276239-22-6Relevant articles and documents
Synthesis of meso-substituted chlorins via tetrahydrobilene-a intermediates
Taniguchi,Ra,Mo,Balasubramanian,Lindsey
, p. 7342 - 7354 (2007/10/03)
Chlorin building blocks incorporating a geminal dimethyl group in the reduced ring and synthetic handles in specific patterns at the perimeter of the macrocycle are expected to have utility in biomimetic and materials chemistry. A prior route employed condensation of a dihydrodipyrrin (Western half) and a bromodipyrromethane-monocarbinol (Eastern half), followed by oxidative cyclization of the putative dihydrobilene-a to form the meso-substituted zinc chlorin in yields of ～10%. The limited stability of the dihydrodipyrrin precluded study of the chlorin-forming process. We now have refined this methodology. A tetrahydrodipyrrin Western half (2,3,4,5-tetrahydro-1,3,3-trimethyldipyrrin) has been synthesized and found to be quite stable. The condensation of the Western half and an Eastern half (100 mM each) proceeded smoothly in CH3CN containing 100 mM TFA at room temperature for 30 min. The resulting linear tetrapyrrole, a 2,3,4,5-tetrahydrobilene-a, also is quite stable, enabling study of the conversion to chlorin. Refined conditions for the oxidative cyclization were found to include the following: the tetrahydrobilene-a (10 mM), AgTf (3-5 molar equiv), Zn(OAc)2 (15 molar equiv), and 2,2,6,6-tetramethylpiperidine (15 molar equiv) in CH3CN at reflux exposed to air for 4-6 h, affording the zinc chlorin. The chlorin-forming process could be implemented in either a two-flask process or a one-flask process. The two-flask process was applied to form six zinc chlorins bearing substituents such as pentafluorophenyl, 3,5-di-tert-butylphenyl, TMS-ethyl benzoate, iodophenyl, or ethynylphenyl (deprotection of the TMS-ethynyl group occurred during the oxidative cyclization process). The stepwise yields (isolated) for the condensation and oxidative cyclization processes forming the tetrahydrobilene and zinc chlorin were 32-72% and 27-62%, respectively, giving overall yields of zinc chlorin from the Eastern and Western halves of 12-45%. Taken together, the refinements introduced enable 100-mg quantities of chlorin building blocks to be prepared in a facile and rational manner.
Rational Synthesis of Meso-Substituted Chlorin Building Blocks
Strachan, Jon-Paul,O'Shea, Donal F.,Balasubramanian, Thiagarajan,Lindsey, Jonathan S.
, p. 3160 - 3172 (2007/10/03)
Chlorins provide the basis for plant photosynthesis, but synthetic model systems have generally employed porphyrins as surrogates due to the unavailability of suitable chlorin building blocks. We have adapted a route pioneered by Battersby to gain access to chlorins that bear two meso substituents, a geminal dimethyl group to lock in the chlorin hydrogenation level, and no flanking meso and β substituents. The synthesis involves convergent joining of an Eastern half and a Western half. A 3,3-dimethyl-2,3-dihydrodipyrrin (Western half) was synthesized in four steps from pyrrole-2-carboxaldehyde. A bromodipyrromethane carbinol (Eastern half) was prepared by sequential acylation and bromination of a 5-substituted dipyrromethane followed by reduction. Chlorin formation is achieved by a two-flask process of acid-catalyzed condensation followed by metal-mediated oxidative cyclization. The latter reaction has heretofore been performed with copper templates. Investigation of conditions for this multistep process led to copper-free conditions (zinc acetate, AgIO3, and piperidine in toluene at 80 °C for 2 h). The zinc chlorin was obtained in yields of ～10% and could be easily demetalated to give the corresponding free base chlorin. The synthetic process is compatible with a range of meso substituents (p-tolyl, mesityl, pentafluorophenyl, 4-[2-(trimethylsilyl)ethynyl]phenyl, 4-iodophenyl). Altogether four free base and four zinc chlorins have been prepared. The chlorins exhibit typical absorption spectra, fluorescence spectra, and fluorescence quantum yields. The ease of synthetic access, presence of appropriate substituents, and characteristic spectral features make these types of chlorins well suited for incorporation in synthetic model systems.
