ChemCatChem
10.1002/cctc.201601653
FULL PAPER
2020. The morphology and structural composition of Ni
2
Si/SBA-15
[1] B. A. Wilhite, a. M. J. McCready, A. Varma, Ind. Eng. Chem. Res. 2002,
3345-3350.
sample were characterized and analyzed by high-resolution field
emission scanning electron microscopy (FE–SEM, Nova NanoSEM 450
from FEI Company), equipped with an energy–dispersive X–ray (EDX)
analyzer. Transmission electron microscopy (TEM) and were performed
by using a Tecnai G2 F30 S–Twin transmission electron microscope
operating at 300 kV. Surface compositions were investigated by X–Ray
photoelectron spectroscopy (XPS) employing an ESCALAB250 (Thermo
VG, USA) spectrometer with Al Kα (1486.6 eV) radiation with a power of
[
2] H. Lindlar, HeIv. Chim. Acta 1952, 35, 446–450.
[3] H. Lindlar, R. Dubuis, Organic Syntheses. John Wiley & Sons, Inc. 2003,
89-89.
[4] a) C. Li, Z. Shao, M. Pang, C. T. Williams, C. Liang, Catal. Today 2012,
1
86, 69-75; b) T. Lopez, R. Gomez, E. Romero, I. Schifter, React. Kinet. Catal.
Lett. 1993, 49, 95-101; c) X. Y. Quek, Y. Guan, R. A. Santen van, E. Hensen,
X. Y. Quek, Y. Guan, R. A. Santen van, E. Hensen, ChemSusChem 2010; d) L.
Shao, X. Huang, D. Teschner, W. Zhang, ACS Catal. 2014, 4, 2369-2373.
[5] a) Y. Chen, C. Li, J. Zhou, S. Zhang, D. Rao, S. He, M. Wei, D. G. Evans,
X. Duan, J. Exp. Zool. 2015, 5, 5756-5765; b) C. Li, Y. Chen, S. Zhang, J.
Zhou, F. Wang, S. He, M. Wei, D. G. Evans, X. Duan, ChemCatChem 2014, 6,
150 W. All core–level spectra were referenced as the C 1s neutral carbon
peak at 284.6 eV and were deconvoluted into Gaussian component
peaks.
8
24–831; c) M. Pang, Z. Shao, W. Xia, X. Wang, C. Liang, AIChE J. 2015, 61,
2522-2531; d) G. Wowsnick, D. Teschner, M. Armbrüster, I. Kasatkin, F.
Girgsdies, Y. Grin, R. Schlögl, M. Behrens, J. Catal. 2014, 309, 221–230.
[6] a) X. Chen, A. Zhao, Z. Shao, C. Li, C. T. Williams, C. Liang, J. Phys.
Chem. C 2010, 114, 16525-16533; b) K. Yang, C. Xiao, J. Guan, C. Liang,
Catal. Today 2014, 246, 176–183.
[7] a) S. N. Girard, X. Chen, F. Meng, A. Pokhrel, J. Zhou, L. Shi, S. Jin, Chem.
Mater. 2014, 26, 5097-5104; b) A. L. Schmitt, Z. Lei, D. Schmeisser, F. J.
Himpsel, J. Song, Cheminform 2006, 110, 18142-18146; c) J. R. Szczech, J.
Mater. Chem. 2010, 7, 1375-1382.
M-Si/SBA-15 catalysts test. According to the procedure previously
employed,[6a] PA hydrogenation (Scheme 1) were performed with metal
silicide catalysts in a 50 mL stainless steel autoclave under vigorous
stirring. Before reaction, catalysts were activated in an ultrapure
hydrogen stream at 400 °C for 2 h and then cooled down to room
temperature and passivated in Ar for 12 h. The reaction was carried out
at 40 oC temperature and 1 MPa H
ethanol substrate solution. The products were analyzed by gas
chromatography using flame ionization detector with SE-54/52
capillary column. A known amount of n-octane solution was used as an
with 0.10 g catalyst in 10 mL 0.1 M
2
[8] a) J. Guan, J. Jin, X. Chen, B. Zhang, D. Su, C. Liang, Chem. Vap.
Deposition 2013, 19, 68-73; b) J. Guan, A. Zhao, X. Chen, M. Zhang, C. Liang,
Stud. Surf. Sci. Catal. 2010, 175, 259-262; c) A. Zhao, X. Zhang, X. Chen, J.
Guan, C. Liang, J. Phys. Chem. C 2010, 114, 3962-3967.
a
a
[9] a) H. Walter, G. Roewer, K. Bohmhammel, J.chem.soc.faraday Trans 1996,
2
internal standard in this analysis. The stability of Ni Si-450/SBA-15, is
9
2, 4605-4608; b) K. Bohmhammel, G. Roewer, H. Walter,
o
also tested at 40 C and 1 MPa H
2
for 5 times.
J.chem.soc.faraday Trans 1995, 91, 3879-3882; c) P. Li, T. Wang, Chin. J.
Chem. Eng. 2015, 23, 681-688.
[10] a) D. Zhao, J. Feng, Q. Huo, N. Melosh, G. H. Fredrickson, B. F. Chmelka,
G. D. Stucky, Science 1998, 279, 548-552; b) D. Zhao, J. Sun, Q. Li, G. D.
Stucky, Chem. Mater. 2000, 12, 275-279.
Acknowledgements
[11] a) S. A Pérez‐García, L. Nyborg, Surf. Interface Anal. 2006, 38, 859-862;
b) J. Zhao, D. M. Poirier, Surf. Sci. Spectra 2000, 329; c) P. J. Grunthaner, F.
J. Grunthaner, A. Madhukar, J. Vac. Sci. Technol. 1982, 20, 680-683.
We gratefully acknowledge the financial support provided by the
National Natural Science Foundation of China (21373038 and
[
12] I. N. Shabanova, V. A. Trapeznikov, J. Electron Spectrosc. Relat.
Phenom., 1975, 6(4):297-307.
[13] M. GarcꢀA-Méndez, F. F. Castillꢁn, G. A. Hirata, M. H. FarꢀA
Beamson, Appl. Surf. Sci. 2000, 161, 61-73.
14] D. W. Oscarson, P. M. Huang, C. Defoss, A. Herbillion, Nature, 1981, 291.
21403026), the China Postdoctoral Science Foundation
㌠
㌠ s, G.
(
2015T80255), the Natural Science Foundation of Liaoning
[
Province in China (2015021014) and Program for Excellent
Talents in Dalian City (2016RD09).
[15] a) L. S. Hsu, A. I. Nesvizhskii, J. Appl. Phys. 2002, 62, 1103-1109; b) Y.
Liu, X. Liu, Q. Feng, D. He, L. Zhang, C. Lian, R. Shen, G. Zhao, Y. Ji, D.
Wang, Adv. Mater. 2016, 28, 4747-4754.
Keywords: Metal Silicide • Chemical vapor deposition •
Phenylacetylene Hydrogenation
This article is protected by copyright. All rights reserved.
