Figure 3. (a) ORTEP diagram of compound PFBT with displacement ellipsoids at a 50% probability level at 110 K. (b) Packing diagram of
compound PFBT along the a axis showing type I and type II F···F contacts along with π···π stacking.
obtained by slow evaporation of ethanol at ambient temper-
atures. Both compounds, PFBT and Br-PFBT, are exhibiting
the type II halogen contacts (Table S2 of the Supporting
Information). The compound PFBT23 crystallizes in a
monoclinic space group P21/n with Z = 2 and Z′ is 1/2. In
crystal packing, molecules are arranged in herringbone packing
along the a direction (Figure 3b). The packing shows habitual
type I F···F contacts in between F4 and F2 of two adjacent
molecules at a distance of 2.83 Å, where the angles are 137.4°
and 135.9° for ∠C5″-F2″···F4 and ∠C3−F4···F2″, respectively
(Figure 3). The structure determined for PFBT exhibited the
type II fluorine contacts at a short distance of 2.67 Å in between
the F5 and F3 of the two adjacent molecules, where the angles
are θ1 = 89.1° and θ2 = 174.2° for ∠C4′-F3′···F5 and ∠C2−
F5···F3′, respectively (Figure S1 of the Supporting Informa-
tion). As mentioned earlier, the CSD search reveals only two
molecules (distance: 2.6−2.7 Å, angles: 60−90° and 150−
180°), where the first molecule confirms type II contact at a
functional of Lee, Yang, and Parr29 (B3LYP keyword in
Gaussian09). Basis set superposition errors (BSSEs) were
accounted for the counterpoise correction method.30 From
these calculations, it was found that the dimer interaction
energy is 8.1 kJ/mol, confirming the attractive nature of the
type II F···F interaction.
HIRSHFELD SURFACE ANALYSIS
■
Further, the intermolecular contacts in the crystal structure of
PFBT are quantified via the Hirshfeld surface analysis,31,32
using the crystal explorer.33 Through the Hirshfeld surface
analysis, one can visualize the intermolecular interactions in
crystal structures.34,35 In the current study, the contacts
involving F atoms and H···F are mainly estimated. The
percentage of contributions to the Hirshfeld surface areas for
these contacts and “other” (F···C, C···S, C···C, H···S, and
N···C) intermolecular contacts are shown in Figure S3 of the
Supporting Information. The analysis shows the F···F halogen
contact as the dominating one (45.0%) in terms of Hirshfeld
surface sharing, whereas only ∼12% contribution comes from
the H···F contacts. The C···F and C···C contacts both
contribute ∼30.0% to the Hirshfeld surface areas. However, it
is notable that these percentage contributions do not
distinguish between the close and distant contacts. The major
contacts C−F···F−C halogen contacts are predominantly
highlighted by conventional mapping of dnorm on molecular
Hirshfeld surfaces (Figure 4). The dark red spots on the
Hirshfeld surfaces indicate the F···F interaction.
24
́
distance of 2.68 Å, in which the angles were 88.1° and 160.6°.
The second molecule shows angles 87.7° and 163.4°,
25
́
respectively, where the distance is 2.69 Å. Apart from having
a shorter F···F contact, the PFBT molecule shows π···π stacking
between the thiazole rings and the phenyl rings. The distance
between cg(1a) and cg(thiazole)(2b) is 3.58 Å, whereas the
same remains for cg(1b′) and cg(thiazole)(2a′) (Figure S2 of
the Supporting Information).
Seik Weng Ng has reported the structure of the phenyl
derivative which shows no specific or significant interactions in
the packing.26 Substitution of hydrogen by fluorine provides
evidence for strong intermolecular type II halogen−halogen
interactions and π···π stacking. This molecule demonstrates the
type I and type II fluorine contacts which were depicted in
Figure 3b.
The energies of monomer PFBT and its dimer were
calculated using Gaussian09. Single crystal coordinates were
used as input for calculations. These Gaussian calculations
employed the split-valence double-exponential 6-31G++(d,p)
basis sets with polarization functions.27 DFT calculations in
Gaussian09 were performed with Becke’s three-parameter
hybrid method,28 combined with the nonlocal correlation
Substitution of bromine in place of hydrogen atoms in PFBT
leads the compound Br-PFBT36 to crystallizes in a monoclinic
space group P21/c with Z = 2, whereas Z′ = 1/2. The hydrogen
atoms in the compound PFBT are replaced by bromine atoms
in this molecule, which shows significant variability from
compound PFBT in packing. The molecules are arranged in a
herringbone manner (Figure 5b), even though the size,
electronegativity, and the repulsion between fluorine and
bromine leads to the twisting of two pentafluorophenyl rings
at a dihedral angle of 59.2°.This guided the packing of Br-PFBT
to be different from that of compound PFBT. Prior to our
attention, this compound also shows type II halogen−halogen
