HIGH-PERFORMANCE PROTOCOL STACKS
Approaches to Im proving Perform ance
of STREAMS-Based Protocol Stacks
Vimal K. Khanna, Cabletron Systems
ABSTRACT
grams and modules. Modules can be dynamically
inserted and removed, and reused in different
STREAMS kernel mechanisms are being used to
implement networking protocols in a number of
operating systems, like UNIX, Windows, and
pSOS. STREAMS provides a number of desir-
able features for modular protocol stack imple-
mentation by defining a high degree of
standardization for implementing protocol layer
modules and for message transfer between the
modules. But this strict layered and modular
approach prevents flexibility in implementing
techniques that can result in high performance.
The original STR E AMS-based stacks have
shown very poor protocol performance. A num-
ber of improved techniques for implementing
STREAMS-based protocol stacks have been sug-
gested in the literature in the past few years.
These techniques have resulted in high-perfor-
mance STREAMS-based stacks that match the
performance of BSD UNIX-based stacks. This
article makes a study of these new approaches
and discusses the performance gains achieved by
them. These approaches can be used for imple-
menting high-performance protocol stacks in the
STREAMS kernel, over both uniprocessor and
multiprocessor systems.
protocol stacks. These STREAMS features facil-
itate easy and fast development of protocol
stacks. The standard interfaces facilitate easy
reusability and migration to different platforms
and applications.
Although these STREAMS mechanisms ease
the implementation of protocols, due to their
lack of flexibility to optimize the implementa-
tion, they introduce inefficiencies in protocol
performance. Traditional STREAMS-based pro-
tocol stacks have been known to have very low
performance on both uni- and multiprocessor
systems. The performance of the stacks has been
much slower than similar implementations on
BSD UNIX Sockets-based stacks [4]. These orig-
inal STREAMS mechanisms prevent transfer of
flow control information across nonadjacent pro-
tocol layer modules, have inefficient memory
buffer handling capabilities, suffer from schedul-
ing delays, and lack parallelism (required for
high performance on multiprocessors).
The past few years have seen innovative tech-
niques being suggested to improve the perfor-
mance of STR E AMS mechanisms. These
techniques have provided solutions to the above
problems. This has resulted in protocol stack
implementations that give high performance
matching the performance of similar stacks
implemented in the BSD environment. This arti-
cle makes a study of these techniques in the lit-
erature, including a technique suggested by the
author. It should be noted that some of the tech-
niques discussed in this article suggest improve-
ments over a version of STREAMS earlier than
that in [1], but the techniques give the same ben-
efits when they are implemented on this recent
STREAMS version. Knowledge of these tech-
niques can help implementers achieve high per-
formance for protocol stacks being implemented
in the STREAMS environment. These gains are
coupled with the other usual benefits of the
STREAMS environment (e.g., the ease of devel-
opment, reusability, and the availability of stan-
dardized interfaces).
INTRODUCTION
Networking protocol stacks follow a layered
model. When a protocol stack is implemented on
a host, the transport and underlying layers are
implemented in the host kernel. These layers are
made to run over a subnetwork protocol driver
and the corresponding network interface card
(NIC). STREAMS kernel mechanisms are being
used to implement protocols in a number of
operating systems. Traditionally STREAMS were
used in AT&T UNIX [1] and are now also being
used in Windows [2]. Besides being used in these
host operating systems, STREAMS is also being
used in the pSOS [3] embedded operating sys-
tem. A large base of networking protocol imple-
menters is using STREAMS to implement their
protocol stacks in these operating systems.
STR EAMS provide a number of desirable
features for implementing layered protocol
stacks. STREAMS follow a very strict layered
modular approach for protocol implementation.
This facilitates implementing protocol layers as
independent modules. STREAMS provide well
defined standard interfaces for message transfer
between modules, and between application pro-
Since a comparison between STREAMS and
Sockets mechanisms has already been made in [5]
and mechanisms for porting programs between
these two subsystems have been discussed in [6],
these issues are not discussed in this article. This
article concentrates only on STREAMS architec-
ture and its implementation approaches.
Editorial liaison:
A. Pakstas.
This article has been arranged as follows.
IEEE Communications Magazine • February 2000
164
0163-6804/00/$10.00 © 2000 IEEE

The STREAMS architecture will be discussed.
The inefficiencies of this architecture are exam-
ined. Different techniques being used to address
these inefficiencies have been studied, and it
has been shown that these techniques result in
high-performance implementations; this is also
discussed.
Stream # 1
Application
Stream # 2
Application
User space
Stream
head
Stream
head
STREAMS MECHANISMS
Kernel space
A typical protocol implementation on a host
consists of the transport layer and underlying
layers residing in the kernel, and the higher lay-
ers residing as user-level applications.
STR EAMS mechanisms reside in the kernel.
This kernel-based protocol implementation
approach provides performance advantage over
some user-applications-based protocol imple-
mentation techniques being suggested in recent
literature (e.g., Java-based implementations). In
a timesharing system like UNIX, the code in the
kernel executes at the highest priority and can-
not be preempted. Thus, protocol processing is
much faster in the kernel than if the protocol
was executing as a low-priority preemptible (with
context switching overheads) user application
process.
TIMOD
TIMOD
Module # 1 Module # 2
Stream # 3
Driver # 1
Transport driver
Internet driver
Driver # 2
Driver # 3
Subnet driver
In a typical STREAMS-based implementa-
tion technique, a user application establishes a
transport connection to the remote by accessing
the underlying transport layer through an access
point. The transport layer of the protocol stack
resides over the Internet layer. These communi-
cate through an access point, as shown in Fig.
1. Below the Internet layer, a separate access
point is required for each underlying subnet-
work interface (e.g., Ethernet) protocol driver.
Let us consider the case of data transmission.
The user application sends the data down to
the underlying transport layer through the
appropriate access point. The transport layer
sends this data down to the Internet layer mod-
ule through its access point. The internet layer
interprets the remote network address, chooses
an appropriate access point over that subnet-
work interface driver, and transmits the data
over it. Exactly the opposite process occurs on
the receive side.
STREAMS mechanisms allow the protocol
layers to run in the kernel as STREAMS “drivers”
or “modules.” Under STREAMS, each layer runs
as an independent driver/module. These
drivers/modules have well defined mechanisms to
pass data messages and commands between each
other. The duplex path from the application to
the underlying drivers/modules, until the NIC, is
called a “stream” (lower case letters used to dif-
ferentiate from the overall concept, STREAMS).
We briefly discuss some important
STREAMS mechanisms. The overall architec-
ture is as in Fig. 1, and a detailed look is shown
in Fig. 2. To present these mechanisms, the orig-
inal STREAMS architecture as defined in [1]
has been chosen.
ꢀ Figure 1. Multiplexing drivers result in the creation of multiple unconnected
streams.
Transport application
User area
Stream head
Kernel area
High water
mark
Pointer to
Pointer to
Message
queue
Message
queue
Low water
mark
trans-ursrv()
trans-uwput()
URQ
Transport driver
LRQ LWQ
UWQ
trans-lrput()
net-ursrv()
trans-lwsrv()
net-uwput()
Internet driver
ꢀ Figure 2. A STREAMS-based stack.
tions between messages being transferred from
the application to the underlying hardware. A
protocol layer can be implemented as a module.
Each module supports a set of data structures
called queues. A queue structure facilitates mes-
sage passing between adjacent modules and acts
as a placeholder for local messages of the driver.
Each queue has a pointer to a linked list of mes-
sages being stored by the module.
MODULARITY
STREAMS allow modular development of pro-
tocols. Each layer is implemented as a separate
module or driver. We will first discuss modules,
and then drivers. A module provides transforma-
Drivers are similar to modules with the addi-
tional facility of having more than one stream con-
IEEE Communications Magazine • February 2000
165

nected to it. In Fig. 1 the transport driver has mul-
tiple streams coming from above and one underly-
ing stream. This facility allows drivers to provide
multiplexing of the message. Two user applica-
tions each have independent streams, # 1 and # 2,
running from applications to the transport driver
through the intervening modules. For example, in
stream # 1 the application interacts with the ker-
nel at a STREAMS module called stream head
that converts user application layer buffers to ker-
nel messages. The head interacts with a module
timod that handles transport connection related
functions, like maintaining the state of the connec-
tion. The stream ends at the transport driver. The
transport driver has an independent single stream
to the Internet driver, stream # 3. The transport
layer multiplexes data from both streams # 1 and
# 2 to this stream. The received data on stream # 3
is demultiplexed to the respective upper stream as
per the message header.
In this article, the terms driver and module
will be used interchangeably, unless the refer-
ence is specifically to a multiplexing driver,
where the term driver will always be used.
The drivers can be dynamically loaded and
linked at runtime. Thus, users can create a com-
plete protocol stack at runtime by linking appro-
priate protocol layer drivers over each other.
These mechanisms give ease of configuration
and flexibility to the users. A more detailed look
at streams is shown in Fig. 1; Fig. 2 shows the
queues in a stream.
from sending more data. Thus, flow control mech-
anisms flow across different layers.
STREAMS also
provide improved
data buffer han-
dling capabilities
for reducing the
number of
As the lower layer is able to transmit its data,
its total queue size falls below its low water mark.
The STREAMS kernel procedures then cause a
predefined service() procedure of its higher-layer
driver to automatically be scheduled. In this ser-
vice() procedure, the higher layer gets the stored
message from its queue by calling a procedure
called getq() and sends more data down.
Let us look at the architecture shown in Fig.
2 (to simplify understanding, timod is not shown)
and see how the above mechanisms work. The
transport driver has four queues associated with
it: upper read queue (URQ), upper write queue
(UWQ), lower read queue (LR Q), and lower
write queue (LWQ). The queues have associated
message buffer queues which store the messages
and have their own high water marks (HWMs)
and low water marks (LWMs). The application
sends the data to the stream head, which sends it
down to the UWQ through its put procedure,
trans-uwput(). The transport driver stores the
data in its message queue and sends a copy to
the Internet driver by invoking the net-uwput()
procedure on the LWQ. When the Internet driv-
er exerts flow control, the message is not sent
down, but only stored in the transport message
queue. The application is put to sleep when the
HWM of UWQ is crossed. The trans-lwsrv() ser-
vice procedure is automatically invoked when
Internet driver relaxes the flow control. The ser-
vice() procedure picks the nontransmitted mes-
sages from the UWQ message queue and sends
these down. The messages stored in the UWQ
message queue are cleared when their acknowl-
edgments are received. When the LWM of the
message queue is reached, the application is
awakened and can send more data. Similar pro-
cedures are followed on the read side, where the
Internet driver sends data up through LRQ, and
the transport driver sends it to the application
through URQ.
memory copies.
These
mechanisms are
called extended
buffer handling
mechanisms. This
allows STREAMS
messages to
point directly to
client-supplied
non-STREAMS
data buffers.
Adjacent driver modules interact with each
other through a pair of queues: read queue
(RQ) and write queue (WQ). The RQ is for the
messages coming from the underlying drivers
and being sent to the higher layers. The WQ
handles messages coming from the higher layers
and being sent down.
FLOW CONTROL AND
SCHEDULING MECHANISMS
STREAMS mechanisms allow high and low water
marks to be defined for each queue. User calls to
send messages are made to sleep when the byte
count in the message list of the WQ between the
user application and transport layer module
exceeds its high water mark. Thus, the user can-
not send any more messages. The transport layer
frees the acknowledged messages when packets
are acknowledged. When the byte count falls
below the low water mark, the user application is
automatically awakened by the STREAMS mech-
anisms, and new messages can be sent.
When the higher layer is a STREAMS driver
rather than a user application, the flow control
mechanisms work as follows. The higher-layer
driver uses a procedure called canput() to check if
the high water mark of the lower driver WQ has
been reached. If the mark has not been crossed, it
keeps sending the data down by a standard proce-
dure, called putnext(). This invokes the put() pro-
cedure of the lower driver, which keeps storing
the data in the WQ. When its high water mark is
reached, the higher-layer driver does not send any
more data down, but stores the data in its own
WQ using a procedure called putq(). This storing
of data makes its own high water mark to be
crossed. This flow control prevents its higher layer
MESSAGE HANDLING
The STREAMS message structure is shown in
Fig. 3. A message starts with a message block.
This links to a data block, which contains the
message type and size, and points to a data
buffer. The data buffer contains the data. A long
message can consist of a large number of mes-
sage blocks linked together by b_cont pointers in
the message blocks.
An allocb() procedure needs to be called to
create a message. This allocates both the mes-
sage blocks and the associated data buffer of the
requested size. Long messages can be created by
multiple calls to allocb() and linking the blocks
together by a linkb() procedure. If the system is
low on memory, allocb() can fail; a bufcall() pro-
cedure needs to be called, which queues the
allocation request and calls a function when the
buffer is available.
STREAMS also provide improved data buffer
handling capabilities for reducing the number of
memory copies. These mechanisms are called
extended buffer handling mechanisms. This allows
STREAMS messages to point directly to client-
supplied non-STREAMS data buffers. For exam-
ple, the data buffer in Fig. 3 can be a dual-port
IEEE Communications Magazine • February 2000
166

R AM on an NIC. The NIC stores the data
received from the communication link in its
dual-port memory data buffer. Since this buffer
is mapped to a STREAMS message, the proto-
col layers process this data just like data in any
normal STREAMS message. The message pass-
es through different protocol layer driver until it
reaches the stream head, where the data buffer
is copied to user buffers. Thus, a single copy is
required in the kernel, which results in improved
performance. It should be noted that copying is
required at the user/kernel interface, since in an
operating system the kernel buffers are different
from user buffers.
Head
Message
block
Data
Data
block
buffer
b_cont
Message
block
Data
block
Data
buffer
INEFFICIENCIES OF
STREAMS MECHANISMS
ꢀ Figure 3. A STREAMS message consisting of two message blocks.
These original STREAMS mechanisms suffer
from a number of inefficiencies when used to
implement protocol stacks over uni- and multi-
processor systems. These inefficiencies have
been categorized under four broad headings,
and the reasons for these problems are described
below.
Finally, the flow control mechanisms can be
exerted only on the basis of byte count in a mes-
sage queue. This is a big limitation.
LIMITED MESSAGE HANDLING CAPABILITIES
STREAMS message processing at the receiving
application is inefficient. On getting a read call,
the application receive buffers are filled only
with the currently available received data at the
stream head, and the read call returns. This is
unlike Sockets mechanisms, where the socket
layer tries to fill the full read buffers by waiting
for more incoming data before returning the
call. Thus, STR E AMS receive mechanisms
require more read system calls, and the corre-
sponding context switches, than Sockets mecha-
nisms. This degrades the performance.
INFLEXIBLE INTERMODULE COMMUNICATION
STREAMS defines standard well defined mes-
sages and interfaces between drivers. Developers
must adhere to these interfaces. This well
defined separation prevents high-performance
mechanisms that require messages to be pro-
cessed across the stream head and the underly-
ing protocol layers boundary. The integrated
layer processing (ILP) technique of combining
checksum calculation with user-to-kernel copy
operation is not possible. ILP techniques opti-
mize costly memory access operations in any
protocol by integrating all data manipulations in
a single processing loop. Since the stream head
is a separate driver from the transport driver, it
is unaware of transport segment boundaries
while copying data from user space to kernel
buffers. Hence, the stream head cannot perform
transport segment checksum calculation simulta-
neously with this copy operation.
ISSUES IN SCHEDULING MECHANISMS
STR EAMS suggests that implementers carry
most of their protocol processing in service()
procedures instead of the put() procedure. The
processing routines should queue their messages
in the put() procedure, to be processed when
STREAMS schedules the service() procedure for
the queue. This prevents the current process
from hogging the kernel and gives a chance to
other kernel functions to execute.
Also, the multiplexer drivers prevent flow of
information across adjacent driver layers. For
example, in Fig. 1 the transport mux driver
causes multiple streams to be created. The mux
driver terminates stream # 1; hence, the stream
does not continue below the mux driver (stream
# 3 is an independent stream). This characteris-
tic of the mux driver prevents the usual flow
control mechanisms (water marks and the asso-
ciated scheduling) of STREAMS to work across
these streams. The implication of this is that
the flow control information in the subnet driv-
er cannot flow to the user applications running
over this subnet, since the information flow is
terminated at the transport driver. Subnet pro-
tocols like asynchronous transfer mode (ATM)
or frame relay usually receive congestion infor-
mation from the network and are supposed to
throttle the applications above them responsi-
ble for sending large data. This is impractical to
implement in STR E AMS since the subnet
stream cannot flow control the application
streams.
This introduces queuing/dequeuing delays.
Also, service() procedures are normally sched-
uled by different threads of execution, such as
the end of a system call or return of an interrupt
routine. This introduces delays due to context
switching and the time required before schedul-
ing service() procedures. These delays cause sig-
nificant performance degradation.
These problems do not exist with put(), and
the processing is faster. A put() procedure is
called with the message to be processed as a
parameter to the procedure. The procedure pro-
cesses the message immediately and passes it to
the next protocol layer by calling the put() pro-
cedure of the next layer. Thus, no queuing and
dequeuing of the messages or any scheduling
delays are incurred.
However, the use of service() procedures pro-
vides additional scheduling mechanisms for
developers that can be effectively used to imple-
ment many of the desired protocol functions
which require such scheduling (e.g., timer han-
IEEE Communications Magazine • February 2000
167

STR E AMS limitations. The work provides
improved intermodule communication and
makes effective use of STREAMS scheduling
mechanisms.
High water mark = 1
The STREAMS mechanisms force strict byte-
count-based intermodule flow control and pre-
vent one from exerting flow control on the
occurrence of any other event in the protocol
driver. These mechanisms were made flexible by
adapting a message storing architecture, as
shown in Fig. 4. The messages coming from
UWQ were stored in a locally defined message
queue that was independent of the STREAMS
message queue. Thus, storage of messages in this
queue does not exert flow control on the upper
modules. A high water mark of 1 byte was
defined for the actual STR E AMS message
queue, where no message was stored.
The protocol driver could exert flow control on
the upper module at any point of time by inserting
a 1-byte message in the STREAMS message queue.
The flow control can be relaxed by removing this 1-
byte message. Thus, one can exert flow control on
any event occurring in the module, independent of
the byte-count in the message queue. This could be
used by the subnet driver to exert flow control over
higher layers on receiving congestion notifications.
Alternatively, the same mechanisms can be used by
transport protocols (e.g., OSI TP4) that would like
to exert flow control on applications based on num-
ber of packets in their window, instead of number
of bytes (as in TCP).
OSI TP4 protocol was implemented using this
architecture. The standard flow control mecha-
nisms require one to choose a transport driver
high water mark based on a maximum number
of unacknowledged bytes in the transmit win-
dow. Since TP4 end-to-end flow control mecha-
nisms are based on a packet-count-based window
size, one needs to decide the HWM byte count
as a multiple of maximum window size (in terms
of number of packets) and maximum transport
packet size. If the average packet is much small-
er than this maximum, large memory buffers are
held onto in the transport driver (which cannot
be transmitted remotely, since the maximum
packet count has been reached) before the driv-
er can exert flow control on the applications.
In our architecture the TP4 packets were
kept in the OOB queue. The packet count was
tracked and 1-byte flow control exerted when
the packet count reached the maximum trans-
port window size. Thus, no memory buffer
wastage could occur. Our performance analysis
at a maximum packet size of 1 kbyte and an
average packet size of 512 bytes showed that the
worst case memory buffer usage in our architec-
ture was 50 percent of the standard STREAMS
approach. It should be noted that the overhead
of having one additional byte, for exerting flow
control, is insignificant compared to the large
memory buffer savings observed.
STREAMS message queue
STREAMS message
queue
URQ
LRQ
UWQ
LWQ
Transport driver
Locally
defined
data
queue
ꢀ Figure 4. Message queues for data in the OOB architecture.
dling). Thus, improved STREAMS architectures
need to judiciously choose between the use of
put() and service() procedures.
LACK OF PARALLELISM
STREAMS mechanisms are not optimized for
multiprocessor architectures. For good scalabili-
ty on such architectures, one must be able to
distribute tasks between the processors and
allow tasks to run in parallel. In STREAMS, the
kernel maintains a single global list of enabled
service() procedures, which are processed in
FIFO manner by the STR E AMS scheduler.
This strict FIFO scheduling prevents paral-
lelism. Service() procedures run in threads that
are out of context of the main data path; trying
to run them in parallel may lead to data being
delivered out of sequence, unless appropriate
locking mechanisms are applied. A large amount
of locking consumes time and degrades perfor-
mance.
Also, mux drivers prevent a stream from
being formed end to end. In Fig.1, one would
like different message paths to be parallelized.
Protocol processing on a message coming from
an application until the time it is transmitted on
the NIC should run on one processor so that
the complete in-sequence data path is paral-
lelized with other similar data paths. It would
require one to lock a stream and then process
data on it. But since streams break at the mux,
end-to-end processing on the stream is not pos-
sible since stream locking at stream# 1 cannot
lock the stream across the driver, stream # 3
(since stream # 3 is used by multiple upper
streams, any single upper stream locking this
lower stream will prevent all other upper
streams from using it, preventing parallelism).
Thus, per-stream parallelism becomes difficult
to implement.
A STUDY OF
IMPROVED ARCHITECTURES
Another contribution of the article was making
intelligent use of STREAMS scheduling mecha-
nisms to implement the timer handling functions
of protocols. The protocol driver stores the data
to be used on timeout in local structures and
invokes the timer by calling the timeout() proce-
dure, with the time period as the parameter. On
timeout, a user-defined function is invoked that
OUT OF BAND ARCHITECTURE
The author implemented a STR EAMS-based
protocol stack in [7] that will be referred to as
the out of band (OOB) architecture. The tech-
niques devised were able to address some of the
IEEE Communications Magazine • February 2000
168

executes the protocol functions by referring to the
data stored in these local structures (e.g., for
retransmission of packets these structures will
point to the messages to be retransmitted). This
implementation was simplified by assigning a sep-
arate queue for timer handling. A controlling
application program opens the transport driver
and creates a stream to it. All the data to be used
on expiry of the timer are stored in the message
queue of this stream. On timer expiry, the time-
out routine calls a STREAMS qenable() routine
to enable the service() procedure of this queue.
The procedure gets the relevant structures from
this message queue and executes its functions.
Thus, it could provide a simplified implementa-
tion by using the existing STREAMS queues and
scheduling mechanisms.
It should also be noted that the Retix archi-
tecture [8] also makes effective use of
STREAMS scheduling mechanisms by having an
independent timer driver based on it. The differ-
ence in our approach is that our timer queue is
within the transport driver, but their architecture
uses a single timer driver that services all proto-
col layers.
processes are dynamically balanced by the oper-
ating system, service() procedures also get auto-
matically balanced without any extra effort.
An interesting
design
Similarly, symmetric multiprocessor hardware
dynamically directs an interrupt to the processor
running the lowest-priority process. This fact was
used to send a scheduling interrupt to make an
instance of scheduler run as the handler of this
interrupt. This provides the thread for the service()
procedure. Since interrupt handlers are dynamical-
ly balanced, so are these service() procedures.
Although [9] does not give any experimental
data, it does mention that performance improve-
ment was observed when additional processors
were added, due to this improved parallelism.
The Sequent architecture also improves the
message handling capabilities of STREAMS for
both uni- and multiprocessors. If the memory
message allocation call fails, STREAMS requires
a bufcall() routine to be called to invoke a user-
defined function on the later availability of the
buffer. But if a stream closes after calling bufcall(),
the user-defined function is unable to find its data
structures and corrupts the kernel. To avoid this, a
new unbufcall() utility was created that cancels the
previous bufcall(). This unbufcall() must be called
as part of any module’s close procedures.
consideration of
the architecture
was improving
STREAMS
scheduling
mechanisms to
implement paral-
lelism. STREAMS
provides strict
FIFO scheduling
of service()
procedures on its
global queue.
This was modified
by having the
scheduler
SEQUENT ARCHITECTURE
We now look at the first parallel STR EAMS
architecture, from Sequent [9]. This architecture
runs on their tightly coupled Symmetry multipro-
cessor system. For improved scalability on multi-
processors, multiple tasks should work in parallel
on multiple processors. The Sequent architecture
provides mechanisms to provide two types of par-
allelism: horizontal parallelism, where functions
within each stream run on one processor (e.g., in
Fig. 1, stream # 1 will run on one processor and
# 2 on another); and vertical parallelism, where
functions within a stream can themselves run in
parallel on different processors (e.g., timod and
transport driver functions of a single stream run-
ning in parallel). Data consistency is achieved by
ensuring fine-grained locking.
An interesting design consideration of the
architecture was improving STREAMS schedul-
ing mechanisms to implement parallelism.
STREAMS provides strict FIFO scheduling of
service() procedures on its global queue. This
was modified by having the scheduler schedule
these procedures on the global queue on any
available processor. The addition and deletion of
procedures on this queue is synchronized by a
global lock. The thread of execution of the pro-
cedures must be provided intelligently to dynam-
ically balance the load on the processors. Two
alternative mechanisms were adopted.
It has been observed that symmetric multi-
processor operating systems inherently balance
the total process load on the number of available
processors. Thus, if a number of applications’
processes are present, the runnable process will
normally be dispatched to run on the processor
running the lowest-priority process. This fact was
used to create multiple system daemon processes
to provide the thread of execution for service()
procedures. These processes wait on a common
semaphore and get awakened when a new ser-
vice() procedure is enqueued in the global
queue. The service() procedure then executes in
the thread of the daemon process. Since daemon
SVR4MP ARCHITECTURE
The Sequent architecture was based on the
assumption that developers are performing most
protocol processing in the service() procedures
rather than in the put() procedures. There can
still be different views on this point, but the Sys-
tem V R elease 4 MultiProcessor (SVR 4MP)
parallel architecture [10] is based on the assump-
tion that put() procedures occur more than ser-
vice() procedures. They have analyzed a running
TCP/IP stack and have shown that put to service
ratio is 1.6:1.
Since parallelizing multiple service() proce-
dures is not required, they have not used the
fine-grained vertical parallelism and complex
scheduling mechanisms adopted in the Sequent
architecture. Instead, horizontal stream-level
parallelism was adopted where each stream was
run over a single processor. In effect, there is
only one operation per stream allowed at a time.
A lock per stream was used which significantly
reduced large number of locking operations
required in finer-grained parallelism approaches.
Thus, throughout the system call and corre-
sponding put() procedures in different modules,
a single stream lock was held. Independent
streams can run in parallel on multiple proces-
sors, improving performance. Results showed
that TCP /IP performance improved when addi-
tional 33 MHz Intel 486 processors were added
on Compaq Systempro. The speedups over one
CPU were 1.78 at two processors, 2.35 at three,
2.55 at four, and 2.93 at five processors.
schedule these
procedures on
the global queue
on any available
processor.
However, the inflexible intermodule commu-
nication of mux drivers prevents the single lock
to work across the streams on two sides of a
mux. For example, in Fig. 1, after locking stream
# 1 and processing data on it, the transport driv-
er put() cannot invoke the Internet driver put()
procedure since stream # 3 is an independent
stream and has not been locked. Thus, the
SVR4MP model fails.
IEEE Communications Magazine • February 2000
169

This problem was solved in
SVR 4MP by designing a coupler
module over the stream below a
mux driver. The upper layer call
will now use this module to give a
call to acquire the lock of the lower
stream. If this succeeds, the mes-
sage is passed to the lower stream.
If the acquisition fails, coupler mod-
ule queues the message in its queue
and tries later from its service()
procedure. A separate queue lock
has been provided that is indepen-
dent of a stream lock so that the
Feature
Architecture
Flexible intermodule communication
Improved message handling
OOB, SVR4MP, demux
Sequent, demux
Efficient use of scheduling mechanisms OOB, Sequent, Retix
Improved parallel architecture
Sequent, SVR4MP,
demux
ꢀ Table 1. A summary of improvements achieved by different
architectures.
messages can be queued even in absence of
holding the stream lock. When the lower layer
service() procedure runs, it is being executed
with its stream lock being held, and hence can
process the data.
frame relay need to control their data transmis-
sion rate on receipt of congestion notification
frames. In the demux architecture, the incoming
congestion notification makes the anchorage
driver exert flow control, which prevents the cor-
responding transport layer from sending more
data on a congested link.
DEMUX ARCHITECTURE
The demultiplexed STREAMS architecture [5]
provides improved intermodule communication
and efficient message handling on uniprocessors
and improved parallelism on multiprocesors.
This architecture, like SVR4MP, uses put()
rather than service() procedures to avoid schedul-
ing delays. As shown in Fig. 5, the architecture is
based on having an end-to-end stream from the
stream head to the lowest layer. The transport
and Internet layers reside as modules, not as
drivers. The protocol control functions are also
implemented as separate streams, for example,
and an ICMP/IP modules stream handles control
packets. The only demultiplexing is performed at
an anchorage driver residing above the subnet
driver. This looks at all protocol layer headers
and demultiplexes incoming packets to the trans-
port applications or control streams to which
they are destined.
The work also gives improved message han-
dling facilities in STR E AMS. In original
STREAMS, when an application sends data on
a stream, the stream head copies the user
buffer to the kernel, and the transport driver
segments it into packets. While segmenting,
the checksums are calculated. The demux
architecture moves the segmentation functions
to the application libraries (called XTI). The
library routines segment the data before send-
ing it down. These segmented buffers are then
copied from user to kernel buffers, and check-
sum is performed simultaneously on it (since
the segment boundaries are already known).
Integrating copying and checksum gives high
performance.
The receive buffer handling performance was
improved by having the stream head completely
fill the application buffers on getting a read call.
Also, to take care of the special case of interac-
tive applications (where application cannot wait
for the complete buffer to be received), an option
was provided in the library to make the read call
return immediately with the data currently avail-
able in the stream head receive buffers.
This architecture removes the limitations
imposed by a mux transport driver. The end-to-
end stream from application to anchorage driver
allows the driver to invoke flow control through
to the transport layer on receipt of subnet con-
gestion information. Protocols like ATM and
These improvements resulted in the
STREAMS TCP/IP stack giving similar perfor-
mance as a BSD TCP/IP stack. The experiments
were conducted running one TCP connection in
loopback mode on a 42 MH z Power DPX/20
running AIX/3.2.5. At a transport service data
unit (TSD U ) size of 8 kbytes, the standard
STR E AMS stack gave a throughput of 3000
kbytes/s, while both the demux and BSD stacks
gave a throughput of 5000 kbytes/s.
The architecture also simplifies multiproces-
sor implementation. As in SVR4MP, per-stream
locking was used to run all streams in parallel.
The clean end-to-end stream from the applica-
tion avoids the locking problems associated
with the breaking of the streams due to mux
drivers. An interesting advantage of the demux
approach is that it gives high parallelism
because the functions within the protocols, such
as control packet handling, can also run in par-
allel on different processors. This is possible
since each function is running in a different
stream (e.g., ICMP/IP is a separate stream).
This is not possible to implement in any other
Head
Head
TIMOD
TIMOD
TCP
module
TCP
module
ICMP
module
IP
IP
IP
module
module
module
Anchorage driver
Subnet
driver
ꢀ Figure 5. Demux STREAMS TCP/IP stack implementation.
IEEE Communications Magazine • February 2000
170

architecture, since all the protocol functions
run as a monolithic unit in their modules. Anal-
ysis has shown that their STREAMS architec-
ture shows better scalability than the BSD
parallel architecture on a four-processor 66
MHz PC601 ESCALA running AIX/4.1.2. The
speedup from one to four processors was 2.6 in
the demux architecture, compared to 2.2 in the
BSD architecture.
REFERENCES
[1] AT&T, Unix System V Release 4 Programmer’s Guide:
STREAMS, Prentice Hall, 1992.
[2] H. Custer, “Inside Windows NT,” Microsoft, 1995, pp.
285–326.
[3] Integrated System Inc., “pSOSystem System Concepts,”
rel. 2.0, 1995.
[4] S. J. Leffler et al., The Design and Implementation of the
4.3 BSD Unix Operating System, Addison-Wesley, 1990.
[5] V. Roca, T. Braun, and C. Diot, “Demultiplexed Architec-
tures: A Solution for Efficient STREAMS-Based Communi-
cation Stacks,” IEEE Network, July/Aug. 1997, pp. 16–26.
[6] B. Krupczak, K. L. Calvert, and M. H. Ammar, “Increas-
ing the Portability and Re-Usability of Protocol Code,”
IEEE/ACM Trans. Net., Aug. 1997, p. 445.
[7] V. K. Khanna, “ISO Transport Protocol Implementation
in Unix STREAMS Environment,” vol. 6, (1995), Inter-
networking Res. and Experience, pp. 143–66.
[8] SCO, “SCO/RETIX OSI/LT-610 Administrator’s Guide,” 1990.
[9] A. Garg, “Parallel STREAMS: A Multi-Processor Imple-
mentation,” Proc. USENIX, Winter 1990, pp. 163–76.
[10] S. Sa xen a e t a l., “Pit fa lls in Mu lt it h rea d in g SVR4
STREAMS a n d Ot h e r We ig h t le ss Pro ce sse s,” Pro c.
USENIX, Winter 1993, San Diego, CA, pp. 85–96.
The performance
of one of
the recent
architecture,
namely the
demux
CONCLUSIONS
architecture, has
been shown to
match the
STR EAMS provides a number of facilities to
ease development of protocol stacks, but the
original STREAMS-based stacks have had very
low performance. The reasons for this are ana-
lyzed in this article. These are limitations in
intermodule communication, inefficient message
handling, problems in scheduling mechanisms,
and lack of parallelism in the STREAMS archi-
tecture. A study of a number of mechanisms
devised in the past few years to improve the per-
formance of STREAMS-based stacks is present-
ed. The use of these mechanisms results in
STREAMS-based protocol implementations that
give high performance, coupled with the other
advantages available with STREAMS. The per-
formance of one recent architecture, namely
demux, has been shown to match the perfor-
mance of protocol stacks implemented in a BSD
Sockets kernel. Improved STREAMS parallel
architectures have shown good scalability on
multiprocessor systems. A summary of the archi-
tectures discussed and the improvements due to
these is given in Table 1.
performance of
protocol stacks
implemented
in a BSD
BIOGRAPHY
Sockets kernel.
VIMAL K. KHANNA heads Cabletron software engineering in
India. He has 14 years of networking software develop-
ment experience in the industry. He has developed prod-
ucts and executed projects in networking protocols like
TCP/IP, SNMP, OSI TP4/CLNP, ATM, frame relay, X.25, Ether-
net, wireless LANs, and others. His areas of research inter-
est also include suggesting operating system extensions to
support high-speed networking protocols. His indepen-
dently written papers have been published in international
networking journals. He is on the editorial board of IEEE
Communications Magazine. He is a recipient of the Nation-
al Talent Search Scholarship and the Central Board of Sec-
o n d a ry Ed u ca t io n Silve r Me d a l in In d ia . He h a s h e ld
positions of merit in the All India Senior Secondary and
Indian Engineering Services examinations.
IEEE Communications Magazine • February 2000
171
