J. Vacek et al.
Free Radical Biology and Medicine 164 (2021) 258–270
(δ = 7.26 and 77.00 ppm, respectively). The coupling constants (J) are
given in Hertz (Hz) with corresponding multiplicity (s = singlet, d =
doublet, t = triplet, q = quartet, m = multiplet).
μ
m) from Kernet Int. (UK). After polishing, the electrode was rinsed
thoroughly with deionized water. The analyses were performed with
Britton-Robinson buffer (titrated to the desired pH with 0.2 M NaOH) at
room temperature with a μAutolab III analyzer (EcoChemie, NL) in a
2.1.1. Preparation of phytocannabinoids
three-electrode setup with a Ag/AgCl/3 M KCl electrode as the reference
and a platinum wire as the auxiliary electrode. Argon was used to
remove oxygen from the supporting electrolyte. Individual settings for
respective voltammetric analyses are given in the Figure legends.
Cannabichromene (CBC) [17] A 100 mL round-bottom flask
equipped with a Dean-Stark trap was charged with 3.00 g (16.64 mmol)
of olivetol, 2.99 mL (17.48 mmol) of citral, 1.76 mL (16.64 mmol) of
tert-butylamine, and 33 mL of toluene. The reaction mixture was
refluxed for 5 hours. After completion, the solvent was removed under
reduced pressure. Flash chromatography using PE/EtOAc (95:5) pro-
vided 3.90 g (12.40 mmol, 74.5%) of CBC as a yellow oil (99% purity).
NMR spectra were in accordance with published data [18].
2.3. Theoretical calculations
Since the cannabinoids are flexible molecules due to the presence of
aliphatic side-chains, a two-stage Monte Carlo approach in the dihedral
space implemented in the program FROG2 [25] was used as the first step
in retrieving the energetically most stable structures of the given com-
pounds. The twenty most favorable conformers found were further
optimized at the DFT level of theory employing the 6-311++G(d, p)
basis set and wB97XD functional, which provides reasonable geometries
and thermodynamics data [26]. The frontier molecular orbitals and
molecular electrostatic potentials were analyzed using the program
Avogadro [27]. The presence of solvent (water, methanol and n-octanol)
was described implicitly using the PCM model [28].
Cannabinol (CBN) [19] A 100 mL round-bottom flask was charged
with 2.00 g (6.36 mmol) of CBD, 3.23 g (12.72 mmol) of iodine, and 50
mL of toluene. The reaction mixture was refluxed for 7 hours. After
completion, the mixture was washed with a saturated solution of
Na2S2O3 and brine. The organic phase was dried over anhydrous MgSO4.
After evaporation of the solvent, flash chromatography using PE/EtOAc
(94:6) provided 0.69 g (2.22 mmol, 35%) of CBN as a yellow oil (99%
purity). NMR spectra were in accordance with published data [20].
Δ8-Tetrahydrocannabinol (Δ8-THC) [21] A Schlenk flask was
charged with 2.00 g (6.36 mmol) of CBD and 33 mL of DCM. The so-
A harmonic vibrational frequency analysis was performed to confirm
that the structures found are the minima at the potential energy surface.
The vertical and adiabatic ionization potentials were calculated by
subtracting the energies of the compound and its cation at the same level
of theory as the previous ab initio calculations were performed. All
quantum mechanical calculations were treated in the program
Gaussian16 [29].
◦
lution was cooled to 0 C, and 0.32 mL (2.54 mmol) of BF3.Et2O was
added dropwise under an Ar atmosphere. The mixture was allowed to
warm to r.t. After an additional hour of stirring, the mixture was poured
into saturated NaHCO3 and extracted with DCM. The combined organic
phases were dried over anhydrous MgSO4. After evaporation of the
solvent, flash chromatography using pentane/Et2O (95:5) provided
1.12 g (3.56 mmol, 56%) of Δ8-THC as a yellow oil (99% purity). NMR
spectra were in accordance with published data [21].
2.3.1. Dissociation of the cannabinoids
Δ9-Tetrahydrocannabinol (Δ9-THC) and Δ8-iso-tetrahydrocan-
nabinol (iso-THC) [22,23] A Schlenk flask was charged with 2.00 g
(6.36 mmol) of CBD and 33 mL of DCM. The solution was cooled to
ꢀ 10 ◦C and 0.32 mL (2.54 mmol) of BF3.Et2O was added dropwise under
an Ar atmosphere. The mixture was stirred at ꢀ 10 ◦C for 120 min. The
reaction was quenched by the addition of saturated NaHCO3. After
extraction with DCM, the combined organic phases were dried over
anhydrous MgSO4. After evaporation of the solvent, flash chromatog-
raphy using pentane/Et2O (97:3) provided 1.04 g (3.31 mmol, 52%) of
Δ9-THC as a yellow oil (99% purity) and 156 mg (0.496 mmol, 7.8%) of
iso-THC as a yellow oil (98% purity). NMR spectra of Δ9-THC are in
accordance with published data [24]. NMR spectra of iso-THC: 1H NMR
(400 MHz, CDCl3) δ 6.28 (d, J = 1.5 Hz, 1H), 6.12 (d, J = 1.5 Hz, 1H),
4.99 (q, J = 1.5 Hz, 1H), 4.93 (s, 1H), 4.54 (s, 1H), 3.46 (q, J = 3.1 Hz,
1H), 2.51–2.40 (m, 2H), 2.34 (s, 1H), 1.93–1.83 (m, 4H), 1.80–1.53 (m,
7H), 1.42–1.21 (m, 7H), 0.92–0.86 (m, 3H). 13C NMR (101 MHz, CDCl3)
δ 157.39, 152.25, 146.07, 142.62, 111.02, 110.78, 107.91, 105.98,
74.63, 43.03, 35.70, 35.45, 31.58, 30.76, 30.48, 29.41, 27.89, 22.65,
22.55, 21.05, 14.01; for more details, see Supplementary Information.
For in vitro cell experiments, methanol (HiPerSolv CHROMANORM
for HPLC, LC-MS grade) was from VWR International s.r.o. (Czech Re-
public). Dulbecco’s modified Eagle’s medium (DMEM), Ham-F12
nutrient mixture, heat-inactivated fetal calf serum (FCS), stabilised
penicillin-streptomycin solution, amphotericin B, hydrocortisone,
adenine, insulin, epidermal growth factor, 3,3’,5-triiodo-L-thyronine,
trypsin, ampicillin, trypsin-EDTA (0.25%), dimethyl sulfoxide (DMSO),
neutral red (NR), and other chemicals were from Sigma-Aldrich (Czech
Republic).
The calculations of pKa were performed based on the procedure [30],
where a corresponding thermodynamics cycle can be found, with the
modification of Pliego [31]. Based on Eq. (1), the calculation of pKa can
be done through the following equations (2) and (3):
HA + H2O ↔ A- + H3O+
ΔGg = Gg(Aꢀ ) + Gg(H3O+) ꢀ Gg(HA) ꢀ Gg(H2O)
(1)
(2)
ΔG = ΔGg + Gsolv(Aꢀ ) + Gsolv(H3O+) ꢀ Gsolv(HA) ꢀ Gsolv(H2O)
(3)
Where Gg corresponds to the chemical potential of the given compound,
and Gsolv to its solvation free energy.
ΔG
RT
Thus, pKa =
ꢀ log[H2O] with [H2O] = 55.49 m ol/dm 3.
(4)
Since the calculated solvation free energy of H3O+ is the main source
of error in this approach, this value was replaced by an experimental one
equal to ꢀ 110.2 kcal/mol [31]. To minimize errors, the pKa values
obtained for HA via equation (4) were scaled by a factor of 1.0165,
corresponding to the ratio between the experimentally found pKa of
phenol (9.88) and the calculated one (9.72). All calculations were per-
formed using the B3LYP/6-311+G(d,p) level of theory. Solvent effects
were considered through the continuum SMD model of water [32].
Besides this, the program Marvin (Marvin 20.8.0, 2020, ChemAxon, http
various chemical descriptors and is fragment-based, was used for
comparison.
2.2. Electrochemical measurement
2.4. (Photo)stability measurement
The substances were analyzed using square-wave voltammetry
(SWV) with the working electrode being a glassy carbon electrode (GCE,
1 mm diameter disc, BASi, USA). Before each electrochemical experi-
ment, the GCE was polished using diamond spray (particle size was 3
To evaluate the stability/photostability of the studied compounds,
stock solutions in DMSO were diluted in a mixture of phosphate buffers
(50 mM, pH 7.4) with methanol (2:1, v:v). The final concentration of
compounds was 20 μM and of DMSO 2% (v/v). Immediately after the
260
