Synthesis and aggregation of a porphyrin cored
hyperbranched polyglycidol and its application as a
macromolecular photosensitizer for photodynamic therapy
Alaa Kadhim, Luke K. McKenzie, Helen E Bryant, and Lance James Twyman
Mol. Pharmaceutics, Just Accepted Manuscript • DOI: 10.1021/acs.molpharmaceut.8b01119 • Publication Date (Web): 29 Jan 2019
Downloaded from http://pubs.acs.org on January 31, 2019
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a service to the research community to expedite the dissemination
of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts appear in
full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been fully
peer reviewed, but should not be considered the official version of record. They are citable by the
Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered to authors. Therefore,
the “Just Accepted” Web site may not include all articles that will be published in the journal. After
a manuscript is technically edited and formatted, it will be removed from the “Just Accepted” Web
site and published as an ASAP article. Note that technical editing may introduce minor changes
to the manuscript text and/or graphics which could affect content, and all legal disclaimers and
ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors or
consequences arising from the use of information contained in these “Just Accepted” manuscripts.
is published by the American Chemical Society. 1155 Sixteenth Street N.W.,
Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
Synthesis and aggregation of a porphyrin cored
hyperbranched polyglycidol and its application as a
macromolecular photosensitizer for photodynamic
therapy.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Alaa Kadhim,1 Luke K. McKenzie,1,2 Helen E. Bryant 2 and Lance James. Twyman 1*
1. Department of Chemistry, University of Sheffield, Sheffield, S3 7HF, UK. 2. Department
of Oncology and Metabolism, University of Sheffield, Sheffield, S10 2RX, UK.
KEYWORDS Photodynamic therapy, drug delivery, hyperbranched polymers, self-assembly.
ABSTRACT
Macromolecules are potentially useful delivery systems for cancer drugs as their size allows
them to utilize the enhanced permeability and retention effect (EPR), which facilitates
selective delivery to (and retention within) tumors. In addition, macromolecular delivery
systems can prolong circulation times as well as protecting and solubilizing toxic and
ACS Paragon Plus Environment
1

Molecular Pharmaceutics
Page 2 of 30
1
2
3
4
5
6
7
8
9
hydrophobic drug moieties. Overall these properties and abilities can result in an enhanced
therapeutic effect. Photodynamic therapy (PDT) combines the use of oxygen and a
photosensitizer (PS), that become toxic upon light-irradiation. We proposed that a PS
encapsulated within a water-soluble macromolecule could exploit the EPR effect and safely
and selectively deliver the PS to a tumor. In this paper, we describe the synthesis of a
porphyrin cored hyperbranched polymer that aggregated into larger micellar structures.
DLS and TEM indicated that these aggregated structures had diameters of 45 nm and 20 nm
for the solvated and non-solvated species respectively. The porphyrin cored HBP (PC-HBP),
along with the non-encapsulated porphyrin (THPP), were screened against EJ bladder
carcinoma cells in the dark and light. Both THPP and PC-HBP displayed good toxicity in
the light, with LD50 concentrations of 0.5 M and 1.7 M respectively. However, in the
dark, the non-incorporated porphyrin (THPP) displayed significant toxicity, generating an
LD50 of 4 M. On the other hand, no dark toxicity was observed for the polymer system
(PC-HBP) at concentrations of 100 M or less. As such, incorporation within the large
polymer aggregate serves to eliminate dark toxicity, whilst maintaining excellent toxicity
when irradiated.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
INTRODUCTION
ACS Paragon Plus Environment
2

Page 3 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
Photodynamic therapy (PDT) is a treatment that exploits the combined action of a
photosensitizer (PS), oxygen and a specific light source.1 Upon irradiation, a PS can activate
molecular oxygen, transforming it into a number of therapeutically active oxygen species
(singlet oxygen and free radicals) which act to destroy abnormal cells. Although the
principle application of PDT has been towards the treatment of cancers, 2 including lung
cancer,3,4 mouth cancer 5 and skin cancer. 6 Other conditions that can be treated with PDT
include, actinic keratosis, 7 Bowen's disease (an early form of skin cancer), 8 macular
degeneration (an eye condition leading to vision loss), 9 and Barrett's oesophagus (treats
damaged cells in the lining of the oesophagus). 10 More recently, PDT has also shown
promise as an antibacterial agent.11 There are also examples of PDT systems that involve a
synergistic delivery of photosensitizers and antitumor drugs.12 Although PDT is an
established principle, the number of photosensitizers approved for clinical use is limited.
This is due to the photosensitizers (PS) either having low water solubility, significant “dark“
toxicity or a lack of specificity. Solubility can be increased and dark toxicity reduced via
modification of the PS. However, this has the potential to reduce or destroy the therapeutic
efficiency of the PS. Alternatively, the PS can be incorporated within a supramolecular
nanocarrier. As well as increasing water solubility and limiting dark toxicity, the use of
nanocarriers can result in the preferential accumulation of the PS within tumors due to the
enhanced permeability and retention effect (EPR effect). 13 For effective EPR, molecules
with molecular weights greater than 40 kDa are required (up to 800 kDa). 14 As well as
effecting tumor accumulation, another benefit of EPR is an increased half-life within the
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
ACS Paragon Plus Environment
3

Molecular Pharmaceutics
Page 4 of 30
1
2
3
4
5
6
7
8
9
blood stream, as the sizes involved exceed the threshold limit for renal extraction. Overall,
nanocarrier PS can be specifically targeted towards tumors and result in a 10-fold increase in
tumor concertation (when compared to smaller PS).15 Examples of proposed nanocarriers for
photodynamic therapy include liposomes, 16,17 polymeric nanoparticles, 18 silica nanoparticles,
19 graphene oxide systems 20 and porphyrin cross-linked polymers. 21 One particularly good
exemplifier of a macromolecular PS are the dendrimer functionalized polyion-complexes
(PIC).22 For example, Kataok reported the use of amino terminated dendrimers capable of
forming micellar PIC when mixed with PEG-b-poly(Asp). In vitro studies on this PIC
showed excellent photodynamic efficacy towards LLC cells, with LD50 values less than 1
M.23 Although the use of dendrimers was successful, their step-wise synthesis is time
consuming, expensive and can be difficult. This has limited their large-scale production and
potential therapeutic exploitation. Hyperbranched polymers (HBP) possess structures and
physical properties that are very similar to those displayed by dendrimers. 24 However, their
synthesis is quick (often involving a single synthetic step) and inexpensive, which enables
them to be made more easily and on a large scale. Our aim was to develop a safe,
synthetically simple hyperbranched polymeric photosensitizer, which was non-toxic in the
dark, would kill cancer cells when irradiated with light, and target tumors by virtue of their
size.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
We have previously studied hyperbrbanched polygylcidols for application as drug delivery
systems. 25 These HBPs are water-soluble and although studies have not been exhaustive,
ACS Paragon Plus Environment
4

Page 5 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
they appear to be safe with respect to clinical application. 26 Previous work within our
laboratory observed that hyperbranched polygylcidols can aggregate at very low
concentrations (critical aggregation concentration/CAC of 0.1 mg/mL).27 A low aggregation
concentration is important with respect to any therapeutic application, as the aggregated PS
should be able to maintain its structure as it circulates through the blood stream. Subsequent
measurements using Dynamic Light Scattering (DLS) indicated that these self-assembled
aggregates had solvated diameters between 40-90 nm, which is similar in size to the
dendrimer functionalized PIC.22 As such, these polymers in their aggregated form make
ideal delivery systems for photosensitizers and for application in PDT.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
EXPERIMENTAL
Materials. All reagents and solvents were obtained from commercial sources (primarily
Sigma- Aldrich) and were used without further purification. Dry solvents were obtained
from the University of Sheffield Chemistry Department Grubbs solvent dispensing system.
All glassware was cleaned and dried in an oven overnight (100 °C) before use.
Instrumentation and methods. UV absorbance was recorded on an Analytic Jena AG Specord
s600 uv/vis spectrometer and analyzed using WinASPECT. Infrared spectra were recorded
using a Perkin-Elmer UATR Infrared spectrometer. Spectra were analyzed with Spectrum100
software. 1H NMR and 13C NMR spectra were recorded using a Brucker AV1400 MHz
ACS Paragon Plus Environment
5

Molecular Pharmaceutics
Page 6 of 30
1
2
3
4
5
6
7
8
9
machine and chemical shifts referenced to residual solvent signals. Chemical shifts are
quoted using ppm and coupling constants quoted in Hertz. The NMR spectra were analyzed
using Topspin 3.0 NMR software. Fluorescence Spectroscopy was obtained using a
FluoroMax-4 spectrometer. Aqueous Gel Permeation Chromatography (GPC) data was
obtained at room temperature using a high molecular weight column (2x aquagel-OH).
Calibration was achieved using polyethylene glycol standards (Mn 220-1,500,000 Da) and
molecular weights are thus reported relative to these specific standards used. Samples were
filtered using Whatman® GD/X syringe filters with a pore size of 0.45 µm before being
injected onto the column through a 200 µL sample loop via a Gilson 234 Auto Injector. The
samples were prepared and eluted using phosphate buffered saline (PBS) at pH 7.4 as solvent
(which was supplied to the columns by a Waters 515 HPLC Pump at 1.00 mL min-1). Sample
detection was via an Erma ERC-7512 refractive index detector.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Synthesis. Tetrakis (4-hydroxyphenyl)-porphyrin (THPP) 1. 5, 10, 15, 20-Tetrakis (4-
hydroxyphenyl)-porphyrin (THPP) was synthesized according to the Rothemund and Adler-
Longo method. 28 In a brief, freshly distilled pyrrole (4.17 mL, 60 mmol) and 4-Hydroxy
benzaldehyde (10 g, 60 mmol) were added to refluxing propionic acid (300 mL). The mixture
was refluxed for 1 hr, allowed to cool to room temperature and placed for 1 hour at −5 °C.
The sample was washed thoroughly with a mixture of cold propionic acid and alcohol (1:1),
followed by cold chloroform. Yield 2.30 g. UV (methanol-nm): 418 (max),516, 554, 588, and
649; IR (neat- cm-1): 3249 (OH), 2924 (NH), 2875 (CH), 1609 (C=N), 1463(C=C), 1HNMR δH
ACS Paragon Plus Environment
6

Page 7 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
(DMSO-d6): 9.99 (s, 4H, OH), 8.85 (s, 8H, β-Pyrrole), 7.97(d, , J=9.0 Hz, 8H phenylic m-CH),
7.18 (d, J=9.0 Hz, 8H, phenylic o-CH), −2.92 (s, 2H, NH-pyrrole). 13CNMR (DMSO-d6):169.1,
157.3, 136.8, 129.2, 114.7, 117.1, 110.9. ESI-MS: 679; MH+ = 679 gmol-1.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Tetrakis (4-hydroxyphenyl)-porphyrin-spacer (THPP-spacer) 3. 5,10,15,20-
Tetrakis(4-hydroxyphenyl)- 21H,23H-porphyrin (177 mg, 0.261 mmol), K2CO3 (453 mg, 3.13
mmol), and 18-crown-6 (10 mg) were added to 30 mL of dimethylformamide (DMF). 1,3-
Bromopropanol (291 mg, 2.09 mmol,) was added and the reaction was vigorously stirred
under reflux overnight followed by TLC. The DMF was evaporated and the reaction mixture
was dissolved in 200 mL of ethyl acetate and extracted three times with water (100 mL). The
solvents were evaporated to yield (80%) a purple solid. UV (methanol-nm): 418 (max), 515,
554, 588, and 649 IR (neat- cm-1): 3249 (OH), 2924 (NH), 2870 (C-H), 1609 (C=N), 1463
(C=C), 1H NMR (DMSO-d6): δ 8.85 (s, 8H, β-Pyrrole), 7.97 (d, J=9.0 Hz, 8H, phenylic m-CH),
7.18 (d, J=9.0 Hz, 8H, phenylic o-CH), 4.58 (s, 4H, phenylic m-OH), 4.20 (t, J=7.0 Hz, 8H, -
O-CH2-CH2-), 3.63 (t, J=7.0 Hz, 8H, -CH2-OH), 2.47 (m, 8H, -CH2-CH2-CH2-), -3.01 (s, 2H,
NH). 13C NMR (DMSO-d6): δ158.4, 135.4, 135.4, 134.6, 119.5, 112.0, 56.9, 54.0, 31.6. ESI-MS:
911: M+ = 911 gmol-1.
Porphyrin cored hyperbranched polyglycerol (PC-HBP) 4. The THPP-spacer 3 (0.1 g,
0.11 mmol) was added to diethylene glycol dimethyl ether (10 mL) in a round bottomed flask
fitted with a condenser. The solution was stirred at 90°C until the porphyrin 3 had dissolved.
Potassium methoxide (0.031 g 0.43 mmol) was added and the reaction left for a further 90
ACS Paragon Plus Environment
7

Molecular Pharmaceutics
Page 8 of 30
1
2
3
4
5
6
7
8
9
minutes. Glycidol (1.63 g 0.43 mmol) was added drop-wise via a syringe pump over 4 hours
and the reaction left for a further 5 hours at 90 °C. The mixture was allowed to cool to room
temperature. The solvent was decanted off and a minimum amount of methanol was added
to cause precipitation of the by-products. The solid material was then removed by filtration,
the filtrate poured into acetone, and the mixture stirred for 1 hour. The solvent was then
decanted off. The material that remained was washed several times with acetone, which was
decanted off after each wash. This was repeated until the washings were colorless. After
removal of all solvent and drying under vacuum, the porphyrin cored hyperbranched
polyglycerol was obtained as an extremely viscous red solid in a yield of 75% by mass. UV
(methanol-nm): 424 (max), 516, 556, 593 and 645; IR (neat- cm-1): 3350 (OH), 2875 (CH),
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
1
1340 (O-C-O), 1070 (C-O). H NMR (D2O): δ 8.88 (br-s,8H, β-Pyrrole), 8.05 (br-d, phenylic
m-CH), 7.25 (br-d, phenylic o-CH), 4.08-3.20 (br-m, H, remaining CH, and CH2). 13C NMR
(D2O): 158, 150.7, 146.3,131.2, 78.7, 77.0, 72.1, 70.3, 66.4, 62.3, 60.4, 42.2; GPC; Mn 32500,
Mw 69200.
Critical Aggregation Concentration (CAC) by pyrene emission. CACs of HPG polymers were
determined by fluorescence measurements using pyrene as a probe. 100 L of an aqueous
pyrene solution (6 x 10-7 M) was added to a series of polymer solutions (4 mL) with
concentrations ranging from 0.001 mg/mL to 1.0 mg/mL. Fluorescence spectra were recorded
using an excitation wavelength of 334nm, and emissions at 372 nm and 384 nm were
ACS Paragon Plus Environment
8

Page 9 of 30
Molecular Pharmaceutics
1
2
3
4
monitored. The CACs were estimated by plotting the intensity ratio I384/I372 vs polymer
5
6
7
concentration.
8
9
Cell culture. EJ (bladder carcinoma) cells were purchased from American Type Culture
Collection–LGC partnership (Teddington, UK) and used within 20 passages of purchase. Cells
were cultured using Dulbecco’s modified Eagles Medium (DMEM) (Lonza, Cambridge UK)
with 10% fetal calf serum (FCS) (Lonza, Cambridge UK) and cultured in an incubator (37 °C,
5 % CO2). The cells were passaged when 70-80 % confluence was reached and regularly
checked for mycoplasma contamination. Stock solutions of compounds were stored in
deionized water, or DMSO, at 10 mM aliquoted in small volumes to avoid freeze/thaw cycles.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Imaging by confocal microscopy. EJ (bladder carcinoma) cells were seeded on sterile cover
slips (22 x 22 mm) in 6 well dishes at a density it of 150,000/well and incubated overnight.
Staining solutions of the desired compound were made by dilution into culture media (10
µM) and added to the cells for 24 hours. Once incubation had taken place the cells were
washed (PBS) and fixed (4% paraformaldehyde solution in PBS, 4 °C, 20 mins) before being
washed again (PBS) and mounted (IMMU-MOUNT, Life Technologies Ltd, Paisley, UK). The
slides were imaged by confocal microscopy (Inverted Zeiss LSM 510 NLO microscope) using
a 60 × lens, with activation by helium-neon laser (λ = 633 nm). Emission was registered in
the region 650-710 nm.
ACS Paragon Plus Environment
9

Molecular Pharmaceutics
Page 10 of 30
1
2
3
4
5
6
7
8
9
MTT assay - Light and dark toxicity. 96 well-plates were seeded with EJ cells at 3000/well
and incubated overnight. The wells were treated with PC-HBP 4 or THPP 1 and incubated
for 24 hours. The media was removed and 40 µL/well PBS was added to each well. For light
toxicity experiments the plate was placed in a foil lined box, 6 cm below the light source for
10 minutes at 450/630 nm using an LED array (at 4.20 and 4.85 mW cm-2 respectively). After
storage in the dark, or exposure to light, media was added (DMEM, 10 % FCS, 200 µL/well)
and the plates were placed in the incubator. Following 24-hour incubation thiazoyl blue
(MTT) solution was added to each well (25 μL, 3 mg ml-1 in PBS). After a 3-hour incubation
the media and MTT solution was removed from each well and DMSO was added (150
μL/well) and crystals dissolved. Optical density of the wells at 540 nm were recorded on a
plate reader (Multiskan fc, Thermo Fisher Scientific, Warrington, UK).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
RESULTS AND DISCUSSION
In this work, we proposed to synthesize a hyperbrbanched polyglycidol with a PS at its
core and study its aggregation and its subsequent application as a macromolecular PS. Due to
their strong absorption (and emission) at therapeutically useful wavelengths, porphyrins are
an established PS for PDT and were selected as our photosensitizer unit. Specifically, the
hydrophobic tetra-hydroxyphenylporphyrin (THPP) 1, was selected as the core for our
macromolecular PS. This is a known PS, with good toxicity in light. However, TCPP 1 also
has considerable toxicity in the dark. We proposed that it’s dark toxicity could be reduced, or
even prevented, by incorporation within a HBP. Therefore, our initial attempt to synthesize
ACS Paragon Plus Environment
10

Page 11 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
a porphyrin cored HBP started with porphyrin 1, 29 which was synthesized in good yield
from 4-hydroxybenzaldehyde and pyrrole using standard procedures, Scheme 1. Porphyrin 1
possess four phenolic OH groups, each capable of initiating the ring opening polymerization
of gylcidol 2. As such, the phenol groups of TCPP 1 were deprotonated (to improve
nucleophilicity), and gylcidol 2 added by slow monomer addition. After workup, aqueous
GPC indicated that a polymer with a modest molecular weight of around 10,000 had been
formed, Scheme 1. However, when compared to the polymer backbone, the signals from the
porphyrin group were very weak in the 1H NMR spectrum. This suggested that porphyrin
incorporation had been very low. A qualitative assessment of core incorporation was
estimated by comparing the Mn values obtained from GPC (a bulk analysis technique) and
NMR (a core group analysis technique), 30, 31 that indicated that less than 20% of the polymer
molecules contained a porphyrin core. The problem was caused by delocalisation of the
phenolate ions into the aromatic ring, resulting in poor nucleophilicity and low reactivity
towards the gylidol monomer.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
ACS Paragon Plus Environment
11

Molecular Pharmaceutics
Page 12 of 30
1
2
3
4
5
6
7
8
9
OH
HO
Br
O
HO
O
OH
N
H
N
HO
i) K2CO3
N
N
NH
HN
PC-HBP
H
N
K2CO3, 18-cromn-6
N
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
O
ii)
OH
2
O
O
HO
OH
3
1
HO
OH
i) NaOMe
O
ii)
OH
HO
2
OH
HO
OH
OH
O
OH
HO
HO
HO
O
O
OH
OH
OH
O
HO
O
O
HO
O
O
O
OH
HO
O
O
HO
O
O
OH
O
O
O
O
O
OH
O
OH
O
O
O
HO
O
OH
OH
OH
O
O
O
O
HO
HO
O
O
OH
O
O
OH
HO
HO
O
N
H
OH
HO
N
N
OH
HO
O
H
N
OH
HO
OH
OH
OH
O
O
O
O
HO
O
HO
HO
O
O
O
O
HO
O
OH
O
O
HO
O
O
O
O
HO
O
O
O
HO
O
OH
OH
O
HO
O
O
O
O
HO
O
O
OH
OH
OH
O
HO
HO
O
OH
O
OH
HO
HO
OH
HO
4
OH
Scheme 1: Synthesis of the porphyrin cored hyperbranched polymer (PC-HBP) 4.
ACS Paragon Plus Environment
12

Page 13 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
The stability and low reactivity of the phenol units can be overcome by breaking the
conjugation between the porphyrin and nucleophilic OH group, which can be achieved by adding
a spacer group. This was accomplished by reacting TCPP 1 with a large excess of 3-
bromopropanol in the presence of K2CO3 and a catalytic amount of 18-crown-6, Scheme 1.
After workup and purification, the extended porphyrin 3 was obtained in excellent yield.
Subsequent deprotonation using sodium methoxide, followed by slow addition of 50 molar
equivalents of glycidol 2, gave the water-soluble porphyrin cored hyperbranched polymer (PC-
HBP) 4 in a good 75 % yield, Scheme 1.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
The 1H NMR spectrum of PC-HBP 4 showed two significant sets of peaks, the first was a
group of broad peaks observed in the aromatic region between 7.85–8.40 ppm. These
corresponded to the aromatic groups of the porphyrin core. The second set of peaks were
larger and appeared as a broad multiplet between 3.25 and 4.20 ppm. This is consistent with
the spectra of other hyperbranched polyglycidols and corresponds to the CH, CH2 and OH
groups of the polyglycidol backbone.32 Comparing the relative intensities of these two
regions allowed us to estimate an Mn value of 32,500 Da.30 Aqueous GPC indicated that the
bulk material had an Mn of 21,000 Da. Comparing this value to the Mn obtained via NMR,
allowed us to estimate a minimum core incorporation of at least 65%. On first inspection,
this may appear somewhat low. However, due to the way in which the two methods
calculate Mn, the actual level of incorporation is much higher. For example, when
employing 1H NMR we assume that every polymer has a porphyrin core, and we compare
the intensity of the porphyrin signals with those obtained from the polymer backbone.
ACS Paragon Plus Environment
13

Molecular Pharmaceutics
Page 14 of 30
1
2
3
4
5
6
7
8
9
However, this method cannot differentiate between polymers with or without core and
consequently overestimates Mn. On the other hand, GPC underestimates the value of Mn
for globular HBPs, due to errors derived from calibration using linear polymers (which have
a larger hydrodynamic radius when compared to globular HBPs with equivalent molecular
weights).33,34 As such we were satisfied that a high proportion of polymers possessed a
porphyrin core. Finally, UV analysis of an aqueous solution of HBP 4 confirmed porphyrin
incorporation, through the presence of a Soret band at 424 nm and four smaller Q bands at
516, 556, 593 and 645 nm.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Aggregation of PC-HBP 4 was established through its critical aggregation concentration
(CAC). This was determined using a fixed concentration of pyrene and measuring changes in
emission intensity with respect to increased polymer concentrations.35 The plot of polymer
concentration vs. changes in pyrene emission is shown in Figure 1. The point at which the
pyrene emission changes can be used to estimate the CAC. Our plot shows a break around
0.15 mg/mL and is the concentration at which the aggregate forms, and the pyrene
environment and local concentration changes (as pyrene moves from the bulk aqueous phase
into the smaller hydrophobic volume of the aggregated polymer). This concentration is
typical of the CAC reported for HBPolyglycidols.36 Although it is not possible to determine
a precise molecular weight, and therefore an accurate molar concentration of a disperse
polymer, a CAC between 10-8 and 10-9 M was approximated using the molecular weight
determined from GPC. The size of the aggregated PC-HBP 4 was measured using DLS at a
ACS Paragon Plus Environment
14

Page 15 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
concentration above the CAC (at 0.25 mg/mL), and showed two peaks. The first was a very
small peak around 9-10 nm and is the non-aggregated PC-HBP 4 (solvated). The second
peak, which corresponds to the solvated aggregate of PC-HBP 4, was present at 45 nm. The
number of PC-HBPs 4 within the aggregated structures can be crudely estimated by
comparing the size of the non-aggregated and aggregated species. The ratio obtained allows
us to estimate that at least five of the porphyrin-cored polymers (and therefore five
porphyrin PS), combine to form the aggregated structure. Although relatively small, the
aggregate would have a combined molecular weight around 175 KDa. A TEM image of PC-
HBP 4 confirmed aggregation and showed spherical structures with diameters around 20-30
nm, Figure 2. This size is large enough to be exploited by the EPR effect, with respect to
tumor selective delivery and localization.13
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1. Determination of critical aggregation concentrations (CAC) using pyrene
encapsulation.
ACS Paragon Plus Environment
15

Molecular Pharmaceutics
Page 16 of 30
1
2
3
4
5
6
7
8
9
The intracellular localization of PC-HBP 4 into EJ (bladder carcinoma) cells were imaged by
confocal microscopy. Figure 3 shows porphyrin fluorescence within the cell, confirming that
PC-HBP 4 has been internalized. This is consistent with the intracellular localization
observed for other macromolecules, including porphyrin-cored dendrimer PICs.37
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
45 nm
200
9 nm
Figure 2. DLS and TEM image of the macro-photosensitizer PC-HBP 4.
(c)
(a)
(b)
ACS Paragon Plus Environment
16

Page 17 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
Figure 3. Confocal microscopy images of the EJ cells; (a) red fluorescence from PC-HBP 4
(excited at 420 nm), (b) greyscale image of EJ cells and (c) overlaid images of (a) and (b)
showing localization of PC-HBP 4 within the cells. Scale bar indicates 20 m.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Having established that PC-HBP 4 could be internalized, the in-vitro cytotoxicity of PC-HBP
4 was assessed using EJ (bladder carcinoma) cells and an MTT assay. For comparison, the
porphyrin core THPP 1 was also studied. In the case of the polymer PC-HBP 4,
concentrations were based on the porphyrin concentration, which was determined using UV
and a Beer Lambert analysis.38 Toxicity was initially measured by incubating the two
compounds with cells for 24 hours in the dark, using 100 M of each compound. Despite
the high concentration, the results indicated a healthy 90-95% cell-viability for PC-HBP 4,
confirming very little dark toxicity for the polymeric photosensitizer. However, when using
the non-incorporated porphyrin PS (THPP 1), a cell-viability of only 25% was observed. This
result was statistically significant such that when comparing the dark toxicity of THPP1 with
PC-HBP 4 at 100 M, a p value of 1.10302×10-5 (Student’s paired 2 tailed T.Test) was
obtained, Figure 4.
ACS Paragon Plus Environment
17

Molecular Pharmaceutics
Page 18 of 30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 4. Cell viability following exposure to 100 M THPP1 or PC-THPP4. Mean and SEM of
3 independent repeats are shown. *** represents p<0.0001 Student’s T.Test.
Repeating the dark toxicity experiment at various concentrations of THPP 1 (0.1 – 100 M)
established an LD50(DARK) of 4 M for the porphyrin core, confirming significant dark
toxicity for THPP 1, Figure 5. This is consistent with the study by James et al, who observed
an LD37 of between 1.2 to 3.1 M for the dark toxicity of THPP 1.39 The photo toxicity of
THPP 1 was subsequently measured using the same MTT assay, but exposing the cells to low
dose light for 10 minutes at 450/630 nm using an LED array (at 4.20 and 4.85 mW cm-2
respectively). The data is shown in Figure 5 and shows that almost all of the cells were killed
at 10 M, with statistically significant differences (p=0.0003 and 6.12829×10-8 respectively
(Student’s paired 2 tailed T-Test)) in toxicity between light and dark conditions only
apparent at 0.1 and 1 M THPP 1 and no difference being seen at 10 M and 100 M (p=0.22
and 0.46 respectively (Student’s paired 2 tailed T-Test)). An LD50(LIGHT) value of 0.5 M (±
ACS Paragon Plus Environment
18

Page 19 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
0.1 M), was determined from a plot of cell viability vs concentration, allowing calculation
of a photodynamic index (PI) of 8 for THPP 1, Figure 5. When the photo-toxicity of PC-
HBP 4 was measured using the same MTT assay, like THPP 1 almost all of the cells were
killed at 10 M, and photo-toxicities of 1.5 M and 0.25 M, were recorded for the LD50 and
LD25 values respectively, Figure 6. However in contrast to THPP 1, PC-HBP 4 did not result
in any dark toxicity at 100 M, Figure 6 and a statistically significant difference in toxicity
could be observed between light and dark toxicity at this high dose (p=3.95796×10-7, 2 tailed
paired Student’s T.Test). At 200 M, some dark toxicity was observed, with a cell viability of
75% being recorded for PC-HBP 4, which equates to an LD25 value of 200M. Given the low
dark toxicity of PC-HBP 4 a precise photodynamic index could not be determined using
LD50 values, as only 25% of cells were killed at the highest concentration studied (200 M).
However, a photodynamic index of 800 was determined for the polymeric photosensitizer
using the LD25 values (0.25 M and 200 M for the dark and light toxicities respectively).
This significant increase in the photodynamic index as a result in reduced dark toxicity is a
major advantage over the simple porphyrin molecule (THPP 1) with respect to any potential
therapeutic application.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
ACS Paragon Plus Environment
19

Molecular Pharmaceutics
Page 20 of 30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 5. Cell viability following exposure to increasing doses of THPP 1 in dark or following
exposure to light. Mean and SEM of at least 5 technical repeats are shown. *** represents
p<0.0001 and ns = non-significant in Student’s T.Test.
Figure 6. Cell viability following exposure to increasing doses of PC-HBP 4 in dark or
following exposure to light. Mean and SEM of 3 independent repeats are shown. ***
represents p<0.0001 in Student’s T.Test.
ACS Paragon Plus Environment
20

Page 21 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
At the outset, we planned to develop a macromolecular photosensitizer that could assemble
into a larger aggregate, and take advantage (in principle) of the enhanced permeability and
retention effect. This was achieved using a water-soluble porphyrin cored hyperbranched
polymer. The polymer was synthesized in two steps and good yield, starting from tetra-
(para-hydroxyphenyl) porphyrin. The level of core/PS incorporation was estimated as 65%
by comparing the molecular weights determined by core analysis (1H NMR) and bulk
analysis (GPC). However, these methods have orthogonal levels of accuracy when
measuring the molecular weight of hyperbranched polymers, which result in an
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
overestimation using the bulk method and an underestimation using the core method. As
such, the actual level of core incorporation is much higher than the 65% estimated. When
added to water, the porphyrin cored hyperbranched polymer self-assembled into larger
spherical aggregates with diameters around 20-25 nm, as determined by TEM. Confocal
microscopy confirmed that the porphyrin cored hyperbranched polymers could be
internalized within EJ bladder carcinoma cells. Subsequent MTT analysis of the non-
incorporated porphyrin (4-hydroxyphenyl porphyrin THPP 1), showed a significant level of
dark toxicity with an LD50 of 4 M. However, when the MTT experiments were repeated
using the porphyrin cored hyperbranched polymer, PC-HBP 4, there was no detectable dark
toxicity (at concentrations up to 100 M). However, exposing the cells to light for 10
minutes at 450/630 nm (4.20/4.85 mW cm-2 respectively), in the presence of the polymer PC-
HBP 4, indicated M toxicity. Studying the activity over a range of concentrations indicated
an LD50 of 1.5 M for the porphyrin-cored polymer. Although an LD50 value could not be
ACS Paragon Plus Environment
21

Molecular Pharmaceutics
Page 22 of 30
1
2
3
4
5
6
7
8
9
determined for the polymer’s dark toxicity (toxicity only reached a maximum or 25% at 200
M), a photodynamic index of 800 was determined from the LD25 values. These results
demonstrate the ability of core functionalized hyperbranched polymers (and their
aggregates), to be applied as effective macromolecular photosensitizer for use in
photodynamic therapy. In addition, incorporation of the photosensitizer within the
polymeric structure eliminated the dark toxicity. As such, this methodology could provide a
useful strategy to overcome any dark toxicity problems associated with otherwise useful
photosensitizers. Work is continuing in our laboratories to develop similar systems with
more active cores, as well as cores that absorb light at a more clinically useful wavelength.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
CORRESPONDING AUTHOR
* Email: l.j.twyman@sheffield.ac.uk
FUNDING SOURCES
This work was supported by the University of Sheffield (AK), Yorkshire Cancer Research,
Cancer Research UK, BBSRC, EPSRC KTA and MRC (LKM and HEB). Microscopy was
performed on equipment purchased by Welcome Trust grant WT093134AIA and MRC
SHIMA award MR/K015753/1
ACS Paragon Plus Environment
22

Page 23 of 30
Molecular Pharmaceutics
1
2
3
4
REFERENCES
5
6
7
8
9
1. Mastera, A.; Livingstona, M.; Guptaab, A. S. Photodynamic Nanomedicine in the
Treatment of Solid tumors: Perspectives and Challenges. J. Controlled Release,
2013, 168(1), 88-102.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2. Klyashchitsky, B. A.; Nechaeva, I. S.; Ponomaryov. G. V. Approaches to Targeted
Photodynamic Tumor Therapy. J. Controlled Release, 1994, 29(1-2), 1-16.
3. Balchum, O. J.; Doiron, D. R.; Huth, G. C. Photoradiation Therapy of
Endobronchial Lung Cancers Employing the Photodynamic Action of
Hematoporphyrin Derivative. Lasers Surg. Med. 1984, 4, 13–30.
4. McCaughan, J. S.; Hicks, W.; Laufman, L.; May, E.; Roach, R. Palliation of
Esophageal Malignancy with Photoradiation Therapy. Cancer, 1984, 54, 2905–
2910.
5. Saini, R.; Lee, N. V.; Liu, K. Y. P; Poh, C. F. Prospects in the Application of
Photodynamic Therapy in Oral Cancer and Premalignant Lesions. Cancers. [Open
access]. DOI: 10.3390/cancers8090083. Published Online September 2, 2016.
6. De Rosa, F. S.; Marchetti, J. M.; Thomazini J. A.; Tedesco, A. C.; Lopes, M. V.;
Bentle, B. A. Vehicle for Photodynamic Therapy of Skin Cancer: Influence of
Dimethylsulphoxide on 5-Aminolevulinic Acid In Vitro Cutaneous Permeation
ACS Paragon Plus Environment
23

Molecular Pharmaceutics
Page 24 of 30
1
2
3
4
and In Vivo Pprotoporphyrin IX Accumulation Determined by Confocal
5
6
7
Microscopy. J. Controlled Release, 2000, 65(3), 359-366.
8
9
7. Jeffes, E. W.; McCullough, J. L.; Weinstein, G. D.; Kaplan, R.; Glazer, S. D.; Taylor,
J. R. Photodynamic Therapy of Actinic Keratoses with Topical Aminolevulinic
Acid Hydrochloride and Fluorescent Blue Light. Journal of the American
Academy of Dermatology, 2001,45(1), 96-104.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
8. Wong, T. W.; Sheu, H. M.; Lee, J. Y. Y.; Fletcher, R. J. Photodynamic Therapy for
Bowen's Disease (Squamous Cell Carcinoma In Situ) of the Digit. Dermatologic
surgery, 2001, 27(5), 452-456.
9. Bressler, N. M. Photodynamic Therapy of Subfoveal Choroidal Neovascularization
in Age-Related Macular Degeneration with Verteporfin: Two-Year Results of 2
Randomized Clinical Trials-Tap Report 2. Archives of ophthalmology,1960,
119(2), 198-207.
10. Overholt, B.F.; Panjehpour, M. Photodynamic Therapy in Barrett's Esophagus.
Journal of clinical laser medicine & surgery, 1996, 14(5), 245-249.
11. Tavares, A.; Carvalho, C.; Faustino, M. A.; Neves, M. G.; Tomé, J. P.; Tomé, A. C.;
Cavaleiro, J. A.; Cunha, Â.; Gomes, N.; Alves, E.; Almeida, A. Antimicrobial
Photodynamic Therapy: Study of Bacterial Recovery Viability and Potential
Development of Resistance After Treatment. Marine Drugs, 2010, 8(1), 91-105.
ACS Paragon Plus Environment
24

Page 25 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
12. Zhang, R,; Xing, R,; Jiao, T,; Ma, K,; Chen, C,; Ma, G,; Yan, X. Carrier-Free,
Chemophotodynamic Dual Nanodrugs via Self-Assembly for Synergistic
Antitumor Therapy. ACS Appl. Mater. Interfaces, 2016, 8 (21), 13262–13269.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
13. Matsumura, Y.; and Maeda, H. A New Concept for Macromolecular Therapeutics
in Cancer Chemotherapy: Mechanism of Tumoritropic Accumulation of Proteins
and the Antitumor Agent Smancs. Cancer Res.1986, 46, 6387-6392.
14. Maeda, H. SMANCS and Polymer-Conjugated Macromolecular Drugs: Advantages
in Cancer Chemotherapy. Adv. Drug Deliv. Rev. 2001, 46, 169-185.
15. Greish, K.; Sawa, T.; Fang, J.; Akaike, T.; Maeda, H. SMA-Doxorubicin, a new
polymeric micellar drug for effective targeting to solid tumors. J. Control Release,
2004, 97, 219–230.
16. Bovis, M. J.; Woodhams, J. H.; Loizidou, M.; Scheglmann, D.; Bown, S. G.;
MacRobert, A. J. Improved In Vivo Delivery of m-THPC via Pegylated Liposomes
for Use in Photodynamic Therapy. J. Controlled Release, 2012, 157, 196–205.
17. Tachikawa, S.; Sato, S.; Hazama, H.; Kaneda, Y.; Awazu, K.; Nakamura, H.
Localization-Dependent Cell-Killing Effects of Protoporphyrin (PPIX)-Lipid
Micelles and Liposomes in Photodynamic Therapy. Bioorg. Med. Chem., 2015, 23,
7578–7584.
ACS Paragon Plus Environment
25

Molecular Pharmaceutics
Page 26 of 30
1
2
3
4
5
6
7
8
9
18. Ogawara, K.; Shiraishi, T.; Araki, T.; Watanabe, T.; Ono, T.; Higaki, K. Efficient
Anti-Tumor Effect of Photodynamic Treatment with Polymeric Nanoparticles
Composed of Polyethylene Glycol and Polylactic Acid Block Copolymer
Encapsulating Hydrophobic Porphyrin Derivative. Eur. J. Pharm. Sci. 2016, 82,
154.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
19. Hocine, Q.; Gary-Bobo, M.; Brevet, D.; Maynadier, M.; Fontanel, S.; Raehm, L.;
Richeter, S.; Loock, B.; Couleaud, P.; Frochot, C.; Charnay, C.; Derrien, G.; Smaihi,
M.; Sahmoune, A.; Morere, A.; Maillard, P.; Garcia, M.; Durand, J. O. Silicalites
and Mesoporous Silica Nanoparticles for Photodynamic Therapy. Int. J. Pharm.
2010, 402, 221–230.
20. Xing, R.; Jiao, T.; Liu, Y.; Ma, K.; Zou, Q.; Ma, G; Yan, X. Co-Assembly of
Graphene Oxide and Albumin/Photosensitizer Nanohybrids towards Enhanced
Photodynamic Therapy. Polymers 2016, 8(5), 181
21. Li, P.; Zhou, G.; Zhu, X.; Li, G., Yan; P., Shen; L., Xu, Q.; Hamblin, M. R.
Photodynamic Therapy with Hyperbranched Poly(ether-ester) Chlorin(e6)
Nanoparticles on Human Tongue Carcinoma CAL-27 Cells. Photodiagnosis and
photodynamic therapy, 2012, 9(1), 76-82.
22. Zhang, G. D.; Harada, A.; Nishiyama, N.; Jiang, D. L.; Koyama, H.; Aida, T.;
Kataoka, K. Polyion Complex Micelles Entrapping Cationic Dendrimer Porphyrin:
ACS Paragon Plus Environment
26

Page 27 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
Effective Photosensitizer for Photodynamic Therapy of Cancer. Journal of
controlled release, 2003, 93(2), 141-150.
7
8
9
23. Hendrik R.; Nishiyama, N.; Jiang, D. L.; Aida, T.; Kataoka, K. Complex Micelles
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Encapsulating
Light-Harvesting
Ionic
Dendrimer
Zinc
Porphyrins,
Langmuir, 2000, 16(21), 8182-8188.
24. Yan D.; Gao C.; Frey H.; Hyperbranched Polymers: Synthesis, Properties, and
Applications. Wiley. New York and London. 1986.
25. Luo L.; Shamsudin S.; Twyman L. J.; Cecchin D.; Battaglia G.; Hua, P.; Roeh,l H.;
Chen, B. Delivery Systems for Small molecule Antiprion Drug Candidates. Prion,
2012, 6, 99-100.
26. Kainthan, R. K.; Janzen, J.; Levin, E.; Devine, D. V.; Brooks, D.E. Biocompatibility
Testing of Branched and Linear Polyglycidol. Biomacromolecules, 2006, 7(3), 703-
709.
27. Aboshnaf. F. O. PhD Thesis, University of Sheffield: 2018.
28. Lindsey, J. S.; Schreiman, I. C.; Hsu, H. C.; Kearney, P. C.; Marguerettaz, A. M.
Rothemund
and
Adler-Longo
Reactions
Revisited:
Synthesis
of
Tetraphenylporphyrins Under Equilibrium Conditions. The Journal of Organic
Chemistry, 1987, 52(5), 827-836.
ACS Paragon Plus Environment
27

Molecular Pharmaceutics
Page 28 of 30
1
2
3
4
5
6
7
8
9
29. Mann G.; Ellis. A.; Twyman L. J. Modifying the Product Distribution of a Reaction
within the Controlled Microenvironment of a Colloidosome. Macromolecules,
2016, 49(11), 4031-4037.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
30. Gittins P. J.; Alston, J.; Ge, Y.; Twyman L. J. Total Core Functionalization of a
Hyperbranched Polymer. Macromolecules, 2004, 37(20), 7428-7431.
31. Gittins P. J.; Twyman, L. J. Post Synthetic Modification at the Focal Point of a
Hyperbranched Polymer. J. Am. Chem. Soc., 2005, 127(6), 1646-1647.
32. Sunder, A.; Hanselmann, R.; Frey, H.; Mülhaupt, R. Controlled Synthesis of
Hyperbranched
Polyglycerols
by
Ring-Opening
Multibranching
Polymerization. Macromolecules, 1999, 32(13), 4240-4246.
33. Twyman L. J.; Beezer A. E.; Mitchell J. C. An Approach for the Rapid Synthesis of
Moderately Sized Dendritic Macromolecules. J. Chem. Soc. Perk (I), 1994, (4),
407-411.
34. Hawker, C.J.; Lee, R.; Fréchet, J. M. J. One-Step Synthesis of Hyperbranched
Dendritic Polyesters. Journal of the American Chemical Society, 1991, 113(12),
4583-4588.
ACS Paragon Plus Environment
28

Page 29 of 30
Molecular Pharmaceutics
1
2
3
4
5
6
7
8
9
35. Aguiar, J.; Carpena, P.; Molina-Bolıvar, J.; Ruiz, C. C. On the Determination of the
Critical Micelle Concentration by the Pyrene 1: 3 Ratio Method. J. Colloid. Interf.
Sci. 2003, 258, 116-122.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
36. Oikawa, Y.; Lee, S.; Kim, D. H.; Kang, D. H.; Kim, B. S.; Saito, K.; Sasaki, S.; Oishi,
Y.; Shibasaki, Y. One-Pot Synthesis of Linear-Hyperbranched Amphiphilic Block
Copolymers
Based
on
Polyglycerol
Derivatives
and
Their
Micelles. Biomacromolecules, 2013, 14(7), 2171-2178.
37. Nishiyama, N.; Stapert, H. R.; Zhang, G. D.; Takasu, D.; Jiang, D. L.; Nagano, T.;
Aida, T.; Kataoka, K. Light-Harvesting Ionic Dendrimer Porphyrins as New
Photosensitizers for Photodynamic Therapy. Bioconjugate Chemistry, 2003, 14(1),
58-66.
38. Due to polydispersity, molar concentration of polymer could not be calculated.
However, calculation of molar concentrations using porphyrin concentration of
(PC-HBP 4 and THPP 1) were possible via Beer–Lambert analysis using THPP 1 as
a reference in water. This ensured that all experiments were carried out at the
same porphyrin concentration.
39. James, D. A.; Arnold, D. P.; Parsons, P. G. Potency and Selective Toxicity of Tetra-
(Hydroxyphenyl) and Tetrakis(dihydroxyphenyl) Porphyrins in Human
ACS Paragon Plus Environment
29
