(3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate

Base Information

• Chemical Name: (3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate
• CAS No.: 1539317-18-4
• Molecular Formula: C₂₃H₂₈N₄O₄S
• Molecular Weight: 456.566
• Mol file: 1539317-18-4.mol

Synonyms:(3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate

Chemical Property of (3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of (3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate

There total 4 articles about (3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield:

(3R,4R)-tert-butyl 3-amino-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate (1539317-17-3) + Benzoyl isothiocyanate (532-55-8) → (3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate (1539317-18-4)

Guidance literature:

In dichloromethane; at -15 ℃; for 1.5h;

Reference yield:

tert-butyl N-allyl-N-[2-oxo-2-(2-pyridyl)ethyl]carbamate (1539317-15-1) → (3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate (1539317-18-4)

Guidance literature:

Multi-step reaction with 3 steps

1: titanium(IV) tetraethanolate / tetrahydrofuran / 97 h / 70 - 80 °C / Sealed tube

2: palladium 10% on activated carbon; ammonium formate / methanol; water / 56 h / 65 °C

3: dichloromethane / 1.5 h / -15 °C

With titanium(IV) tetraethanolate; palladium 10% on activated carbon; ammonium formate; In tetrahydrofuran; methanol; dichloromethane; water;

Reference yield:

(3aR,6aR)-tert-butyl 1-((R)-1-phenylethyl)-6a-(pyridin-2-yl)tetrahydro-1H-pyrrolo[3,4-c]isoxazole-5(3H)-carboxylate (1539317-16-2) → (3R,4R)-tert-butyl 3-(3-benzoylthioureido)-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate (1539317-18-4)

Guidance literature:

Multi-step reaction with 2 steps

1: palladium 10% on activated carbon; ammonium formate / methanol; water / 56 h / 65 °C

2: dichloromethane / 1.5 h / -15 °C

With palladium 10% on activated carbon; ammonium formate; In methanol; dichloromethane; water;

upstream raw materials:

tert-butyl allyl(2-morpholino-2-oxoethyl)carbamate

tert-butyl N-allyl-N-[2-oxo-2-(2-pyridyl)ethyl]carbamate

(3aR,6aR)-tert-butyl 1-((R)-1-phenylethyl)-6a-(pyridin-2-yl)tetrahydro-1H-pyrrolo[3,4-c]isoxazole-5(3H)-carboxylate

(3R,4R)-tert-butyl 3-amino-4-(hydroxymethyl)-3-(pyridin-2-yl)pyrrolidine-1-carboxylate

Downstream raw materials:

(4aR,7aR)-tert-butyl 2-benzamido-7a-(pyridin-2-yl)-4a.5.7.7a-tetrahvdropyrrolo[3,4-d][1,3]thiazine-6(4H)-carboxylate

N-((4aR,7aR)-7a-(pyridin-2-yl)-4,4a.5,6.7.7a-hexahydropyrrolo[3,4-d][1,3]thiazin-2-yl)benzamide

N-((4aR,7aR)-6-carbamimidoyl-7a-(pyridin-2-yl)-4,4a.5,6.7.7a-hexahydropyrrolo[3,4-d][1,3]thiazin-2-yl)benzamide hydrochloride

N-((4aR,7aR)-6-(5-fluoro-4-methyl-6-oxo-1,6-dihydropyrimidin-2-yl)-7a-(pyridin-2-yl)-4,4a.5,6.7.7a-hexahydropyrrolo[3,4-d][1,3]thiazin-2-yl)benzamide
