3,8-Bis(bromomethyl)-2,7-dioxaspiro(4.4)nonane-1,6-dione

Base Information

• Chemical Name: 3,8-Bis(bromomethyl)-2,7-dioxaspiro(4.4)nonane-1,6-dione
• CAS No.: 60012-87-5
• Molecular Formula: C9H10Br2O4
• Molecular Weight: 341.9813
• DSSTox Substance ID: DTXSID50975436
• Mol file: 60012-87-5.mol

Synonyms:3,8-Bis(bromomethyl)-2,7-dioxaspiro(4.4)nonane-1,6-dione;60012-87-5;Bis(3-bromo-beta-hydroxypropyl)malonic acid dilactone;2,7-Dioxaspiro(4.4)nonane-1,6-dione, 3,8-bis(bromomethyl)-;3,8-bis(bromomethyl)-2,7-dioxaspiro[4.4]nonane-1,6-dione;DTXSID50975436;LS-62414

Chemical Property of 3,8-Bis(bromomethyl)-2,7-dioxaspiro(4.4)nonane-1,6-dione

Chemical Property:

• Vapor Pressure: 1.95E-12mmHg at 25°C
• Boiling Point: 556.9°Cat760mmHg
• Flash Point: 290.6°C
• Density: 1.95g/cm³
• XLogP3: 1.9
• Hydrogen Bond Donor Count: 0
• Hydrogen Bond Acceptor Count: 4
• Rotatable Bond Count: 2
• Exact Mass: 341.89253
• Heavy Atom Count: 15
• Complexity: 275

Purity/Quality:

99% ^*data from raw suppliers

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

SDS file from LookChem

Useful:

• Canonical SMILES: C1C(OC(=O)C12CC(OC2=O)CBr)CBr

Technology Process of 3,8-Bis(bromomethyl)-2,7-dioxaspiro(4.4)nonane-1,6-dione

There total 5 articles about 3,8-Bis(bromomethyl)-2,7-dioxaspiro(4.4)nonane-1,6-dione which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield:

2,2-diallylmalonic acid (4372-31-0) → 3,8-bis-bromomethyl-2,7-dioxa-spiro[4.4]nonane-1,6-dione (60012-87-5)

Guidance literature:

With bromine; acetic acid;

Reference yield:

→ 3,8-bis-bromomethyl-2,7-dioxa-spiro[4.4]nonane-1,6-dione (60012-87-5)

Guidance literature:

With diethyl ether; bromine;

Reference yield:

diallylmalonic acid diethyl ester (3195-24-2) → 3,8-bis-bromomethyl-2,7-dioxa-spiro[4.4]nonane-1,6-dione (60012-87-5)

Guidance literature:

With chloroform; bromine; by/at 156-158 degree melting form;

upstream raw materials:

2,2-diallylmalonic acid

diallylmalonic acid diethyl ester
