5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane>

Base Information

• Chemical Name: 5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane>
• CAS No.: 130256-93-8
• Molecular Formula: C₁₈H₁₇N₃O₂S
• Molecular Weight: 339.418
• Mol file: 130256-93-8.mol

Synonyms:5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane>

Chemical Property of 5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane>

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of 5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane>

There total 3 articles about 5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane> which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 84.6%

2,3-dihydro-5-nitro-4-(phenylthio)spiro<1H-benzimidazole-2,1'-cyclohexane> (130256-92-7) → 5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane> (130256-93-8)

Guidance literature:

With manganese(IV) oxide; In dichloromethane; for 0.333333h; Ambient temperature;

DOI:10.1002/hlca.19900730417

Reference yield:

thiophenol (108-98-5) → 5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane> (130256-93-8)

Guidance literature:

Multi-step reaction with 2 steps

1: 76.4 percent / AcOH / CH₂Cl₂ / 0.17 h / Ambient temperature

2: 84.6 percent / MnO₂ / CH₂Cl₂ / 0.33 h / Ambient temperature

With manganese(IV) oxide; acetic acid; In dichloromethane;

DOI:10.1002/hlca.19900730417

Reference yield:

5-nitrospiro<2H-benzimidazole-2,1'-cyclohexane> (65023-47-4) → 5-nitro-4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane> (130256-93-8)

Guidance literature:

Multi-step reaction with 2 steps

1: 76.4 percent / AcOH / CH₂Cl₂ / 0.17 h / Ambient temperature

2: 84.6 percent / MnO₂ / CH₂Cl₂ / 0.33 h / Ambient temperature

With manganese(IV) oxide; acetic acid; In dichloromethane;

DOI:10.1002/hlca.19900730417

upstream raw materials:

2,3-dihydro-5-nitro-4-(phenylthio)spiro<1H-benzimidazole-2,1'-cyclohexane>

thiophenol

5-nitrospiro<2H-benzimidazole-2,1'-cyclohexane>

Downstream raw materials:

4,5-diamino-2,1,3-benzoxadiazole

<1,2,5>oxadiazolo<3,4-f>quinoxaline

8H-imidazo<4,5-e>-2,1,3-benzoxadiazole

4-(phenylthio)spiro<2H-benzimidazole-2,1'-cyclohexane>
