process, where an added surfactant with a head-group containing a
cationic N–CH3 stabilizes an interfacial 1 : CS complex with 2 : 1
stoichiometry. This dynamic recognition model is supported by
recent studies indicating that electrostatic interactions with
aromatic groups can be a dominant factor in interfacial binding.14
In conclusion, we report that hydrophilic, divalent ligand, CS,
can bind cooperatively to a membrane-bound receptor, 1. Ligand
binding is enhanced as the receptor loading level in the membrane
is increased, because the membrane confines the receptor to two-
dimensions and promotes the formation of receptor : ligand
complexes with 2 : 1 stoichiometry. Ligand binding is further
enhanced by the presence of membrane additives that contain a
cationic N–CH3 group. This relatively simple, dynamic molecular
recognition system demonstrates how localization of a membrane-
bound receptor can be utilized as a method to modulate ligand
binding affinity. This work was supported by the NIH (USA).
Fig. 4 Fluorescence intensity of CS (10 mM, ex: 400 nm, em: 480 nm) in
the presence of POPC vesicles containing 20 mol% 1, such that [1]/[CS] =
2 : 1. The independent samples were titrated with: $: TEGME, m:
LDAO, &: DOTAC. All vesicles contained 2 mol% DPPE-PEG-2000 and
were in buffer (pH 7.4, 10 mM TES and 145 mM NaCl).
Notes and references
{ Definitions: K1 = [CS?1]/([CS] [1]) M21; K2 = [CS?12]/([CS?1] [1]) M21
1 (a) M. Mammen, S. Choi and G. M. Whitesides, Angew. Chem., Int.
Ed., 1998, 37, 2754–2794; (b) L. L. Kiessling, J. E. Gestwicki and
L. E. Strong, Curr. Opin. Chem. Biol., 2000, 4, 696–703.
2 E. L. Doyle, C. A. Hunter, H. C. Phillips, S. J. Webb and
N. H. Williams, J. Am. Chem. Soc., 2003, 125, 4593–4599 and
references therein.
3 (a) V. Marchi-Artzner, M.-J. Brienne, T. Gulik-Krzywicki, J.-C. Dedieu
and J.-M. Lehn, Chem.-Eur. J., 2004, 10, 2343–2350; (b) B. J. Ravoo,
J.-C. Jacquier and G. Wenz, Angew. Chem., Int. Ed., 2003, 42,
2066–2070; (c) P. Falvey, C. W. Lim, R. Darcy, T. Revermann,
U. Karst, M. Giesbers, A. T. M. Marcelis, A. Lazar, A. W. Coleman,
D. N. Reinhoudt and B. J. Ravoo, Chem.-Eur. J., 2005, 11, 1171–1180;
(d) D. Y. Sasaki, Cell Biochem. Biophys., 2003, 39, 145–161.
4 (a) T. A. Duke and D. Bray, Proc. Natl. Acad. Sci. USA, 1999, 96,
10104–10108; (b) J. E. Gestwicki, L. E. Strong and L. L. Kiessling,
Chem. Biol., 2000, 7, 583–591; (c) A. Schoen and E. Freire, Biochemistry,
1989, 28, 5019–5024; (d) R. Willmann and C. Fuhrer, Cell. Mol. Life
Sci., 2002, 59, 1296–1316; (e) V. Marchi-Artzner, B. Lorz, U. Hellerer,
M. Kantlehner, H. Kessler and E. Sackmann, Chem.-Eur. J., 2001, 7,
1095–1101.
5 D. E. Leckband, T. Kuhl, H. K. Wang, J. Herron, W. Muller and
H. Ringsdorf, Biochemistry, 1995, 34, 11467–11478.
6 (a) F. M. Menger, K. L. Caran and V. A. Seredyuk, Angew. Chem., Int.
Ed., 2001, 40, 3905–3907; (b) P. Barton, C. A. Hunter, T. J. Potter,
S. J. Webb and N. H. Willaims, Angew. Chem., Int. Ed., 2002, 41,
3878–3881.
Scheme 3
recognition process which may be quite complicated because it
involves ionic species on a membrane surface. However, one
intriguing possibility is the cationic DOTAP head-group stabilizes
a high order interfacial 1 : CS complex. When CS binds to
receptor 1 the hydroxyl residues in CS deprotonate and coordinate
to the receptor’s Zn2+ atom.7,13 Thus, after binding to the receptor,
the CS becomes a highly electron-rich, aromatic surface that will
be attracted to the DOTAP trimethylammonium cation. This may
enable the DOTAP to promote receptor clustering and formation
of the 2 : 1 (1 : CS) complex. Evidence that supports this
hypothesis was gained from the following experiments. A solution
of CS (10 mM) was mixed with vesicles composed of POPC : 1 (80 :
20) such that the ratio of 1 : CS was 2 : 1. At this receptor : ligand
ratio, about 20% of the CS fluorescence is quenched because it is
bound to the receptor. The vesicle dispersion was split into three
equal samples. One sample was titrated with cationic surfactant,
7 (a) M. S. Han and D. H. Kim, Angew. Chem., Int. Ed., 2002, 41,
3809–3811; (b) D. H. Lee, J. H. Im, S. K. Son, Y. K. Chung and
J. Hong, J. Am. Chem. Soc., 2003, 125, 7752–7753; (c) D. H. Lee,
S. Y. Kim and J. Hong, Angew. Chem., Int. Ed., 2004, 43, 4777–4780;
(d) A. Ojida, Y. Mito-oka, M. Inoue and I. Hamachi, J. Am. Chem.
Soc., 2002, 124, 6256–6258.
didodecyltrimethylammoniunm chloride (DOTAC, cmc
=
16 mM), which resulted in dose dependent quenching of the CS
fluorescence (Fig. 4). UV spectra of the titration samples showed
the appearance of a red-shifted absorbance,8 confirming that the
DOTAC promotes formation of a 1 : CS complex. A similar but
weaker effect was observed when the the second vesicle sample was
titrated with dipolar surfactant, lauryl dimethylamine N-oxide
(LDAO, cmc = 2 mM), whereas, titration of the third vesicle
sample with non-ionic surfactant, tetraethyleneglycol monooctyl
ether (TEGME, cmc = 8 mM) had no effect on the sample’s UV
or fluorescence spectra (Fig. 4). The data are consistent with the
rationalization shown in Scheme 3; a three component assembly
8 R. G. Hanshaw, S. M. Hilkert, H. Jiang and B. D. Smith, Tetrahedron
Lett., 2004, 45, 8721–8724.
9 R. P. Bonar-Law and J. K. M. Sanders, J. Am. Chem. Soc., 1995, 117,
259–271.
10 R. M. Epand and R. Zraayenhof, Chem. Phys. Lipids, 1999, 101, 57–64.
11 D. D. Lasic, Angew. Chem., Int. Ed. Engl., 1994, 33, 1685–1698.
12 M. A. Cooper and D. H. Williams, Chem. Biol., 1999, 6, 891–899.
13 (a) M. S. Han and D. H. Kim, Tetrahedron, 2004, 60, 11251–11257; (b)
K. D. Karlin, Y. Gultneh, T. Nicholson and J. Zubieta, Inorg. Chem.,
1985, 24, 3727–3729.
14 (a) R. V. Stahelin and W. Cho, Biochemistry, 2001, 40, 4672–4678; (b)
M. E. Weber, E. K. Elliott and G. W. Gokel, Org. Biomol. Chem., 2006,
4, 83–89.
This journal is ß The Royal Society of Chemistry 2006
Chem. Commun., 2006, 1407–1409 | 1409
