LETTER
Palladium-Catalysed Alkynylation of Aryl Bromides in an Ionic Liquid
3007
R
4 hours: from bromobenzene (82%, entry 6, row 2), from
4-bromonitrobenzene (58%, entry 8) and from 3,5-bis(tri-
fluoromethyl)bromobenzene (92%, entry 9). Therefore,
and contrary to the case of deactivated substrates, an ac-
curate control of the reaction time is required to increase
the selectivity towards the desired enyne.
R
H
[Pd]/L/pyrrolidinium
[BMIM][BF4]
R'
R'
H
+
R
H
R'
H
(E)
(Z)
Scheme 2 Hydrogenation side products obtained from enynes.
The coupling reaction of phenylacetylene to 4-bromoni-
trobenzene appeared as a particular case, for which a sig-
nificant concurrent reaction was the arylation of the
pyrrolidine base. Thus, substantial amounts of pyrrolidi-
nyl-4-nitrobenzene (17–34%, entry 8) were formed what-
ever the reaction time (2–20 h). Eventually, this product
spontaneously crystallised from the crude ethereal extrac-
tion mixture upon standing few hours at low temperature:
the X-ray crystal structure determined is presented in
Figure 2.15
In summary, we have disclosed the first methodology
allowing the alkynylation of a variety of functionalised
aryle bromides in an ionic liquid medium. The copper-
free system combining 0.5 mol% of [Pd(allyl)Cl]2, 3
mol% PPh3 and 1.2 equiv pyrrolidine is economic, simple
and readily accessible. In [BMIM][BF4] the coupling of
demanding bromides is more selective comparatively to
the coupling of activated aryl bromides. This fact is prob-
ably due to the inertness of demanding substrates (elec-
tronic or steric in origin) as supported by the various side
reactions obtained from activated bromides. Finally, the
presumed palladium-catalysed hydrogenation of aryl/
alkyne subsequent to Heck or Sonogashira reaction has
never been documented before, and could lead, after de-
velopment and optimisation, to very elegant cascade-type
catalysis.
Figure 2 POV-Ray representation (ORTEP) of the molecular struc-
ture of the amine arylation product pyrrolidinyl-4-nitrobenzene.
Acknowledgment
Thanks are due to S. Royer and G. Delmas for their technical help.
We sincerely thank the ‘Conseil Régional de Bourgogne’ for finan-
cial support, especially concerning GC apparatus.
We checked the possibility, using our catalytic system, to
employ aliphatic acetylenes for Heck alkynylation in
[BMIM][BF4]. For this purpose, we chose the long-chain
aliphatic terminal alkyne 1-decyne. Without optimisation,
good to excellent conversions were obtained using either
activated or deactivated bromides (Table 1, entries 10–
13); the side products obtained were mostly the result of
triple-bond isomerisation, with some hydrogenation prod-
ucts also detected.
References and Notes
(1) (a) Tykwinski, R. R. Angew. Chem. Int. Ed. 2003, 42, 1566.
(b) Negishi, E.-I.; Anastasia, L. Chem. Rev. 2003, 103, 1979.
(2) (a) Shi Shun, A. L. K.; Tykwinski, R. R. Angew. Chem. Int.
Ed. 2006, 45, 1034. (b) Bunz, U. H. F. Chem. Rev. 2000,
100, 1605.
(3) Dieck, H. A.; Heck, F. R. J. Organomet. Chem. 1975, 93,
259.
The enyne hydrogenation observed (Scheme 2) suggests
that after completion of the coupling reaction, the palladi-
um catalyst then acts as a hydrogen-transfer catalyst. Al-
though at this point the formation of a palladium-hydride
species through insertion of the metal into the imidazoli-
um C2–H bond cannot be totally ruled out,16 it seems more
reasonable to propose a protonation of a Pd(0) centre by
the acidic hydrogenopyrrolidinium salt resulting from the
terminal acetylene deprotonation step of the C–C cou-
pling.17 The origin of the side reactions detected, namely
(i) the addition reactions onto the enyne triple bond (main-
ly hydrogenation), and (ii) the amine arylation, would
then be rather different. While the triple-bond activation
probably originates from a palladium-catalysed process,
blank experiments performed in [BMIM][BF4] and in the
absence of any metal and ligand have shown that pyrroli-
dine can be coupled in non-negligible yields to electroni-
cally activated substrates such as 4-bromobenzonitrile
(33% in 6 h) or 4-bromoacetophenone (20% in 2 h).18
(4) Sonogashira, K. J. Organomet. Chem. 2002, 653, 46.
(5) (a) Nakamura, K.; Okubo, H.; Yamaguchi, M. Synlett 1999,
549. (b) Mery, D.; Heuze, K.; Astruc, D. Chem. Commun.
2003, 1934. (c) Hundertmark, T.; Littke, A. F.; Buchwald, S.
L.; Fu, G. C. Org. Lett. 2000, 2, 1729.
(6) (a) Thorand, S.; Krause, N. J. Org. Chem. 1998, 63, 8551.
(b) Alonso, D. A.; Najera, C.; Pacheco, M. C. Tetrahedron
Lett. 2002, 43, 9365.
(7) (a) Hierso, J.-C.; Fihri, A.; Amardeil, R.; Meunier, P.;
Doucet, H.; Santelli, M.; Ivanov, V. V. Org. Lett. 2004, 6,
3473. (b) Feuerstein, M.; Berthiol, F.; Doucet, H.; Santelli,
M. Org. Biomol. Chem. 2003, 1, 2235.
(8) (a) Kollhofer, A.; Pullmann, T.; Plenio, H. Angew. Chem.
Int. Ed. 2003, 42, 1056. (b) Gelman, D.; Buchwald, S. L.
Angew. Chem. Int. Ed. 2003, 42, 5993.
(9) Fukuyama, T.; Shinmen, M.; Nishitani, S.; Sato, M.; Ryu, I.
Org. Lett. 2002, 4, 1691.
(10) Park, S. B.; Alper, H. Chem. Commun. 2004, 1306.
(11) (a) Gholap, A. R.; Venkatesan, K.; Pasricha, R.; Daniel, T.;
Lahoti, R. J.; Srinivasan, K. V. J. Org. Chem. 2005, 70,
4869. (b) Corma, A.; Garcia, H.; Leyva, A. Tetrahedron
2005, 61, 9848.
Synlett 2006, No. 18, 3005–3008 © Thieme Stuttgart · New York
