Inorganic Chemistry
Article
ClCH2CH2Cl/CH3CH2OH (10/10 mL). The mixture was refluxed
overnight under an argon atmosphere. To the solution, NH4PF6 (648
mg, 3.9 mmol) was added. After being stirred at room temperature for
1 h, the reaction mixture was purified by column chromatography on
silica gel (200−300 mesh) with acetone/CH2Cl2 (1:20) as the eluent,
affording a yellow solid (327 mg, 0.32 mmol). Yield: 80%. Mp > 360
°C (dec.). 1H NMR (acetone-d6, 400 MHz, δ [ppm]): 8.94 (d, J = 8.0
Hz, 2H), 8.38 (t, J = 7.6 Hz, 2H), 8.27 (d, J = 5.2 Hz, 2H), 7.86−7.76
(m, 2H), 7.54 (t, J = 7.6 Hz, 2H), 7.42 (d, J = 7.6 Hz, 4H), 7.03 (t, J
= 7.6 Hz, 2H), 6.83 (t, J = 7.6 Hz, 2H), 6.75 (d, J = 7.2 Hz, 2H), 6.47
(d, J = 7.6 Hz, 2H), 2.13 (s, 6H), 1.93 (s, 6H), 1.71 (s, 6H). 13C
NMR (acetone-d6, 101 MHz, δ [ppm]): 165.10, 158.26, 156.96,
151.05, 149.29, 139.80, 136.15, 135.92, 135.16, 133.14, 131.36,
131.28, 131.12, 129.22, 129.13, 128.56, 124.90, 123.81, 122.90, 28.99,
28.80, 28.60, 28.41, 16.68, 16.35, 11.04. HRMS (ESI, m/z): 873.2941
[M − PF6]+ (calcd. 873.3000). Anal. Found: C, 52.11; H, 4.11; N,
10.94. Anal. Calcd for C44H40F6IrN8P: C, 51.91; H, 3.96; N, 11.01.
Synthesis of [Ir(dphtz)2(pzpy)]PF6 (2). The synthesis of [Ir-
(dphtz)2(pzpy)]PF6 followed a procedure similar to that for
[Ir(dphtz)2(bpy)]PF6, except that pzpy replaced bpy, affording an
verify the chemical structures of the four complexes.
Photophysical and electrochemical characteristics of the
complexes have been systematically investigated with the aid
of theoretical calculations. The use of the complexes as
emitting materials in LECs has also been evaluated.
EXPERIMENTAL SECTION
■
General Information. All solvents and reactants were commer-
cially obtained and used as received. NMR spectra, mass
spectrometry, and elemental analysis were measured with a BRUKER
400/500 NMR spectrometer, an LTQ-ORBITRAP-ETD mass
spectrometer, and an EA3000 elemental analyzer (Eurovector,
Italy), respectively. Absorption spectra, photoluminescence (PL)
spectra, and the PL transient lifetimes were measured with a
Shimadzu UV-2450 spectrophotometer, a HITACHI F-4600
spectrometer, and a transient spectrofluorimeter (Edinburgh Instru-
ments, FLSP920), respectively. The photoluminescent quantum
yields (PLQYs) in solution were measured relative to quinine sulfate
(Φp = 0.545 in 1 M H2SO4). The PLQYs in thin films were measured
with a Hamamatsu C11347 PLQY measurement system equipped
with an integrating sphere. Cyclic voltammetry was conducted with a
RST5200 voltammetric analyzer in dichloromethane (for oxidation of
complexes 1−4 and reduction of complexes 1−3) or N,N-
dimethylformamide (for reduction of complex 4) solutions (10−3
M), and the solutions were degassed with argon before measure-
ments. The cyclic voltammetry was performed at a scan rate of 100
mV s−1 by using a glass-carbon plate, a silver wire, and a platinum wire
as the working, pseudoreference, and counter electrodes, respectively.
Ferrocene and tetrabutylammonium hexafluorophosphate (0.1 M)
were employed as the internal standard and the supporting electrolyte,
respectively.
1
off-white solid. Yield: 72%. Mp > 350 °C (dec.). H NMR (acetone-
d6, 400 MHz, δ [ppm]): 9.22 (d, J = 2.8 Hz, 1H), 8.58 (d, J = 8.0 Hz,
1H), 8.43 (t, J = 7.2 Hz, 1H), 8.07 (d, J = 5.2 Hz, 1H), 7.66 (t, J = 6.8
Hz, 1H), 7.61−7.51 (m, 3H), 7.47−7.38 (m, 4H), 7.04−6.94 (m,
3H), 6.87−6.71 (m, 4H), 6.46 (t, J = 7.6 Hz, 2H), 2.16−2.10 (m,
6H), 2.00 (s, 3H), 1.94 (s, 3H), 1.83 (s, 3H), 1.79 (s, 3H). 13C NMR
(acetone-d6, 101 MHz, δ [ppm]): 165.07, 164.97, 158.16, 158.15,
150.30, 149.53, 148.00, 144.90, 143.97, 141.86, 136.16, 136.14,
135.90, 135.18, 135.16, 133.38, 133.26, 132.31, 131.52, 131.48,
131.29, 131.10, 130.89, 129.21, 129.13, 125.24, 123.77, 123.44,
122.97, 122.78, 113.63, 111.42, 16.67, 16.41, 16.36, 11.26, 11.04.
HRMS (ESI, m/z): 862.2906 [M − PF6]+ (calcd. 862.2952). Anal.
Found: C, 50.31; H, 4.14; N, 12.41. Anal. Calcd for C42H39F6IrN9P:
C, 50.09; H, 3.90; N, 12.52.
Synthesis. pzpy and dma-pzpy were synthesized following
reported procedures.16,45 The chloro-bridged iridium dimers, [Ir-
(dphtz)2Cl]2 and [Ir(Mephtz)2Cl]2, were prepared by reacting dphtz
or Mephtz with IrCl3·nH2O in refluxed water/2-ethoxylethanol (1:3)
under an argon atmosphere according to a reported procedure.46
Synthesis of 1-(2,6-Dimethylphenyl)-3-methyl-5-phenyl-1H-
1,2,4-triazole (dphtz). Benzoyl chloride (2.67 g, 19 mmol) and
ethyl acetimidate hydrochloride (2.35 g, 19 mmol) were dissolved in
chloroform (50 mL). To the solution, triethylamine (3.84 g, 38
mmol) was added dropwise under stirring. After being stirred at room
temperature for 18 h under an argon atmosphere, the reaction mixture
was washed with water and dried over anhydrous sodium sulfate. The
solvent was removed under a vacuum, and the residual was dissolved
in chloroform (50 mL). To the solution, 2,6-dimethylphenylhydrazine
hydrochloride (4.32 g, 25 mmol) and triethylamine (9.60 g, 95 mmol)
were added. The mixture was refluxed overnight under an argon
atmosphere. The solvent was removed under a vacuum, and the
residue was purified by column chromatography on silica gel (200−
300 mesh) with ethyl acetate/petroleum ether (1:10) as the eluent,
affording a white solid (2.34 g, 8.8 mmol). Yield: 46%. Mp: 96−97
°C. 1H NMR (CDCl3, 400 MHz, δ [ppm]): 7.48 (d, J = 7.6 Hz, 2H),
7.39−7.27 (m, 4H), 7.16 (d, J = 7.6 Hz, 2H), 2.55 (s, 3H), 1.98 (s,
6H). 13C NMR (CDCl3, 101 MHz, δ [ppm]): 160.98, 154.45, 136.95,
135.85, 129.99, 129.80, 128.74, 128.69, 127.54, 127.25, 17.62, 14.03.
HRMS (ESI, m/z): 264.1504 [M + H]+ (calcd. 264.1495). Anal.
Found: C, 77.78; H, 6.77; N, 16.08. Anal. Calcd for C17H17N3: C,
77.54; H, 6.51; N, 15.96.
Synthesis of 1,3-Dimethyl-5-phenyl-1H-1,2,4-triazole (Mephtz).
The synthesis of Mephtz is similar to that of dphtz, except that
methylhydrazine sulfate replaced 2,6-dimethylphenylhydrazine hydro-
chloride. Yield: 43%. Mp: 72−73 °C. 1H NMR (CDCl3, 500 MHz, δ
[ppm]): 7.69−7.61 (m, 2H), 7.54−7.46 (m, 3H), 3.93 (s, 3H), 2.43
(s, 3H). 13C NMR (CDCl3, 101 MHz, δ [ppm]): 159.80, 154.95,
129.96, 128.79, 128.55, 127.99, 36.59, 13.81. HRMS (ESI, m/z):
174.1036 [M + H]+ (calcd. 174.1026). Anal. Found: C, 69.65; H,
6.64; N, 24.31. Anal. Calcd for C10H11N3: C, 69.34; H, 6.40; N, 24.26.
Synthesis of [Ir(dphtz)2(bpy)]PF6 (1). [Ir(dphtz)2Cl]2 (300 mg,
0.20 mmol) and bpy (65 mg, 0.42 mmol) were dissolved in
Synthesis of [Ir(Mephtz)2(pzpy)]PF6 (3). The synthesis of [Ir-
(Mephtz)2(pzpy)]PF6 followed a procedure similar to that for
[Ir(dphtz)2(bpy)]PF6, except that [Ir(dphtz)2Cl]2 and bpy were
replaced by [Ir(Mephtz)2Cl]2 and pzpy, respectively, yielding an off-
1
white solid. Yield: 80%. Mp > 350 °C (dec.). H NMR (acetone-d6,
500 MHz, δ [ppm]): 9.15 (d, J = 3.0 Hz, 1H), 8.47 (d, J = 8.4 Hz,
1H), 8.33 (td, J = 8.0, 1.5 Hz, 1H), 7.91 (d, J = 5.0 Hz, 1H), 7.82 (d, J
= 7.5 Hz, 1H), 7.80 (d, J = 7.5 Hz, 1H), 7.53 (t, J = 6.0 Hz, 1H), 7.37
(d, J = 1.5 Hz, 1H), 7.17−7.04 (m, 2H), 7.03−6.89 (m, 3H), 6.55 (d,
J = 7.5 Hz, 1H), 6.52 (d, J = 7.5 Hz, 1H), 4.34 (s, 3H), 4.33 (s, 3H),
1.64 (s, 3H). 1.60 (s, 3H). 13C NMR (acetone-d6, 101 MHz, δ
[ppm]): 164.40, 164.33, 156.08, 150.09, 149.83, 147.33, 144.20,
144.00, 141.51, 133.42, 133.34, 132.08, 132.04, 131.94, 130.40,
130.00, 125.12, 124.99, 124.78, 122.62, 122.46, 113.20, 111.14, 37.47,
10.92, 10.71. HRMS (ESI, m/z): 682.2026 [M − PF6]+ (calcd.
682.2013). Anal. Found: C, 40.85; H, 3.52; N, 15.03. Anal. Calcd for
C28H27F6IrN9P: C, 40.68; H, 3.29; N, 15.25.
Synthesis of [Ir(Mephtz)2(dma-pzpy)]PF6 (4). The synthesis of
[Ir(Mephtz)2(dma-pzpy)]PF6 followed a procedure similar to that of
[Ir(dphtz)2(bpy)]PF6, except that [Ir(dphtz)2Cl]2 and bpy were
replaced by [Ir(Mephtz)2Cl]2 and dma-pzpy, respectively, yielding an
1
off-white solid. Yield: 72%. Mp > 350 °C (dec.). H NMR (acetone-
d6, 500 MHz, δ [ppm]): 9.15 (d, J = 3.0 Hz, 1H), 7.81−7.76 (m, 2H),
7.53 (d, J = 2.5 Hz, 1H), 7.29−7.25 (m, 2H), 7.10−7.00 (m, 2H),
6.99−6.89 (m, 2H), 6.84−6.81 (m, 1H), 6.69 (dd, J = 6.8, 2.6 Hz,
1H), 6.53 (d, J = 7.6 Hz, 2H), 4.34−4.33 (m, 6H), 3.22 (s, 6H), 1.72
(s, 3H), 1.63 (s, 3H). 13C NMR (acetone-d6, 101 MHz, δ [ppm]):
164.67, 164.40, 156.50, 155.94, 155.91, 150.14, 148.29, 147.71,
145.70, 142.88, 133.71, 133.33, 132.31, 132.06, 130.81, 130.17,
129.82, 124.91, 124.65, 122.17, 122.07, 110.57, 107.69, 93.34, 39.01,
37.42, 37.40, 11.18, 10.63. HRMS (ESI, m/z): 725.2413 [M − PF6]+
(calcd. 725.2435). Anal. Found: C, 41.23; H, 3.84; N, 16.01. Anal.
Calcd for C30H32F6IrN10P: C, 41.42; H, 3.71; N, 16.10.
X-ray Crystallography. The X-ray experiments on single crystals
of complexes 1 and 2 were performed with a Bruker Apex Duo CCD
diffractometer at 150 K. The X-ray experiments on single crystals of
C
Inorg. Chem. XXXX, XXX, XXX−XXX
