ARTICLES
15. Desai, L. V., Hull, K. L. & Sanford, M. S. Palladium-catalyzed oxygenation of
unactivated sp3 hybridized C–H bonds. J. Am. Chem. Soc. 126,
9542–9543 (2004).
16. Dupont, J., Consorti, C. C. & Spencer, J. The potential of palladacycles: more
than just precatalysts. Chem. Rev. 105, 2527–2572 (2005).
(Fig. 3c). Using the new C–H arylation, we can synthesize the active
pharmaceutical agent in four steps from an inexpensive material
(13). The C–H arylation of 14 with the readily available
diaryliodonium salt 15 proceeds in high yield to construct the
framework of fingolimod 4u. Acid hydrolysis of the protecting
groups affords the active pharmaceutical ingredient 16a. Given
that fingolimod has multiple indications and is currently in
seven clinical trials across a number of therapeutic areas47, a
streamlined strategy for the synthesis of analogues would be
extremely useful. By changing the amine starting material, the
diaryliodonium salt or using the sequential functionalization
tactic (vide supra), we were able to rapidly access a representative
selection of potentially interesting fingolimod analogue molecules
using this strategy (16b–e).
The advances outlined here demonstrate that amino alcohols are
ideal candidates for a remarkably broad C–H activation strategy. We
believe that two factors are responsible for this facile C–H activation:
(1) the presence of a putative hydrogen bond between the palladium
bound amine and acetate ligands is important in facilitating the
C–H activation step as it locks the conformational relationship
between the two groups and projects the C–H bond into an ideal
trajectory for palladation; (2) the hindered nature of the amine sub-
strates destabilizes the off-cycle bis(amine) palladium complex to
favour the mono-ligated species required for C–H activation.
The range of palladium-catalysed C–H activation reactions shown
here enable either simple functional group additions or frame-
work-changing transformations on a versatile and synthetically
useful amino alcohol scaffold. Taken together, the broad scope
and applications of these transformations suggest that the C–H acti-
vation strategy will be beneficial to the synthesis of complex amines
with both established and unexplored biological properties and will
be of widespread utility to chemists in both academic and
industrial institutions.
17. Lyons, T. W. & Sanford, M. S. Palladium-catalyzed ligand-directed C–H
functionalization reactions. Chem. Rev. 110, 1147–1169 (2010).
18. Ackermann, L. Carboxylate-assisted transition-metal-catalyzed C–H bond
functionalizations: mechanism and scope. Chem. Rev. 111, 1315–1345 (2011).
19. Colby, D. A., Bergman, R. G. & Ellman, J. A. Rhodium-catalyzed C–C bond
formation via heteroatom directed C–H bond activation. Chem. Rev. 110,
624–655 (2010).
20. Ryabov, A. D. Mechanisms of intramolecular activation of carbon–hydrogen
bonds in transition-metal complexes. Chem. Rev. 90, 403–424 (1990).
21. He, G., Zhao, Y., Zhang, S., Lu, C. & Chen, G. Highly efficient syntheses of
azetidines, pyrrolidines, and indolines via palladium-catalyzed intramolecular
amination of C(sp3)–H and C(sp2)–H bonds at the γ and δ positions. J. Am.
Chem. Soc. 134, 3–6 (2012).
22. Zhang, S.-Y. et al. Palladium-catalyzed picolinamide-directed alkylation of
unactivated C(sp3)–H bonds with alkyl iodides. J. Am. Chem. Soc. 135,
2124–2127 (2013).
23. Chan, K. S. L. et al. Ligand-enabled cross-coupling of C(sp3)-H bonds with
arylboron reagents via Pd(II)/Pd(0) catalysis. Nature Chem. 6, 146–150 (2014).
24. Yuan, J., Liu, C. & Lei, A. Construction of N-containing heterocycles via
oxidative intramolecular N–H/X–H coupling. Chem. Commun. 51,
1394–1409 (2015).
25. Lovering, F., Bikker, J. & Humblet, C. Escape from flatland: increasing saturation
as an approach to improving clinical success. J. Med. Chem. 52, 6752–6756 (2009).
26. Cho, J.-Y., Tse, M. K., Holmes, D., Maleczka, R. E. Jr. & Smith, M. R. III.
Remarkably selective iridium catalysts for the elaboration of aromatic C–H
bonds. Science 295, 305–308 (2002).
27. Ishiyama, T. et al. Mild iridium-catalyzed borylation of arenes. High turnover
numbers, room temperature reactions, and isolation of a potential intermediate.
J. Am. Chem. Soc. 124, 390–391 (2002).
28. Ferreira, E. M. & Stoltz, B. M. Catalytic C−H bond functionalization with
palladium(II): aerobic oxidative annulations of indoles. J. Am. Chem. Soc. 125,
9578–9579 (2003).
29. Zhang, Y.-H., Shi, B.-F. & Yu, J.-Q. Pd(II)-catalyzed olefination of electron-deficient
arenes using 2,6-dialkylpyridine ligands. J. Am. Chem. Soc. 131, 5072–5074 (2009).
30. Emmert, M. H., Cook, A. K., Xie, Y. J. & Sanford, M. S. Remarkably high
reactivity of Pd(OAc)2/pyridine catalysts: nondirected C−H oxygenation of
arenes. Angew. Chem. Int. Ed. 50, 9409–9412 (2011).
31. Giri, R., Lan, Y., Peng, L., Houk, K. N. & Yu, J.-Q. Understanding reactivity and
stereoselectivity in palladium-catalyzed diastereoselective sp3 C−H bond
activation: intermediate characterization and computational studies. J. Am.
Chem. Soc. 134, 14118–14126 (2012).
32. McNally, A., Haffemayer, B., Collins, B. S. L. & Gaunt, M. J. Palladium-catalysed
C–H activation of aliphatic amines to give strained nitrogen heterocycles. Nature
510, 129–133 (2014).
33. Bera, K. & Namboothiri, I. N. N. Asymmetric synthesis of quaternary α-amino
acids and their phosphonate analogues. Asian J. Org. Chem. 3, 1234–1260 (2014).
34. Reichard, G. A. & Corey, E. J. Total synthesis of lactacystin. J. Am. Chem. Soc.
114, 10677–10678 (1992).
35. Strader, C. R., Pearce, C. J. & Oberlies, N. H. Fingolimod (FTY720): a recently
approved multiple sclerosis drug based on a fungal secondary metabolite. J. Nat.
Prod. 74, 900–907 (2011).
36. Gorelsky, S., Lapointe, D. & Fagnou, K. Analysis of the concerted metalation–
deprotonation mechanism in palladium-catalyzed direct arylation across a broad
range of aromatic substrates. J. Am. Chem. Soc. 130, 10848–10849 (2008).
37. Garcia-Cuadrado, D., Braga, A. A. C., Maseras, F. & Echavarren, A. M. Proton
abstraction mechanism for the palladium-catalyzed intramolecular arylation.
J. Am. Chem. Soc. 128, 1066–1067 (2006).
38. Giri, R., Chen, X. & Yu, J.-Q. Palladium-catalyzed asymmetric iodination of
unactivated C–H bonds under mild conditions. Angew. Chem. Int. Ed. 44,
2112–2115 (2005).
39. Hickman, A. J. & Sanford, M. S. High-valent organometallic copper and
palladium in catalysis. Nature 484, 177–185 (2012).
40. Darabantu, M. et al. Synthesis and stereochemistry of some 1,3-oxazolidine
systems based on TRIS (α,α,α-trimethylolaminomethane) and related
aminopolyols—skeleton (II): 1-aza-3,7-dioxabicyclo[3.3.0]octanes. Tetrahedron
56, 3799–3816 (2000).
Received 27 May 2015; accepted 2 September 2015;
published online 2 November 2015
References
1. Jia, C., Kitamura, T. & Fujiwara, Y. Catalytic functionalization of arenes and
alkanes via C−H bond activation. Acc. Chem. Res. 34, 633–639 (2001).
2. Godula, K. & Sames, D. C–H bond functionalization in complex organic
synthesis. Science 312, 67–72 (2006).
3. Davies, H. M. L. & Manning, J. R. Catalytic C–H functionalization by metal
carbenoid and nitrenoid insertion. Nature 451, 417–424 (2008).
4. Davies, H. M. L., Du Bois, J. & Yu, J.-Q. C–H functionalization in organic
synthesis. Chem. Soc. Rev. 40, 1855–1856 (2011).
5. Yamaguchi, J., Yamaguchi, A. D. & Itami, K. C–H bond functionalization:
emerging synthetic tools for natural products and pharmaceuticals. Angew.
Chem. Int. Ed. 51, 8960–9009 (2012).
6. Mkhalid, I. A. I., Barnard, J. H., Marder, T. B., Murphy, J. M. & Hartwig, J. F.
C–H activation for the construction of C–B bonds. Chem. Rev. 110,
890–931 (2010).
7. Wencel-Delord, J., Dröge, T., Liu, F. & Glorius, F. Towards mild metal-catalyzed
C–H bond activation. Chem. Soc. Rev. 40, 4740–4761 (2011).
8. Jazzar, R., Hitce, J., Renaudat, A., Sofack-Kreutzer, J. & Baudoin, O.
Functionalization of organic molecules by transition-metal-catalyzed C(sp3)–H
activation chemistry. Chem. Eur. J. 16, 2654–2672 (2010).
9. Daugulis, O., Do, H.-Q. & Shabashov, D. Palladium- and copper-catalyzed
arylation of carbon–hydrogen bonds. Acc. Chem. Res. 42, 1074–1086 (2009).
10. Engle, K. M., Wu, H.-C. & Yu, J.-Q. Weak coordination as a powerful means for
developing broadly useful C–H functionalization reactions. Acc. Chem. Res. 45,
788–802 (2012).
11. Wang, D.-H., Engle, K. M., Shi, B.-F. & Yu, J.-Q. Ligand-enabled reactivity and
selectivity in a synthetically versatile aryl C–H olefination. Science 327,
315–319 (2010).
41. Deprez, N. R., Kalyani, D., Krause, A. & Sanford, M. S. Room temperature
palladium-catalyzed 2-arylation of indoles. J. Am. Chem. Soc. 128,
4972–4973 (2006).
42. Donohoe, T. J., Bataille, C. J. R. & Churchill, G. W. Highlights of natural product
synthesis. Annu. Rep. Prog. Chem. B 102, 98–122 (2006).
12. Wasa, M., Engle, K. M. & Yu, J.-Q. Pd(0)/PR3-catalyzed intermolecular arylation
of sp3 C–H bonds. J. Am. Chem. Soc. 131, 9886–9887 (2009).
13. Simmons, E. M. & Hartwig, J. F. Catalytic functionalization of unactivated
primary C–H bonds directed by an alcohol. Nature 483, 70–73 (2012).
14. Zaitsev, V. G., Shabashov, D. & Daugulis, O. Highly regioselective arylation of
sp3 C–H bonds catalyzed by palladium acetate. J. Am. Chem. Soc. 127,
13154–13155 (2005).
43. Kozitsyna, N. Y. et al. Novel heterometallic palladium–silver complex. Inorg.
Chim. Acta 370, 382–387 (2011).
