Please do not adjust margins
Organic & Biomolecular Chemistry
Page 4 of 5
DOI: 10.1039/C7OB02391J
COMMUNICATION
Journal Name
[4] R. Chattopadhyaya, W. E. Meador, A. R. Means, F. A. Quiocho, J Mol Biol 1992,
228, 1177-1192.
[5] M. Zhang, T. Tanaka, M. Ikura, Nat Struct Biol 1995, 2, 758-767.
[6] (a) J. M. Goldberg, R. F. Wissner, A. M. Klein, E. J. Petersson, Chem Commun
2012, 48, 1550-1552; (b) R. F. Wissner, S. Batjargal, C. M. Fadzen, E. J. Petersson,
J Am Chem Soc 2013, 135, 6529-6540; (c) Y. F. He, M. M. Haque, D. J. Stuehr, H.
P. Lu, Proc Natl Acad Sci USA 2015, 112, 11835-11840; (d) D. Jensen, N. Reynolds,
Y. P. Yang, S. Shakya, Z. Q. Wang, D. J. Stuehr, C. C. Wei, BMC Biochem 2015, 16,
6; (e) E. M. Jones, G. Balakrishnan, T. C. Squier, T. G. Spiro, Protein Sci 2014, 23,
1094-1101; (f) S. Liu, Y. Sui, K. Guo, Z. Yin, X. Gao, Nanoscale Res Lett 2012, 7,
433-440.
[7] M. Liu, T. Y. Chen, B. Ahamed, J. Li, K. W. Yau, Science 1994, 266, 1348-1354.
[8] G. M. Contessa, M. Orsale, S. Melino, V. Torre, M. Paci, A. Desideri, D. O. Cicero, J
Biomol NMR 2005, 31, 185-199.
[9] (a) A. P. Yamniuk, H. J. Vogel, Mol Biotechnol 2004, 27, 33-57; (b) H. Tidow, P.
Nissen, FEBS J 2013, 280, 5551-5565.
[10] N. Kotera, N. Tassali, E. Leonce, C. Boutin, P. Berthault, T. Brotin, J. P. Dutasta, L.
Delacour, T. Traore, D. A. Buisson, F. Taran, S. Coudert, B. Rousseau, Angew
Chem Int Ed Engl 2012, 51, 4100-4103.
[11] (a) G. K. Seward, Q. Wei, I. J. Dmochowski, Bioconjugate Chem 2008, 19, 2129-
2135; (b) G. K. Seward, Y. Bai, N. S. Khan, I. Dmochowski, Chem Sci 2011, 2, 1103-
1110.
[12] J. R. De Laeter, J. K. Bohlke, P. De Bievre, H. Hidaka, H. S. Peiser, K. J. R. Rosman,
P. D. P. Taylor, Pure Appl Chem 2003, 75, 683-800.
Figure 5. FRRIAR-TUC alone and in the presence of apo CaM resulted in no hp 129Xe
NMR signal (a); CaM bound to FRRIAR-TUC resulted in two distinct 129Xe NMR
resonances (b). NMR performed in 10 mM HEPES, 1 mM CaCl2, pH 7.2 with 1% DMSO.
129Xeaq peak shown at 192.8 ppm. CaM binding peptide structure taken from PDB 1SY9.
Image generated in PyMOL (Delano Scientific, LLC; South San Francisco, CA USA).
[13] (a) Y. Wang, I. J. Dmochowski, Chem Commun 2015, 51, 8982-8985; (b) J. A.
Finbloom, C. C. Slack, C. J. Bruns, K. Jeong, D. E. Wemmer, A. Pines, M. B. Francis,
Chem Commun 2016, 52, 3119-3122; (c) F. T. Hane, T. Li, P. Smylie, R. M.
Pellizzari, J. A. Plata, B. DeBoef, M. S. Albert, Sci Rep 2017, 7; (d) M. Kunth, C.
Witte, A. Hennig, L. Schroder, Chem Sci 2015, 6, 6069-6075; (e) O. Taratula, P. A.
Hill, Y. B. Bai, N. S. Khan, I. J. Dmochowski, Org Lett 2011, 13, 1414-1417; (f) D. R.
Jacobson, N. S. Khan, R. Colle, R. Fitzgerald, L. Laureano-Perez, Y. Bai, I. J.
Dmochowski, Proc Natl Acad Sci USA 2011, 108, 10969-10973; (g) P. A. Hill, Q.
Wei, R. G. Eckenhoff, I. J. Dmochowski, J Am Chem Soc 2007, 129, 11662-11662;
(h) P. A. Hill, Q. Wei, T. Troxler, I. J. Dmochowski, J Am Chem Soc 2009, 131,
3069-3077; (i) R. M. Fairchild, A. I. Joseph, K. T. Holman, H. A. Fogarty, T. Brotin,
J. P. Dutasta, C. Boutin, G. Huber, P. Berthault, J Am Chem Soc 2010, 132, 15505-
15507; (j) G. Huber, L. Beguin, H. Desvaux, T. Brotin, H. A. Fogarty, J. P. Dutasta,
P. Berthault, J Phys Chem A 2008, 112, 11363-11372.
In conclusion, we report a straightforward synthesis for the
first “turn-on” cryptophane-xenon biosensor, which was used
to detect Ca2+-bound CaM protein. This so-called turn-on
effect improves signal-to-noise, especially in scenarios where
there are multiple biosensors with both “free” and “bound”
signals. The observation of signal only in the presence of target
analyte will also facilitate ultrasensitive detection using
hyperpolarized chemical exchange saturation transfer (Hyper-
CEST) NMR techniques.16e For example, large-spectral-width,
high-power pulses that increase detection sensitivity can be
employed without interfering signal from untargeted
biosensor(s). Thus, this work highlights a potential new
paradigm for cryptophane-based xenon biosensors. Future
studies will help to elucidate the nature of peptide-
cryptophane interactions that can produce the “OFF” state.
This research was supported by National Institutes of
Health (NIH R01-GM097478). EJP acknowledges support for
CaM projects through the National Science Foundation (NSF
CHE-1150351). We thank Dr. Rakesh Kohli for assistance with
MALDI-MS (NSF MRI-0820996). We thank Drs. George Furst
and Jun Gu for assistance with NMR spectroscopy. We also
thank the University of Pennsylvania Biological Chemistry
Resource Center for automated peptide synthesis supported
by UPenn Laboratory for Research on the Structure of Matter
(NSF MRSEC DMR 0520020, 1120901). RFW thanks the NIH for
funding through the Chemistry-Biology Interface Training
Program (T32 GM07133). We thank Dr. Jacob Goldberg for
help with data analysis.
[14] O. Taratula, P. A. Hill, N. S. Khan, P. J. Carroll, I. J. Dmochowski, Nat Commun
2010, 1.
[15] (a) J. M. Chambers, P. A. Hill, J. A. Aaron, Z. H. Han, D. W. Christianson, N. N.
Kuzma, I. J. Dmochowski, J Am Chem Soc 2009, 131, 563-569; (b) N. S. Khan, B. A.
Riggle, G. K. Seward, Y. Bai, I. J. Dmochowski, Bioconjugate Chem 2015, 26, 101-
109; (c) B. A. Riggle, Y. Wang, I. J. Dmochowski, J Am Chem Soc 2015, 137, 5542-
5548.
[16] (a) M. M. Spence, S. M. Rubin, I. E. Dimitrov, E. J. Ruiz, D. E. Wemmer, A. Pines, S.
Q. Yao, F. Tian, P. G. Schultz, Proc Natl Acad Sci USA 2001, 98, 10654-10657; (b)
T. Meldrum, K. L. Seim, V. S. Bajaj, K. K. Palaniappan, W. Wu, M. B. Francis, D. E.
Wemmer, A. Pines, J Am Chem Soc 2010, 132, 5936-5937; (c) M. M. Spence, E. J.
Ruiz, S. M. Rubin, T. J. Lowery, N. Winssinger, P. G. Schultz, D. E. Wemmer, A.
Pines, J Am Chem Soc 2004, 126, 15287-15294; (d) C. Boutin, A. Stopin, F. Lenda,
T. Brotin, J. P. Dutasta, N. Jamin, A. Sanson, Y. Boulard, F. Leteurtre, G. Huber, A.
Bogaert-Buchmann, N. Tassali, H. Desvaux, M. Carriere, P. Berthault, Bioorg Med
Chem 2011, 19, 4135-4143; (e) L. Schröder, T. J. Lowery, C. Hilty, D. E. Wemmer,
A. Pines, Science 2006, 314, 446-449; (f) S. Klippel, J. Dopfert, J. Jayapaul, M.
Kunth, F. Rossella, M. Schnurr, C. Witte, C. Freund, L. Schröder, Angew Chem Int
Ed Engl 2014, 53, 493-496; (g) S. Klippel, C. Freund, L. Schröder, Nano Lett 2014,
14, 5721-5726; (h) K. K. Palaniappan, R. M. Ramirez, V. S. Bajaj, D. E. Wemmer, A.
Pines, M. B. Francis, Angew Chem Int Ed Engl 2013, 52, 4849-4853; (i) K. Jeong, C.
Netirojjanakul, H. K. Munch, J. Sun, J. A. Finbloom, D. E. Wemmer, A. Pines, M. B.
Francis, Bioconjugate Chem 2016, 27, 1796-1801.
[17] Q. Wei, G. K. Seward, P. A. Hill, B. Patton, I. E. Dimitrov, N. N. Kuzma, I. J.
Dmochowski, J Am Chem Soc 2006, 128, 13274-13283.
[18] (a) C. Witte, V. Martos, H. M. Rose, S. Reinke, S. Klippel, L. Schröder, C. P. R.
Hackenberger, Angew Chem Int Ed Engl 2015, 54, 2806-2810; (b) M. Schnurr, K.
Sydow, H. M. Rose, M. Dathe, L. Schröder, Adv Healthc Mater 2014; (c) H. M.
Rose, C. Witte, F. Rossellaa, S. Klippel, C. Freund, L. Schrӧder, Proc Natl Acad Sci
USA 2014, 111, 11697-11702.
[19] (a) V. V. Rostovtsev, L. G. Green, V. V. Fokin, K. B. Sharpless, Angew Chem Int Ed
Engl 2002, 41, 2596-2599; (b) C. W. Tornoe, C. Christensen, M. Meldal, J Org
Chem 2002, 67, 3057-3064.
[20] (a) H. Brzeska, S. Venyaminov, Z. Grabarek, W. Drabikowski, FEBS Lett 1983, 153,
169-173; (b) G. Gibrat, L. Assairi, C. T. Craescu, G. H. B. Hoa, D. Loew, B. Lombard,
L. Blouquit, M. C. Bellissent-Funel, Biochimica Et Biophysica Acta-Proteins and
Proteomics 2012, 1824, 1097-1106; (c) L. Masino, S. R. Martin, P. M. Bayley,
Protein Sci 2000, 9, 1519-1529; (d) I. Protasevich, B. Ranjbar, V. Lobachov, A.
Makarov, R. Gilli, C. Briand, D. Lafitte, J. Haiech, Biochemistry 1997, 36, 2017-
2024; (e) B. R. Sorensen, M. A. Shea, Biochemistry 1998, 37, 4244-4253.
[21] W. E. Meador, A. R. Means, F. A. Quiocho, Science 1992, 257, 1251-1255.
Notes and references
[1] S. W. Vetter, E. Leclerc, Eur J Biochem 2003, 270, 404-414.
[2] Y. Ye, X. Liu, G. Xu, M. Liu, C. Li, Angew Chem Int Ed Engl 2015, 54, 5328-5330.
[3] (a) M. A. Schumacher, M. Crum, M. C. Miller, Structure 2004, 12, 849-860; (b) H.
Kuboniwa, N. Tjandra, S. Grzesiek, H. Ren, C. B. Klee, A. Bax, Nat Struct Biol 1995,
2, 768-776.
