The reaction mixture was cooled and concentrated under reduced
pressure, at which point it was diluted with ether. A 6 M solution of
HCl was added slowly until the mixture was pH neutral. The mixture
was then transferred to a separatory funnel and extracted three times
with CH2Cl2. The combined organic layer was dried with brine and
sodium sulfate before being concentrated under reduced pressure to
afford a black oil.
This crude oil was dissolved in CH2Cl2 (200 mL), and DDQ (15.5
g, 68.16 mmol) was added. The reaction mixture was stirred overnight
open to air before being concentrated under reduced pressure. The
reaction mixture was purified through a pad of silica (1:9 CH2Cl2/
hexanes to 4:6 CH2Cl2/hexanes) before being recrystallized in hot
hexanes to afford red needles (20.25 g, 54% over three steps): mp
157−159 °C; IR (neat) 2952, 2928, 2858, 1650, 1607, 1503, 1466,
1296, 1137 cm−1; 1H NMR (500 MHz, CDCl3) δ 6.99 (s broad, 16H),
2.54 (t, J = 7.7 Hz, 8H), 1.54 (tt, J = 7.7, 7.2 Hz, 8H), 1.29 (qt, J = 7.2,
7.2 Hz, 8H), 0.89 (t, J = 7.2 Hz, 12H); 13C (125 MHz, CDCl3) δ
187.25, 142.91, 142.78, 130.82, 130.33, 127.58, 35.38, 33.23, 22.22,
13.93; MALDI-TOF m/z calcd for C46H52O2Na (M)+ 659.4, found
659.4.
Tetraphenyl-Substituted Terminal Dichloride 10. A Schlenk
flask was charged with a stir bar, 8 (2.61 g, 2.43 mmol), 9 (2.4 g, 5.35
mmol), Pd(PPh3)4 (280 mg, 0.28 mmol), and CsCO3 (3.96 g, 14
mmol). The flask was then evacuated and backfilled with N2. Toluene
and methanol were sparged with N2 in separate flasks and
subsequently syringed into the Schlenk flask (143 and 13 mL
respectively). The reaction mixture was heated to 80 °C and stirred for
16 h. Upon cooling, the reaction mixture was diluted with H2O and
transferred to a separatory funnel. The aqueous layer was extracted
with CH2Cl2 (3×), and the combined organic layers were
subsequently washed with brine and dried over sodium sulfate.
Upon concentration under reduced pressure, the reaction mixture was
purified by column chromatography (alumina) with an eluent of 2:8
diethyl ether/hexanes to afford a white solid (2.66 g, 75%): mp 116−
128 °C; IR (neat) 2954, 2930, 1491, 1013, 951, 907, 821, 728 cm−1;
1H NMR (500 MHz, CDCl3) δ 7.73−7.56 (broad, overlap, 4H), 7.58
(d, J = 8.6 Hz, 4H), 7.49−7.40 (broad overlap, 4H), 7.43 (d, J = 8.6
Hz, 4H), 7.36 (d, J = 8.8 Hz, 4H), 7.28 (d, J = 8.8 Hz, 4H), 6.67 (d, J
= 8.3 Hz, 8H), 6.62 (d, J = 8.3 Hz, 8H), 6.16 (d, J = 10.24 Hz, 4H),
6.08 (d, J = 10.24 Hz, 4H), 3.87 (s, 6H), 3.45 (s, 6H), 3.44 (s, 6H),
2.34 (t, J = 7.5 Hz, 8H), 1.37 (tt, J = 7.5, 7.4 Hz, 8H), 1.13 (qt, J = 7.4,
7.4 Hz, 8H), 0.80 (t, J = 7.4 Hz, 12H); 13C (125 MHz, CDCl3) δ
142.53, 142.46, 142.06, 142.03, 140.40, 140.06, 138.34, 136.04, 133.74,
133.39, 132.95, 131.15, 128.49, 128.32 (broad), 127.48, 126.88,
126.72, 126.31, 125.72, 81.44, 74.64, 74.51, 52.14, 52.02, 52.02, 34.98,
35.14, 21.96, 13.91; MALDI-TOF m/z calcd for C99H99Cl2O5 (M −
CH3O)+ 1438.7, found 1438.7.
Tetraphenyl-Substituted Diiodide Diol 7. 1,4-Diiodobenzene
(43 g, 129 mmol) was placed in a flame-dried flask with a stir bar. THF
(380 mL) was added, and the solution was cooled to −78 °C, at which
point nBuLi (46 mL, 115 mmol) was added dropwise. The solution
stirred for 30 min, at which point 6 (30.5 g, 47.9 mmol) was
introduced as a solution in THF (120 mL) over 10 min. The reaction
mixture was stirred for 30 min and then quenched with H2O at −78
°C. The reaction mixture was warmed and then diluted with H2O and
diethyl ether before being transferred to a separatory funnel. The
aqueous layer was extracted three times with ether and then three
times with CH2Cl2. The combined organic layers were washed with
brine and dried over sodium sulfate before being concentrated under
reduced pressure. The reaction mixture was purified by silica gel
chromatography with an eluent mixture gradient of 3:7−8:2 CH2Cl2/
hexanes to afford a white solid (34.6 g, 69%): mp 220−221 °C; IR
Macrocyclic 12. A three-necked flask was charged with a stir bar,
10 (882 mg, 0.6 mmol), 11 (424 mg, 0.78 mmol), Pd2(dba)3 (54 mg,
0.06 mmol), S-Phos (98.4 mg, 0.24 mmol), and K3PO4 (254.4 mg, 1.2
mmol). The flask was fitted with a condenser and septa and
subsequently evacuated and backfilled with N2. The flask was then
additionally purged with N2 for 30 min. Separately, a flask containing
DMF and a flask containing H2O were sparged with N2. The DMF
and H2O were syringed into the reaction flask (540 and 60 mL,
respectively), and the reaction mixture was lowered into a hot oil bath
at 125 °C. The reaction mixture was stirred for 16 h.
1
(neat) 2954, 2928, 2857, 1505, 1480, 1389, 1005, 906, 732 cm−1; H
NMR (500 MHz, CDCl3) δ 7.55 (d, J = 8.3 Hz, 4H), 7.10 (d, J = 8.3
Hz, 4H), 6.70 (d, J = 8.2 Hz, 8H), 6.66 (d, J = 8.2 Hz, 8H), 2.42 (s,
2H), 2.35 (t, J = 7.6 Hz, 8H), 1.38 (tt, J = 7.6, 7.2 Hz, 8H), 1.14 (qt, J
= 7.2, 7.2 Hz, 8H), 0.81 (t, J = 7.2 Hz, 12H); 13C (125 MHz, CDCl3)
δ 142.96, 140.74, 140.34, 136.47, 134.14, 131.29, 129.60, 126.90,
92.97, 75.11, 35.00, 33.12, 22.03, 13.88; MALDI-TOF m/z calcd for
C58H62I2O2Na (M)+ 1067.2, found 1067.3.
Upon cooling, the reaction mixture was filtered through Celite, and
the Celite was then washed with CH2Cl2. The filtered solution was
transferred to a separatory funnel, and the organic layer was washed
multiple times (∼15) with H2O until the DMF was removed. Upon
concentration under reduced pressure, the reaction mixture was
purified by column chromatography (silica) with an eluent gradient of
10:90 to 15:85 EtOAc/hexanes to afford a white solid (244 mg, 24%):
mp 185−190 °C; IR (neat) 2953, 2927, 2855, 1491, 1083, 1026, 1006,
Tetraphenyl-Substituted Diiodide 8. Diol 7 (34.6 g, 33 mmol)
was placed into a dry flask with a stir bar, at which point THF (300
mL) was added and the reaction mixture was cooled to 0 °C. A NaH
powder in oil (6.6 g, 165 mmol) was added in three portions over 20
min. The reaction mixture was then stirred for 30 min, and MeI (12.3
mL, 198 mmol) was subsequently added as a stream over 5 min. The
ice bath was allowed to warm to room temperature as the reaction
mixture was stirred for 16 h. The reaction mixture was then quenched
with H2O and diluted with diethyl ether before being transferred to a
separatory funnel. The aqueous layer was extracted three times with
diethyl ether, and the combined organic layers were washed with brine
and dried over sodium sulfate before being concentrated under
reduced pressure. The crude mixture was suspended in 150 mL of
hexanes and stirred at 0 °C for 30 min. The solution was filtered and
the solid was washed with cold hexanes (2 × 50 mL) to afford a white
solid (26.5 g, 75%). The yield may be improved if purified through
silica gel chromatography (1:9 CH2Cl2/hexanes) to afford a white
solid (92%): mp 218 °C; IR (neat) 2955, 2924, 2857, 1507, 1480,
1
951, 820 cm−1; H NMR (500 MHz, CDCl3) 7.64−7.34 (m, 32H),
6.66 (d, J = 8.3 Hz, 8H), 6.62 (d, J = 8.3 Hz, 8H), 6.18−6.12 (m,
12H), 3.84 (s, 6H), 3.46 (s, 6H), 3.45 (s, 6H), 3.44 (s, 6H), 2.34 (t, J
= 7.6 Hz, 8H), 1.37 (tt, J = 7.6, 7.5 Hz, 8H), 1.13 (qt, J = 7.5, 7.5 Hz,
8H), 0.79 (t, J = 7.5 Hz, 12H); 13C (125 MHz, CDCl3) δ 142.53,
142.52, 142.40, 142.37, 142.26, 140.41, 140.25, 140.15, 140.09, 138.76,
136.02, 133.40, 133.35, 133.34, 133.33, 131.15, 128.27, 127.14, 127.13,
126.99, 126.71, 126.39, 126.34, 125.81, 81.45, 74.70, 74.60, 74.59,
52.05, 52.00, 51.98 (2), 34.94, 33.12, 21.93, 13.89; MALDI-TOF m/z
calcd for C119H118O7 (M − CH3O)+ 1658.8, found 1658.2.
Tetraphenyl-Substituted [12]CPP 1. A dry flask was charged
with a glass stir bar, and sodium metal was washed with hexanes to
remove oil (405 mg, 17.6 mmol). Dry THF (15 mL) was added,
followed by naphthalene (1.92 g, 15 mmol) in portions. This reagent
was allowed to stir overnight for complete formation.
Macrocycle 12 (240 mg, 0.14 mmol) was placed in a dry flask along
with a glass stir bar. THF (40 mL) was added, and the reaction
mixture was cooled to −78 °C. Freshly prepared sodium naphthalide
(7 mL, 7 mmol) was added dropwise, and the reaction mixture
immediately changed color to a dark purple solution. The reaction
mixture was stirred for 40 min, at which point the excess reagent was
quenched with a 1 M iodine solution in THF. A saturated solution of
sodium thiosulfate was added, and the reaction mixture was allowed to
warm to room temperature while stirring.
1
1458, 1387, 1096, 1006, 907, 758, 733 cm−1; H NMR (500 MHz,
CD2Cl2) δ 7.62−7.08 (broad, 8H), 6.60 (d, J = 8.2 Hz, 8H), 6.51 (d, J
= 8.2 Hz), 3.76 (s, 6H), 2.28 (t, J = 7.6 Hz, 8H), 1.31 (tt, J = 7.6, 7.2
Hz, 8H), 1.08 (qt, J = 7.2, 7.2 Hz, 8H), 0.75 (t, J = 7.2 Hz, 12H); 13C
(125 MHz, CDCl3) δ 143.05, 142.36, 140.66, 136.35, 135.54, 130.96,
129.85 (broad), 126.83, 92.56, 81.14, 52.10, 34.95, 33.10, 21.95, 13.90;
MALDI-TOF m/z calcd for C59H63I2O (M − CH3O)+ 1041.3, found
1041.3.
