial materials in
three steps.18a The ligands 7b-e (Scheme 2) were pre-
pared from this material as described previously.13a,18a
Ligands 7f and 7g were prepared by N-alkylation as
shown in Scheme 2.
To survey the utility of the 1,5-diaza-cis-decalin struc-
ture, a number of oxidative metal complexes were
formulated using chiral 7a (Table 1, entries 1-3). The
manganese,19 iron,20 and copper complexes all provided
some selectivity in the oxidative biaryl coupling of
3-methoxycarbonyl-2-naphthol (8a ) with oxygen as the
terminal oxidant (eq 1). The copper catalyst gave the
(8) One of the most efficient routes to enantiomerically pure BINOL
relies on a classical resolution employing a cinchonidine salt: (a) Hu,
Q.-S.; Vitharana, D.; Pu, L. Tetrahedron: Asymmetry 1995, 6, 2123-
2126. For other resolution methods, see: (b) Periasamy, M.; Venkatra-
man, L.; Thomas, K. R. J . J . Org. Chem. 1997, 62, 4302-4306. (c) Toda,
F.; Tanaka, K. Chem. Commun. 1997, 1087-1088. (d) Hu, Q.-S.;
Vitharana, D.; Pu, L. Tetrahedron: Asymmetry 1995, 6, 2123-2126.
(e) Cai, D.; Hughes, D. L.; Verhoeven, T. R.; Reider, P. J . Tetrahedron
Lett. 1995, 7991-7994. (f) Kawashima, M.; Hirayama, A. Chem. Lett.
1990, 2299-2300.
(9) The development of an efficient catalytic asymmetric BINOL
synthesis has been the focus of several research groups: (a) Hamada,
T.; Ishida, H.; Usui, S.; Watanabe, Y.; Tsumura, K.; Ohkubo, K. Chem.
Commun. 1993, 909-911. (b) Smrcˇina, M.; Pola´kova´, J .; Vyskocˇil, Sˇ.;
Kocˇovsky´, P. J . Org. Chem. 1993, 58, 4534-4537. (c) Nakajima, M.;
Kanayama, K.; Miyoshi, I.; Hashimoto, S. Tetrahedron Lett. 1995, 36,
9519-9520. (d) Nakajima, M.; Miyoshi, I.; Kanayama, K.; Hashimoto,
S.-I.; Noji, M.; Koga, K. J . Org. Chem. 1999, 64, 2264-2271 (10 mol %
catalyst, 78% ee for 9a , 17% ee for BINOL). (e) Irie, R.; Masutani, K.;
Katsuki, I. Synlett 2000, 1453-1436 (2 mol % catalyst, 65% ee for
BINOL). (f) Chu, C.-Y.; Hwang, D.-R.; Wang, S.-K.; Uang, B.-J . Chem.
Commun. 2001, 980-981 (2 mol % catalyst, 51% ee for BINOL). (g)
Hon, S.-W.; Li, C.-H.; Kuo, J .-H.; Barhate, N. B.; Liu, Y.-H.; Wang, Y.;
Chen, C.-T. Org. Lett. 2001, 3, 869-872 (10 mol % catalyst, 62% ee
for BINOL). (h) Luo, Z.; Liu, Q.; Gong, L.; Cui, X.; Mi, A.; J iang, Y.
Chem. Commun. 2002, 914-915 (10 mol % catalyst, 6 d, 83% ee for
BINOL). (i) Barhate, N. B.; Chen, C.-T. Org. Lett. 2002, 4, 2529-2532
(10 mol % catalyst, 15 d, 87% ee for BINOL). (j) Luo, Z. B.; Liu, Q. Z.;
Gong, L. Z.; Cui, X.; Mi, A. Q.; J iang, Y. Z. Angew. Chem., Int. Ed.
2002, 41, 4532-4535 (10 mol % catalyst, 8 d, 90% ee for BINOL). (k)
Chu, C.-Y.; Uang, B.-J . Tetrahedron: Asymmetry 2003, 14, 53-55 (10
mol % catalyst, 73% ee for BINOL).
(14) For reviews of 1,2-diamines, see: (a) Lucet, D.; LeGall, T.;
Mioskowski, C. Angew. Chem., Int. Ed. 1998, 37, 2580-2627. (b)
Bennani, Y. L.; Hanessian, S. Chem. Rev. 1997, 97, 3161-3195. (c)
Mukaiyama, T.; Asami, M. Top. Curr. Chem. 1985, 127, 133-167.
(15) For reviews of sparteine, see: (a) Hoppe, D.; Hense, T. Angew.
Chem., Int. Ed. Engl. 1997, 36, 2282-2316. (b) Beak, P.; Basu, A.;
Gallagher, D. J .; Park, Y. S.; Thayumanavan, S. Acc. Chem. Res. 1996,
29, 552-560.
(16) Kozlowski, M. C.; Waters, S. P.; Skudlarek, J . W.; Evans, C. A.
Org. Lett. 2002, 4, 4391-4393.
(10) (a) Brussee, J .; J ansen, A. C. A. Tetrahedron Lett. 1983, 24,
3261-3262. (b) Brussee, J .; Groenendijk, J . L. G.; te Koppele, J . M.;
J ansen, A. C. A. Tetrahedron 1985, 41, 3313-3319.
(17) Ganguly, B.; Freed, D. A.; Kozlowski, M. C. J . Org. Chem. 2001,
66, 1103-1108.
(18) (a) Li, X.; Schenkel, L. B.; Kozlowski, M. C. Org. Lett. 2000, 2,
875-878. (b) Xu, Z.; Kozlowski, M. C. J . Org. Chem. 2002, 67, 3072-
3078.
(19) For Mn-promoted biaryl couplings, see: (a) Dewar, M. J . S.;
Nakaya, T. J . Am. Chem. Soc. 1968, 90, 7134-7135. (b) Yamamoto,
K.; Fukushima, H.; Okamoto, Y.; Hatada, K.; Nakazaki, M. Chem.
Commun. 1984, 1111-1112.
(20) For Fe-promoted biaryl couplings, see: (a) Pummerer, R.; Prell,
E.; Rieche, A. Chem. Ber. 1926, 59, 2159-2161. (b) Feringa, B.;
Wynberg, H. J . Org. Chem. 1981, 46, 2547-2557. (c) Toda, F.; Tanaka,
K.; Iwata, S. J . Org. Chem. 1989, 54, 3007-3009. (d) Ding, K.; Wang,
Y.; Zhang, L.; Wu, Y.; Matsuura, T. Tetrahedron 1996, 52, 1005-1010.
(e) Deussen, H.-J .; Frederiksen, P.; Bjoernholm, T.; Bechgaard, K. Org.
Prep. Proc. Int. 1996, 28, 484-486.
(11) (a) Yamamoto, K.; Fukushima, H.; Nakazaki, M. Chem. Com-
mun. 1984, 1490-1491. (b) Yamamoto, K.; Fukushima, H.; Yumioka,
H.; Nakazaki, M. Bull. Chem. Soc. J pn. 1985, 58, 3633-3634.
(12) (a) Smrcˇina, M.; Lorenc, M.; Hanusˇ, V.; Sedmera, P.; Kocˇovsky´,
P. J . Org. Chem. 1992, 57, 1917-1920. (b) See also ref 9b, which
describes one reaction with
terminal oxidant.
a copper catalyst using AgCl as the
(13) (a) For our preliminary work in this area, see: Li, X.; Yang, J .;
Kozlowski, M. C. Org. Lett. 2001, 3, 1137-1140. (b) For application to
1,1′-binaphthyl polymerization, see: Xie, X.; Phuan, P.-W.; Kozlowski,
M. C. Angew. Chem., Int. Ed. 2003, 42, 2168-2170. (c) For application
to perylenequinone precursors, see: Mulrooney, C. A.; Li, X.; DiVirgilio,
E. S.; Kozlowski, M. C. J . Am. Chem. Soc. 2003, 125, 6856-6857.
J . Org. Chem, Vol. 68, No. 14, 2003 5501
