Organometallics
Article
solution was neutralized by slow addition of a saturated aqueous
solution of NaOH. The water phase was extracted with CH2Cl2. The
combined organic extracts were dried over Na2SO4, filtered, and
concentrated to afford L1 as a white solid (2.30 g, 93%). Mp: 155−
159 °C. HR-MS (ESI) Calcd for C11H10N2O + H: 187.0871. Found:
Method B. NEt3 (0.017 g, 0.16 mmol) was added into a solution of
1 (0.05 g, 0.08 mmol) in CH3OH (5 mL) under stirring for 1 h.
Then, the precipitate was filtered off and the filtrate was concentrated.
The crude product was washed with ether to give 2 as a yellow
powder (0.036 g, 76%).
Synthesis of 3. A solution of 6-hydroxy-2,2′-bipyridine (0.1 g,
0.58 mmol) and [Cp*IrCl2]2 (0.24 g, 0.29 mmol) was refluxed in
dried CH3OH (15 mL) with stirring for 24 h. The mixture was
allowed to cool to room temperature, and the yellow precipitate was
collected, washed with acetone, and dried under vacuum to provide 3
as a yellow powder (0.15 g, 90%). Mp: 178 °C (dec.). Anal. Calcd for
C20H23Cl2IrN21O: C, 42.10; H, 4.06; N, 4.91. Found: C, 42.26; H,
4.07; N, 4.88. H NMR (400 MHz, DMSO-d6, ppm): 13.78 (s, 1H),
8.93 (d, J = 4.8 Hz, 1H), 8.64 (d, J = 8.4 Hz, 1H), 8.26 (t, J = 8.0 Hz,
1H), 8.14 (d, J = 7.6 Hz, 1H), 8.05 (t, J = 8.0 Hz, 1H), 7.80 (t, J = 6.4
Hz, 1H), 7.31 (d, J = 7.6 Hz, 1H), 1.60 (s, 15H). No satisfactory 13C
NMR data could be obtained due to low solubility.
Synthesis of 4. A solution of 2-(2-pyridylmethyl)pyridine (0.25 g,
1.47 mmol) and [Cp*IrCl2]2 (0.6 g, 0.74 mmol) was refluxed in dried
CH3OH (20 mL) with stirring for 24 h. The mixture was allowed to
cool to room temperature, and the yellow precipitate was collected,
washed with acetone, and dried under vacuum to provide 4 as a
yellow powder (0.23 g, 84%). Mp: 175−177 °C (dec.). Anal. Calcd
for C21H25Cl2IrN2: C, 44.36; H, 4.43; N, 4.93. Found: C, 44.23; H,
4.47; N, 4.84. 1H NMR (400 MHz, DMSO-d6, ppm): 8.76 (d, J = 5.8
Hz, 2H), 8.09 (t, J = 7.6 Hz, 2H), 7.91 (d, J = 7.6 Hz, 2H), 7.57 (t, J =
5.8 Hz, 2H), 4.90 (d, J = 15.6 Hz, 1H), 3.78 (d, J = 15.6 Hz, 1H),
1.55 (s, 15H). 13C NMR (100 Hz, DMSO-d6, ppm): 156.3, 155.6,
141.3, 126.3, 126.1, 88.6, 46.0, 8.8.
1
187.0872. H NMR (400 MHz, CDCl3, ppm): 8.62 (d, J = 4.0 Hz,
1H), 7.70 (t, J = 8.0 Hz, 1H), 7.38−7.34 (m, 2H), 7.27−7.24 (m,
1H), 6.45 (d, J = 8.8 Hz, 1H), 6.14 (d, J = 6.8 Hz, 1H), 4.04 (s, 2H)
(the −OH proton did not appear). 13C NMR (100 Hz, CDCl3, ppm):
165.3, 156.6, 149.5, 146.6, 141.7, 137.1, 123.7, 122.2, 117.7, 106.0,
41.2.
Synthesis of 2-(tert-Butoxy)-6-((6-methoxypyridin-2-yl)-
methyl)pyridine. A solution of n-BuLi (11.7 mL, 2.4 M, 28.1
mmol) was added to 2-methoxy-6-methylpyridine (3.6 g, 28.1 mmol)
in 50 mL of THF at −78 °C. When temperature naturally warmed to
−20 °C, 2-bromo-6-tert-butoxypyridine (3.2 g, 13.9 mmol) was
added. The reaction mixture was stirred at −20 °C for 3 h and
refluxed overnight. After addition of 25 mL of water, the water phase
was extracted with CH2Cl2. The crude product was purified by
column chromatography on silica gel (petroleum ether/ethyl acetate,
v/v = 5:1) to give 2-(tert-butoxy)-6-((6-methoxypyridin-2-yl)methyl)-
pyridine (3.0 g, 80%) as a yellow liquid. HR-MS (ESI) Calcd for
1
C16H20N2O2 + H: 273.1603. Found: 273.1601. H NMR (400 MHz,
CDCl3, ppm): 7.48−7.40 (M, 2H), 6,78−6.76 (M, 2H), 6.55 (d, J =
8.4 Hz, 1H), 6.47 (d, J = 8.4 Hz, 1H), 4.08 (s, 2H), 3.90 (s, 3H), 1.51
(s, 9H). 13C NMR (100 Hz, CDCl3, ppm): 163.6, 163.3, 157.7, 156.8,
138.7, 116.1, 115.4, 110.4, 107.7, 79.3, 53.2, 46.6, 28.6.
Synthesis of 2-Hydroxy-6-((6-methoxypyridin-2-yl)methyl)-
pyridine. A solution of 2-(tert-butoxy)-6-((6-methoxypyridin-2-
yl)methyl)pyridine (0.6 g, 2.2 mmol) in 5 mL of CH2Cl2 and 8 mL
of CF3COOH was stirred for 30 min at room temperature. The
solution was neutralized by slow addition of a saturated aqueous
solution of NaOH. The water phase was extracted with CH2Cl2. The
combined organic extracts were dried over Na2SO4, filtered, and
concentrated to afford 2-hydroxy-6-((6-methoxypyridin-2-yl)methyl)-
pyridine as a yellow solid (0.44 g, 91%). Mp: 146 °C. HR-MS (ESI)
Synthesis of 5. A solution of 2-methoxy-6-((6-methoxypyridin-2-
yl)methyl)pyridine (0.10 g, 0.43 mmol) and [Cp*IrCl2]2 (0.18 g, 0.22
mmol) was refluxed in dried CH3OH (15 mL) with stirring for 24 h.
The mixture was allowed to cool to room temperature, and the
precipitate was collected, washed with acetone, and dried under
vacuum to provide 5 as a yellow powder (0.12 g, 89%). Mp: 171 °C
(dec.). Anal. Calcd for C23H29Cl2IrN2O2: C, 43.95; H, 4.65; N, 4.46.
1
Calcd for C12H12N2O2 + H: 217.0977. Found: 217.0979. H NMR
1
Found: C, 43.93; H, 4.65; N, 4.69. H NMR (400 MHz, DMSO-d6,
(400 MHz, CDCl3, ppm): 12.43 (s, 1H), 7.50 (t, J = 8.0 Hz, 1H),
7.36−7.32 (m, 1H), 6.87 (d, J = 7.2 Hz, 1H), 6.63 (d, J = 8.0 Hz,
1H), 6.43 (d, J = 9.2 Hz, 1H), 6.10 (d, J = 6.8 Hz, 1H), 3.94 (s, 2H),
3.93 (s, 3H). 13C NMR (100 Hz, CDCl3, ppm): 164.9, 163.8, 153.8,
146.5, 141.5, 139.4, 117.7, 115.9, 109.3, 105.6, 53.5, 40.7.
ppm): 7.62 (t, J = 7.6 Hz, 2H), 6.86 (d, J = 7.2 Hz, 2H), 6.64 (d, J =
8.0 Hz, 2H), 4.05 (s, 2H), 3.81 (s, 6H), 1.63 (s, 15H). 13C NMR
(100 Hz, DMSO-d6, ppm): 163.5, 157.4, 139.9, 116.6, 108.4, 92.6,
55.4, 53.3, 8.7.
Synthesis of 6. A solution of 2-hydroxy-6-((6-methoxypyridin-2-
yl)methyl)pyridine (0.10 g, 0.46 mmol) and [Cp*IrCl2]2 (0.19 g, 0.23
mmol) was refluxed in dried CH3OH (15 mL) with stirring for 24 h.
The mixture was allowed to cool to room temperature and the
precipitate was collected, washed with acetone and dried under
vacuum to provide 6 as a yellow powder (0.13 g, 91%). Mp: 170 °C
(dec.). Anal. Calcd for C22H27Cl2IrN2O2: C, 42.99; H, 4.43; N, 4.56.
Synthesis of 1. A solution of L1 (0.09 g, 0.48 mmol) and
[Cp*IrCl2]2 (0.2 g, 0.25 mmol) was refluxed in dried CH3OH (20
mL) with stirring for 24 h. The mixture was allowed to cool to room
temperature and the yellow precipitate was collected, washed with
acetone, and dried under vacuum to provide 1 as a yellow solid (0.23
g, 82%). Single crystals suitable for X-ray crystallographic determi-
nation were grown with CH3OH/ether at 0 °C. Mp: 195 °C (dec.).
Anal. Calcd for C21H25Cl2IrN2O: C, 43.15; H, 4.31; N, 4.79. Found:
1
Found: C, 42.78; H, 4.55; N, 4.55. H NMR (400 MHz, DMSO-d6,
1
ppm): 11.6 (s, 1H), 7.66 (t, J = 7.6 Hz, 1H), 7.34 (t, J = 7.6 Hz, 1H),
6.89 (d, J = 7.2 Hz, 1H), 6.69 (d, J = 8.4 Hz, 1H), 6.17 (d, J = 8.4 Hz,
1H), 5.98 (d, J = 5.6 Hz, 1H), 3.86 (s, 2H), 3.81 (s, 3H), 1.63 (s,
15H). 13C NMR (100 Hz, DMSO-d6, ppm): 163.6, 163.5, 155.4,
147.5, 141.5, 140.3, 117.5, 116.3, 109.0, 105.0, 92.6, 55.4, 53.4, 8.7.
General Procedure for the Alkylation of Anilines. Under air
condition, in a 25 mL Schlenk tube, a mixture of amines (1.0 mmol),
methanol (2 mL), complex 1 (5.8 mg, 1 mol %), trialkyl amines (2.0
mmol), and NEt3·HCl (20%, 0.2 mmol) were stirred at 120 °C for 12
h. Then, it was allowed to cool to room temperature, and 0.1 mL of
the reaction mixture was sampled and immediately diluted with 5 mL
of CH3OH precooled to 0 °C for GC analysis for calculating
conversation and product selectivity of the reaction. After the reaction
was completed, the reaction mixture was condensed under reduced
pressure and subjected to purification by flash silica gel column
chromatography to afford the target product, which was identified by
NMR analyses. All analytical data of the known compounds are
consistent with those reported in the literature.
C, 43.43; H, 4.32; N, 4.81. H NMR (400 MHz, DMSO-d6, ppm):
13.03 (s, 1H), 8.71 (d, J = 5.6 Hz, 1H), 8.04 (t, J = 7.6 Hz, 1H), 7.83
(d, J = 7.6 Hz, 1H), 7.78 (t, J = 8.0 Hz, 1H), 7.52 (t, J = 6.4 Hz, 1H),
7.26 (d, J = 7.2 Hz, 1H), 7.02 (d, J = 8.4 Hz, 1H), 4.68 (d, J = 14.8
Hz, 1H), 3.70 (d, J = 14.8 Hz, 1H), 1.56 (s, 15H). 13C NMR (100
Hz, DMSO-d6, ppm):165.6, 157.4, 155.7, 153.4, 142.6, 141.0, 125.6,
125.3, 116.7, 111.4, 88.1, 49.1, 9.2.
Synthesis of 2. Method A. NaOtBu (0.039 g, 0.41 mmol) was
added into a solution of 1 (0.2 g, 0.34 mmol) in H2O (10 mL) under
stirring for 1 h. Then, the precipitate was filtered off, and the filtrate
was concentrated. The crude product was recrystallized with
CH3OH/ether to give 2 as a yellow powder (0.15 g, 79%). Mp:
180 °C (dec.). Anal. Calcd for C21H24ClIrN2O: C, 46.02; H, 4.41; N,
5.11. Found: C, 46.31; H, 4.54; N, 5.06. 1H NMR (400 MHz,
DMSO-d6, ppm): 8.72 (d, J = 5.6 Hz, 1H), 7.99 (t, J = 7.6 Hz, 1H),
7.76 (d, J = 7.6 Hz, 1H), 7.47 (t, J = 6.8 Hz, 1H), 7.37 (br s, 1H),
6.69 (br s, 1H), 6.48 (br s, 1H), 4.41 (d, J = 14.4 Hz, 1H), 3.60 (d, J =
14.4 Hz, 1H), 1.55 (s, 15H). 13C NMR (100 Hz, DMSO-d6, ppm):
168.4, 159.3, 155.8, 150.7, 140.1, 136.6, 124.7, 124.2, 115.5, 104.1,
86.7, 47.9, 9.4.
N-Ethylaniline.6h 1H NMR (400 MHz, CDCl3, ppm): 7.17 (t, J =
7.2 Hz, 2H), 6.69 (t, J = 7.6 Hz, 1H), 6.61 (d, J = 7.6 Hz, 2H), 3.16
F
