Stereocontrolled Synthesis of Highly Substituted Proline Esters via [3 + 2] Cycloaddition between N-Metalated Azomethine Ylides and Nitroalkenes. Origins of the Metal Effect on the Stereochemical Outcome

Article abstract of DOI:10.1021/jo971212q

The [3 + 2] cycloaddition reaction between several N-metalated azomethine ylides and nitroalkenes has been studied using AgOAc and LiClO₄ as metalating reagents in the presence of triethylamine. The reaction is found to be very versatile and can be extended to homochiral nitroalkenes. In general, lithium and silver salts promote preferential formation of the endo and exo cycloadducts, respectively. The presence of a phenol moiety induces a shift toward the exo-cycloadduct even when lithium is used. A model based upon the experimental results obtained and SCF-MO calculations is proposed to explain the variable stereochemical outcome of these reactions.

Full text of DOI:10.1021/jo971212q

J . Org. Chem. 1998, 63, 1795-1805
1795
Ster eocon tr olled Syn th esis of High ly Su bstitu ted P r olin e Ester s
via [3 + 2] Cycloa d d ition betw een N-Meta la ted Azom eth in e Ylid es
a n d Nitr oa lk en es. Or igin s of th e Meta l Effect on th e
Ster eoch em ica l Ou tcom e
Mirari Ayerbe, Ana Arrieta, and Fernando P. Coss´ıo*
Kimika Fakultatea, Euskal Herriko Unibertsitatea, P.K. 1072, San Sebastia´n-Donostia, Spain
Anthony Linden
Organisch-chemisches Insitut der Universita¨t Zurich,Winterthurestrasse 190,
CH-8057, Zurich, Switzerland
Received J uly 2, 1997 (Revised Manuscript Received J anuary 5, 1998 )
The [3 + 2] cycloaddition reaction between several N-metalated azomethine ylides and nitroalkenes
has been studied using AgOAc and LiClO4 as metalating reagents in the presence of triethylamine.
The reaction is found to be very versatile and can be extended to homochiral nitroalkenes. In
general, lithium and silver salts promote preferential formation of the endo and exo cycloadducts,
respectively. The presence of a phenol moiety induces a shift toward the exo-cycloadduct even
when lithium is used. A model based upon the experimental results obtained and SCF-MO
calculations is proposed to explain the variable stereochemical outcome of these reactions.
In tr od u ction
interesting feature of this reaction is that the stereocon-
trol observed is usually satisfactory. Thus, the reaction
between R,â-unsaturated carbonyl compounds and N-
metalated azomethine ylides derived from amino esters
and aldehydes yields endo-cycloadducts9 as the major
stereoisomers.10 However, To¨ke et al.11 have observed a
reversal of stereoselectivity in the 1,3-dipolar cycloaddi-
tion between several azomethine ylides and aryl nitro
olefins. These authors reported that lithium metalation
promotes the preferential formation of endo cycloadducts,
whereas the use of silver salts favors the formation of
exo-pyrrolidines as major stereoisomers.
The importance of substituted prolines1 in the design
of new catalysts2 or in the chemical synthesis of phar-
macologically3 or biologically interesting4 molecules is
well recognized. The [3 + 2] reaction of azomethine
ylides and alkenes is one of the most useful methods for
the preparation of these molecules in a convergent
manner.5 Among the different versions of this reaction,6
the interaction between N-metalated azomethine ylides
and π-defficient alkenes is specially promising, since, in
general, it allows the synthesis of proline nuclei under
mild conditions and with good chemical yields.7 In
addition, the reaction is very versatile and consequently
is well suited for combinatorial chemistry.8 Another
Within this context and in connection to our ongoing
research program on nitroalkene chemistry,12 we present
(8) (a) Murphy, M. M.; Schullek, J . R.; Gordon, E. M.; Gallop, M. A.
J . Am. Chem. Soc. 1995, 117, 7029. (b) Hamper, B. C.; Dukesherer, D.
R.; South, M. S. Tetrahedron Lett. 1996, 37, 3671. (c) Marx, M. A.;
Grillot, A.-L.; Louer, C. T.; Beaver, K. A.; Bartlett, P. A. J . Am. Chem.
Soc. 1997, 119, 6153.
(9) We denote the endo and exo stereoisomers as those in which the
electron-withdrawing group at C4 and the substituent at the C5
position are in a cis and trans relationship, respectively.
(1) (a) Pichon, M.; Figade`re, B. Tetrahedron: Asymmetry 1996, 7,
927. (b) Sharma, R.; Lubell, W. D. J . Org. Chem. 1996, 61, 202. (c)
Collado, I.; Ezquerra, J .; Pedregal, C. J . Org. Chem. 1995, 60, 5011.
(d) Mulzer, J .; Meier, A.; Buschmann, J .; Luger, P. Synthesis 1996,
123.
(2) (a) Catalytic Asymmetric Synthesis; Ojima, I. Ed.; VCH Publish-
ers: New York, 1993. (b) Noyori, R. Asymmetric Catalysis in Organic
Synthesis; Wiley: New York, 1994.
(3) See, for example: (a) Waid, P. P.; Flynn, G. A.; Huber, E. W.;
Sabol, J . S. Tetrahedron Lett. 1996, 37, 4091. (b) Khav, V. V.;
Martinelli, M. J . Tetrahedron Lett. 1996, 37, 4323. (c) Kolodziej, S. A.;
Nikiforovich, G. V.; Skeean, R.; Lignon, M.-F.; Martinez, J .; Marshall,
G. R. J . Med. Chem. 1995, 38, 137.
(4) See for example: (a) Fishwick, C. W. G.; Foster, R. J .; Carr, R.
E. Tetrahedron Lett. 1996, 37, 3915. (b) Bianco, A.; Maggini, M.;
Scorrano, G.; Toniolo, C.; Marconi, G.; Villani, C.; Prato, M. J . Am.
Chem. Soc. 1996, 118, 4072. (c) Hirschmann, R. Angew. Chem., Int.
Ed. Engl. 1991, 30, 1278. (d) Giannis, A.; Kolter, T. Angew. Chem.,
Int. Ed. Engl. 1993, 32, 1244.
(10) See for example: (a) Tsuge, O.; Kanemasa, S.; Yoshioka, M. J .
Org. Chem. 1988, 53, 1384. (b) Kanemasa, S.; Yoshiora, M.; Tsuge, O.
Bull. Chem. Soc. J pn. 1989, 62, 2196. (c) Grigg, R.; Kemp, J . J . Chem.
Soc. Chem. Commun. 1978, 2885. (d) Tsuge, O.; Kanemasa, S.; Ohe,
M.; Yorozu, K.; Takenaka, S.; Veno, K. Chem. Lett. 1986, 1271. (e)
Tsuge, O.; Kanemasa, S.; Ohe, M.; Yorozu, K.; Takenaka, S.; Veno, K.
Bull. Chem. Soc. J pn. 1987, 60, 4067.
(11) (a) Nyerges, M.; Bala´zs, L.; Bitter, I.; Ka´das, I.; Ko¨vesdi, I.;
To¨ke, L. Tetrahedron 1995, 51, 6783. (b) Nyerges, M.; Rudas, M.; To´th,
G.; Here´nyi, B.; Ka´das, I.; Bitter, I.; To¨ke, L. Tetrahedron 1995, 51,
13321. (c) Nyerges, M.; Bitter, I.; Ka´das, I.; To´th, G.; To¨ke, L.
Tetrahedron Lett. 1994, 35, 4413.
(5) (a) Huisgen, R. Angew. Chem. 1983, 2, 565. (b) Huisgen, R. J .
Org. Chem. 1976, 41, 403.
(6) (a) Grigg, R. Chem. Soc. Rev. 1987, 16, 89. (b) Lowin, J . W. In
1,3-Dipolar Cycloaddition Chemistry; Padwa, A., Ed.; J . Wiley &
Sons: New York, 1984; Vol. 1, pp 653-732. (c) Tsuge, O.; Kanemasa,
S. In Advances in Heterocyclic Chemistry; Katritzky, A. R., Ed.;
Academic Press: San Diego, 1989; Vol. 45, pp 232-349. (d) Vedejs, E.
In Advances in Cycloaddition; Curran, D. P., Ed.; J ai Press: Green-
wich, 1988; Vol. 1, pp 33-51.
(12) (a) Ayerbe, M.; Coss´ıo, F. P. Tetrahedron Lett. 1995, 36, 4447.
(b) Ayerbe, M.; Morao, I.; Arrieta, A.; Linden, A.; Cossı´o, F. P.
Tetrahedron Lett. 1996, 37, 2311.
(7) Kanemasa, S.; Tsuge, O. In Advances in Cycloaddition; Curran,
D. P., Ed.; J ai Press: Greenwich, 1993; Vol. 3, pp 99-159.
S0022-3263(97)01212-7 CCC: $15.00 © 1998 American Chemical Society
Published on Web 02/24/1998

1796 J . Org. Chem., Vol. 63, No. 6, 1998
Ayerbe et al.
Ch a r t 1
Sch em e 2a
Sch em e 1a
a
Only one enantiomer of the cycloadducts 4 is drawn.
1, entry 2). In contrast, the same reaction in the presence
of 0.15 equiv of LiClO4 yields 4b in a 30% yield with a
endo:exo ratio of 63:37. When 5 equiv of LiClO4 were
used, the cycloadduct was obtained in a 47% yield and
with higher stereocontrol (see Table 1, entry 2). This
effect is more pronounced with more substituted sub-
strates. Thus, when the 1c+2b f 4e transformation was
performed in the presence of 0.15 equiv of LiClO4, a
reaction time of 20 h was required to obtain a 56:44 endo/
exo mixture of cycloadducts 4e in a 30% yield. When the
same reaction was carried out with 5 equiv of LiClO4,
only 4 h were required to achieve a higher yield of 4e
(see Table 1, entry 5). Similar results were observed in
other cases. Therefore, we decided to use 5 equiv of this
salt in all cases, because of the lower reaction times
required to achieve acceptable yields and/or the higher
stereocontrol observed.
a
The substituents at the different positions are not specified.
herein our results on the reaction between nitro olefins
and azomethines. We have extended the reaction to
highly substituted azomethine ylides and nitroalkenes,
and we provide an explanation to the metal dependence
of the stereochemical outcome of this important reaction.
Resu lts a n d Discu ssion
To obtain structurally diverse cycloadducts, imines
1a -g and nitroalkenes 2a -d were selected (see Chart
1). In particular, compounds 1b-f were studied because
of the potential of the corresponding cycloadducts as
tridentate ligands.2 Nitroalkene 2d was also selected in
order to study the synthetic potential of the reaction
when homochiral nitroalkenes are used as dipolarophiles.
Lithium and silver azomethine ylides (see Scheme 2)
derived from imines 1a -g were generated from LiClO4
and AgOAc, respectively, in the presence of triethylamine
as base and acetonitrile as solvent. LiClO4 has not been
previously described as a source of N-lithiated azo-
methines. These reactive intermediates are usually
generated by means of either the LiBr/NEt3 or the LDA/
NEt3 systems.7 We have observed that LiClO4 usually
leads to cleaner crude reaction mixtures with respect to
the above-mentioned lithium salts. The results obtained
are collected in Table 1. We have found that when
AgAcO is used to promote the formation of azomethine
ylides, the reaction takes place faster than when forma-
tion of the dipoles is assisted by LiClO4. For example,
reaction between 1a and 2b in the presence of 0.15 equiv
of AgOAc yields a mixture of endo- and exo-4b after 3 h
of reaction at room temperature in a 69% yield (see Table
We have observed a preferential formation of the exo-
cycloadduct when a silver azomethine ylide possessing a
noncoordinating aromatic substituent reacts with an
aromatic nitroalkene. In the case of the corresponding
lithium azomethine, the endo-stereoisomer is formed
preferentially under similar conditions. For instance,
exo-4a is the major product in the reaction between 1a
and 2a in the presence of AgOAc, whereas endo-4a is
preferentially formed when LiClO4 is used (see Table 1,
entry 1). Similar results were obtained in the reaction
between 1a and 2b (entry 2). When the same experi-
ments were repeated using N,N-diisopropylethylamine
as base instead of triethylamine, the same stereochemical
outcome was observed. These results are in agreement
with the observations of To¨ke et al.11 for structurally
related compounds.
We have found that the above-mentioned trend can be
modified when azomethines incorporating certain groups
at the aromatic moiety are used. Thus, when imine 1b
derived from salicylaldehyde and glycine was allowed to

Synthesis of Highly Substituted Proline Esters
J . Org. Chem., Vol. 63, No. 6, 1998 1797
Ta ble 1. [3 + 2] Cycloa d d ition betw een N-Meta la ted Azom eth in es Der ived fr om Im in es 1a -g a n d Nitr oa lk en es 2a -c
Usin g Aceton itr ile a s Solven t a n d in th e P r esen ce of AgOAc a n d LiClO4
method A (AgOAc)
method B (LiClO4)
entry product
R1
R2
R3
R4
time (h) yielda (%) endo:exob time (h) yielda (%) endo:exob
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
4a
4b
4c
4d
4e
4f
4g
4h
4i
4j
4k
4l
4m
4n
4o
C6H5
C6H5
2-HO-C6H4
2-HO-C6H4
2-HO-C6H4
H
H
H
H
CH3
H
H
4-Cl-C6H4
4-CH3OC6H4
4-Cl-C6H4
4-CH3OC6H4
4-CH3OC6H4
3
3
2.5
2.5
48
17
40
2
60
69
