262 J . Org. Chem., Vol. 63, No. 2, 1998
Bravo et al.
Oxid a tion of Ad a m a n ta n e a n d Cycloh exa n e by DMD
in th e P r esen ce of P r oton a ted Qu in a ld in e or Lep id in e.
The hydrocarbon (4 mmol), the heteroaromatic base (1 mmol),
and CF3COOH (1 mmol) were added to a solution of 1 mmol
of DMD in 11.2 mL of acetone. The reaction was carried out
at 0 °C for 8 h or at 50 °C for 1 h. The solution was analyzed
by GC and GC-MS. With cyclohexane in the presence of
quinaldine five products were formed, in the amounts reported
in brackets respectively for 0 and 50 °C: cyclohexanol (4.3 and
6.4%), cyclohexanone (1.8 and 3.8%), quinaldine N-oxide (28.5
and 22.8%), 2,4-dimethylquinoline (3.6 and 2.4%), and 2-meth-
yl-4-cyclohexylquinoline (0.6 and 2.2%). With adamantane in
the presence of lepidine, lepidine N-oxide was the main
reaction product at 50 °C (38.2%), 1-adamantanol was a
significant reaction product (17.8%), and a small amount
(1.8%) of 2-(1-adamantyl)-4-methylquinoline was also formed.
The reaction products were identified by comparison with
authentic commercial samples, with the exception of 4-cyclo-
hexyl-2-methylquinoline and 2-(1-adamantyl)-4-methylquino-
line, previously prepared by known procedures.20
Oxid a tion of Alk a n es by DMD in th e P r esen ce a n d in
th e Absen ce of Oxygen . Gen er a l P r oced u r e A. A solution
of 1 mmol of DMD in 10.8 mL of acetone was purged with
oxygen for 10 min and then kept under oxygen for the duration
of the experiment. Alkane (1 mmol) was added and the
solution was kept at 20 °C for 8 h. The solution was directly
analyzed by GC and GC-MS by using authentic samples for
the identification and the quantitative analysis.
Gen er a l P r oced u r e B. The reaction was carried out as
in method A, but the acetone solution was purged with argon
and kept under argon for the duration of the experiments.
The results are reported in Table 3.
of acetone. After 8 h the solution was analyzed by GC and
GC-MS: quinaldine N-oxide was formed in 12% yield, 2,4-
dimethylquinoline in 1.2% yield, and 2-methyl-4-ethylquinoline
in 3.2% yield. Authentic samples were used for the identifica-
tion and the quantitative analysis. Iodometric titration re-
vealed that 79% of DMD had reacted, leading mainly to
ethanol, acetaldehyde, and acetic acid (a quantitative evalu-
ation was not carried out) as previously reported.30
Similarly, THF gave 23% of quinaldine N-oxide, 3.2% of 2,4-
dimethylquinoline, and 2.8% of 4-(a-tetrahydrofuranyl)-2-
methylquinoline.
In d u ced Hom olysis of DMD by Diisop r op yl Eth er
u n d er Ar gon . A solution of 1 mmol of DMD and 4 mmol of
diisopropyl ether in 11 mL of acetone was purged with argon
for 10 min and then kept under argon for 6 h at 22 °C.
Iodometric titration revealed that 83% of DMD had reacted;
NMR analysis of the acetone solution, carried out as above-
described, has shown the presence of CH4, CH3COOCH3 (38.4%
based on DMD), CH3OH (12.1%), and acetoxyacetone (11.8%).
The same experiment, carried out in the presence of diethyl
ketone (2 mL), gave 9.6% of R-acetoxydiethyl ketone and 2.1%
of acetoxyacetone.
In the absence of diisopropyl ether under the same condi-
tions, no substantial decomposition of DMD occurred.
Oxid a tion of Cycloh exa n ol by DMD u n d er Ar gon a n d
u n d er Oxygen . Meth od A. The reaction was carried out
under argon as for diisopropyl ether. GC and NMR analyses
revealed the formation of cyclohexanone (45% based on DMD),
CH3CO-OCH3 (27.2%), CH3OH (13.5%), acetoxyacetone (12.1%),
and CH4.
Meth od B. As in method A under oxygen, cyclohexanone
was obtained in 87% yield.
Com p lete An a lysis of th e Oxid a tion of Ad a m a n ta n e
by DMD u n d er Ar gon . The reaction was carried out as in
method B with adamantane at 23 °C. After 6 h iodometric
titration revealed that 76% of the DMD had reacted. GC
analysis of the solution revealed the formation of 1-adaman-
tanol (27%), traces of 2-adamantanol (<1%), 1-acetoxyada-
mantane (18.8%), 2-acetoxyadamantane (4.2%), and acetoxy-
acetone (7.2%).
Deuterated acetone (0.2 mL) was added to 0.8 mL of the
reaction solution and the resulting solution was analyzed by
NMR. The deuterated solvent was used to provide a deuter-
ium signal for the instrument lock. For cost reasons the
reaction was carried out in nondeuterated acetone, so the NMR
spectrum is dominated by the solvent signal. Such a very
intense peak precludes the detection of weak signals and thus
it was suppressed using the presaturation technique: a long
soft RF pulse (55-60 dB attenuation) was applied at the
frequency of acetone (2.05 ppm) during the recycle delay
followed by the acquisition of the spectrum. To avoid any
saturation of the signals the spectra were acquired with a long
recycle delay (10-15 s) between pulses. Due to the presatu-
ration RF field, the signals near the region of 2 ppm are
distorted and partially suppressed; thus, in this region they
are difficult to assign and cannot be integrated.
We observe clean singlets due to the presence of methane
(0.15 ppm, CH4), methanol (3.29 ppm, CH3), methyl acetate
(3.58 ppm, OCH3) and acetoxyacetone (4.70 ppm, -OCH2-).
All these products have been unequivocally identified by
addition to the solution of traces of the authentic samples. The
signals have been carefully integrated to determine the
relative quantities of the products in solution. The integration
was done after a very careful baseline correction of the
spectrum and phase adjustment of the signals to minimize
errors. The evaluation of methane, in that it is a gas, can be
only qualitative. In this way we have determined, for methyl
acetate, methanol, and acetoxyacetone, a ratio 3.2:0.8:1 and,
considering that the yield of acetoxyacetone, determined by
GC, was 7.2%, the yields of methanol and methyl acetate were
5.8% and 23.1%, respectively.
Oxid a tion of Aceta ld eh yd e a n d P iva la ld eh yd e by
DMD in th e P r esen ce of P r oton a ted Qu in a ld in e or
Lep id in e. Method A. A 10 mmol portion of acetaldehyde, 1
mmol of quinaldine, and 1 mmol of CF3COOH were dissolved
at 0 °C in a solution of 1 mmol of DMD in 10.8 mL of acetone.
After 8 h the solution was analyzed by GC and GC-MS: acetic
acid was obtained in 77% yield, quinaldine N-oxide in 7% yield,
2,4-dimethylquinoline in 4.1% yield, and 2-methyl-4-acetylquin-
oline in 4.2% yield.
Meth od B. As in method A but using pivalaldehyde and
lepidine instead of acetaldehyde and quinaldine, lepidine
N-oxide (60%) and pivalic acid (26%) were the main reaction
products, but small amounts of 4-methyl-2-tert-butylquinoline
(0.4%) and 2-pivaloyl-4-methylquinoline (1.1%) were also
determined.
Oxid a tion of P h en yla ceta ld eh yd e by DMD u n d er
Oxygen a n d u n d er Ar gon . Meth od A. A 1 mmol sample
of phenylacetaldehyde was dissolved at 20 °C in a solution of
1 mmol of DMD in 11.4 mL of acetone under an oxygen
atmosphere. After 6 h, 76% conversion of phenylacetaldehyde
was observed, with formation of phenylacetic acid in 98%
selectivity.
Meth od B. The reaction was carried out under argon as
in method A. Only 6% of phenylacetaldehyde was converted,
with 67% selectivity in benzyl acetate and 33% in phenylacetic
acid; CH3COOCH3 was the main reaction product (42%), with
minor amounts of CH3OH (9.1%), acetoxyacetone (8.4%), and
CH4. At 60 °C the conversion of phenylacetaldehyde increases
to 16% with 87% selectivity in benzyl acetate and 13% in
phenylacetic acid.
Com p etitive Oxid a tion of Cycloh exen e a n d Qu in olin e
by DMD a n d m -CP BA. By DMD. A 4 mmol portion of
cyclohexene and 4 mmol of quinoline were dissolved in a
solution of DMD (1 mmol) in 10.5 mL of acetone at 18 °C. After
4 h, GC analysis only revealed the formation of cyclohexene
epoxide, without traces of quinoline N-oxide.
By m -CP BA. A 4 mmol portion of cyclohexene and 4 mmol
of quinoline were dissolved in a solution of DMD (1 mmol) in
10.5 mL of acetone at 18 °C. After 4 h, GC analysis revealed
the formation of 13% of cyclohexene epoxide and 87% of
quinoline N-oxide.
Oxid a tion of Dieth yl Eth er a n d THF by DMD in th e
P r esen ce of P r oton a ted Qu in a ld in e. Diethyl ether (10
mmol), quinaldine (1 mmol), and CF3COOH (1 mmol) were
dissolved at 0 °C in a solution of 1 mmol of DMD in 11.2 mL
Oxid a tion of r- a n d â-Meth ylstyr en e by DMD. r-Meth -
ylstyr en e. A 2 mmol sample of R-methylstyrene was dis-
