Synthesis, coordination behaviour, structural features and use in asymmetric
hydrogenations of bifep-type biferrocenes†
Gustavo Espino,b Li Xiao,a Michael Puchberger,c Kurt Mereiter,c Felix Spindler,d Blanca R. Manzano,e
Fe´lix A. Jalo´ne and Walter Weissensteiner*a
Received 22nd September 2008, Accepted 20th January 2009
First published as an Advance Article on the web 20th February 2009
DOI: 10.1039/b816544k
A protocol for the synthesis of C2- and C1-symmetric 2,2¢¢-diarylphosphino-substituted biferrocenes
(bifep-type ligands) is presented and the preparation of four representatives is described
[(Sp,Sp)-2-R1 P-2¢¢- R2 P-1,1¢¢-biferrocene; 1 (bifep): R1 = R2 = Ph; 2: R1 = Ph, R2 = Cy; 3: R1 = R2 =
2
3,5-Me2C6H3; 4: R1 = 23,5-Me2-4-OMe-C6H2, R2 = 3,5-(CF3)2C6H3]. In addition, the synthesis of three
palladium(II) complexes ([PdX2(L)], 10: L = 1, X = Cl; 11: L = 4, X = Cl; 12: L = 1, X = C6F5 and of
four bifep ruthenium complexes (13: [RuCl(p-cymene)(1)]PF6; 14: [RuI(p-cymene)(1)]PF6; 15:
[RuCl(benzene)(1)]PF6; 16: [RuI(p-cymene)(1)]I) is reported. In the solid state the biferrocene unit of
complexes 10, 11 and 15 adopt either a (P)-shaped (10) or an (M)-shaped (11, 15) conformation. In
solution, palladium complexes 10 and 11 are present as equilibrium mixtures of rapidly interconverting
(P)- and (M)-shaped conformers. Rhodium- and iridium-mediated asymmetric hydrogenations of a
number of olefins and one imine give products with only low to moderate enantiomeric excess, while in
the ruthenium-catalyzed hydrogenation of ketones a maximum e.e. of 82% is obtained. The low
enantioselectivities are assumed to be related to the conformational flexibility of bifep-type ligands.
Introduction
Diphosphines based on C2-symmetric biaryl backbones are
widely used as ligands for enantioselective catalysts, with 2,2¢-
bis(diphenylphosphino)-1,1¢-binaphthyl (binap) certainly being
one of the most prominent examples.1 In addition to binaph-
thyl, a number of alternative biaryl-type backbones2 (including
biphenyl, bispyridyl and other bisheteroaromatic ligand scaffolds)
have been investigated. This concept has further been extended
to 2,2¢¢-disubstituted biferrocenes and the synthesis of 2,2¢¢-
bis(diphenylphosphino)-1,1¢¢-biferrocene (bifep)3 and some of its
P-stereogenic analogues4 have been described (e.g. I, Fig. 1). On
using the latter type of ligand, catalytic allylic amination reactions
resulted in products with up to 93% e.e.4
In a previous communication, we briefly described a protocol for
the synthesis of 2,2¢¢-disubstituted biferrocenes that allowed not
only the preparation of C2- but also of C1-symmetric biferrocenes.5
In addition, the use of a few bifep-type ligands in ruthenium-
catalyzed asymmetric hydrogenations of ethyl acetoacetate was
Fig. 1 Binap, bifep, and P-chiral analogues I and II.
aFaculty of Chemistry, University of Vienna, Wa¨hringer Straße 38, 1090,
described as well as structural features of dichloro palladium(II)
Wien, Austria. E-mail: walter.weissensteiner@univie.ac.at
bDepartamento de Qu´ımica, Facultad de Ciencias, Universidad de Burgos,
Pza Misael Ban˜uelos s/n., 09001, Burgos, Spain. E-mail: gespino@ubu.es
complexes of bifep and one C1-symmetric analogue. We noticed
with interest that in the solid-state the helicity of the biferrocene
backbone in these complexes changed on changing the type of
phosphino substituents and this observation was interpreted as
being the result of conformational flexibility of the biferrocene
backbone.
We now describe in detail the synthesis of C2- and
C1-symmetric bifep-type biferrocenes, their coordination be-
haviour and additional rhodium- and ruthenium-mediated asym-
metric hydrogenations of alkenes and ketones. These catalytic
reactions were carried out with catalysts obtained either in situ
cFaculty of Technical Chemistry, Vienna University of Technology,
Getreidemarkt 9/164SC, 1060, Wien, Austria. E-mail: mpuchber@mail.
zserv.tuwien.ac.at, kurt.mereiter@tuwien.ac.at
dSolvias AG, Catalysis & Synthesis, P.O. Box, CH-4002, Basel, Switzerland.
E-mail: felix.spindler@solvias.com
eDepartamento de Qu´ımica Inorga´nica, Orga´nica y Bioqu´ımica, IRICA,
Universidad de Castilla-La Mancha, Avda. C. J. Cela, 10, 13071, Ciudad
Real, Spain. E-mail: blanca.manzano@uclm.es, felix.jalon@uclm.es
† CCDC reference numbers 158065, 158066, 655658 and 703046. For
crystallographic data in CIF or other electronic format see DOI:
10.1039/b816544k
This journal is
The Royal Society of Chemistry 2009
Dalton Trans., 2009, 2751–2763 | 2751
©

View Article Online
Fig. 2 Synthesis of ligands 1–4.
from ligands and an appropriate metal source or from isolated
metal ligand complexes. In addition, a more extensive study on
the structural features of palladium and ruthenium complexes of
bifep-type ligands is reported.
Results
Synthesis of ligands and complexes
Fig. 3 Preparation of palladium and ruthenium complexes 10–16.
C2- and C1-symmetric ligands 1–4 were prepared in three steps
from (S,Rp)-5 (Fig. 2), which was easily available from (S)-(4-
methylphenyl)sulfinyl ferrocene.6 An Ullmann-type reaction of
iodide (S,Rp)-5 with Cu powder gave enantiopure (S,S,Sp,Sp)-
2,2¢¢-bis-(p-tolylsulfinyl)-1,1¢¢-biferrocene (6, 77%), which served
as the key intermediate that allowed the stepwise replace-
ment of both p-tolylsulfinyl units. Intermediates 7–9 were ob-
tained by treatment of 6 with t-BuLi (1.2 equiv.) and subse-
quent quenching with the appropriate chloro(diaryl)phosphine
[(S,Sp,Sp)-7, chloro(diphenyl)phosphine, 60% yield; (S,Sp,Sp)-
8, chlorobis(3,5-dimethylphenyl)phosphine, 80%, (S,Sp,Sp)-9,
chlorobis(3,5-dimethyl-4-methoxyphenyl)phosphine, 66%]. In the
final step, the second sulfinyl group was removed by reaction
of 7, 8, or 9 with t-BuLi followed by addition of either a
chloro(diaryl)phosphine or a chloro(dialkyl)phosphine, resulting
in ligands (Sp,Sp)-1 [chloro(diphenyl)phosphine, 49%], (Sp,Sp)-
2 [chloro(dicyclohexyl)phosphine, 10%], (Sp,Sp)-3 [chlorobis(3,5-
dimethylphenyl)phosphine, 30%], and (Sp,Sp)-4 [chlorobis[3,5-
bis(trifluoromethyl)phenyl]phosphine, 42%]. Interestingly, all at-
tempts to transform 6 directly into the C2-symmetric ligands 1 and
3 failed [e.g. by treatment of 6 with 2.2 equiv. of t-BuLi followed by
quenching with a chloro(diaryl)phosphine]. In neither case could
both sulfinyl groups of 6 be replaced in one step by phosphino
substituents.
In order to study the coordination behaviour of bifep-type
ligands, three palladium(II) complexes of ligands 1 and 4, as well as
four ruthenium(II) complexes of bifep (1), were prepared as model
compounds (Fig. 3). In addition, all bifep-ruthenium complexes
weretestedas pre-catalysts in asymmetric hydrogenation reactions.
The dichloro palladium(II) complexes [PdCl2(1)], 10 and
[PdCl2(4)], 11, were prepared by treating the respective ligands
with [PdCl2(MeCN)2] in benzene while reaction of ligand 1
with [Pd(C6F5)2(COD)] in CH2Cl2 gave the bis(pentafluorophenyl)
palladium(II) complex [Pd(C6F5)2(1)], 12. All monocationic ruthe-
nium complexes [RuX(arene)(1)]PF6 were obtained by reaction of
ligand 1 (2 equiv.) in THF with the respective [RuX2(arene)]2 dimer
(1 equiv.) in the presence of AgPF6 (13: [RuCl(p-cymene)(1)]PF6;
14: [RuI(p-cymene)(1)]PF6; and 15: [RuCl(benzene)(1)]PF6). Com-
plex 16, [RuI(p-cymene)(1)]I, was obtained by reacting 2 equiv. of
ligand 1 with [RuI2(p-cymene)]2 in a mixture of CH2Cl2 and MeOH
(4 : 1) in the absence of AgPF6.
The structural integrity of all ligands (1–4) and complexes (10–
16) was assessed by NMR spectroscopy and for ligand 1 and
complexes 10, 11, and 15 single crystals were also studied by
X-ray diffraction (see below). The absolute (Sp,Sp)-configuration
of ligands 1–4 follows from the known absolute configuration
of the starting material (S)-(4-methylphenyl)sulfinyl ferrocene.6
Furthermore, the X-ray data for ligand 1 and complexes 10,
11, and 15 also confirmed the absolute (Sp,Sp)-configuration of
ligands 1 and 4.
Molecular structures of bifep, 1, and complexes [PdCl2(1)] (10),
[PdCl2(4)] (11) and [RuCl(benzene)(1)]PF6 (15), in the solid-state
Single crystals were obtained by vapour-liquid diffusion of diethyl
ether into a solution of the respective ligand or complex in
either CHCl3 (1) or CH2Cl2 (11) or by liquid–liquid diffusion
of ethanol into a solution of 10 in CHCl3, and liquid–liquid
diffusion of hexane into a solution of 15 in acetone. Details for
the X-ray crystallography experiments are given in Table 1 and
in the Experimental. Views of the molecular structures of these
compounds are shown in Fig. 4 and selected geometrical data are
given in Table 2. The absolute configuration of each compound
was determined from the X-ray anomalous dispersion effects and
was consistent with the chemical evidence.
Ligand (Sp,Sp)-1 crystallizes in the orthorhombic space group
P212121 and contains one molecule per asymmetric unit. Although
in the crystal 1 is found in an asymmetric environment, it adopts
a clear C2 pseudosymmetry when viewed perpendicular to the
2752 | Dalton Trans., 2009, 2751–2763
