Iodine-catalyzed Direct Thiolation of Indoles with Thiols Leading to 3-Thioindoles Using Air as the Oxidant

Article abstract of DOI:10.1007/s10562-016-1798-2

Abstract: A simple and convenient method has been developed for the construction of 3-thioindoles via molecular iodine-catalyzed direct thiolation of indoles with thiols. The present protocol, which employs thiols as the thiolating agents, inexpensive mol

Full text of DOI:10.1007/s10562-016-1798-2

Catal Lett
DOI 10.1007/s10562-016-1798-2
Iodine-catalyzed Direct Thiolation of Indoles with Thiols Leading
to 3-Thioindoles Using Air as the Oxidant
Xiaoxia Liu1 Huanhuan Cui1 Daoshan Yang1 Shicui Dai1
•
•
•
•
Guoqin Zhang1 Wei Wei1 Hua Wang1
•
•
Received: 28 April 2016 / Accepted: 17 June 2016
Ó Springer Science+Business Media New York 2016
Abstract A simple and convenient method has been devel-
oped for the construction of 3-thioindoles via molecular iodine-
catalyzed direct thiolation of indoles with thiols. The present
protocol, which employs thiols as the thiolating agents, inex-
pensive molecular iodine as the catalyst, and environmentally
benignair as the oxidant, allows theregioselective generationof
3-thioindoles in good to excellent yields.
1 Introduction
Indole represents an important class of structural scaffold
omnipresent in various natural products, pharmaceutically
active compounds and materials [1–8]. In particular, 3-thioin-
doles constitute a permanent focus of scientific interest since
they have a broad spectrum of biological and pharmaceutical
activities, such as anti-cancer activity [9], anti-HIV activity
[10], anti-bacterial infection [11], anti-obesity [12, 13], and
inhibitory activity against tubulin polymerization [14]. For
example, compound I can be used as inhibitor against
5-lipoxygenase, which may increase the antitumor activity of
celecoxib in colorectal cancer [16]; compound II is a powerful
and selective CRTh2 antagonist [17]; compound III is a potent
inhibitor of tubulin polymerization, inhibiting the growth of
breast cancer cells (Fig. 1) [14, 15, 18].
Graphical Abstract
Because of the importance of such compounds, numer-
ous synthetic methods have been successfully established.
Among them, the C3-thiolation of indoles has been
exhibited to be the most efficient and extensively explored
one. So far, a variety of thiolating agents such as aryl-
sulfenyl halides [19, 20], arylsulfonyl chlorides [21–23],
sulfonyl hydrazides [24, 25], diaryl disulfides [26–33], N-
thiophthalimides [34–37], O,S-acetals [38, 39], arylsulfo-
nium salts [40, 41], sulfinic acids [42] and Bunte Salts [43]
have been employed for C3-thiolation of indoles. Despite
the merits of these methods, most of these reactions require
an additional step for the synthesis of thiolating reagents.
From a synthetic standpoint, the direct use of thiols as
thiolating reagents is an effective strategy for constructing
3-thioindoles because of its advantages of low cost, easy
availability, and high atom economy. Up to date, a few
methods have been reported to synthesize 3-thioindoles
from thiols [44–50]. Nevertheless, most of these methods
suffer from some limitations such as the need for toxic
Keywords Molecular iodine Á Thiolation Á 3-Thioindoles Á
Indoles Á Thiols
Electronic supplementary material The online version of this
article (doi:10.1007/s10562-016-1798-2) contains supplementary
material, which is available to authorized users.
& Wei Wei
weiweiqfnu@163.com
& Hua Wang
huawang_qfnu@126.com
1
The Key Laboratory of Life-Organic Analysis and Key
Laboratory of Pharmaceutical Intermediates and Analysis of
Natural Medicine, School of Chemistry and Chemical
Engineering, Qufu Normal University,
Qufu 273165, Shandong, China
123

X. Liu et al.
25 mL round-bottomed flack at room temperature under
air. The reaction vessel was allowed to stir at 80 °C for
16 h. After the reaction, the solvent was then removed
under vacuum. The residue was purified by flash column
chromatography using a mixture of petroleum ether and
ethyl acetate as eluent to give the desired 3-thioindoles 3.
The characterization of the corresponding products was
shown in Supporting Materials.
Fig. 1 Biologically active 3-thioindoles
3 Results and Discussions
In an initial experiment, indole 1a and 4-methylben-
zenethiol 2a were chosen as the model substrates to opti-
mize the reaction conditions in the presence of various
iodine reagents (Table 1, entries 1–4). Among the iodide-
containing reagents (20 mol%) examined, molecular iodine
was found to be the most efficient catalyst for mediating
the formation of product 3aa in 65 % yield (Table 1, entry
4), others such as NaI, KI, and TBAI did not promote this
reaction (Table 1, entries 1–3). Further optimization of
catalyst loading showed that 5 mol % of iodide was the
best choice, giving the corresponding product 3aa in 87 %
yield (Table 1, entry 8). Moreover, none of product was
detected when the reaction was conducted in the absence of
molecular iodine (Table 1, entry 10). The screening of
various solvents found that CH3CN was the optimal reac-
tion medium (Table 1, entries 8, 11–17). In contrast, only a
trace amount of product 3aa was detected when reaction
was performed in THF, EtOH, or DMF (Table 1, entries
15–17). In addition, the reaction efficiency was obviously
low with the decreasing of reaction temperature (Table 1,
entries 18–19), and only 17 % yield was obtained when
reaction was conducted at room temperature. The appro-
priate proportion of the indole 1a and 4-methylben-
zenethiol 2a was 1:1.5 (Table 1, entries 20–22).
Scheme 1 Molecular iodine-catalyzed regioselective synthesis of
3-thioindoles
metal catalysts, relatively harsh reaction conditions, poor
substrate scope, and the use of stoichiometric amounts of
base or potentially dangerous oxidants. Therefore, it is still
a highly desirable task to develop a convenient and effi-
cient approach to 3-thioindoles directly from thiols.
With our continuous interests in the synthesis of sulfur-
containing compounds [51–61], here, we wish to present a
simple and efficient synthesis method for the direct thio-
lation of indoles with various thiols in the presence of
inexpensive and environmentally friendly iodine under air
conditions (Scheme 1). The present protocol provides a
convenient and highly attractive approach to a variety of
3-thioindoles in good to excellent yields, and does not
require any metal catalyst, base, or peroxide oxidants.
2 Experimental
2.1 General Information
Under the optimized conditions, we then examined the
scope of the thiolation reactions. As shown in Table 2,
generally, aryl thiols bearing an electron-donating group or
an electron-withdrawing group on the aryl rings could react
smoothly to give the corresponding products in good to
excellent yields (3aa–3an). It should be noted the steric
effect of aryl thiols did not affect the yields significantly.
The ortho- or meta-substituted aryl thiols were effectively
reacted with indole to deliver the desired products (3ac–
3aj) in good yields. Moreover, functionalities such as
amino and halogen groups were compatible with this
reaction leading to the products 3ag–3am, which are the
potential substrates for further transformations. As expec-
ted, 2-naphthalenethiol was also tolerated in this process to
afford desired product 3ao obtained in 82 % yield. Nota-
bly, various alkyl thiols such as thiophen-3-ylmethanethiol,
phenylmethanethiol and 2-phenylethanethiol were
All commercially available reagents and chemicals were
purchased from chemical suppliers and used as received
without further purification. All reactions were carried out
under air. Column chromatography was performed on silica
1
gel (200–300 mesh). H NMR (500 MHz) and 13C NMR
(125 MHz) spectra were recorded of samples dissolved in
CDCl3 with TMS as internal standard at room temperature.
Mass analyses and HRMS were obtained on a Finnigan-
LCQDECA mass spectrometer and a Bruker Daltonics Bio-
TOF-Q mass spectrometer by the ESI method, respectively.
2.2 General Procedure for Regioselective Synthesis
of 3-Thioindoles Under Air
Acetonitrile (2 mL) was added into a mixture of indoles 1
(0.25 mmol), thiols 2 (0.375 mmol) and I2 (5 mol %) in a
123

Iodine-catalyzed Direct Thiolation of Indoles with Thiols Leading to 3-Thioindoles Using Air…
Table 1 Screening of the reaction conditions
Entry
Catalyst (mol%)
Solvent
T (oC)
Yield (%)a
1
NaI (20)
KI (20)
TBAI(20)
I2(20)
I2(30)
I2(40)
I2(10)
I2(5)
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
1,4-Dioxane
DMSO
Toluene
DME
80
0
2
80
0
3
80
0
4
80
65
5
80
40
6
80
38
7
80
68
8
80
87
9
I2(2)
80
72
10
11
12
13
14
15
16
17
18
19
20
21
22
I2(0)
80
0
I2(5)
80
29
I2(5)
80
77
I2(5)
80
14
I2(5)
80
10
I2(5)
THF
Reflux
Reflux
80
Trace
Trace
Trace
17
I2(5)
EtOH
I2(5)
DMF
I2(5)
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
25
I2(5)
60
66
I2(5)
80
73b
83c
55d
I2(5)
80
I2(5)
80
Reaction conditions 1a (0.25 mmol), 2a (0.375 mmol), Iodine reagent (0–40 mol%), solvent (2 mL), 25–80 °C, 16 h, under air
a
Isolated yields based on 2a
b
1a (0.5 mmol), 2a (0.5 mmol)
c
1a (0.5 mmol), 2a (0.6 mmol)
d
1a (0.5 mmol), 2a (1 mmol)
suitable for this reaction, with the desired products
obtained in good yields (3ap–3ar). With respect to indoles,
in addition to 1-H indole, some substituted indoles such as
reaction pathway was proposed as shown in Scheme 2.
Initially, the interaction of thiol 2 with molecular iodine
would give electrophilic species R3-SI 4 with the con-
comitant generation of HI [66–71]. Subsequently, the
intermediate 5 could be produced by a direct electrophilic
substitution of indole 2 with R3-SI at the C-3 position.
Next, the loss of HI from 5 led to the formation of desired
product 3. Finally, the formed two equivalents of HI would
be oxidized by air oxygen into molecular iodine to
accomplish the catalytic cycle.
N-methylindole,
2-methylindole,
2-phenylindole,
5-methylindole, and 7-methylindole worked well with this
thiolation reaction to generate the corresponding products
in good yields (3ba–3ei).
Although the detailed reaction mechanism is still
unclear at the present stage, based on the above experi-
ments and previous studies [44–51, 62–71], a possible
123

X. Liu et al.
Table 2 Results for iodine-catalyzed regioselective synthesis of 3-thioindoles
Reaction conditions 1 (0.25 mmol), 2 (0.375 mmol), I2 (5mol%), CH3CN(2 mL), 80 °C, 16 h
Isolated yields based on 1
123

Iodine-catalyzed Direct Thiolation of Indoles with Thiols Leading to 3-Thioindoles Using Air…
11. Khandekar SS, Gentry RD, Van Aller GS, Doyle ML, Chambers
PA, Konstantinidis AK, Brandt M, Daines RA, Lonsdale JT
(2001) J Biol Chem 276:30024
12. Berger JP, Doebber TW, Leibowitz M, Moller DE, Mostley RT,
Tolman RL, Ventre J, Zhang BB, Zhou G (2001) PCT Int. Appl,
WO 0130343
13. Acton JL, Meinke PT, Wood H, Black RM (2004) PCT Int Appl
WO2004/019869 A2
14. Maeda Y, Koyabu M, Nishimura T, Uemura S (2004) J Org
Chem 69:7688
15. De Martino G, Edler MC, La Regina G, Coluccia A, Barbera MC,
Barrow D, Nicholson RI, Chiosis G, Brancale A, Hamel E, Artico
M, Silvestri R (2006) J Med Chem 49:947
16. Cianchi F, Cortesini C, Magnelli L, Fanti E, Papucci L, Schi-
avone N, Messerini L, Vannacci A, Capaccioli S, Perna F, Lulli
M, Fabbroni V, Perigli G, Bechi P, Masini E (2006) Mol Cancer
Ther 5:2716
Scheme 2 Postulated reaction pathway
17. Luker T, Bonnert R, Brough S, Cook AR, Dickinson MR, Dou-
gall I, Logan C, Mohammed RT, Paine S, Sanganee HJ, Sargent
C, Schmidt JA, Teague S, Thom S (2011) Bioorg Med Chem Lett
21:6288
4 Conclusions
18. De Martino G, La Regina G, Collucia A, Edler MC, Barbera MC,
Brancale A, Wilcox E, Hamel E, Artico M, Silvestri R (2004) J
Med Chem 47:6120
In conclusion, a simple and efficient method has been
successfully developed for the synthesis of 3-thioindoles
via molecular iodine-catalyzed direct thiolation of indoles
with thiols using air as the oxidant. In comparison with
previous methods, the present protocol, which possesses
some advantages of cheap and metal-free catalysts, readily-
available starting materials, mild and environmentally
friendly reaction conditions. Further studies on the scope
and application of this reaction are underway.
19. Raban M, Chern L-J (1980) J Org Chem 45:1688
´
20. Hamel P, Preville P (1996) J Org Chem 61:1573
21. Wu Q, Zhao D, Qin X, Lan J, You J (2011) Chem Commun
47:9188
22. Chen M, Huang Z, Zheng Q (2012) Chem. Commun 48:11686
23. Kumaraswamy G, Raju R, Narayanarao V (2015) RSC Adv
5:22718
24. Yang F, Tian S (2013) Angew Chem Int Ed 52:4929
25. Li X, Xu Y, Wu W, Jiang C, Qi C, Jiang H (2014) Chem Eur J
20:7911
26. Browder CC, Mitchell MO, Smith RL, El-Stdayman G (1993)
Tetrahedron Lett 34:6245
27. Li Z, Hong J, Zhou X (2011) Tetrahedron 67:3690
28. Silveira CC, Mendes SR, Wolf L, Martins GM, Mu¨hlen L (2012)
Tetrahedron 68:10464
Acknowledgments This work was supported by the National Natural
Science Foundation of China (No. 21302109, 21302110, and
21375075), the Taishan Scholar Foundation of Shandong Province,
the Natural Science Foundation of Shandong Province
(ZR2015JL004).
29. Ge W, Wei Y (2012) Synthesis 44:934
30. Ge W, Wei Y (2012) Green Chem 14:2066
31. Huang D, Chen J, Dan W, Ding J, Liu M, Wu H (2012) Adv
Synth Catal 354:2123
References
1. Katritzky AR, Pozharskii AF (2000) Handbook of heterocyclic
chemistry. Pergamon Press, Oxford
2. Seigler DS (2001) Plant secondary metabolism. Springer, New
York, p 628
32. Sang P, Chen Z, Zou J, Zhang Y (2013) Green Chem 15:2096
33. Zhou X, Li X (2014) RSC Adv 4:1241
34. Tudge M, Tamiya M, Savarin C, Humphrey GR (2006) Org Lett
8:565
3. Hibino S, Choshi T (2002) Nat Prod Rep 19:148
4. Takayama H, Tsutsumi SI, Kitajima M, Santiarworn D,
Liawruangrath B, Aimi N (2003) Chem Pharm Bull 51:232
5. Humphrey GR, Tsutumi JT (2006) Chem Rev 106:2875
6. Campbell JA, Bordunov V, Borka CA, Browner MF, Kress JM,
Mirzadegan T, Ramesha C, Sanpablo BF, Stabler R, Takahara P,
Villasenor A, Walker KAM, Wang J-H, Welch M, Weller P
(2004) Bioorg Med Chem Lett 14:4741
35. Silveira CC, Mendes SR, Wolf L, Martins GM (2010) Tetrahe-
dron Lett 1:2014
36. Marcantoni E, Cipolletti R, Marsili L, Menichetti S, Properzi R,
Viglianisi C (2013) Eur J Org Chem 1:132
37. Hostier T, Ferey V, Ricci G, Pardo DG, Cossy J (2015) Chem
Commun 51:13898
38. Matsugi M, Gotanda K, Murata K, Kita Y (1997) Chem Commun
15:1387
`
7. Holenz J, Pauwels PJ, Diaz JL, Merce R, Codony X, Buschmann
H (2006) Drug Discov Today 11:283
39. Matsugi M, Murata K, Nambu H, Kita Y (2001) Tetrahedron Lett
42:1077
8. Kochanowska-Karamyan AJ, Hamann MT (2010) Chem Rev
110:4489
9. La Regina G, Edler MC, Brancale A, Kandil S, Coluccia A,
40. Xiao F, Xie H, Liu S, Deng G-J (2014) Adv Synth Catal 356:364
41. Rao H, Wang P, Wang J, Li Z, Sun X, Cao S (2014) RSC Adv
4:49165
´
Piscitelli F, Hamel E, De Martino G, Matesanz R, Dıaz JF,
42. Liu C, Ding L (2015) Org Biomol Chem 13:2251
43. Qi H, Zhang T, Wan K, Luo M (2016) J Org Chem 81:4262
44. Maeda Y, Koyabu M, Nishimura T, Uemura S (2004) J Org
Chem 69:7688
45. Schlosser KM, Krasutsky AP, Hamilton HW, Reed JE, Sexton K
(2004) Org Lett 6:819
Scovassi AI, Prosperi E, Lavecchia A, Novellino E, Artico M,
Silvestri R (2007) J Med Chem 50:2865
10. Ragno R, Coluccia A, La Regina G, De Martino G, Piscitelli F,
Lavecchia A, Novellino E, Bergamini A, Ciaprini C, Sinistro A, Maga
G, Crespan E, Artico M, Silvestri R (2006) J Med Chem 49:3172
123

X. Liu et al.
46. Barraja P, Diana P, Carbone A, Cirrincione G (2008) Tetrahedron
64:11625
59. Wei W, Liu C, Yang D, Wen J, You J, Suo Y, Wang H (2013)
Chem Commun 49:10239
47. Wu G, Wu J, Wu J, Wu L (2008) Synth Commun 38:1036
48. Zhang X, Zhou X, Xiao H, Li X (2013) RSC Adv 3:22280
49. Liu Y, Zhang Y, Hu C, Wan J-P, Wen C (2014) RSC Adv
4:35528
60. Liu X, Cui H, Yang D, Dai S, Zhang T, Sun J, Wei W, Wang H
(2016) RSC Adv 6:51830
61. Wen J, Wei W, Xue S, Yang D, Lou Y, Gao C, Wang H (2015) J
Org Chem 80:4966
50. Zhang H, Bao X, Song Y, Qu J, Wang B (2015) Tetrahedron
71:8885
51. Cui H, Liu X, Wei W, Yang D, He C, Zhang T, Wang H (2016) J
Org Chem 81:2252
62. Hamdouchi C, Sanchez C, Ezquerra J (1998) Synthesis 6:867
63. Ravi C, Mohan DC, Adimurthy S (2014) Org Lett 16:2978
64. Mitra S, Ghosh M, Mishra S, Hajra A (2015) J Org Chem
80:8275
52. Cui H, Wei W, Yang D, Zhang J, Xu Z, Wen J, Wang H (2015)
RSC Adv 5:84657
65. Bagdi AK, Mitra S, Ghosh M, Hajra A (2015) Org Biomol Chem
13:3314
53. Wei W, Wen J, Yang D, Guo M, Wang Y, You J, Wang H (2015)
Chem Commun 51:768
54. Wei W, Wen J, Yang D, Jing H, You J, Wang H (2015) RSC Adv
5:4416
55. Wei W, Liu X, Yang D, Dong R, Cui Y, Yuan F, Wang H (2015)
Tetrahedron Lett 56:1808
66. Fang X-L, Tang R-Y, Zhong P, Li J-H (2009) Synthesis 24:4183
67. Liao Y, Jiang P, Chen S, Qi H, Deng G-J (2013) Green Chem
15:3302
68. Ge W, Zhu X, Wei Y (2013) Adv Synth Catal 355:3014
69. Azeredo JB, Godoi M, Martins GM, Silveira CC, Braga AL
(2014) J Org Chem 79:4125
56. Wei W, Wen J, Yang D, Du J, You J, Wang H (2014) Green
Chem 16:2988
57. Wei W, Li J, Yang D, Wen J, Jiao Y, You J, Wang H (2014) Org
Biomol Chem 12:1861
70. Vieira AA, Azeredo JB, Godoi M, Santi C, da Silva EN Jr, Braga
AL (2015) J Org Chem 80:2120
71. Parumala SKR, Peddinti RK (2015) Green Chem 17:4068
58. Wei W, Wen J, Yang D, Wu M, You J, Wang H (2014) Org
Biomol Chem 12:7678
123
