Generation of Masked TiII Intermediates from TiIV Amides via β‑H
Abstraction or Alkyne Deprotonation: An Example of Ti-Catalyzed
Nitrene-Coupled Transfer Hydrogenation
Adam J. Pearce,† Yukun Cheng,† Rachel J. Dunscomb, and Ian A. Tonks*
Cite This: https://dx.doi.org/10.1021/acs.organomet.0c00577
Read Online
sı
*
Metrics & More
Article Recommendations
Supporting Information
ACCESS
ABSTRACT: Simple Ti amide complexes are shown to act as
sources for masked TiII intermediates via several pathways, as
demonstrated through the investigation of a unique Ti-catalyzed
nitrene-coupled transfer hydrogenation of 3-hexyne. This reaction
proceeds through reduction of azobenzene by a masked TiII catalyst,
wherein both amines and 3-hexyne can serve as the hydrogen
source/reductant for Ti by forming putative titanaziridines via β-H
abstraction or putative titanacyclopentynes via protonolysis,
respectively.
report the reactivity of masked TiII intermediates generated
from simple Ti amides via β-H abstraction or internal alkyne
deprotonation (Figure 1, bottom).
itanium(II) complexes and intermediates play important
1
Troles in various redox reactions, such as Kulinkovich
cyclopropanations,2 alkyne cyclotrimerization,3−5 and many
other annulations.6,7 Common methods for generating low-
valent metals involve reduction of metal halides or β-H
abstraction of alkyl ligands (Figure 1, top).8−10 In many cases,
these low-valent TiII intermediates are trapped or masked via
backbonding into π-acidic ligands. In the interest of expanding
the accessibility of TiII intermediates in catalysis, we herein
The η2-titanaziridine complexes can be easily generated
through β-H abstraction, and their insertion chemistry in the
context of alkene hydroaminoalkylation catalysis is well-
established.11−13 We hypothesized that η2-titanaziridine
complexes could alternately be considered as masked TiII
species for redox transformations, in direct analogy to
chemistry mediated by η2-olefin/titanacyclopropane complexes
(Figure 1, bottom). In fact, Rothwell demonstrated that an η2-
titanaziridine could furnish a Ti imido upon stoichiometric
reaction with azobenzene.14,15 The use of diazenes to capture
these reactive species could ultimately allow for catalytic
nitrene transfer reactions16−18 from simple and readily
available Ti amide compounds.
Following this hypothesis, TiCl2(NMe2)2 was examined as a
catalyst for 3-hexyne cyclotrimerization19 as well as [2 + 2 + 1]
pyrrole synthesis.16 3-Hexyne underwent successful cyclo-
trimerization with 5 mol % of TiCl2(NMe2)2 as the catalyst,
yielding 58% of C6Et6 after 22 h at 145 °C (eq 1)consistent
with the hypothesis that TiII species could be accessed from
Received: August 30, 2020
Figure 1. Masked TiII reagents generated via β-H abstraction by Ti
alkyls (top) or Ti amides (bottom).
https://dx.doi.org/10.1021/acs.organomet.0c00577
© XXXX American Chemical Society
Organometallics XXXX, XXX, XXX−XXX
A

Organometallics
pubs.acs.org/Organometallics
Communication
the amide, as cyclotrimerization typically occurs through a
TiII/TiIV mechanism.20−23
Surprisingly, the attempted [2 + 2 + 1] nitrene transfer
reaction (eq 2) did not yield tetraethylpyrrole as the major
product, instead generating a mixture of (Z)- and (E)-N-
phenylhexan-3-imine in 62% yieldthe product of formal
nitrene-coupled hydrogenation of the alkyne. Although
metallacycle protonation by free HNMe2 resulting from β-H
abstraction could account for some imine formation, yields in
excess of the catalyst loading indicate that other mechanisms
and chemical species must at least partly be involved in Ti
redox and hydrogen transfer.
To investigate the source of hydrogen, the reaction was
carried out with perdeuterated 3-hexyne-d10 (eq 3). This
reaction yielded a mixture of 3-d10, 3-d11, and 3-d12 in a ratio of
0.16:0.73:1.0 (eq 3). The predominance of 3-d12 suggests that
3-hexyne is the major hydrogen source (vide infra). Mean-
while, the formation of 3-d10 and mixed product 3-d11 indicates
that HNMe2 (from β-H abstraction of dimethylamide ligand)
also contributes a non-negligible amount of hydrogen. Notably,
based on the catalyst loading, the dimethylamide ligands can
account for the majority of hydrogen for 3-d10 and 3-d11.
However, as H/D scrambling of 3 with 3-hexyne can occur
(see Supporting Information for a scrambling experiment), the
approximate ratio of β-H abstraction versus alkyne deproto-
nation may be underestimated. This reaction is a rare example
of Ti-catalyzed transfer hydrogenation24,25 and a unique
example of nitrene-coupled transfer hydrogenation.
Based on the information above, we propose the mechanism
for nitrene-coupled transfer hydrogenation in Figure 2. Starting
from TiCl2(NMe2)2 (A), two pathways are possible: first,
coordination of 3-hexyne to Ti and subsequent deprotonation
of the propargylic C−H affords titanacyclopentyne complex B
(pathway I). Coordination of another oxidizing π-acid such as
azobenzene could then liberate 2,3,4-hexatriene to furnish a Ti
η2-hydrazido(2−) complex C. Although 2,3,4-hexatriene is not
observed in reaction mixtures, metallacyclopentyne complexes
of group 4 metals have been studied previously,26−29 and this
mechanism best accounts for the poor mass balance in 3-
hexyne (despite 85% conversion of 3-hexyne, less than 50% 3-
hexyne is converted to 3), although we cannot rule out other
dehydrogenation products of 3-hexyne being involved.
Alternately, TiCl2(NMe2)2 can undergo β-H abstraction to
generate an η2-titanaziridine D (pathway II), which could
similarly undergo exchange with azobenzene to liberate N-
methylformimine and generate the Ti η2-hydrazido(2−) C. We
have observed similar π-acid/azobenzene exchange with low-
valent Ti halides during Ti-catalyzed isocyanide amination
reactions.30
Figure 2. Plausible mechanism of hydroamination of 3-hexyne with
azobenzene catalyzed by TiCl2(NMe2)2. Teal and black hydrogens
indicate their origin from −NMe2 or 3-hexyne, respectively.
Ti η2-hydrazido(2−) complexes like C are well-established
to undergo bimetallic scission to Ti imido complexes (E).16,31
From E, [2 + 2] cycloaddition of 3-hexyne yields
azatitanacyclobutadiene F, which can undergo protonolysis
by HNMe2 to liberate the hydroaminated product32−34 and
regenerate TiCl2(NMe2)2. HNMe2 ultimately serves the role of
a proton shuttle in the reaction, moving protons from either 3-
hexyne or another equivalent of −NMe2 to the imine product.
Prompted by these dual pathways, we hypothesized that
secondary amines bearing more acidic α-hydrogens would be a
more efficient source of hydrogen than 3-hexyne. In fact,
reaction of 3-hexyne with N-benzylaniline (4) and azobenzene
resulted in near quantitative (91% based on PhNNPh)
formation of 3 (eq 4), along with significant formation of N-
phenylaldimine dehydrogenated byproduct 5 (45%)indicat-
ing that β-H abstraction from more reactive Ti-amides can
occur at rates competitive with those of 3-hexyne deprotona-
tion.
Following the success of N-benzylaniline in the nitrene-
coupled transfer hydrogenation reaction, we also investigated
simple azobenzene hydrogenation35,36 using 4 as a direct probe
of the efficiency of transfer hydrogenation via solely β-H
abstraction (eq 5; see Supporting Information for the full
proposed mechanism). In this case, good yield (36%) of
PhNH2 6 could be achieved with prolonged heating, although
the reaction was not as fast or efficient as those with 3-hexyne
as a hydrogen source. Satisfyingly, the reactions in eqs 4 and 5
allowed observation of the dehydrogenated byproduct 5:
previously, N-methylformimine and 2,3,4-hexatriene were not
detected, presumably due to their decomposition at elevated
temperature.
B
https://dx.doi.org/10.1021/acs.organomet.0c00577
Organometallics XXXX, XXX, XXX−XXX

Organometallics
pubs.acs.org/Organometallics
Communication
(2) Kulinkovich, O. G.; Sviridov, S. V.; Vasilevski, D. A. Reaction of
Ethylmagnesium Bromide with Esters of Carboxylic-Acid in the
Presence of Tetraisopropoxytitanium. Zh. Org. Khim. 1989, 25,
2244−2245.
(3) Okamoto, S. Synthetic Reactions Using Low-Valent Titanium
Reagents Derived from Ti(OR)4 or CpTiX3 (X = O-i-Pr or Cl) in the
Presence of Me 3 SiCl and Mg. Chem. Rec. 2016, 16 (2), 857−872.
(4) See, X. Y.; Beaumier, E. P.; Davis-Gilbert, Z. W.; Dunn, P. L.;
Larsen, J. A.; Pearce, A. J.; Wheeler, T. A.; Tonks, I. A. Generation of
Ti II Alkyne Trimerization Catalysts in the Absence of Strong Metal
Reductants. Organometallics 2017, 36 (7), 1383−1390.
(5) Yamamoto, K.; Nagae, H.; Tsurugi, H.; Mashima, K.
Mechanistic Understanding of Alkyne Cyclotrimerization on Mono-
nuclear and Dinuclear Scaffolds: [4 + 2] Cycloaddition of the Third
Alkyne onto Metallacyclopentadienes and Dimetallacyclopentadienes.
Dalton Trans 2016, 45 (43), 17072−17081.
(6) Tarselli, M. A.; Micalizio, G. C. Aliphatic Imines in Titanium-
Mediated Reductive Cross-Coupling: Unique Reactivity of Ti(O-i-
Pr)4/n-BuLi. Org. Lett. 2009, 11 (20), 4596−4599.
Similar reactions catalyzed by other simple early transition
metal amides, such as Ti(NMe2)4, Zr(NMe2)4, V(NMe2)4, and
Ta(NMe2)5 (Tables S1 and S2), were not as effective as
TiCl2(NMe2)2, highlighting the sensitivity of this chemistry to
the coordination environment and Lewis acidity of the metal.
In conclusion, we have discovered that TiII can be accessed
from a simple Ti diamide via β-H abstraction or alkyne
deprotonation, and these elementary steps can be incorporated
into a unique Ti-catalyzed nitrene-coupled transfer hydro-
genation reaction. An isotope labeling study indicates that
alkyne deprotonation appears more facile than β-H abstraction.
Although these catalytic reactions are likely not of practical
value, the strategy for accessing TiII synthons from low-cost
and stable Ti amide precursors will be of value for future
endeavors in low-valent Ti catalysis,10 surface organometallic
chemistry of Ti,37,38 and chemical vapor deposition of
nitrogen-doped Ti thin films.39,40
(7) Kier, M. J.; Leon, R. M.; O’Rourke, N. F.; Rheingold, A. L.;
Micalizio, G. C. Synthesis of Highly Oxygenated Carbocycles by
Stereoselective Coupling of Alkynes to 1,3- and 1,4-Dicarbonyl
Systems. J. Am. Chem. Soc. 2017, 139 (36), 12374−12377.
(8) Roskamp, E. J.; Pedersen, S. F. The First Practical Niobium(III)
Reagent in Organic Synthesis. A Convenient Route to 2-Amino
Alcohols via the Coupling of Imines with Aldehydes or Ketones
Promoted by NbCl3(DME). J. Am. Chem. Soc. 1987, 109 (21), 6551−
6553.
(9) Tsurugi, H.; Mashima, K. A New Protocol to Generate
Catalytically Active Species of Group 4−6 Metals by Organosilicon-
Based Salt-Free Reductants. Chem. - Eur. J. 2019, 25 (4), 913−919.
(10) Davis-Gilbert, Z. W.; Tonks, I. A. Titanium Redox Catalysis:
Insights and Applications of an Earth-Abundant Base Metal. Dalton
Trans 2017, 46 (35), 11522−11528.
ASSOCIATED CONTENT
* Supporting Information
The Supporting Information is available free of charge at
https://pubs.acs.org/doi/10.1021/acs.organomet.0c00577.
■
sı
Full experimental details (PDF)
AUTHOR INFORMATION
Corresponding Author
Ian A. Tonks − Department of Chemistry, University of
MinnesotaTwin Cities, Minneapolis, Minnesota 55455,
United States; orcid.org/0000-0001-8451-8875;
Email: itonks@umn.edu
■
(11) Kubiak, R.; Prochnow, I.; Doye, S. Titanium-Catalyzed
Hydroaminoalkylation of Alkenes by C-H Bond Activation at sp3
Centers in the α-Position to a Nitrogen Atom. Angew. Chem., Int. Ed.
2009, 48 (6), 1153−1156.
Authors
Adam J. Pearce − Department of Chemistry, University of
MinnesotaTwin Cities, Minneapolis, Minnesota 55455,
United States
Yukun Cheng − Department of Chemistry, University of
MinnesotaTwin Cities, Minneapolis, Minnesota 55455,
United States; orcid.org/0000-0002-2379-9404
Rachel J. Dunscomb − Department of Chemistry, University of
MinnesotaTwin Cities, Minneapolis, Minnesota 55455,
United States
(12) Eisenberger, P.; Ayinla, R. O.; Lauzon, J. M. P.; Schafer, L. L.
Tantalum-Amidate Complexes for the Hydroaminoalkylation of
Secondary Amines: Enhanced Substrate Scope and Enantioselective
Chiral Amine Synthesis. Angew. Chem. 2009, 121 (44), 8511−8515.
̈
(13) Manßen, M.; Lauterbach, N.; Dorfler, J.; Schmidtmann, M.;
Saak, W.; Doye, S.; Beckhaus, R. Efficient Access to Titanaaziridines
by C-H Activation of N-Methylanilines at Ambient Temperature.
Angew. Chem., Int. Ed. 2015, 54 (14), 4383−4387.
Complete contact information is available at:
https://pubs.acs.org/10.1021/acs.organomet.0c00577
(14) Hill, J. E.; Profilet, R. D.; Fanwick, P. E.; Rothwell, I. P.
Synthesis, Structure, and Reactivity of Aryloxo(Imido)Titanium
Complexes. Angew. Chem., Int. Ed. Engl. 1990, 29 (6), 664−665.
(15) Durfee, L. D.; Hill, J. E.; Fanwick, P. E.; Rothwell, I. P.
Formation and Characterization of Η2-Imine and Η2-Azobenzene
Derivatives of Titanium Containing Ancillary Aryloxide Ligation.
Organometallics 1990, 9 (1), 75−80.
Author Contributions
†A.J.P. and Y.C. contributed equally.
Notes
The authors declare no competing financial interest.
(16) Gilbert, Z. W.; Hue, R. J.; Tonks, I. A. Catalytic Formal [2 +
2+1] Synthesis of Pyrroles from Alkynes and Diazenes via TiII/TiIV
redox Catalysis. Nat. Chem. 2016, 8 (1), 63−68.
ACKNOWLEDGMENTS
■
(17) Beaumier, E. P.; Ott, A. A.; Wen, X.; Davis-Gilbert, Z. W.;
Wheeler, T. A.; Topczewski, J. J.; Goodpaster, J. D.; Tonks, I. Ti-
Catalyzed Ring-Opening Oxidative Amination of Methylenecyclopro-
panes with Diazenes. Chem. Sci. 2020, 11 (27), 7204−7209.
(18) Heins, S. P.; Wolczanski, P. T.; Cundari, T. R.; MacMillan, S.
N. Redox Non-Innocence Permits Catalytic Nitrene Carbonylation by
(Dadi)Ti = NAd (Ad = Adamantyl). Chem. Sci. 2017, 8 (5), 3410−
3418.
Financial support was provided by the National Institutes of
Health (R35GM119457) and the Alfred P. Sloan Foundation
(I.A.T. is a 2017 Sloan Fellow). Instrumentation for the
University of Minnesota Chemistry NMR facility was
supported from a grant through the National Institutes of
Health (S10OD011952).
REFERENCES
(19) See, X. Y.; Beaumier, E. P.; Davis-Gilbert, Z. W.; Dunn, P. L.;
Larsen, J. A.; Pearce, A. J.; Wheeler, T. A.; Tonks, I. A. Generation of
TiIIalkyne Trimerization Catalysts in the Absence of Strong Metal
Reductants. Organometallics 2017, 36 (7), 1383−1390.
■
(1) Beaumier, E. P.; Pearce, A. J.; See, X. Y.; Tonks, I. A. Modern
Applications of Low-Valent Early Transition Metals in Synthesis and
Catalysis. Nat. Rev. Chem. 2019, 3 (1), 15−34.
C
https://dx.doi.org/10.1021/acs.organomet.0c00577
Organometallics XXXX, XXX, XXX−XXX

Organometallics
pubs.acs.org/Organometallics
Communication
́
(20) Yamamoto, K.; Nagae, H.; Tsurugi, H.; Mashima, K.
Mechanistic Understanding of Alkyne Cyclotrimerization on Mono-
nuclear and Dinuclear Scaffolds: [4 + 2] Cycloaddition of the Third
Alkyne onto Metallacyclopentadienes and Dimetallacyclopentadienes.
Dalton Trans 2016, 45 (43), 17072−17081.
(37) Coperet, C.; Comas-Vives, A.; Conley, M. P.; Estes, D. P.;
́
Fedorov, A.; Mougel, V.; Nagae, H.; Nunez-Zarur, F.; Zhizhko, P. A.
Surface Organometallic and Coordination Chemistry toward Single-
Site Heterogeneous Catalysts: Strategies, Methods, Structures, and
Activities. Chem. Rev. 2016, 116 (2), 323−421.
(38) Aldrich, K. E.; Odom, A. L. A Silica-Supported Titanium
Catalyst for Heterogeneous Hydroamination and Multicomponent
Coupling Reactions. Dalton Trans 2019, 48 (30), 11352−11360.
(39) Kim, S. J.; Xu, K.; Parala, H.; Beranek, R.; Bledowski, M.;
Sliozberg, K.; Becker, H. W.; Rogalla, D.; Barreca, D.; Maccato, C.;
Sada, C.; Schuhmann, W.; Fischer, R. A.; Devi, A. Intrinsic Nitrogen-
Doped CVD-Grown TiO2 Thin Films from All-N-Coordinated Ti
Precursors for Photoelectrochemical Applications. Chem. Vap.
Deposition 2013, 19 (1−3), 45−52.
(21) Ozerov, O. V.; Ladipo, F. T.; Patrick, B. O. Highly
Regioselective Alkyne Cyclotrimerization Catalyzed by Titanium
Complexes Supported by Proximally Bridged P-Tert- Butylcalix[4]-
Arene Ligands. J. Am. Chem. Soc. 1999, 121 (34), 7941−7942.
(22) Ladipo, F. T. Synthesis and Reactivity of Well-Characterized
Low-Valent Titanium Species. Comments Inorg. Chem. 2006, 27 (3−
4), 73−102.
(23) Although alkyne cyclotrimerization commonly undergoes redox
mechanisms, it has also been reported to occur through nonredox
pathways. For example: (a) Solari, E.; Floriani, C.; Chiesi-Villa, A.;
Guastini, C. Titanium Tetrachloride Binding and Making Arenes from
Acetylenes: The Synthesis and X-Ray Crystal Structure of a
Titanium(IV)−Hexamethylbenzene Complex. J. Chem. Soc., Chem.
Commun. 1989, No. 22, 1747−1749. (b) Musso, F.; Solari, E.;
Floriani, C.; Schenk, K. Hydrocarbon Activation with Metal Halides:
Zirconium Tetrachloride Catalyzing the Jacobsen Reaction and
Assisting the Trimerization of Alkynes via the Formation of η6-
Arene−Zirconium(IV) Complexes. Organometallics 1997, 16 (22),
4889−4895.
(40) Jin, N.; Yang, Y.; Luo, X.; Xia, Z. Development of CVD Ti-
Containing Films. Prog. Mater. Sci. 2013, 58 (8), 1490−1533.
(24) Hickey, A. K.; Crestani, M. G.; Fout, A. R.; Gao, X.; Chen, C.-
H.; Mindiola, D. J. Dehydrogenation of Hydrocarbons with Metal-
Carbon Multiple Bonds and Trapping of a Titanium(II) Intermediate.
Dalton Trans 2014, 43 (26), 9834−9837.
́
(25) Aguilar-Calderon, J. R.; Metta-Magana, A. J.; Noll, B.; Fortier,
̃
S. C(sp3)−H Oxidative Addition and Transfer Hydrogenation
Chemistry of a Titanium(II) Synthon: Mimicry of Late-Metal Type
Reactivity. Angew. Chem., Int. Ed. 2016, 55 (45), 14101−14105.
(26) Rosenthal, U.; Burlakov, V. V.; Bach, M. A.; Beweries, T. Five-
Membered Metallacycles of Titanium and Zirconium - Attractive
Compounds for Organometallic Chemistry and Catalysis. Chem. Soc.
Rev. 2007, 36 (5), 719.
(27) Suzuki, N.; Aihara, N.; Takahara, H.; Watanabe, T.; Iwasaki,
M.; Saburi, M.; Hashizume, D.; Chihara, T. Synthesis and Structure of
1-Zirconacyclopent-3-Yne Complexes without Substituents Adjacent
to the Triple Bond. J. Am. Chem. Soc. 2004, 126 (1), 60−61.
(28) Suzuki, N.; Nishiura, M.; Wakatsuki, Y. Isolation and Structural
Characterization of 1-Zirconacyclopent-3-Yne, Five-Membered Cyclic
Alkynes. Science 2002, 295 (5555), 660−663.
(29) Rosenthal, U.; Burlakov, V. V.; Arndt, P.; Baumann, W.;
Spannenberg, A. Five-Membered Titana- and Zirconacyclocumulenes:
Stable 1-Metallacyclopenta-2,3,4-Trienes †. Organometallics 2005, 24
(4), 456−471.
(30) Beaumier, E. P.; McGreal, M. E.; Pancoast, A. R.; Wilson, R.
H.; Moore, J. T.; Graziano, B. J.; Goodpaster, J. D.; Tonks, I. A.
Carbodiimide Synthesis via Ti-Catalyzed Nitrene Transfer from
Diazenes to Isocyanides. ACS Catal. 2019, 9 (12), 11753−11762.
(31) Gray, S. D.; Thorman, J. L.; Adamian, V. A.; Kadish, K. M.;
Woo, L. K. Synthesis, Electrochemistry, and Imido Transfer Reactions
of (TTP)Ti(Η2-PhN = NPh). Inorg. Chem. 1998, 37 (1), 1−4.
(32) Muller, T. E.; Hultzsch, K. C.; Yus, M.; Foubelo, F.; Tada, M.
̈
Hydroamination: Direct Addition of Amines to Alkenes and Alkynes.
Chem. Rev. 2008, 108 (9), 3795−3892.
(33) Bielefeld, J.; Doye, S. Dimethylamine as a Substrate in
Hydroaminoalkylation Reactions. Angew. Chem., Int. Ed. 2017, 56
(47), 15155−15158.
(34) We considered 3-hexyne as a potential protonolysis partner;
however, as coordination of 3-hexyne leads to pyrrole formation, this
pathway seems less likely than HNMe2 protonolysis.
(35) Zurita, D. A.; Flores-Alamo, M.; García, J. J. Catalytic Transfer
Hydrogenation of Azobenzene by Low-Valent Nickel Complexes: A
Route to 1,2-Disubstituted Benzimidazoles and 2,4,5-Trisubstituted
Imidazolines. Dalton Trans 2016, 45 (25), 10389−10401.
(36) Brieger, G.; Nestrick, T. J. Catalytic Transfer Hydrogenation.
Chem. Rev. 1974, 74 (5), 567−580.
D
https://dx.doi.org/10.1021/acs.organomet.0c00577
Organometallics XXXX, XXX, XXX−XXX
