Excited Charge Transfer States in Donor–Acceptor
Fluorescent Phenanthroimidazole Derivatives
J. Jayabharathi & V. Thanikachalam & R. Sathishkumar
Received: 19 July 2013 /Accepted: 27 September 2013
#
Springer Science+Business Media New York 2013
Abstract Solvent-dependent electronic structure of the select-
ed donor (D) acceptor (A) derivatives of phenanthroimidazole
derivatives containing fluoro substituent as an electron acceptor
fragment in the fluorescent charge transfer (CT) states has been
investigated. The mechanism of the radiative charge recombi-
nation CT→S0 is discussed in terms of the Mulliken–Murrell
model of the CT complexes and the Marcus theory of photoin-
duced electron transfer (ET). Solvatochromic effects on the
spectral position and profile of the stationary fluorescence
spectra clearly indicate the CT character of the emitting singlet
states of all of the compounds studied both in a polar and a non
polar environment. An analysis of the CT fluorescence leads to
the quantities relevant for the electron transfer in the Marcus
inverted region. The values of the fluorescence rate constants
(kr) and corresponding transition dipole moments (M) and their
solvent polarity dependence indicate that the electronic cou-
pling between the emitting 1CT state and the ground state is a
governing factor of the radiative transitions. The relatively large
values of M indicate a nonorthogonal geometry of the donor
and acceptor subunits in the fluorescent states. It is shown that
Marcus theory can be applied for the quantitative description of
the radiationless charge recombination processes in the cases
when an intersystem crossing to the excited triplet states can be
neglected.
Introduction
The wide investigations of the intramolecular electron transfer
(ET) in donor (D)-acceptor (A) compounds such as carbazol-
9-yl derivatives of aromatic nitriles [1] and aryl or hetero aryl
derivatives of aromatic amines [2] suggest a possibility to
predict the photophysical behaviour of a particular D–A mol-
ecule from the properties of the individual chromophores as
far as the electronic interactions between the lowest excited
charge transfer state CT and the ground state S0 (V0) and/or
the locally excited states LE, localized either in the acceptor
(V1,3A) or in the donor (V1,3D) respectively, are taken into
account. A similar approach can be applied to describe the
properties of the singlet CT states e.g., the transition dipole
moments for the CT absorption (1CT←S0) and the fluores-
cence (1CT→S0) as well as the characteristics of the triplet
3CT states [3] (e.g., the zero-field splitting parameters).
The study of the intramolecular ET reactions is to identify
structural elements that promote electronic coupling between
an electron donor and an acceptor is a challenging one. The
application of different models [4–6] used to determine the
electronic matrix elements from the solvent polarity effects on
the electronic transition dipole moments of the CT emission
(Mflu) [7, 8] and the CTabsorption (Mabs) [2]. The appropriate
values of the electronic coupling elements are mainly deter-
mined by the interactions between the atoms forming the bond
A–D can be theoretically predicted following the formalism
proposed by Dogonadze et al. [9, 10]. Neglecting contribu-
tions from the σ orbitals, one can obtain for π-electronic
systems
.
.
.
Keywords Phenanthroimidazole Charge transfer Donor
.
Acceptor Lifetime
V0 ¼ CALUMOCHd OMOβADcosðθAꢀꢀDÞ þ const:;
V1A;3 ¼ CAHOMOCHDOMOβADcosðθAꢀꢀDÞ þ const:;
V1D;3 ¼ CALUMOCLDUMOβADcosðθAꢀꢀDÞ þ const:;
ð1Þ
ð2Þ
ð3Þ
:
:
J. Jayabharathi (*) V. Thanikachalam R. Sathishkumar
Department of Chemistry, Annamalai University,
Annamalainagar 608 002, Tamilnadu, India
e-mail: jtchalam2005@yahoo.co.in

J Fluoresc
where θA-D denotes the angle between the planes of the
acceptor and donor subunits and CHOMO and CLUMO are the
LCAO coefficients (as obtained for the individual chromo-
phores) of the 2pZ atomic orbitals (where z is the axis perpen-
dicular to the acceptor or donor rings) of the highest occupied
molecular orbital (HOMO) and of the lowest unoccupied
molecular orbital (LUMO) located on the atoms forming the
A–D bond. β is the resonance integral for these AD atoms and
const. is related to the electronic interactions between the
remaining pairs of atoms in the D–A molecule (this contribu-
tion is usually small and negligible) . Expressions 2 and 3
assume that the 1LE state is mainly described by a configura-
tion corresponding to the HOMO→LUMO excitation (e.g.,
1La state in Platt’s notation)
In this work, we used the Lippert solvent parameter (Δf),
the normalized ET (30) polarity scale, and the multi parameter
Kamlet-Taft and Catalan solvent scales to describe the solvent
effect on the fluorescence emission and stokes shift of
phenanthroimidazole derivatives. We have also addressed
the influence of solvents on the photophysical properties of
2-(4-fluorophenyl)-1-phenyl-1H-phenanthro [9,10-d]
imidazole (1)
Yield: 94 %. Anal. Calcd. for C27H17FN2: C, 83.49; H,
1
4.41; N, 7.21. Found: C, 83.61; H, 4.32; N, 7.30. H
NMR (400 MHz, d6-DMSO): δ 7.07 (d, J=8 Hz, 1H),
7.23 (t, J=7.2 Hz, 2H), 7.36 (t, J=7.2 Hz, 1H), 7.55 (t, J=
8 Hz, 1H), 7.59–7.63 (m, 2H), 7.67–7.72 (m, 6H), 7.78 (t,
J=6.8 Hz 1H), 8.69 (d, J=6.8 Hz 1H), 8.88 (d, J=8.4 Hz
1H), 8.93 (d, J=8 Hz 1H). 13C NMR (100 MHz, d6-
DMSO): δ 115.16, 115.37, 120.11, 121.96, 122.41,
123.65, 124.48, 125.22, 125.74, 126.63, 126.75,
126.78, 127.46, 127.64, 127.70, 128.47, 129.11,
130.26, 130.35, 131.34, 131.43, 136.34, 137.99,
149.69, 161.08, 163.54. MS: m/z. 389.27 [M+].
2-(4-fluorophenyl)-1-p-tolyl-1H-phenanthro [9,10-d]
imidazole (2)
Yield: 92 %. Anal. calcd. for C28H19FN2: C, 83.56; H,
1
4.76; N, 6.96. Found: C, 83.95; H, 4.65; N, 7.01. H
NMR (400 MHz, CDCl3): δ 2.48(s, 3H), 7.13 (d, J=
7.6 Hz, 1H), 7.21 (t, J=8.8 Hz, 2H), 7.35 (t, J=7.6 Hz,
1H), 7.46–7.48 (m, 2H), 7.53–7.63 (m, 5H), 7.68 (t, J=
6.8 Hz 1H), 7.77 (t, J=7.2 Hz, 1H), 8.68 (d, J=8.8 Hz,
the synthesized molecules in terms of hceυvabasc; hceυvac and
flu
ꢀ
ꢁ
hceυvaabcs−hceυvac with solvent polarity function. The reported
1H), 8.87 (d, J=8 Hz, 1H), 8.92 (d, J=8.4 Hz, 1H). 13
C
flu
NMR (100 MHz, d6-DMSO): δ 20.92, 115.16, 115.37,
120.13, 121.95, 122.48, 123.64, 124.44, 125.19, 125.71,
126.64, 126.82, 126.85, 127.43, 127.62, 127.73, 128.43,
128.77, 13.80, 131.33, 131.41, 135.36, 136.29, 139.79,
149.79, 161.06, 163.52. MS: m/z. 403.44 [M+].
2-(4-fluorophenyl)-1-(4-methoxyphenyl)-1H-phenanthro
[9,10-d] imidazole (3)
results are based on a study of the solvent effects on the
spectral position of absorption and fluorescence spectra as
well as on the CT emission quantum yields and excited state
depopulation kinetics.
Yield: 95 %. Anal. calcd. for C28H19FN2O: C, 80.37;
H, 4.58; N, 6.69. Found: C, 81.01; H, 4.25; N, 6.60. 1H
NMR (400 MHz, d6-DMSO): δ 3.89 (s, 3H), 7.15–7.25
(m, 5H), 7.38 (t, J=8 Hz, 1H), 7.595–7.67 (m, 6H), 7.76
(t, J=7.6Hz, 1H), 8.66 (d, J=12 Hz, 1H), 8.89 (dd, J=
12 Hz, 2H). 13C NMR (100 MHz, d6-DMSO): δ 60.86,
120.36, 120.65, 125.45, 127.21, 128.85, 129.66, 130.42,
130.92, 131.91, 131.99, 132.20, 132.64, 132.93, 133.18,
133.75, 135.46, 135.72, 136.56, 136.68, 141.55, 155.27,
165.34. MS: m/z. 419.39 [M+].
Experimental
Chemicals
4-fluorobenzaldehyde and Phenanthrene 9, 10-dione have
been supplied by Sigma Aldrich (St. Louis, USA). Aniline,
4-Methylaniline, 4-Methoxyaniline, and 3,5- Dimethylaniline
used were of analytical grade and received from S.D. Fine
(Mumbai, India).
2-(4-fluorophenyl )-1-(3,5-dimethylphenyl )-1H-
phenanthro [9,10-d] imidazole (4)
One Pot Synthesis of Phenanthrimidazoles
Yield: 97 %. Anal. calcd. for C29H21FN2: C, 83.63; H,
1
Phenanthrimidazole derivatives have been prepared by
four components condensation of phenanthrene-9, 10-dione
(40 mmol), ammonium acetate (30 mmol), 4-
fluorobenzaldehyde (30 mmol) and aniline (30 mmol)
refluxed in ethanol at 80 °C in the presence of Indium (III)
fluoride (InF3) as Lewis acid catalyst (Scheme 1) for 30 min.
The completion of the reaction was monitored by thin layer
chromatography. The reaction mixture was extracted with di-
chloromethane and purified by column chromatography using
benzene: ethyl acetate (9:1) as the eluent.
5.08; N, 6.73. Found: C, 83.21; H, 5.24; N, 6.38. H
NMR (400 MHz, d6-DMSO): δ 2.41 (s, 6H), 7.07 (t, J=
8Hz, 2H), 7.15–7.31 (m, 5H), 7.54 (t, J=7.6 Hz, 1H),
7.60–7.68 (m, 3H), 7.73 (t, J=8 Hz 1H), 8.74 (d, J=
7.6 Hz 2H), 8.80 (d, J=8 Hz 1H). 13C NMR (100 MHz,
d6-DMSO): δ 20.79, 114.75, 114.96, 120.43, 122.00,
122.35, 122.88, 123.64, 124.76, 125.32, 125.83,
126.20, 126.44, 126.91, 127.54, 127.57, 128.37,
130.83, 130.91, 131.36, 136.19, 137.50, 139.72,
149.26, 161.06. MS: m/z. 417.02 [M+].

J Fluoresc
InF3
C
H
O
R'
NH3
-H2O
InF3
O
C
R'
HN
O
O
H2N
H
R
InF3
NH4COOCH3
-H2O
N
R
InF3
InF3
O
H
O
H
N
N
R'
H
R'
H2O
N
-H2O
-InF3
N
R
R
N
H
N
N
R'
R'
N
R
R
Scheme 1 Possible mechanism of catalytic synthesis of phenanthroimidazole

J Fluoresc
Table 1 Effect of amount and catalytic activity of catalyst in the synthe-
sis of phenanthroimidazoles (1–4)
