60
S. Gandomkar, Z. Habibi / Journal of Molecular Catalysis B: Enzymatic 110 (2014) 59–63
of 1,2-dihydro-˛-santonin has not been studied before by any
fungal strains, this compound was selected for investigating the
biotransformation ability of two mentioned strains.
In the previous reports on the biotransformation of 6˛-santonin
by fungal strains, the yield of the products was low. Despite var-
ious studies on bioconversion of 6˛-santonin, trying to find new
strains for its bioconversion and the production of pharmaceuti-
cal ingredients or precursors with good yield is still a great deal of
interest.
acetate. The extract was evaporated under reduced pressure on a
rotary evaporator. The concentrated residue was re-dissolved in
chloroform and loaded on preparative TLC with n-hexane/ethyl
acetate (4:6 v/v). All the purified metabolites were identified by
spectral data. Further support was obtained by comparison with
literature data.
2.6. Analytical methods
1H NMR spectra were recorded using a Bruker Avance-300 MHz
spectrometer with tetramethylsilane (TMS) as internal standard in
CDCl3. Chemical shifts (ı) are given in parts per million (ppm) rel-
ative to TMS. Mass (MS) spectra were obtained on a Finnigan MAT
TSQ-70 instrument by electron impact (EI) at 70 eV. Infrared (IR)
spectra were recorded using KBr disks on a Magna-IR 550 Nicolet
FTIR spectrometer. Thin layer chromatography (TLC) and prepar-
ative TLC was performed on 20 × 20 cm 0.25-mm thick layers of
silica gel G (Silica gel 60 GF254, Merck). Layers were prepared on
glass plates and activated at 110 ◦C 1 h before use.
2. Experimental
2.1. Materials
6˛-Santonin was purchased from Sigma–Aldrich (Taufkirchen,
Germany). Yeast extract and agar were purchased from Scharlau
(Barcelona, Spain). Inorganic salts, analytical grade reagents, sol-
vents and silica gel 60 GF254 fluorescent thin layer chromatographic
plates (TLC) were obtained from Merck (Darmstadt, Germany).
2.2. Microorganisms and cultural conditions
3. Result
The fungal strains A. chrysogenum PTCC 5271 and R. pusillus PTCC
5134 were obtained from the Persian type culture collection (Ira-
nian Research Organization for Science and Technology).
3.1. Biotransformation of 6˛-santonin by A. chrysogenum and R.
pusillus
R. pusillus was maintained on potato-dextrose agar plates (com-
position, g/L: glucose 20 g, diced potatoes 300 g, agar 15.0 g) and A.
chrysogenum was maintained on yeast extract agar plates (yeast
extract, 4.0 g; soluble starch, 15.0 g; K2HPO4, 1.0 g; MgSO4•7H2O,
0.5 g; agar, 15.0 g, distilled water, 1000.0 ml) at 4 ◦C and freshly
sub-cultured before using in the transformation experiment. All
media were sterilized by autoclaving at 121 ◦C for 20 min. Ten 250-
ml Erlenmeyer flasks, each containing 150 ml of liquid medium of
potato-dextrose broth for R. pusillus and ten 250 ml Erlenmeyer
flasks, each containing 150 ml of liquid medium of yeast extract
broth for A. chrysogenum, were inoculated with freshly obtained
spores from agar slope cultures and incubated 24 h at 26 ◦C in a
rotary shaker (120 rpm).
chrysogenum, four metabolites 2–5 and by R. Pusillus, two metabo-
lites 2 and 3 were obtained. On the basis of the spectral data
including 1H NMR, FT-IR and MS, the structures of the products
were identified (Scheme 1). Their chemical and spectral data were
in a good agreement with those reported in the literature. The
observed bioconversion reactions were: C1–C2 double bond reduc-
tion in 2, C-8 hydroxylation in 3, 15-methyl hydroxylation in 4 and
C4–C5 double bond reduction in 5.
3.2. Biotransformation of 1,2-dihydro-˛-santonin by A.
chrysogenum and R. pusillus
Biotransformation of 1,2-dihyro-˛-santonin by A. chrysogenum
and R. pusillus produced tetrahydro-˛-santonin (6) and tetrahy-
droartemisin (7) by different yields (Scheme 2). The physical and
spectral data were in good agreement with literature. The observed
bioconversion reaction was reduction of C4–C5 double bond in
The obtained yields of all the metabolites from the biotransfor-
mation of 6˛-santonin and 1,2-dihyro-˛-santonin by two fungi and
a comparison of them with previously reported yields is shown in
Table 1. Chemical shifts of all metabolites are shown in Table 2.
2.3. Synthesis of 1,2-dihydro-˛-santonin
A mixture of 1 g of 6˛-santonin (4 mmol), 30 ml of dried CH2Cl2
and 150 mg of 2% Pd–C was stirred under 1 atm H2 at room tem-
perature for 10 h. Then the catalyst was removed and the filtrate
was concentrated under reduced pressure on a rotary evapora-
tor. The concentrated residue was re-dissolved in chloroform and
loaded on preparative TLC with n-hexane/ethyl acetate (7:3 v/v) for
further purification. Finally, 1,2-dihydro-˛-santonin was separated
and purified (60% yield) for using in biotransformation reaction.
2.4. General procedure for the biotransformation of 6˛-santonin
and 1,2-dihydro-˛-santonin using whole cells
4. Discussion
After preparation of fermentation media, 6˛-santonin (1 g) was
dissolved in acetone (10 ml); 1 ml of the solution was added to each
250-ml Erlenmeyer flask for each fungi. Higher concentrations of
substrate resulted in lower conversion and a decrease in metabo-
lites yields. The reaction was monitored by TLC. After 8 days of
incubation under the same conditions, the highest conversion was
achieved.
Metabolite 2: The MS spectrum of metabolite 2 showed a
molecular ion peak at m/z 248 and provided the molecular formula
C15H20O3, which was two units higher than 6˛-santonin suggest-
ing that double bond reduction was occurred. The optical rotation
of this metabolite was measured; [˛]D25 +90◦ (c 6.1, CHCl3) (lit. [14],
[˛]D +89◦). In 1H NMR spectrum of compound 2, elimination of
25
signals at ı 6–6.7 confirmed reduction of C1–C2 double bond. Dou-
blet at ı 4.67 was related to H-6. Addition of signals at ı 2.44 and
ı 2.52 related to H-2a and 2b confirmed the structure. Singlet at
ı 1.98 was related to Me-15. Chemical shift for this methyl group
showed olefinic structure at C-4.
2.5. Extraction of 6˛-santonin and 1,2-dihydro-6˛-santonin
transformation metabolites
At the end of incubation, all identical fermentation broths were
combined and extracted three times with equal volume of ethyl
Previously, 1,2-dihydro-˛-santonin (2) was obtained from
the incubation of 6˛-santonin with Cunninghamella bainieri,
