Synthesis, absolute configuration, and biological profile of the enantiomers of trans-[2-(2,6-dimethoxyphenoxy)ethyl][(3-p-tolyl-2,3-dihydro-1,4-benzodioxin-2- yl)methyl]amine (mephendioxan), a potent competitive α1A-adrenoreceptor antagonist

Article abstract of DOI:10.1021/jm960069a

The enantiomers of trans-[2-(2,6-dimethoxyphenoxy)ethyl][(3-p-tolyl-2,3-dihydro-1,4-benzodioxin-2- yl)methyl]amine (mephendioxan, 2) were synthesized from the chiral trans-3-p-tolyl- 2,3-dihydro-1,4-benzodioxin-2-carboxylic acids [(+)-3 and (-)-3] which in turn were obtained through the resolution of the racemic acid with (R)- and (S)-α-methylbenzylamine. Comparison of CD spectra of the enantiomers of 2 with that of (2S,3S)-3-methyl-2-phenyl-1,4-benzodioxane allowed the assignment of the 2S,3S configuration to the (-)-enantiomer of 2 and of the 2R,3R configuration to the other enantiomer. The binding profile of the enantiomers of 2 was assessed at α₁, α₂, D₂, and 5-HT_1A receptors, in comparison to WB 4101 (1), 5-methylurapidil, and (+)- niguldipine. In addition, the two enantiomers were investigated at native and cloned α₁-adrenoreceptor subtypes. (-)-2 was 10-30 times as potent as the (+)-enantiomer at α₁- adrenoreceptor subtypes in both functional and binding assays. It was 36-fold selective for the α_1A- versus α_1B-adrenoreceptor and 60- and 20-fold selective in binding to the α_1a- adrenoreceptor relative to α_1b and α_1d subtypes, respectively. Furthermore, the enantiomer (-)-2 displayed selectivities of 12000-, 2500-, and 250-fold in binding to α_1a-adrenoreceptors relative to α₂-adrenoreceptors and 5-HT_1A and D₂ receptors. These results indicate that (-)-2 may be a valuable tool in the characterization of α₁-adrenoreceptor subtypes.

Full text of DOI:10.1021/jm960069a

J . Med. Chem. 1996, 39, 2253-2258
2253
Syn th esis, Absolu te Con figu r a tion , a n d Biologica l P r ofile of th e En a n tiom er s of
tr a n s-[2-(2,6-Dim eth oxyp h en oxy)eth yl][(3-p-tolyl-2,3-d ih yd r o-1,4-
ben zod ioxin -2-yl)m eth yl]a m in e (Mep h en d ioxa n ), a P oten t Com p etitive
r1A-Ad r en or ecep tor An ta gon ist
Wilma Quaglia,† Maria Pigini,† Seyed K. Tayebati,† Alessandro Piergentili,† Mario Giannella,†
Amedeo Leonardi,‡ Carlo Taddei,‡ and Carlo Melchiorre*,§
Department of Chemical Sciences, University of Camerino, Via S. Agostino 1, 62032 Camerino, Italy, Research and
Development Division, Recordati S.p.A., Via Civitali 1, 20148 Milano, Italy, and Department of Pharmaceutical Sciences,
University of Bologna, Via Belmeloro 6, 40126 Bologna, Italy
Received J anuary 22, 1996X
The enantiomers of trans-[2-(2,6-dimethoxyphenoxy)ethyl][(3-p-tolyl-2,3-dihydro-1,4-benzo-
dioxin-2-yl)methyl]amine (mephendioxan, 2) were synthesized from the chiral trans-3-p-tolyl-
2,3-dihydro-1,4-benzodioxin-2-carboxylic acids [(+)-3 and (-)-3] which in turn were obtained
through the resolution of the racemic acid with (R)- and (S)-R-methylbenzylamine. Comparison
of CD spectra of the enantiomers of 2 with that of (2S,3S)-3-methyl-2-phenyl-1,4-benzodioxane
allowed the assignment of the 2S,3S configuration to the (-)-enantiomer of 2 and of the 2R,3R
configuration to the other enantiomer. The binding profile of the enantiomers of 2 was assessed
at R1, R2, D2, and 5-HT1A receptors, in comparison to WB 4101 (1), 5-methylurapidil, and (+)-
niguldipine. In addition, the two enantiomers were investigated at native and cloned
R1-adrenoreceptor subtypes. (-)-2 was 10-30 times as potent as the (+)-enantiomer at R1-
adrenoreceptor subtypes in both functional and binding assays. It was 36-fold selective for
the R1A- versus R1B-adrenoreceptor and 60- and 20-fold selective in binding to the R1a-
adrenoreceptor relative to R1b and R1d subtypes, respectively. Furthermore, the enantiomer
(-)-2 displayed selectivities of 12000-, 2500-, and 250-fold in binding to R1a-adrenoreceptors
relative to R2-adrenoreceptors and 5-HT1A and D2 receptors. These results indicate that (-)-2
may be a valuable tool in the characterization of R1-adrenoreceptor subtypes.
In tr od u ction
R1-Adrenoreceptors are not a homogeneous family as
clearly evidenced by pharmacological tools and molec-
ular biological techniques.1 Two native R1-adreno-
receptor subtypes, R1A and R1B, have been formerly
characterized by functional and binding assays. The R1A
subtype has high affinity for antagonists such as WB
Our research group has previously been involved in
4101, 5-methylurapidil, and (+)-niguldipine and is
designing new R1-adrenoreceptor antagonists structur-
ally related to WB 4101 {[2-(2,6-dimethoxyphenoxy)-
et h yl][(2,3-dih ydr o-1,4-ben zodioxin -2-yl)m et h yl]-
amine, 1} and in studying structure-affinity and
structure-selectivity relationships with the goal of
developing high-affinity, site-selective ligands for sub-
types of the R1-adrenoreceptor.8-11 Among a variety of
structural modifications performed on 1, we have dem-
onstrated that the insertion of a substituent at the
3-position having a trans relationship with the 2-side
chain markedly affects the affinity for R2-adrenorecep-
tors whereas that for R1-adrenoreceptors is only slightly
decreased.12 The overall result of that structural modi-
fication was a significant improvement in selectivity
toward rat vas deferens R1-adrenoreceptors compared
to 1. Thus, it is evident that a 3-substituent (trans) may
have a crucial role in the modulation of selectivity for
R1-adrenoreceptor subtypes.
insensitive to inactivation by chloroethylclonidine (CEC).
The R1B subtype displays lower affinity for the above
antagonists, but is preferentially inactivated by the
alkylating agent CEC.1 However, very recently it has
been demonstrated that the R1-adrenoreceptor mediat-
ing contraction upon activation in isolated rat aorta may
belong to the R1D subtype.2 Cloning studies have
confirmed the existence of at least three distinct R1-
adrenoreceptors, which are now designated as R1a, R1b,
and R1d subtypes.3-5 The recombinant R1a-adreno-
receptor (formerly designated as R1c)4 corresponds to the
native R1A-adrenoreceptor, the recombinant R1b to the
native R1B, and the R1d (formerly designated as R1a/d in
some publications) to the native R1D-adrenoreceptor
recently characterized in rat aorta. Thus, R1-adreno-
receptors are now classified as R1A (R1a), R1B (R1b), and
R1D (R1d), with upper and lower case subscripts being
used to designate native or recombinant receptor,
respectively.6,7
Among the analogues of 1 bearing a 3-substituent the
p-tolyl derivative mephendioxan (2) resulted in the most
potent and selective antagonist for the rat vas deferens
R1-adrenoreceptor subtype. Since the enantiomers of 1
have different affinity for R1-adrenoreceptors,13,14 we
† University of Camerino.
‡ Recordati S.p.A.
§ University of Bologna.
X Abstract published in Advance ACS Abstracts, April 15, 1996.
S0022-2623(96)00069-6 CCC: $12.00 © 1996 American Chemical Society

2254 J ournal of Medicinal Chemistry, 1996, Vol. 39, No. 11
Quaglia et al.
Sch em e 1a
F igu r e 1. CD spectra of enantiomers of 2 (oxalate salts: c
0.015, MeOH): (-)-2 (- - -) and (+)-2 (s).
was observed for (+)-2 and (-)-2 (as the free bases) at
δ 3.81 and 3.83 ppm, respectively.
Knowledge of the absolute configuration of (2S,3S)-
3-methyl-2-phenyl-1,4-benzodioxane15 (5) allows a de-
termination of the stereochemistry of the two enanti-
omers of 2. The CD spectra for the enantiomers (as
a
(a) (S)-(-)-R-methylbenzylamine, 95% EtOH, room tempera-
ture, 30 h; (b) (R)-(+)-R-methylbenzylamine, 95% EtOH, room
temperature, 30 h; (c) EtOCOCl, Et3N, CHCl3, 30 min, 0 °C, then
2-(2,6-dimethoxyphenoxy)ethylamine, room temperature, 12 h,
silica gel (petroleum ether-EtOAc, 75:25); (d) BH3‚Me2S, diglyme,
120 °C, 12 h, then MeOH, room temperature, 5 h, HCl, 120 °C, 4
h, silica gel (CHCl3-EtOAc, 95:5).
thought it of interest to investigate whether the enan-
tiomers of 2, that have an additional chiral center might
be able to discriminate among R1-adrenoreceptor sub-
types.
We report here the synthesis of the two enantiomers
of 2 together with their biological profile assessed by
functional and binding assays. The absolute configu-
ration of the enantiomers of 2 was assigned by correlat-
ing their CD spectra with that of (2S,3S)-3-methyl-2-
phenyl-1,4-benzodioxanes.15
oxalate salts) of mephendioxan (2) are shown in Figure
1. They show a short-wavelength maximum at ca. 229
nm, [θ] ≈ 20 000 and two nearly overlapping long-
wavelength maxima at ca. 275.5 and 281 nm, [θ] ≈ 3000,
of opposite sign from the short-wavelength transition.
The (-)-enantiomer of 2 showed negative Cotton effects
in the 275-281 nm region and a positive transition in
the 229 nm region. The (+)-enantiomer of 2 displayed
a CD spectrum which was the mirror image of that of
the other enantiomer, suggesting that the two enanti-
omers have similar optical purity (>98%). The (-)-
enantiomer of 2 and 515 have almost identical CD
spectra, which suggests that the (-)-enantiomer of 2 has
the same absolute configuration (2S,3S) of the reference
compound 5. It derives that (+)-2 has a 2R,3R config-
uration. Since the two enantiomers of 2 showed high
enantiomeric purity, it reasonably follows that, unless
there was an unlike complete inversion of configuration
in the course of reactions outlined in Scheme 1, (-)-3
and (+)-3 have a 2S,3R and 2R,3S configuration,
respectively, and, consequently, (+)-4 and (-)-4 have a
2S,3R and 2R,3S configuration, respectively.
Ch em istr y
1
All the compounds were characterized by H NMR,
IR, and elemental analyses. Efforts to resolve racemic
2 by fractional crystallization of the dibenzoyl l-tartrate
and d-tartrate salts were unsuccessful. Therefore, acid
(()-312 was resolved with (R)-(+)- and (S)-(-)-R-meth-
ylbenzylamine. The two enantiomeric salts were con-
verted into the free acids (-)-3 and (+)-3, followed by
amidation with 2-(2,6-dimethoxyphenoxy)ethylamine.16
Intermediate amides (+)-4 and (-)-4 were reduced with
borane-methyl sulfide complex to (+)-2 and (-)-2
(Scheme 1). Enantiomeric purity, determined by 1H
NMR spectroscopy in comparison to the spectrum of
racemic 2 and on addition of the chiral shift reagent (R)-
(+)-R-methoxy-R-(trifluoromethyl)phenylacetic acid [(+)-
MTPA],17 was found to be >98% (detection limit) for
both enantiomers. The spectrum of racemic 2 (as the
free base) in the presence of (+)-MTPA showed a double
singlet signal at δ 3.82 ppm for the methoxy protons of
the 2,6-methoxyphenoxy group whereas only a singlet
Biology
F u n ction a l Stu d ies. The pharmacological profile of
the enantiomers of 2 was evaluated at R1- and R2-
adrenoreceptors on isolated rat vas deferens tissues. To
allow comparison of the results, we used the same
techniques and statistical evaluation of the bioassays

Synthesis of Enantiomers of Mephendioxan
J ournal of Medicinal Chemistry, 1996, Vol. 39, No. 11 2255
as for other 1,4-benzodioxan-related compounds.12 WB
4101 (1) was used as the standard compound. R1-
Adrenoreceptor blocking activity was assessed by an-
tagonism of (-)-norepinephrine-induced contractions of
the epididymal portion, while R2-adrenoreceptor block-
ing activity was determined by antagonism of the
clonidine-induced depression of the twitch responses of
the field-stimulated prostatic portion of rat vas deferens.
The potencies of the drugs were expressed as pA2
values,18,19 or, in the case of compounds with low
potency, as -log KB values.20
Ta ble 1. R1- and R2-Adrenoreceptor pA2 Values in the Isolated
Rat Vas Deferensa
c
R1 pA2 against
norepinephrine
R2 -logKB
against clonidine
R1/R2
no.b
selectivity ratio
1
2
9.13 ( 0.05
8.67 ( 0.02
7.59 ( 0.10
8.92 ( 0.09
6.29 ( 0.07d
692
>4700
>390
<5e
<5e
<5e
(+)-2
(-)-2
>8300
a
pA2 and -log KB values, plus or minus standard error of
estimate, were calculated according to Arunlakshana and Schild18,19
and van Rossum,20 respectively. With the exception of 1 that was
b
a hydrochloride salt, all other compounds were oxalates. c The R1/
R2 selectivity ratio is the antilog of the difference between pA2 and
Bin d in g Exp er im en ts. Receptor subtype selectivity
of the enantiomers of 2 was further determined by
employing receptor binding assays. [3H]Prazosin was
used to label R1-adrenoreceptors binding sites of rat
d
-log KB values at R1- and R2-adrenoreceptors, respectively. Cal-
culated at only one concentration (10 µM). e Inactive up to 10 µM.
cerebral cortex homogenates as well as R1A- and R1B
-
enantiomers of 1.13 Thus a 2S,3S configuration as-
signed to (-)-2 is consistent with a 2S configuration for
the most active enantiomer of 1 as one would expect if
related compounds act on the same receptor site.
adrenoreceptor subtypes of CEC pretreated rat hippo-
campus and liver membranes. In addition, competition
assays were performed using [3H]prazosin, and mem-
branes were prepared from COS-7 cells expressing
bovine R1a-, hamster R1b-, or rat R1d-adrenoreceptor
subtypes. Finally, [3H]rauwolscine, [3H]-8-OH-DPAT,
and [3H]spiperone were used to label R2-adrenoreceptors
in rat cerebral cortex, 5-HT1A receptors in rat hippo-
campus, and D2 receptors in rat striatum, respectively.
Binding affinities were expressed as pKi values derived
using the Cheng-Prusoff equation.21 WB 4101 (1),
5-methylurapidil, and (+)-niguldipine were used as the
reference compounds.
An analysis of the binding affinities at native and
cloned R1-adrenoreceptor subtypes reveals that (-)-2 is
36-fold selective for R1A- versus R1B-adrenoreceptors.
Comparable results were obtained for 5-methylurapidil
and (+)-niguldipine that exhibited selectivities of 47-
and 60-fold, respectively. Compound (-)-2 bound to
cloned R1-adrenoreceptors with pKi values of 9.46 (R1a),
7.68 (R1b), and 8.18 (R1d) and exhibited selectivities of
60- and 20-fold in binding to the R1a-adrenoreceptors
relative to R1b- and R1d-adrenoreceptors, respectively. In
parallel experiments, 5-methylurapidil and (+)-nigul-
dipine displayed selectivities of 520- and 66-fold, re-
spectively, for the R1a-adrenoreceptor relative to the R1b
subtype, and selectivities of 87- and 210-fold, respec-
tively, for the R1a versus the R1d subtype. Clearly, the
enantiomer (-)-2 has an affinity profile at both native
and cloned R1-adrenoreceptor subtypes qualitatively
similar to that of 5-methylurapidil and (+)-niguldipine
which are classified as R1A-adrenoreceptor selective
antagonists. However, 5-methylurapidil and (+)-nigul-
dipine have also additional biological properties such
as high affinity for 5-HT1A receptors and potent calcium
channel blocking activity, respectively, which limit their
utility as pharmacological tools in receptor characteriza-
tion. Interestingly, (-)-mephendioxan [(-)-2] was also
12000-, 2500-, and 250-fold selective in binding to R1a-
adrenoreceptors relative to R2-adrenoreceptors and
5-HT1A and D2 receptors, respectively. On these bases,
(-)-2 can be considered as a lead R1A-selective antago-
nist having a similar profile but a structure very
different from the recently reported analogue of (+)-
niguldipine.24
Resu lts a n d Discu ssion
The characterization of R1-adrenoreceptor subtypes
has been difficult due to the lack of selective ligands.
Availability of R1-adrenoreceptor selective antagonists
is of paramount importance not only for receptor
characterization and classification but also for potential
therapeutic implications such as the treatment of benign
prostatic hyperplasia, cardiac arrhythmia and hyper-
tension.22 However, the design of receptor subtype
selective ligands is inherently difficult and remains a
formidable challenge to medicinal chemists due to the
high homology among receptors. For example, R-
adrenoreceptor subtypes share about 45% identity with
serotoninergic and dopaminergic receptors.23 As a
consequence, R1-adrenoreceptor antagonists which are
currently classified as subtype selective have also
significant affinity for other receptor systems. WB 4101
(1) is selective for R1A-adrenoreceptors versus R1B- and
R1d-adrenoreceptors but have also high affinity for R2-
adrenoreceptors and 5-HT1A receptors.
We have already demonstrated that the insertion of
a 3-substituent in 1 affording mephendioxan (2) and
related compounds decreases significantly the functional
affinity for R2-adrenoreceptors.12 This finding has been
confirmed by present investigation in both functional
and binding assays (Tables 1 and 2). Furthermore, in
comparison to 1, compound 2 has 100-fold lower affinity
for the 5-HT1A receptor.
In conclusion, the present investigation has demon-
strated that the insertion of a trans aryl substituent at
the 3-position of 1 affording 2 increases affinity and
selectivity for R1A-adrenoreceptors while significantly
decreasing the affinity for R2-adrenoreceptors and 5-HT1A
and D2 receptors in comparison to the prototype 1.
Furthermore, it has been shown that the affinity and
selectivity reside predominantly in the enantiomer (-)-
mephendioxan [(-)-2] which may represent not only a
valuable tool for the characterization of R1-adreno-
receptor subtypes but also a lead compound for the
development of selective R1A-adrenoreceptor antagonists
for the treatment of benign prostatic hypertrophy.22
The affinity profile of (+)-2 and (-)-2 is shown in
Tables 1 and 2. Clearly, (-)-mephendioxan [(-)-2] was
10-30-fold more potent than the other enantiomer
toward R1-adrenoreceptor subtypes in both functional
and binding assays. The observed stereoselectivity of
the enantiomers of 2 is similar to that reported for the

2256 J ournal of Medicinal Chemistry, 1996, Vol. 39, No. 11
Quaglia et al.
Ta ble 2. Affinity Constants (Ki) of the Enantiomers of Mephendioxan (2) for Native and Cloned R1-Adrenoreceptor Subtypes, Native
R2-Adrenoreceptor, and 5-HT1A and D2-Receptors in Comparison to Reference Compoundsa
Ki (nM), native receptors (rat)
Ki (nM), cloned receptors
hippocampus
+ 10 µM
CEC, R1A
hamster
smooth
muscle, R1b rat brain, R1d
cerebral
cortex, R1
cerebral
cortex, R2
hippocampus,
5-HT1A
bovine
striatum, D2 brain, R1a
no.
liver, R1B
1
8.72 ( 2.02 1.29 ( 0.39
25.64 ( 4.86 14.72 ( 1.16 7.26 ( 2.40
122.8( 25.7
102.9 ( 8.1 3501 ( 874 606.2 ( 52.1 82.34 ( 8.65 0.91 ( 0.21 51.38 ( 4.31 11.76 ( 2.43
(+)-2 121.2 ( 10.4 40.33 ( 4.11 774.3 ( 77.6 2142 ( 667 1262 ( 372 827.3 ( 5.2 8.34 ( 3.12 195.2 ( 36.4 191.1 ( 50.9
0.62 ( 0.16 57.34 ( 14.25 6.26 ( 1.18
(()-2 17.03 ( 2.45 5.32 ( 0.67
(-)-2 9.97 ( 0.92 1.76 ( 0.53
METb 28.25 ( 3.84 4.66 ( 1.82
NIGc 27.80 ( 7.40 6.38 ( 1.29
62.61 ( 2.38 4293 ( 1502 888.9 ( 379.0 86.48 ( 11.01 0.35 ( 0.18 21.08 ( 3.20 6.57 ( 0.87
220.2 ( 20.3 432.4 ( 65.1 1.20 ( 0.37
379.9 ( 41.0 1611 ( 235 > 10000
935.1 ( 115.6 2.02 ( 0.53 1058 ( 183
175.1 ( 21.3
294.9 ( 56.6 0.38 ( 0.06 25.01 ( 1.67 82.41 ( 11.95
a
Values are the mean ( SE of at least three separate experiments performed in triplicate. The pseudo-Hill coefficients (nH) were not
significantly different from unity (p > 0.05) with the exception of rat cerebral cortex, where a heterogeneous R1-adrenoreceptor population
is present. Equilibrium dissociation constants (Ki) were derived using the Cheng-Prusoff equation.21 Scatchard plots were linear or
almost linear in all preparation tested. The affinity estimates were derived from displacement of [3H]prazosin from R1-adrenoreceptors,
[3H]rauwolscine from R2-adrenoreceptors, [3H]spiperone from D2 receptors, and [3H]-8-hydroxy-2-(di-n-propylamino)tetraline from 5-HT1A
b
receptors. MET, 5-methylurapidil. c NIG, (+)-niguldipine.
[(+)-4]. Ethyl chlorocarbonate (0.34 g, 3.03 mmol) was added
dropwise to a stirred and cooled (0 °C) solution of (-)-3 (0.82
g, 3.03 mmol) and Et3N (0.31 g, 3.03 mmol) in chloroform (20
mL), followed after 30 min by the addition of a solution of
2-(2,6-dimethoxyphenoxy)ethylamine16 (0.59 g, 3.03 mmol) in
chloroform (10 mL). The resulting reaction mixture was
stirred overnight at room temperature and then washed with
2 N HCl, 2 N NaOH, and finally with water. Removal of dried
solvent gave a solid which was purified by column chroma-
tography. Eluting with petroleum ether-EtOAc (75:25) af-
forded (+)-4: 1.0 g (74% yield); mp 120-122 °C; [R]D +3.81°
(c 1, MeOH); 1H NMR (CDCl3) δ 2.32 (s, 3, CH3C6H4), 3.50 (m,
2, NCH2), 3.85 (s, 6, OCH3), 4.02 (t, 2, CH2O), 4.58 (d, J ) 6.7
Hz, 1, 2-H), 5.07 (d, J ) 6.7 Hz, 1, 3-H), 6.58-7.25 (m, 11,
ArH), 7.52 (br t, 1, NH exchangeable with D2O).
Exp er im en ta l Section
Ch em istr y. Melting points were taken in glass capillary
tubes on a Bu¨chi SMP-20 apparatus and are uncorrected. IR
1
and H NMR spectra were recorded on Perkin-Elmer 297 and
Varian VXR 300 instruments, respectively. Chemical shifts
are reported in parts per million (ppm) relative to tetrameth-
ylsilane (TMS), and spin multiplicities are given as s (singlet),
d (doublet), t (triplet), or m (multiplet). Although the IR
spectra data are not included (because of the lack of unusual
features), they were obtained for all compounds reported and
were consistent with the assigned structures. Optical activity
was measured at 20 °C with a Perkin-Elmer 241 polarimeter.
Circular dichroism (CD) spectra were measured at room
temperature with a J ASCO J 710 spectropolarimeter using a
0.1 cm path length cell. Data were handled with a mathematic
noise reduction routine (J ASCO software). The elemental
compositions of the compounds agreed to within (0.4% of the
calculated value. When the elemental analysis is not included,
crude compounds were used in the next step without further
purification. Chromatographic separations were performed on
silica gel columns (Kieselgel 40, 0.040-0.063 mm, Merck) by
flash chromatography. Petroleum ether refers to the fraction
with a boiling point of 40-60 °C. The term “dried” refers to
the use of anhydrous sodium sulfate.
(2R,3S)-(-)-3-p -Tolyl-2,3-d ih yd r o-1,4-b en zod ioxin -2-
ca r boxylic Acid [2-(2,6-Dim eth oxyp h en oxy)eth yl]a m id e
[(-)-4]. This was obtained from (+)-3 following the procedure
described for the enantiomer (+)-4 and purified by column
chromatography: 1.1 g (81% yield); mp 120-122 °C; [R]D
1
-3.96° (c 1, MeOH). The H NMR spectrum was identical to
that of (+)-4.
(2R,3R)-(+)-[2-(2,6-Dim eth oxyph en oxy)eth yl][(3-p-tolyl-
2,3-d ih yd r o-1,4-ben zod ioxin -2-yl)m eth yl]a m in e Oxa la te
Em ih yd r a te [(+)-2]. A solution of 10 M BH3‚CH3SCH3 (0.2
mL) in dry diglyme (1 mL) was added dropwise at room
temperature to a solution of (+)-4 (1.0 g, 2.2 mmol) in dry
diglyme (40 mL) with stirring under a stream of dry nitrogen
with exclusion of moisture. When the addition was completed,
the reaction mixture was heated at 120 °C for 12 h. After
cooling at 0 °C, excess borane was destroyed by cautious
dropwise addition of MeOH (5 mL). The resulting mixture was
left to stand for 5 h at room temperature, treated with HCl
gas for 10 min, and then heated at 120 °C for 4 h. Removal of
the solvent under reduced pressure gave a residue which was
dissolved in water. The aqueous solution was basified with
NaOH pellets and extracted with chloroform (4 × 30 mL).
Removal of dried solvent gave a residue which was purified
by column chromatography. Eluting with CHCl3-EtOAc (95:
5) afforded (+)-2 as the free base: 1H NMR (CDCl3) δ 2.25 (br
s, 1, NH, exchangeable with D2O), 2.38 (s, 3, CH3C6H4), 2.70-
2.84 (m, 4, CH2NCH2), 3.85 (s, 6, OCH3), 4.10 (t, 2, CH2O),
4.20 (m, 1, 2-H), 4.96 (d, J ) 7.91 Hz, 1, 3-H), 6.56-7.35 (m,
11, ArH); enantiomeric purity > 98% (detection limit), deter-
mined with (+)-MTPA as the chiral shift reagent.
(+)-2 free base was transformed into the oxalate salt by
treating an ether solution with oxalic acid. It was recrystal-
lized from 2-PrOH: 0.64 g (55% yield); [R]D +22.04° (c 1,
MeOH), CD (c 0.015, MeOH) [θ]281 +3369, [θ]275.5 +3768, [θ]229
-20140. The melting point was indefinite; fusion started at
147 °C and was complete at 157-158 °C. Anal. (C26H29NO5‚
H2C2O4‚0.5H2O) C, H, N.
(2S,3S)-(-)-[2-(2,6-Dim eth oxyph en oxy)eth yl][(3-p-tolyl-
2,3-d ih yd r o-1,4-ben zod ioxin -2-yl)m eth yl]a m in e Oxa la te
Hyd r a te [(-)-2]. This was obtained as free base from (-)-4
Resolu tion of (()-tr a n s-3-p-Tolyl-2,3-d ih yd r o-1,4-ben -
zod ioxin -2-ca r boxylic Acid (3). Racemic 312 (4.1 g, 15.0
mmol) in 95% EtOH (65 mL) was treated with a solution of
(S)-(-)-R-methylbenzylamine (1.82 g, 15.0 mmol) in 95% EtOH
(77 mL) and left at room temperature for 30 h. The white
crystals were crystallized twice from 95% EtOH: 1.4 g; mp
223.5-225.5 °C; [R]D -4.71° (c 1, MeOH).
The salt was dissolved in water (50 mL), and the ice-cooled
solution was made basic with 2 N NaOH (50 mL). The
resulting mixture was extracted with ether (3 × 30 mL) to
recover the amine and then acidified with cold 2 N HCl and
extracted with CHCl3 (3 × 30 mL). Removal of dried solvent
gave (2S,3R)-(-)-3-p-tolyl-2,3-dihydro-1,4-benzodioxin-2-car-
boxylic acid [(-)-3]: 0.85 g; mp 169-172 °C; [R]D -1.81° (c 1,
1
MeOH); H NMR (CDCl3) δ 2.37 (s, 3, CH3C6H4), 4.81 (d, J )
6.0 Hz, 1, 2-H), 5.24 (d, J ) 6.0 Hz, 1, 3-H), 6.82-7.30 (m, 8,
ArH), 8.50 (br s, 1, COOH). Anal. (C16H14O4) C, H.
The acid recovered from the mother liquors by a similar
alkaline treatment (3.25 g, 12.0 mmol) was dissolved in 95%
EtOH (39 mL) and treated with a solution of (R)-(+)-R-
methylbenzylamine (1.5 g, 12.0 mmol) in 95% EtOH (55 mL).
The solution was left at room temperature for 30 h and the
white crystals were crystallized twice from 95% EtOH: 1.1 g;
mp 223.5-224.5 °C; [R]D +5.48° (c 1, MeOH).
This salt was treated as described for the other enantiomer
to give (2R,3S)-(+)-3-p-tolyl-2,3-dihydro-1,4-benzodioxin-2-car-
boxylic acid [(+)-3]: 0.7 g; mp 169-172 °C; [R]D +1.64° (c 1,
1
MeOH); the H NMR spectrum was identical to that of (-)-3.
Anal. (C16H14O4) C, H.
(2S,3R)-(+)-3-p -Tolyl-2,3-d ih yd r o-1,4-b en zod ioxin -2-
ca r boxylic Acid [2-(2,6-Dim eth oxyp h en oxy)eth yl]a m id e

Synthesis of Enantiomers of Mephendioxan
J ournal of Medicinal Chemistry, 1996, Vol. 39, No. 11 2257
as described for the enantiomer (+)-2 and purified by column
Ack n ow led gm en t. This work was supported by a
grant from MURST. We express our thanks to Prof. G.
P. Spada (University of Bologna) for performing CD
measurements and for valuable discussions.
1
chromatography. The H NMR spectrum exhibited the same
resonances as that of the other enantiomer; enantiomeric
purity was >98% (detection limit), determined with (+)-MTPA
as the chiral shift reagent.
(-)-2 free base was transformed into the oxalate salt by
treating an ether solution with oxalic acid. It was recrystal-
lized from 2-PrOH: 0.76 g (60% yield); [R]D -23.23° (c 1,
MeOH), CD (c 0.015, MeOH) [θ]281 -3173, [θ]275.5 -3566, [θ]229
+21000. The mp was indefinite; fusion started at 96 °C and
was complete at 154-155 °C. Anal. (C26H29NO5‚H2C2O4‚H2O)
C, H, N.
Refer en ces
(1) Bylund, D. B.; Eikenberg, D. C.; Hieble, J . P.; Langer, S. Z.;
Lefkowitz, R. J .; Minneman, K. P.; Molinoff, P. B.; Ruffolo, R.
R., J r.; Trendelenburg, U. IV. International Union of Pharmacol-
ogy Nomenclature of Adrenoceptors. Pharmacol. Rev. 1994, 46,
121-136.
Biology. F u n ction a l An ta gon ism in Isola ted Ra t Va s
Defer en s. Male albino rats (175-200 g) were killed by a
sharp blow on the head, and both vasa deferentia were
isolated, freed from adhering connective tissue, and trans-
versely bisected. Functional experiments at R1- and R2-
adrenoreceptors were carried out in the epididymal and
prostatic portions of the vas deferens using (-)-norepinephrine
and clonidine as the agonists, respectively, as previously
described.12
(2) (a) Ko, F.-N.; Guh, J .-H.; Yu, S.-M.; Hou, Y.-S.; Wu, Y.-C.; Teng,
C.-M. (-)-Discretamine, a Selective R1D-Adrenoceptor Antagonist
Isolated from Fissistigma Glauceseens. Br. J . Pharmacol. 1994,
112, 1174-1180. (b) Goetz, A. S.; King, H. K.; Ward, S. D. C.;
True, T. A.; Rimele, T. J .; Saussy, D. L., J r. BMY 7378 Is a
Selective Antagonist of the D Subtype of R1-Adrenoceptors. Eur.
J . Pharmacol. 1995, 272, R5-R6. (c) Testa, R.; Destefani, C.;
Guarneri, L.; Poggesi, E.; Simonazzi, I.; Taddei, C.; Leonardi,
A. The R1d-Adrenoceptor Subtype Is Involved in the Noradrena-
line-Induced Contractions of Rat Aorta. Life Sci. 1995, 57, PL
159-163.
(3) Cotecchia, S.; Schwinn, D. A.; Randall, R. R.; Lefkowitz, R. J .;
Caron, M. G.; Kobilka, B. K. Molecular Cloning and Expression
of the cDNA for the Hamster R1-Adrenergic Receptor. Proc. Natl.
Acad. Sci. U.S.A. 1988, 85, 7159-7163.
(4) Schwinn, D. A.; Lomasney, J . W.; Lorenz, W.; Szklut, P. J .;
Fremeau, R. T.; Yang-Feng, T. L.; Caron, M. G.; Lefkowitz, R.
J .; Cotecchia, S. Molecular Cloning and Expression of the cDNA
for a Novel R1-Adrenergic Receptor Subtype. J . Biol. Chem. 1990,
265, 8183-8189.
(5) Lomasney, J . W.; Cotecchia, S.; Lorenz, W.; Leung, W. Y.;
Schwinn, D. A.; Yang-Feng, T. L.; Brownstein, M.; Lefkowitz,
R. J .; Caron, M. G. Molecular Cloning and Expression of the
cDNA for the R1A-Adrenergic Receptor, the Gene for Which Is
Located on Human Chromosome 5. J . Biol. Chem. 1991, 266,
6365-6369.
(6) (a) Ford, A. P. D. W.; Williams, T. J .; Blue, D. D.; Clarke, D. E.
R1-Adrenoceptor Classification: Sharpening Occam's Razor.
Trends Pharmacol. Sci. 1994, 15, 167-170. (b) Hieble, J . P.;
Bylund, D. B.; Clarke, D. E.; Eikenburg, D. C.; Langer, S. Z.;
Lefkowitz, R. J .; Minneman, K. P.; Ruffolo, R. R. International
Union of Pharmacology X. Recommendation for Nomenclature
of R1-Adrenoceptors: Consensus Update. Pharmacol. Rev. 1995,
47, 267-270.
(7) Faure, C.; Pimoule, C.; Arbilla, S.; Langer, S. Z.; Graham, D.
Expression of R1-Adrenoceptor Subtypes in Rat Tissues: Impli-
cations for R1-Adrenoceptor Classification. Eur. J . Pharmacol.
Mol. Pharmacol. Sect. 1994, 268, 141-149.
(8) Melchiorre, C.; Giardina`, D.; Gallucci, P.; Brasili, L. Structural
Requirements for Competitive R-Adrenoreceptor Occupancy by
Cyclic and Open Analogues of WB 4101. J . Pharm. Pharmacol.
1982, 34, 683-644.
Ra d ioliga n d Bin d in g Assa ys. Male rats (200-300 g,
Charles River, Italy) were killed, and their hippocampus,
striatum, cerebral cortex, and liver were dissected, frozen on
dry ice, and then stored at -70 °C until used.
Na tive Recep tor s. Binding studies at R1- and R2-adreno-
ceptors and 5-HT1A and D2 receptors were carried out in rat
cerebral cortex (R1 and R2), hippocampus (5-HT1A), and stria-
tum (D2) membranes as previously described.25 The respective
radioligands were [3H]prazosin (specific activity 79.2 Ci/mmol),
[3H]rauwolscine (specific activity 80.5 Ci/mmol), [3H]-8-hy-
droxy-2-(di-n-propylamino)tetraline (8-OH-DPAT) (specific ac-
tivity 162.9 Ci/mmol), and [3H]spiperone (specific activity 17.7
Ci/mmol). CEC pretreated rat hippocampus and liver mem-
branes were used to determine [3H]prazosin binding to native
R
1A- and R1B-adrenoceptor subtypes, respectively, as previously
described.26
Clon ed Recep tor s. [3H]Prazosin binding to cloned R1-
adrenoceptor subtypes was performed in COS-7 cells express-
ing transiently bovine R1a- (previously named R1c), hamster
R1b-, and rat R1d-adrenoceptors. Construction and transfection
of individual R1-adrenoceptor subtypes were carried out by Dr.
S. Cotecchia (Universite´ de Lausanne, Switzerland) as previ-
ously described.3-5 COS-7 cell membranes (35-70 µg of
proteins) were incubated in 50 mM Tris-HCl, pH 7.4, contain-
ing 10 µM pargyline and 0.1% ascorbic acid, with 0.3-0.6 nM
[3H]prazosin, in the absence or presence of the displacing drug,
in
a final volume of 0.22 mL. Nonspecific binding was
(9) Melchiorre, C.; Brasili, L.; Giardina`, D.; Pigini, M.; Strappa-
ghetti, G. 2-[[[2-(2,6-Dimethoxyphenoxy)ethyl]amino]methyl]-
1,4-benzoxathian: a New Antagonist with High Potency and
Selectivity Toward R1-Adrenoreceptors. J . Med. Chem. 1984, 27,
1535-1536.
(10) Pigini, M.; Brasili, L.; Giannella, M.; Giardina`, D.; Gulini, U.;
Quaglia, W.; Melchiorre, C. Structure-Activity Relationships in
1,4-Benzodioxan-Related Compounds. Investigation on the Role
of the Dehydrodioxane-Ring on R1-Adrenoreceptor Blocking
Activity. J . Med. Chem. 1988, 31, 2300-2304.
determined in presence of 100 µM phentolamine. The reaction
mixture was incubated for 30 min at 25 °C and then stopped
by addition of ice cold Tris-HCl buffer and rapid filtration
through Whatman GF/B filters.
Da ta An a lysis. The dissociation constants (pA2 values,
Table 1) were determined by Schild plots18 obtained from the
dose ratios at the EC50 values of the agonists calculated at
three antagonist concentrations. Each concentration was
tested five times, and Schild plots were constrained to slope
-1.19 The compounds were tested at only one concentration
when determining R2-adrenoreceptor blocking activity because
of their low affinity for this receptor. In these cases, pA2 (-log
KB) values were calculated according to van Rossum.20 Data
are presented as the mean ( SE of n experiments. Differences
between mean values were tested for significance by student’s
t-test.
(11) Quaglia, W.; Pigini, M.; Giannella, M.; Melchiorre, C. 3-Phenyl
Analogues of 2-[[[2-(2,6-Dimethoxyphenoxy)ethyl]amino]methyl]-
1,4-benzodioxan (WB 4101) as Highly Selective R1-Adrenorecep-
tor Antagonists. J . Med. Chem. 1990, 33, 2946-2948.
(12) Quaglia, W.; Pigini, M.; Tayebati, S. K.; Piergentili, A.; Giannella,
M.; Marucci, G.; Melchiorre, C. Structure-Activity Relationships
in 1,4-Benzodioxan-Related Compounds. 4. Effect of Aryl and
Alkyl Substituents at Position 3 on R-Adrenoreceptor Blocking
Activity. J . Med. Chem. 1993, 36, 1520-1528.
(13) Nelson, W. L.; Powell, M. L.; Dyer, D. C. Absolute Configuration
of Glycerol Derivatives. 7. Enantiomers of 2-[[[2-(2,6-Dimethoxy-
Binding data were analyzed using a nonlinear curve-fitting
program Allfit.27 Scatchard plots were linear or almost linear
in all preparations. All pseudo-Hill coefficients (nH) were not
significantly different from unity (p > 0.05). Equilibrium
dissociation constants (Ki) were derived from the Cheng-
Prusoff equation,21 Ki ) IC50/(1 + L/Kd), where L and Kd are
the concentration and the equilibrium dissociation constant
of the radioligand, respectively. pKi values (Table 2) are the
mean ( SE of three separate experiments performed in
triplicate.
phenoxy)ethyl]amino]methyl]-1,4-benzodioxane (WB-4101),
a
Potent Competitive R-Adrenergic Antagonist. J . Med. Chem.
1979, 22, 1125-1127.
(14) Andrisano, V.; Marucci, G.; Melchiorre, C.; Tumiatti, V. Stereo-
selectivity at R-Adrenoreceptor Subtypes: Observations With the
Enantiomers of WB 4101 Separated Through Their Amides of
N-Tosyl-(S)-proline. Chirality 1992, 4, 16-20.
(15) Arnoldi, A.; Merlini, L. Asymmetric Synthesis of 3-Methyl-2-
phenyl-1,4-benzodioxanes. Absolute Configuration of the Neo-
lignans Eusiderin and Eusiderin C and D. J . Chem. Soc., Perkin
Trans. 1 1985, 2555-2557.

2258 J ournal of Medicinal Chemistry, 1996, Vol. 39, No. 11
Quaglia et al.
(16) Woolley, D. W. Probable Evolutionary Relations of Serotonin and
Indole-Acetic Acid, and Some Practical Consequences Therefrom.
Nature (London) 1957, 180, 630-633.
(17) Villani, F. J ., J r.; Costanzo, M. J .; Inners, R. R.; Mutter, M. S.;
McClure, D. E. Determination of Enantiomeric Purity of Tertiary
Amines by Proton NMR of R-Methoxy-R-(trifluoromethyl)phenyl
Acetic Complexes. J . Org. Chem. 1986, 51, 3715-3718.
(18) Arunlakshana, O.; Schild, H. O. Some Quantitative Uses of Drug
Antagonists. Br. J . Pharmacol. 1959, 14, 48-58.
(19) Tallarida, R. J .; Cowan, A.; Adler M. W. pA2 and Receptor
Differentiation: a Statistical Analysis of Competitive Antago-
nism. Life Sci. 1979, 25, 637-654.
(20) Van Rossum, J . M. Cumulative Dose-response Curves. II.
Technique for the Making of Dose-response Curves in Isolated
Organs and the Evaluation of Drug Parameters. Arch. Int.
Pharmacodyn. 1963, 143, 299-330.
(21) Cheng, Y. C.; Prusoff, W. H. Relationship Between the Inhibition
Constant (Ki) and the Concentration of Inhibitor Which Causes
50% Inhibition (I50) of an Enzymatic Reaction. Biochem. Phar-
macol. 1973, 22, 3099-3108.
(22) Ruffolo, R. R., J r.; Bondinell, W.; Hieble, J . P. R- and â-Adreno-
ceptors. From the Gene to the Clinic. 2. Structure-Activity
Relationships and Therapeutic Applications. J . Med. Chem.
1995, 38, 3681-3716.
(23) Trumpp-Kallmeyer, S.; Hoflack, J .; Bruinvels, A.; Hibert, M.
Modeling of G-Protein-Coupled Receptors: Application to Dopam-
ine, Acetylcholine, and Mammalian Opsin Receptors. J . Med.
Chem. 1992, 35, 3448-3462.
(24) Wetzel, J . M.; Miao, S. W.; Forray, C.; Borden, L. A.; Branchek,
T. A.; Gluchowski, C. Discovery of R1a-Adrenergic Receptor
Antagonists Based on the L-Type Ca2+ Channel Antagonist
Niguldipine. J . Med. Chem. 1995, 38, 1579-1581.
(25) Foreman, M. M.; Fuller, R. W.; Rasmussen, K; Nelson, D. L.;
Calligaro, D. O.; Zhang, L.; Barret, J . E.; Booher, R. N.; Paget,
C. J ., J r.; Flaugh, M. E. Pharmacological Characterization of
LY293284: a 5-HT1A Receptor Agonist with High Potency and
Selectivity. J . Pharmacol. Exp. Ther. 1994, 270, 1270-1281.
(26) Testa, R.; Guarneri, L.; Ibba, M.; Strada, G.; Poggesi, E.; Taddei,
C.; Simonazzi, I.; Leonardi, A. Characterization of R1-Adreno-
ceptor Subtypes in Prostate and Prostatic Urethra of Rat, Rabbit,
Dog and Man. Eur. J . Pharmacol. 1994, 249, 307-315.
(27) De Lean, A.; Munson, P. J .; Rodbard, D. Simultaneous Analysis
of Families of Sigmoidal Curves: Application to Bioassay,
Radioligand Assay, and Physiological Dose-Response Curves.
Am. J . Physiol. 1978, 235, E97-E102.
J M960069A
