1752 Journal of Medicinal Chemistry, 2006, Vol. 49, No. 5
Białas et al.
Crystallization from an ethyl acetate/hexane yielded a pure chlo-
rmethyl ketone as a crystalline white solid.
and emission at 445 nm were used to maximize the free AMC (7-
amino-4-methylcoumarin) fluorescence signal. First-order inactiva-
tion rate constants (kobs) were obtained from the plots showing the
dependence of -ln(V/V0) versus time. The second-order rate constant
(kass) was calculated from the equation kass ) kobs/[I]. The measure-
ments were repeated at least twice for every compound tested. Mean
values of kass, which differed by less than 20% for potent inhibitors
(kobs/[I] > 104 M-1 s-1) and less than 30% for weaker ligands,
were calculated for every compound.
General Procedures for Preparation of the Protected Chlo-
romethyl Ketones: R2-Arg(Z)2-CH2Cl (12), R2-Lys(Z)-CH2Cl
(13), and R3-Phe-Lys(Z)-CH2Cl (14). Method A: Acylation with
an Appropriate Acid Chloride. H-Arg(Z)2-CH2Cl (10), H-Lys-
(Z)-CH2Cl (11), or H-Phe-Lys(Z)-CH2Cl hydrochloridates were
obtained from Boc-Arg(Z)2-CH2Cl (8), Boc-Lys(Z)-CH2Cl (9), or
Boc-Phe-Lys(Z)-CH2Cl (13e) (2 mmol), respectively, dissolved in
a minimum quantity of THF and treated with an excess of 7.5 M
HCl in methanol (13.4 mL, 10 mmol) within 40 min for arginine
and 15 min for lysine derivative at 0 °C. After evaporation, the
obtained salt was suspended in anhydrous THF (30 mL). N-
Methylmorpholine (0.55 mL, 5 mmol) and an acid chloridate (2.4
mmol, 5 min later) were added consecutively to the stirred mixture
and cooled in a water/ice bath. Acid chloridates were either
commercial or synthesized from the appropriate acid upon reaction
with thionyl chloride in the standard way. After 24 h of stirring,
the mixture was concentrated under reduced pressure. The residue
was taken up with ethyl acetate (50 mL) and water (10 mL) and
washed consecutively with 5% NaHCO3 (40 mL), 5% citric acid
(2 × 40 mL), and brine (40 mL). The organic layer was then dried
over anhydrous Na2SO4. After removal of the solvent, the residue
was purified on silica gel column. A solution of ethyl acetate/hexane
was used as the eluent. The obtained material was additionally
recrystallized from an ethyl acetate/hexane mixture, giving pure
chloromethyl ketones as white crystals.
Acknowledgment. This work is supported by the Committee
of Scientific Research (KBN, Poland, grant 6 P04B 025 21).
J.P. acknowledges grants DE 09761 and 3 P04A 003 24 from
the National Institutes of Health and the Committee of Scientific
Research (KBN, Poland), respectively. J.P. was the recipient
of an award SUBSYDIUM PROFESORSKIE from the Founda-
tion for Polish Science (FNP, Warszawa, Poland). We thank
Rachael Riley and David Shultis (University of Virginia,
Charlottesville) for critical reading of the manuscript.
Supporting Information Available: NMR, IR, and elemental
analysis data and HPLC chromatograms of the protected and final
products. This material is available free of charge via the Internet
References
Method B: Mixed Anhydrides. To a stirred solution of an acid
(2 mmol) in anhydrous THF (50 mL) were added NMM (0.55 mL,
5 mmol) and isobutyl chloroformate (0.31 mL, 2.4 mmol) at 0 °C.
Stirring was continued for 45 min. Then H-Arg(Z)2-CH2Cl (10),
H-Lys(Z)-CH2Cl (11), or H-Phe-Lys(Z)-CH2Cl hydrochloridate (2
mmol, obtained as described above for method A) suspended in
anhydrous THF (30 mL) was added. After 24 h of stirring, the
mixture was worked up and purified the same manner as described
above.
(1) DeStefano, F.; Anda, R. F.; Kahn, H. S.; Williamson, D. F.; Russell,
C. M. Dental disease and risk of coronary heart disease and mortality.
Br. Med. J. 1993, 306, 688-691.
(2) Beck, J. D.; Pankow, J.; Tyroler, H. A.; Offenbacher, S. Dental
infections and atherosclerosis. Am. Heart J. 1999, 138, S528-533.
(3) Scannapieco, F. A. Role of oral bacteria in respiratory infection. J.
Periodontol. 1999, 70, 793-802.
(4) Teng, Y. T.; Taylor, G. W.; Scannapieco, F.; Kinane, D. F.; Curtis,
M.; et al. Periodontal health and systemic disorders. J. Can. Dent.
Assoc. 2002, 68, 188-192.
(5) Shapira, L.; Ayalon, S.; Brenner, T. Effects of Porphyromonas
gingiValis on the central nervous system: Activation of glial cells
and exacerbation of experimental autoimmune encephalomyelitis. J.
Periodontol. 2002, 73, 511-516.
(6) Romero, B. C.; Chiquito, C. S.; Elejalde, L. E.; Bernardoni, C. B.
Relationship between periodontal disease in pregnant women and
the nutritional condition of their newborns. J. Periodontol. 2002, 73,
1177-1183.
(7) Jeffcoat, M. K.; Hauth, J. C.; Geurs, N. C.; Reddy, M. S.; Cliver, S.
P.; et al. Periodontal disease and preterm birth: Results of a pilot
intervention study. J. Periodontol. 2003, 74, 1214-1218.
(8) Kadowaki, T.; Baba, A.; Abe, N.; Takii, R.; Hashimoto, M.; et al.
Suppression of pathogenicity of Porphyromonas gingiValis by newly
developed gingipain inhibitors. Mol. Pharmacol. 2004, 66, 1599-
1606.
(9) Slots, J.; Bragd, L.; Wikstrom, M.; Dahlen, G. The occurrence of
Actinobacillus actinomycetemcomitans, Bacteroides gingiValis and
Bacteroides intermedius in destructive periodontal disease in adults.
J. Clin. Periodontol. 1986, 13, 570-577.
(10) Holt, S. C.; Ebersole, J.; Felton, J.; Brunsvold, M.; Kornman, K. S.
Implantation of Bacteroides gingiValis in nonhuman primates initiates
progression of periodontitis. Science 1988, 239, 55-57.
(11) Pike, R.; McGraw, W.; Potempa, J.; Travis, J. Lysine- and arginine-
specific proteinases from Porphyromonas gingiValis. Isolation,
characterization, and evidence for the existence of complexes with
hemagglutinins. J. Biol. Chem. 1994, 269, 406-411.
Deprotection. Removal of the Nꢀ-benzyloxycarbonyl residue
from the lysine derivatives was achieved under acidic conditions
of 10% anisol in trifluoracetic acid mixture at ambient temperature
for 24 h. For deprotection of arginine Nδ- and Nω-benzyloxycarbonyl
residues, thioanisol was applied in place of anisol. A 2-mL portion
of solution was used for 0.1 mmol of a chloromethyl ketone. After
completion of the reaction, TFA was evaporated, and the residue
was worked up with water (HPLC grade) and washed three times
with ether. The water phase was concentrated and the resulting
mixture was applied on preparative HPLC. The collected samples
were lyophilized. Their purity and homogeneity were verified by
analytical HPLC.
Determination of the Residual Activity of Gingipainss
General. Substrates Tos-Gly-Pro-Arg-AMC and Tos-Gly-Pro-Lys-
AMC were purchased from Bachem (Switzerland); all other
reagents were purchased from Sigma. Substrates were dissolved
in DMSO. Inhibitors were dissolved in MiliQ water or DMSO.
Final stock solutions were diluted in the reaction buffer.
Activation of Gingipains. RgpB and Kgp were purified from
P. gingiValis HG66 culture medium as described by Pike et al.11
The enzymes were activated with 10 mM cysteine in 50 mM
HEPES (pH 7.5), 10 mM CaCl2 for 15 min at 37 °C. The activated
proteases were diluted with reaction buffer [0.1 M Tris (pH 7.5),
0.15 M NaCl, 10 mM CaCl2, 10 mM cysteine, 0.025% Triton
X-100] prior to use.
(12) Potempa, J.; Mikolajczyk-Pawlinska, J.; Brassell, D.; Nelson, D.;
Thogersen, I. B.; et al. Comparative properties of two cysteine
proteinases (gingipains R), the products of two related but individual
genes of Porphyromonas gingiValis. J. Biol. Chem. 1998, 273,
21648-21657.
(13) Nakayama, K.; Ratnayake, D. B.; Tsukuba, T.; Kadowaki, T.;
Yamamoto, K.; et al. Haemoglobin receptor protein is intragenically
encoded by the cysteine proteinase-encoding genes and the haemag-
glutinin-encoding gene of Porphyromonas gingiValis. Mol. Microbiol.
1998, 27, 51-61.
(14) Okamoto, K.; Nakayama, K.; Kadowaki, T.; Abe, N.; Ratnayake,
D. B.; et al. Involvement of a lysine-specific cysteine proteinase in
hemoglobin adsorption and heme accumulation by Porphyromonas
gingiValis. J. Biol. Chem. 1998, 273, 21225-21231.
Inhibition Assays. The rate of gingipain inactivation was
measured under pseudo-first-order conditions: the concentration
of an inhibitor exceeded the protease concentration by at least 10
times. A 50-µL aliquot of the activated enzyme was mixed with
5-15 µL of an inhibitor solution, incubated at 21 °C for the 5-180
s, and diluted at least 15 times with the reaction buffer containing
substrate. The final concentration of Tos-Gly-Pro-Arg-AMC and
Tos-Gly-Pro-Lys-AMC substrates was 1.5 × 10-6 and 7.0 × 10-6
M, respectively. Residual enzyme activity was measured with an
FP-750 spectrofluorimeter (Jasco) for 150 s. Excitation at 355 nm
