ORGANIC
LETTERS
2011
Vol. 13, No. 6
1474–1477
Palladium-Catalyzed Oxidative
Alkynylation of Heterocycles with
Terminal Alkynes under Air Conditions
Seok Hwan Kim, Jungho Yoon, and Sukbok Chang*
Department of Chemistry, Korea Advanced Institute of Science and Technology
(KAIST), Daejeon 305-701, Republic of Korea
sbchang@kaist.ac.kr
Received January 18, 2011
ABSTRACT
Pd-Catalyzed oxidative alkynylation of azoles with terminal alkynes was developed via simultaneous activation of both heterocyclic sp2 C-H and
alkynyl sp C-H bonds. The choice of palladium catalyst source and external base resulted in being important factors for performing the reaction
with high efficiency and selectivity, and air was successfully utilized as an environmental oxidant in the present alkynylation procedure.
In recent years, a promising strategy of C-H bond
activation has been extensively utilized for C-C bond
formation which is one of the most important topics in
organic chemistry.1 This direction of research has been
stimulated mainly due to the advantage of enabling a more
straightforward access to target molecules without requiring
prefunctionalization of starting molecules, thus minimizing
side products in fewer steps. Therefore, although the C-H
bond functionalization often requires relatively harsh reac-
tion conditions, it is considered as an attractive alternative
to the conventional coupling approaches, in which both
reactants are preactivated (Scheme 1, path I).2 With regard
to this aspect, highly efficient C-C bond forming protocols
have been developed from the direct reaction of heteroar-
enes with aryl- or vinyl-(pseudo)halides (path II).3
More recently, a more challenging route to the C-C
bond formation has been scrutinized using two nonacti-
vated reactants (path III). Indeed, the oxidative C-C bond
formation via the activation of C(sp2)-H or C(sp3)-H
bonds has been extensively studied using various metal
catalysts.4,5 On the other hand, while the activation of
C(sp)-H bonds has been examined for the oxidative
couplings,6 synthetic applications of the strategy still re-
main largely unexplored mainly because of the undesired
homocoupling of terminal alkynes under the conditions.
Although Sonogashira reaction is a powerful tool for
(1) (a) Ritleng, V.; Sirlin, C.; Pfeffer, M. Chem. Rev. 2002, 102, 1731.
(b) Colby, D. A.; Bergman, R. G.; Ellman, J. A. Chem. Rev. 2010, 110,
624. (c) Johansson, C. C. C.; Colacot, T. J. Angew. Chem., Int. Ed. 2010,
49, 676.
(4) For recent examples of C-C bond formation via C(sp2)-H bond
activation, see: (a) Boele, M. D. K.; van Strijdonck, G. P. F.; de Vries,
A. H. M.; Kamer, P. C. J.; de Vries, J. G.; van Leeuwen, P. W. N. M. J.
Am. Chem. Soc. 2002, 124, 1586. (b) Dwight, T. A.; Rue, N. R.; Charyk,
D.; Josselyn, R.; DeBoef, B. Org. Lett. 2007, 9, 3137. (c) Hull, K. L.;
Sanford, M. S. J. Am. Chem. Soc. 2007, 129, 11904. (d) Stuart, D. R.;
Villemure, E.; Fagnou, K. J. Am. Chem. Soc. 2007, 129, 12072. (e) Cho,
S. H.; Hwang, S. J.; Chang, S. J. Am. Chem. Soc. 2008, 130, 9254. (f)
Egami, H.; Katsuki, T. J. Am. Chem. Soc. 2009, 131, 6082. (g) Kwon,
K.-H.; Lee, D. W.; Yi, C. S. Organometallics 2010, 29, 5748. (h) Morimoto,
K.; Hirano, K.; Satoh, T.; Miura, M. Org. Lett. 2010, 12, 2068. (i) Wei, Y.;
Su, W. J. Am. Chem. Soc. 2010, 132, 16377.
(2) (a) Shilov, A. E.; Shul’pin, G. B. Chem. Rev. 1997, 97, 2879. (b)
Daugulis, O.; Do, H.-Q.; Shabashov, D. Acc. Chem. Res. 2009, 42, 1074.
(c) Giri, R.; Shi, B.-F.; Engle, K. M.; Maugel, N.; Yu, J.-Q. Chem. Soc.
Rev. 2009, 38, 3242. (d) Sun, C.-L.; Li, B.-J.; Shi, Z.-J. Chem. Commun.
2010, 46, 677. (e) Gunay, A.; Theopold, K. H. Chem. Rev. 2010, 110,
1060. (f) Hwang, S. J.; Cho, S. H.; Chang, S. J. Am. Chem. Soc. 2008,
130, 16158. (g) Park, E. J.; Kim, S. H.; Chang, S. J. Am. Chem. Soc. 2008,
130, 17268. (h) Cho, S. H.; Kim, J. Y.; Lee, S. Y.; Chang, S. Angew.
Chem., Int. Ed. 2009, 48, 9127. (i) Kim, J. Y.; Cho, S. H.; Joseph, J.;
Chang, S. Angew. Chem., Int. Ed. 2010, 49, 9899. (j) Kim, J.; Chang, S. J.
Am. Chem. Soc. 2010, 132, 10272.
(5) For recent examples of C-C bond formation via C(sp3)-H
activation, see: (a) Lin, S.; Song, C. X.; Cai, G. X.; Wang, W.-H.; Shi,
Z.-J. J. Am. Chem. Soc. 2008, 130, 12901. (b) Li, C.-J. Acc. Chem. Res.
2009, 42, 335. (c) Chen, X.; Engle, K. M.; Wang, D.-H.; Yu, J.-Q. Angew.
Chem., Int. Ed. 2009, 48, 5094. (d) Urkalan, K. B.; Sigman, M. S. J. Am.
Chem. Soc. 2009, 131, 18042.
(3) (a) Seregin, I. V.; Gevorgyan, V. Chem. Soc. Rev. 2007, 36, 1173.
(b) Lewis, J. C.; Bergman, R. G.; Ellman, J. A. Acc. Chem. Res. 2008, 41,
1013. (c) Daugulis, O.; Do, H.-Q.; Shabashov, D. Acc. Chem. Res. 2009,
42, 1074.
r
10.1021/ol200154s
Published on Web 02/24/2011
2011 American Chemical Society

introducing organic groups at the terminal alkynyl carbon,
a recent advance in the direct alkynylation of C(sp2)-H
bonds appears as a promising alternative to the conven-
tional Sonogashira procedure, in which aryl or vinyl
halides are employed.7
(e.g., entry 2). Use of other oxidants such as iodobenzene-
diacetate or tert-butyl hydroperoxide resulted in much lower
product yields (entries 3 and 4, respectively). While Pd(PPh3)4
alone displayed similar catalytic activity compared to that
from combined use of Pd(OAc)2/bipyridyl (entry 5), a higher
product yield was obtained when the reaction was carried
out open to air, a weaker oxidant for oxidizing the phos-
phine ligand, than under an O2 atmosphere (compare entries
5 and 6).
Scheme 1. Strategies of C-C Bond Formation
Table 1. Optimization of the Pd-Catalyzed Alkynylationa
temp yield
entry
catalyst/ligand
oxidant
solvent
(°C)
(%)b
1
Pd(OAc)2/bipyridyl O2
Pd(OAc)2/bipyridyl O2
toluene
toluene
100
100
100
100
100
100
100
100
100
100
100
80
30
2c
3
N.R.
N.R.
<5
Pd(OAc)2/bipyridyl PhI(OAc)2 toluene
Recently, our group has disclosed a Pd-catalyzed alky-
nylation of azoles using 1-haloalkynes, and its efficiency was
observed to be dependent on the ease of C(sp2)-H bond
activation.8 During the course of this study, we found that
a terminal alkyne itself was able to be coupled with azoles
under oxidative catalytic conditions. In fact, oxidative alky-
nylation of arenes with 1-alkynes was developed using Au6h
or Cu6i catalytic systems. In addition, Miura revealed an
elegant protocol of oxidative alkynylation of azoles using a
Ni catalyst.6m Despite these developments, plenty of room
for improvement still remains with regard to reaction effi-
ciency and substrate scope. We herein describe a new proce-
dure for the oxidative alkynylation of azoles using terminal
alkynes under Pd-catalyzed conditions.
5-Methylbenzoxazole (1a) and phenylacetylene (2a)
were chosen as model substrates in order to optimize the
oxidative alkynylation conditions (Table 1).9 We were
pleased to observe that a desired product (3a) was obtained
albeit in moderate yield when a Pd(OAc)2 catalyst was used
in the presence of a 2,20-bipyridine (bipyridyl) ligand under
an O2 atmosphere (entry 1). The reaction efficiency was
highly sensitive to the choice of bases, and LiO-t-Bu pro-
vided the best results among the various bases examined
4
Pd(OAc)2/bipyridyl t-BuOOH
toluene
toluene
toluene
toluene
toluene
toluene
toluene
toluene
toluene
xylene
5
Pd(PPh3)4
Pd(PPh3)4
Pd(PPh3)4
Pd(PPh3)4
none
O2
air
air
air
air
air
air
air
air
38
6
50
7d
8e
9
67f
74f
N.R.
<5
10
11
12
13
Pd2(dba)3
Pd(dba)2/PPh3
Pd(PPh3)4
Pd(PPh3)4
44
15
130
<5
a 1a (1.5 equiv), 2a (0.5 mmol), palladium catalyst (5 mol %), ligand
(bidentate: 5.5 mol %; monodentate: 11 mol %), base (2 equiv), oxidant
(O2 and air: 1 atm, others: 2 equiv), solvent (3 mL) for 12 h. b NMR yield.
N.R. indicates no reaction. c KO-t-Bu (2 equiv) was used instead of LiO-
t-Bu. d 1a (2 equiv) and base (3 equiv). e 1a (3 equiv) and base (4 equiv).
f Isolated yield.
A higher product yield was obtained with the larger
equivalent of oxazole and base (entries 7-8). While no
reaction was observed in the absence of the Pd(PPh3)4
species (entry 9), other Pd sources showed lower activity
even in the presence of the PPh3 ligand (entries 10-11).
The reaction proceeded slowly at lower temperature while
decomposition of azole was dominant at higher tempera-
tures (entries 12-13).
Various terminal alkynes were next applied to the opti-
mized conditions in the reaction with 1a (Table 2). Pheny-
lacetylenes bearing a range of substituents were coupled at
the 2-position of 1a to afford the desired products in good
yields (entries 1-8). Steric bulkiness at the aryl part did not
diminish the reaction efficiency as demonstrated in entry 2.10
While the reaction of phenylacetylenes substituted with
electron-donating groups readily took place to provide high
product yields, electron-withdrawing substituents resulted in
slightly lower yields mainly due to dimerization of the
alkynes (entries 6-8). 1-Naphthylacetylene and conjugated
enyne readily reacted with 1a under the optimized conditions
