Ruthenium-catalyzed cycloisomerization of cis-3-en-1-ynes to cyclopentadiene and related derivatives through a 1,5-sigmatropic hydrogen shift of ruthenium vinylidene intermediates

Article abstract of DOI:10.1021/ja053674o

We report a new ruthenium-catalyzed cycloisomerization of unactivated cis-3-en-1-ynes, which produces substituted cyclopentadiene and related derivatives. The mechanism of this cyclization is proposed to involve a [1,5]-sigmatropic hydrogen shift of ruthenium-vinylidene intermediates on the basis of deuterium-labeling experiments. Copyright

Full text of DOI:10.1021/ja053674o

Published on Web 07/27/2005
Ruthenium-Catalyzed Cycloisomerization of cis-3-En-1-ynes to
Cyclopentadiene and Related Derivatives through a 1,5-Sigmatropic Hydrogen
Shift of Ruthenium-Vinylidene Intermediates
Swarup Datta, Arjan Odedra, and Rai-Shung Liu*
Department of Chemistry, National Tsing-Hua UniVersity, Hsinchu, Taiwan, ROC
Received June 4, 2005; E-mail: rsliu@mx.nthu.edu.tw.
Scheme 1
The [1,5]-sigmatropic hydrogen shift is a useful tool in organic
synthesis,1-4 and it has been employed frequently in the synthesis
of complex bioactive molecules.1 This process occurs very ef-
ficiently with cis-1,3-dienes,1,2 cis-1-alkyl-2-vinylcyclopropanes1,3
and cis-1-allen-4-enes1,4 at suitable conditions (Scheme 1, eqs 1-3),
but it proceeds sluggishly with cis-3-en-1-ynes even at elevated
temperatures.3a One possible approach to realize the [1,5]-hydrogen
shift of cis-3-en-1-ynes is to mimic the thermal rearrangement of
cis-1-allen-4-enes, using a suitable metal species to generate metal-
vinylidene intermediates (eq 4). To the best of our knowledge,
examples of such reactions have never been documented, even
Scheme 2
though there is considerable interest in metal-vinylidene chemis-
try.5 On the basis of this strategy, we report here a new ruthenium-
catalyzed cycloisomerization of cis-3-en-1-ynes into cyclopenta-
diene and related derivatives, which are appealing building blocks
to construct the skeletons of complex molecules.6,7
As shown in Scheme 2, treatment of 1-ethynyl-3-ols 1 and 2
with p-toluenesulfonic acid (p-TSA, 5 mol %) in hot toluene (110
°C, 12 h) gave cis-3-en-1-ynes 3 (91%) and 4 (92%), respectively.
The cis-configuration of enynes 3,4 was confirmed by proton NOE
spectra.8 Heating a benzene solution (80 °C) of alcohol 1 (Ar )
2-methoxyphenyl, 0.15 M) with TpRuPPh3(CH3CN)2PF69 (10 mol
%, Tp ) tris(1-pyrazolyl)borate) for 4 h gave cyclopentadiene 5
in 51% yield and enyne 3 (40%). At a longer period (12 h, entry
a [Ru] ) 10 mol % TpRuPPh3(CH3CN)2PF6. b[substrate] ) 0.15 M, 80
2), the desired diene 5 was obtained up to 79% yield with complete
consumption of enyne 3. Entry 3 confirms that cis-enyne 3 is truly
c
°C. Yields were reported after separation from a silica column.
the active intermediate in the cyclization of alcohol 1 to diene 5.
Heating species 3 with the catalyst (10 mol %) in benzene (80 °C,
12 h) produced diene 5 in 80% yield; structural assignment of diene
5 was based on the 1H NOE spectra.8 Similarly, the alcohol 2 (Ar
) 2-thienyl) and its cis-enyne derivative 4 were shown to be equally
active in this catalytic cyclization; they each gave diene 6 in 65-
66% yields (entries 4 and 5). The ruthenium catalyst has dual roles
in catalytic activities: dehydration of 1-ethynyl-3-ols and cyclization
of cis-enyne.
To examine the generality of this cycloisomerization, we used
various 1-ethynyl-3-ols 7-16 (Table 1) in the catalytic cyclization
because these alcohols are equally active as their dehydrated cis-
enyne derivatives. Most of these alcohols bear aryl or heteroaryl
substituents at their C(3) and C(5) carbons to ensure the formation
of a single and thermally stable cyclopentadiene regioisomer.10
Entries 1-3 reveal that the C(5)-phenyl substituent of alcohols 7
was catalytically as active as their 4-MeOPh and 4-CF3Ph analogues
8 and 9. This ruthenium catalyst is also active in the cyclizations
of alcohols 10-11 bearing a furyl group and gave cyclopentadienes
27-28 in 62-65% yields. Entries 6-8 indicate the effects of
alternating the C(3)-phenyl substituent of the alcohols 12-14; the
benzene group (12) produces a greater yield of cyclized product
than do the reactions of its 4-tolyl (13) and 4-CF3Ph counterparts
(14). The value of this cyclization is highlighted by its applicability
to the activation of a non-benzylic C-H bond, as represented by
substrates 15 and 16. The corresponding cylopentene products 32
and 33 were obtained in 71% and 53% yields, respectively (entries
9 and 10). The molecular structures of cyclopentadiene 29 and
cyclopentene 33 were also characterized by X-ray diffraction
studies.8 The high efficiencies were maintained when this cycliza-
tion was applied to the synthesis of trisubstituted cyclopentene 34-
35 (80-84%) and cyclopentene 36 (89%) from cis-enyne substrates
17-19. Entries 14-17 show additional instances for cyclization
of cis-enynes 20-23 via a non-benzylic C-H bond activation, and
the cyclized products 37-39 and 34 were obtained in 71-79%
yields. This new approach is very useful to construct bicyclic
carbocyclic skeletons because only one regioisomer was formed
exclusively (entries 11, 12, 14-17).
As shown in Scheme 3 (eq 1), the alkynyl deuterium of d1-3
produced the diene d1-5 bearing only 21% deuterium excess at the
CHdCPh carbon. The remaining three diene protons of d1-5
contained a total 0.42D content according to mass analysis.11 The
1,5-hydrogen shift2,6-7 of the cyclopentadiene framework hampers
a precise interpretation of 2H NMR labeling studies. Using a highly
deuterated enyne d3-3 circumvented this problem. Equation 2 shows
the deuterium distribution of diene d3-5 generated from this d3-3
enyne. The kinetic isotope effect of the CD2 group of d3-5 inhibits
this 1,5-hydrogen shift.12 Notably, one CeD2Ph deuterium of species
9
11606
J. AM. CHEM. SOC. 2005, 127, 11606-11607
10.1021/ja053674o CCC: $30.25 © 2005 American Chemical Society

C O M M U N I C A T I O N S
Table 1. Ruthenium-Catalyzed Cyclization of 1-Ethynyl-3-ols and
cis-Enynes
a reaction intermediate, which equilibrates with its σ-allyl species
F and would ultimately generate diene d3-5 bearing a deuterium
distribution inconsistent with our observation.
Although cis-3-en-1-yne is a common and practical functional-
ity,14 cycloisomerization of this moiety into a cyclopentadiene or
related framework is unprecedented before our findings. Here we
report that TpRuPPh3(CH3CN)2PF6 implements the cycloisomer-
ization of unactivated cis-3-en-1-ynes and efficiently produces stable
cyclopentadiene and related derivatives. The mechanism of this
cyclization is proposed to involve a [1,5]- sigmatropic hydrogen
shift of ruthenium-vinylidene intermediates on the basis of
deuterium-labeling experiments.
Acknowledgment. We thank the National Science Council,
Taiwan, for supporting this work.
Supporting Information Available: NMR spectra, spectral data
2
1
of compounds 1-39, NMR spectra of H-labeled d3-3 and d3-5, H
NOE spectra of 3, 5, 37, and 39, and X-ray structural data of cyclized
products 29 and 33. This material is available free of charge via the
Internet at http://pubs.acs.org.
References
(1) (a) Robin, M. J.; Guo, Z. O.; Samano, M. C.; Wnuk, S. F. J. Am. Chem.
Soc. 1999, 121, 1425. (b) Okamura, W. H.; Aurrecoechea, J. M.; Gibbs,
R. A.; Norman, A. W. J. Org. Chem. 1989, 54, 4072. (c) Chandraratna,
R. A. S.; Bayerque, A. L.; Okamura, W. A. J. Am. Chem. Soc. 1983,
105, 3588.
(2) (a) Alabugin, I. V.; Manoharan, M.; Breiner, B.; Lewis, F. D. J. Am. Chem.
Soc. 2003, 125, 9329 and references therein. (b) Kless, A.; Nendel, M.;
Willsey, S.; Houk, K. N. J. Am. Chem. Soc. 1999, 121, 4524. (c)
Loncharich, R. J.; Houk, K. N. J. Am. Chem. Soc. 1988, 110, 2089. (d)
Hess, B. A., Jr.; Baldwin, J. E. J. Org. Chem. 2002, 67, 6025. (e) Replogle,
K. S.; Carpenter, B. K. J. Am. Chem. Soc. 1984, 106, 5751.
a 10 mol % catalyst, [substrate] ) 0.15 M, benzene, 80 °C, 12 h. b Product
yields were given after separation from a silica column. c Diene 38 was
obtained in a 10:1 mixture of two isomers, and only the major isomer was
shown.
Scheme 3
(3) (a) Hudlicky, T.; Reed, J. W. In ComprehensiVe Organic Synthesis; Trost,
B. M., Fleming, I., Eds.; Pergamon Press: Oxford, 1991; Vol. 5, Part
8.1, p 899. (b) Lin, Y.-L.; Turos, E. J. Am. Chem. Soc. 1999, 121, 856.
(c) Parziale, P. A.; Berson, J. A. J. Am. Chem. Soc. 1990, 112, 1650. (d)
Spangler, C. W. Chem. ReV. 1976, 76, 187.
(4) (a) Wu, K.-M.; Midland, M. M.; Okamura, W. H. J. Org. Chem. 1990,
55, 4381. (b) Shen, G. Y.; Tapia, R.; Okamura, W. H. J. Am. Chem. Soc.
1987, 109, 7499.
Scheme 4
(5) (a) Trost, B. M. Acc. Chem. Res. 2002, 35, 695. (b) Bruneau, C.; Dixneuf,
P. Acc. Chem. Res. 1999, 32, 311. (c) Bruneau, C. Top. Organomet. Chem.
2004, 11, 125.
(6) (a) Winterfieldt, E. Chem. ReV. 1993, 93, 827. (b) Corey, E. J.; Cheng
X.-M. The Logic of Chemical Synthesis; Wiley: New York, 1989; Chapter
7, p 249.
(7) (a) Walters, M. A.; Arcand, H. R. J. Org. Chem. 1996, 61, 1478. (b)
Leach, A. G.; Goldstein, E.; Houk, K. N. J. Am. Chem. Soc. 2003, 125,
8330.
(8) The 1H NOE spectra of compounds 3, 5, 37, and 39 and X-ray diffraction
studies of compounds 29 and 33 are provided in Supporting Information.
(9) For formation of metal-vinylidene intermediates using this catalyst, see:
Lian, J.-J.; Odedra, A.; Wu, C.-J.; Liu, R.-S. J. Am. Chem. Soc. 2005,
127, 4186 and our related work cited therein.
(10) Substituted cyclopentadienes readily undergo a [1,5]-hydrogen shift and
form several regioisomers. In this study, the aromatic substituent of
cyclized products tends to conjugate with diene functionality to give one
single regioisomer, which is inactive toward intramolecular [4+2]-
cycloaddition under catalytic conditions.
(11) The d1-5 and d3-5 samples were obtained at catalytic reactions at 30%
conversion level (80 °C, 3 h). In the case of sample d1-5, a loss of 23%
deuterium content is caused by the proton exchange of the alkynyl proton
of species d1-5 with residual water. This is a common phenomenon for
metal-vinylidene chemistry; see our related work.9
(12) Heating diene d3-5 in hot benzene (80 °C, 16 h) led to a 96% and 91%
recovery of this sample in the absence and presence of ruthenium catalyst,
respectively. Its Cb-H proton content was decreased to 0.55H and 0.46H,
respectively.
(13) (a) Maier, G. Angew. Chem., Int. Ed. Engl. 1967, 6, 402. (b) Tessier, P.
L.; Nguyen, N.; Clay, M. D.; Fallis, A. G. Org. Lett. 2005, 7, 767. (c)
Rautenstrauch, V. J. Org. Chem. 1984, 49, 950.
d3-3 relocates to the CD2 fragment of diene d3-5, and the other
deuterium is present at the Ca-carbon of d3-5. In this transformation,
the alkynyl proton of d3-3 undergoes a 1,2-shift to relocate to the
Cb-carbon of d3-5.
Scheme 4 shows a plausible mechanism to rationalize the
deuterium-labeling experiments. The 1,2-shift of the alkynyl
hydrogen of d3-3 indicates the formation of ruthenium-vinylidene
intermediate5 A, which undergoes a subsequent 1,5-sigmatropic shift
to generate ruthenahaxa-3,5-triene B. A subsequent 6π-electro-
cyclization13 of species B gives ruthenacyclohexa-2,4-diene species
C. Reductive elimination of this Ru(IV)-triene species produces
cyclopentadiene D and ultimately yields the most stable regioisomer
d3-5 via a 1,5-hydrogen shift. The deuterium distribution of d3-5
in Scheme 3 precludes an involvement of ruthenium-π-allyl E as
(14) For metal-catalyzed reactions of 3-en-1-ynes, see (a) Saito, S.; Yamamoto,
Y. Chem. ReV. 2000, 100, 2901. (b) Nieto-Oberhuber, C.; Lopez, S.;
Echavarren, A. M. J. Am. Chem. Soc. 2005, 127, 6178. (c) Saito, S.;
Ohmori, O.; Yamamoto, Y. Org. Lett. 2000, 2, 3853.
