The influences of different substituents on spectral properties of
Rhodamine B based chemosensors for mercury ion and application in
EC109 cells
4
5
Wenqi Du[a], Yu Cheng[a],Weixin Shu[a], Baoying Wu[a], Zhineng Kong[a], Zhengjian
Qi*[a]
6
7
8
[a]College of Chemistry and Chemical Engineering,Southeast University Road 2,
Jiangning District 211189, Nanjing, Jiangsu Province, P.R. China
9
10
11
Email:qizhengjian506@163.com
*For correspondence
12
13

Page 2 of 27
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Abstract: Six rhodamine-based “Turn-on” fluorescence chemosenors(L1~6) with
different substituents for Hg2+ were readily synthesized and investigated, which
displayed high selectivity and chelation enhanced ratiometric fluorescence change and
colorimetric change with Hg2+ among the metal ions examined. Based on UV spectral
data and fluorescence spectral data, the effect of different substituents on spectral
properties of the probes were presented and discussed. The detection limit of Hg2+ to
probe L1 was as low as 50 nM, which attribute to its electron donating group.
Theoretical calculation also support the process of reaction. Confocal laser scanning
microscopy experiments showed that probe could be usedto detect Hg2+ in living
cells.
Keywords: Rhodamine B; Fluorescent chemosesor ; Sensing mercury ion; Living
cells.
1.Introduction
Various transition-metal ions are essential to the life of creatures. Mercury is a
dangerous and hazardous toxic which has posed a great threat to our environment1-4.
Mercury is heavy metal, which can be dispersed in the atmosphere, the ocean, and
the soil. Different speciation mercury can penetrate our environment by various ways,
such as methyl mercury produced by aquatic microbes which bioaccumulates
through the food chain and oxidation of mercury vapor in atmosphere to
water-soluble Hg2+ ions5-7. After long-term exposure in the environment, mercury ion
accumulate in organisms which can cause nausea, vomiting, abdominal pain, renal
dysfunction and other diseases.
At present, UV spectrophotometry, electrochemical methods, ionization coupled
plasma mass spectrometry, ionization coupled plasma atomic emission spectrometry,
atomic absorption spectroscopy and other analytical methods can be used to identify
and detect metal ions8-12. However, these methods have some disadvantages in the
application, such as high detection costs, narrow range of applications, and can’t
achieve real-time detection. In contrast, the fluorescent molecular probe has no

Page 3 of 27
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
damage to the sample, and gives its priority to easy operability and high sensitivity,
so fluorescence analytical methods are effective and efficient ways to detect ions13-15
.
Compared with other fluorescent dyes, rhodamine dyes have some excellent
photophysical properties, such as high fluorescence quantum yield, pH insensitive,
high molar absorptivity and high extinction coefficient, particularly in its nucleotide
and nucleic acid conjugates16. Some rhodamine-based chemosensors for Hg2+ ions
have been reported17-22, but dual colorimetric and fluorescent chemosensors for
mercury ion were still rare23 and some of them were not efficient enough to be
selective toward mercury ion.
Here, we report six rhodamine-based caprolactam derivatives as a sensor for
Hg2+, when binding phenomena could be probed through binding-induced changes in
an electronic spectral pattern. The difference between these probes are that we
selected different substitutional group such as methyl group, nitro group, aldehyde
group, halogen group, phenyl group. These rhodamine-based derivatives that
behaves as a fluorescent Hg2+ sensor with high emission sensitivity and selectivity,
which exhibited sensitive detection toward Hg2+ via significant fluorescence
enhancement in solution, and in the meantime they showed a significant color
change from colorless to rose red. We have designed some similar structures to
compounds L1~6 and conduct a series of experiments to explore their properties
which have the correlations of nature of substituent group. After comparison of
optical properties,probe L1 showed a good performance in the recognition toward
Hg2+,which indicated that the different electronic distribution among the senors’
structures make an influence on their properties. For this reason, we selected L1 as a
typical example to expound in the following discussion.
2. Experimental
2.1 Apparatus and Materials
Fluorescence spectra measurement were performed on Horiba Jobin Yvon Inc.
1
Fluorolog 3-TSCPC. H NMR spectrum was run on a Bruker 300 MHz spectrometer
using TMS as the internal standard. Mass spectrum was recorded with a VG ZAB-HS
double focusing mass spectrometer. Absorption spectra were measured on a UV-2201

Page 4 of 27
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
double-beam UV/VIS spectrometer. Melting point was determined using an SGW X-4
digital melting point apparatus.
All the materials for synthesis were purchased from Sinopharm Chemical Reagent
Co.,Ltd (Shanghai, China) and used without further purification. Metal solutions
were prepared from their analytical grade nitrate salts. The metal ions were prepared
as 0.2 mM in water solution.
2.2 Syntheses
As shown in Scheme 1, the compounds L1~L6 were prepared by reacting RBH with
aromatic aldehyde. RBH was synthesized according to literature.
2.2.1 Synthesis of RBH
As for the synthesis of RBH, sereval different procedures have been reported24-26
In this work, RBH was synthesized by a modified method according to Xiang27. m/z:
.
－
1
457.2265 ([M+H]+); M+ calculated 456.2265. IR(KBr,cm ):ν= 3428, 2987，2926,
1689, 1614, 1514, 1380, 1218, 1117, 818, 767. 1H NMR (300 MHz, CDCl3, δ ppm), δ
(ppm):1.17 (t, 12H), 3.34 (q, 8H), 3.62 (bs, 2H), 6.29 (dd, 2H), 6.43(d, 2H),6.45 (d,
2H), 7.11 (dd, 1H), 7.42 (d, 1H), 7.44(d, 1H), 7.93 (dd, 1H). (Fig.S1~S3)
2.2.2 Synthesis of L1
RBH ( 0.5 mmoL, 0.24 g) was dissolved in 30 mL ethanol, and then p-tolualdehyde
(0.5 mmoL, 0.12 g) was slowly added. The mixture was stirred and refluxed for 12 h
at 80 ℃. After distillation in vacuum, the residue was recrystallized with methanol
and water to give the final product L1 in yield of 79.8%. m/z: 559.3020([M+H]+);
1
M+calculated 558.3020. H NMR (300 MHz, CDCl3, δ ppm): 8.64 (s, 1H),7.97 (m,
1H), 7.49 (d, 2H), 7.45 (m, 2H),7.26 (d, 1H), 7.09 (m, 2H), 6.54 (d, 2H), 6.43 (s, 2H),
6.26 (d, 2H), 3.33 (q, 8H), 2.29 (s, 3H), 1.15(t, 12H). (Fig.S4~S6)
2.2.3 Synthesis of L2~6
Compound L2~6 was prepared using a general procedure which is essentially similar
to that used for L1. (Fig.S7~S21)
3. Results and Discussion
1
The structure of compounds L1~6 were characterized by H NMR, HR-MS. The
results were in good agreement with the structure showed in Scheme 1. Fluorescence

Page 5 of 27
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
and UV–vis studies were performed using a 20 µM solution of L1~6 in a CH3CN/H2O
(1:1, v/v) solution with appropriate amounts of metal ions.
3.1 Comparison of six rhodamine B based senors
Under the same conditions,we explore the sensitivity measurement of ion probes.
As shown in Fig.1, rhodamine B derivatives with methyl exhibits excellent sensitivity
towards mercury ion. Derivatives with halogen group also show good sensitivity
owing to its electron donating groups. Based on these phenomena, it suggested that
chelation-enhanced fluorescence appears when compounds with electron donating
groups are complexed with Hg2+. In order to further explore the affinity capacity
between probes and metal ions, association constants were calculated to verify the
experiment we have conducted. It is indicated in the Scheme 2, the numerical size of
association constants minished in order, which in accordance with the results of
fluorescence intensity when different substituents with rhodamine B binds to mercury.
After comparison between these probes, we can come to conclude that methyl
group, halogen group and phenyl group belong to electron donating group while nitro
group, aldehyde group belong to electron-attracting group. When interacting with
mercury icon, electron donating group provide electron to coordination site which
make it easier to combine. On the contrary, electron-attracting group make it more
difficult for probe to interact with mercury icon. So, we prefer to select electron
withdrawing substituents to detect metal ions which reveals high sensitivity. To
investigate photoelectric properties of these probes further,we selected L1 as an
typical example to expound in the discussion.
3.2 Metal ion selectivity and competition experiments
As shown in Fig.2, UV–vis spectrum of compound L1 (20µM) exhibited only very
weak bands over 450 nm, which could be attributed to the presence of a trace amount
of the ring-opened form of compounds. On addition of 10 equiv. Hg2+ into solution,
L1 immediately resulted in a significant enhancement of absorbance at about 556 nm
simultaneously the color changed into rose red. Other metal ions such as Zn2+, Mg2+,
Ca2+, Cd2+, Cu2+, Pb2+, Ba2+, Ni2+, Mn2+, K+, Li+, Ag+, Co2+, except for Fe3+, did not
show any significant color and spectral change under any significant color and

Page 6 of 27
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
spectral change under identical conditions. These phenomena suggest that these
compounds can serve as a “naked-eye” chemosensor for Hg2+. To further investigate
the interaction of Hg2+ and the probe, the Hg2+ binding stoichiometry of the probe can
be determined from titration and the Job plot28, 29. As shown in Fig.3, it is obvious that
the fluorescence intensity reached a maximum when the ratio was 0.5, which
suggesting that a 1:1 stoichiometry of the Hg2+ to the probes respectively in the
complex. Furthermore, we also conducted the competitive experiments which
indicates the background metal ions showed very low interference with the detection
of Hg2+ in the water solutions (Fig.4.).
3.3 Emission spectra and detection limit of sensor
A fluorescence titration experiment was carried out in order to further explore the
interaction of probes and Hg2+. On addition and gradual increase concentration of
mercury ions to the L1 in CH3CN/H2O(V:V=1：1), the fluorescence intensity gradually
increased and the solutions turned colorless to rose red. Limit detection of metal ions
plays an important role in evaluating fluorescence chemosensor. As for probe L1, the
linear response for the fluorescence intensity response of compound L1 was between 0
and 140 µM (Fig. 5), and the detection limit of Hg2+ was measured to be 0.05 µM.
The association constant K of the complex L1–Hg2+ was then calculated to be
3.24×103 M−1 with a linear relationship (Fig. 6) by Benesi–Hildebrand method, Eq.
(1)30, 31
1
1
1
154
=
+
F
F − F0 K(F − F )[Hg2+ ]
− F
Max
Min
Max
Min
(1)
155
156
157
158
159
160
161
162
As shown in the Fig.7, probe L1 show a weak fluorescence in the absence of metal
ions. On the addition of 10 eqiv. metal ions, the fluorescence intensity has changed. It
is obvious that when 10 eqiv. Hg2+ was introduced into a solution of L1 in
CH3CN/H2O (1:1, v/v), the fluorescence intensity increased sharply. Under this
conditions, Fe3+ induce a mild fluorescence enhancement while Zn2+, Mg2+, Ca2+,
Cd2+, Cu2+, Pb2+, Ba2+, Ni2+, Mn2+, K+, Li+, Ag+, Al3+, Co2+ and Na+ did not show
remarkable changes in fluorescence intensity and the color.
3.4 Time-dependence and Fluorescent lifetime

Page 7 of 27
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
Time-dependence for binding of the probe L1 with Hg2+ is given in Fig.8.
Following the addition of 10 equiv. Hg2+ ion to 20.0 µM probe L1, the fuorescence
intensity of probe L1 was turn on rapidlly and reached a stable value within 2 min.
The fluorescence lifetime was measured at an excitation 460 nm of the NanoLED
source. The decays of probes were found to be monoexponential. The lifetime decays
in the absence of Hg2+ and in the presence of Hg2+ are shown in Fig.9. The average
lifetime of L1 was 1.87 ns and 5.00 ns (XSQ = 1.06) while the lifetime of L1 + Hg2+
was 1.91 ns (XSQ = 1.14). Double exponential fitting equation was used to describe
the fluorescence lifetime of probe itself , because xanthene was a chromophore which
formed a conjugated system. The upper part of structure formed a plane and
orthogonalized with the ring of xanthene which also can be seen as a chromophore.
After adding metal ions，the upper part including carbanyl group and phenyl group do
not conjugate with xanthene,and the stereo-hindrance effect of carbanyl group limits
the rotation of the benzene ring. So the major chromophore is still xanthene which
used single exponential fitting equation.
3.5 Application
3.5.1 Test papers
To demonstrate the practical application of our sensor, we prepared the test papers
of sensor L1. As depicted in Fig.10, the color of the test paper changed from colorless
to purple and deepened gradually with the increasing of Hg2+ concentration. These
paper-made test kits may be used as a simple tool for detecting Hg2+ in environmental
184
185
186
samples.
3.5.2 Fluorescence imaging for EC109 cells
Owing to its favourable spectroscopic properties of the response to Hg2+, L1 should
187
188
189
190
191
192
be suited for fluorescence imaging in living cells. Laser scanning confocal
microscopy was used to investigate this proposition. As determined by laser
scanningconfocal microscope, EC109 cells with a 10ꢀM solution of probe L1 in
CH3CN–H2O (1:1, v/v) 30 min at 25 ◦C led to no intracellular fluorescence(Fig.11b.).
After washed with PBS three times, the staining cells were then supplemented with 10
ꢀM of Hg2+ under the same condition for 30 min, a significant increase of

Page 8 of 27
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
fluorescence from the intracellular area was observed ( Fig.11c).
3.6 Mechanism
To investigate the interaction of probes and metal ions, probe L1 was selected as an
example to explain mechanism. IR spectra of L1 and L1+Hg2+ were taken in KBr disks
(Fig.S22). It can be seen that the peak at 1698 cm-1 which relates to the amide
carbonyl absorption disappeared upon with the addition of Hg2+. To further
investigate the mechanism of the reaction,we selected L1 as an typical example to
explain the phenomena. In addition，EDTA-adding experiment has been conducted to
confirm the reversibility of reaction and the result was shown in the Fig.12,when the
30 eqiv. EDTA was added into L1+ Hg2+ in CH3CN/H2O solution, the fluorescence
intensity was decreased rapidly(green line).Then after adding the 30 eqiv. Hg2+, the
fluorescence intensity was recovered（red line）. This phenomenon indicates that the
reaction between the compound and the metal ion are reversible.
As shown in the Fig.13, it indicates that these sereval chemosenors exhibit
reversible and sensitive detection to Hg2+. While hydrolytic action of compounds
might be happen after a long-term interaction with metal ions. Theoretical calculation
has been conducted to verify the stability of compound L7, we assume the structure L7
was existed after interacting with Hg2+. Frequency calculation successfully provide
the evidence for the existence of the stable structure. To investigate the possible
mechanism of the absorption and fluorescent emission of L1, theoretical calculation of
L1 which based on the optimized structures of the ground S0 state and the first
excited S1 state were performed in Fig.14. After adding Hg2+, the energy gap between
the HOMO and LUMO is greatly decreased32.
4. Conclusions
In summary, we reported the design and synthesis of six new rhodamine-based
derivatives L1~6 used as sensitive and selective chemosenor, which could specifically
recognize Hg2+ ion in solutions by naked eyes. These six probe display 1:1 complex
formation with Hg2+ which could be monitored by the spectral changes as well as
color changes. Based on the experiment above, after a series comparison of these
probes with different substituent group, L1 shows better optical properties than others

Page 9 of 27
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
owing to its electron donating group and excellent properties. Confocal laser scanning
microscopy experiments showed that L1 could beused to detect Hg2+ in living cells.
Futhermore, these six new probes show a great potential for biotic environmental
detection.
Supplementary Information (SI)
The structure of compounds RBH, L1~6 were characterized by 1H NMR, HR-MS,IR in
Supplementary Information. Supplementary Information is available at
www.ias.ac.in/chemsci.
Acknowledgements
This work was supported by the Fundamental Research Funds for the Central
Universities (KYLX15_0125) and National Major Scientific Instruments and
Equipment Development Projects (2014YQ060773) and A Project Funded by the
Priority Academic Program Development of Jiangsu Higher Education Institutions
(1107047002) and Policy Guidance Program (Research Cooperation)--Prospective
Joint Research Project (BY2016076-02).
References
1.
Boening, D. W. Chemosphere 2000, 40, 1335
Nolan, E. M.; Lippard, S. J.Chem. Rev. 2008,108, 3443
Nolan, E. M.; Lippard, S. J. J.Am.Soc. 2003, 125, 14270
Wang, C. Inorg.Chem. 2013, 52, 13432
2.
3.
4.
5.
Clarkson, T. W.; Magos, L.; Myers, G. J. New. Engl. J. Med. 2003, 349, 1731
Llobet, J.J.Agr. Food. Chem. 2003 51 838
6.
7.
Suresh, M. Org. Lett. 2008, 10, 3013
8.
Chen, Y.; Han, K. Y.; Liu, Y. Bioorgan.Med.Chem.2007, 15, 4537
Roy, P. Inorg.Chem. 2007, 46, 6405
9.
10.
11.
12.
Royzen, M. J. Am. Soc .2006, 128, 3854
Banerjee, A. Analyst 2012,137, 2166
Ding, P. New. J. Chem.2015, 39, 342

Page 10 of 27
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
13.
14.
15.
16.
Lee, H. Y. Sensor. Actuat. B-Che.2013, 182, 530
Sen, S. Analyst. 2012, 137, 3975
Patil, R. Dal.Trans. 2014, 43, 2895
Haugland, R. P The handbook: a guide to fluorescent probes and labeling
technologies 2005,p.52
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
Huang, J.; Xu, Y . J. Org.Chem. 2009, 74, 2167
Suresh, M. Org. Lett. 2009, 11, 2740
Zhou, Y. Org. Lett. 2009,11,4442
Du, J. Org. Lett. 2010, 12 476
McClure, D. S. J. Chem. Phys. 1952, 20, 682
Suresh, M.; Ghosh, A. Chem. Commun. 2008, 33, 3906
Renzoni, A.; Zino, F.; Franchi,E. Environ. Res. 1998, 77, 68
Dujols, V. F.; Ford, A. W.; J. Am. Soc. 1997,119, 7386
Yang, X.; Guo,R.; Zhao, Y, B.; Talanta. 2002,57, 883
Geng,T.; R, Huang.; Wu D. RSC Adv. 2014, 4, 46332
Xiang, Y. Anal. Chim. Acta. 2007, 581, 132
Huang, C. Y. Method. Enzymol. 1981, 87, 509
Renny, J. S. Angew. Chem. Int. Edit. 2013, 52, 11998
Liu, Y, J. Helv. Chim. Acta. 2004, 87, 3119
Yan, L. Spectrochim. Acta. A. 2016, 155, 116
Liu, X. J. Tetrahedro. 2015, 71, 8194
274
275

Page 11 of 27
276
277
278
Scheme 1. Synthetic route of target compounds.

Page 12 of 27
279
280
Fig.1. Fluorescence intensity (at 580 nm) of L1~6 (20µM) in CH3CN/H2O (1:1, v/v) with the
281
282
presence of Hg2+ (100 µM) (λex = 500 nm)

Page 13 of 27
283
Coordination constant
Br C6H6
-R
CH3
F
NO2
CHO
Coordination
3.24E3
2.67E3 2.38E3 2.27E3 3.70E2 2.56E2
constant/M−1
284
285
Scheme 2.The coordination constant of six probes

Page 14 of 27
286
287
Fig. 2. Absorbance spectra of L1(20 µM) in CH3CN/H2O (1:1,v/v) solutions with the presence of
10 equiv. of various species.
288
289

Page 15 of 27
290
291
Fig.3. Job's plot of the complexation between L1 and Hg2+, the total concentration of L1 and Hg2+
292
293
is 20.0 ꢀM .

Page 16 of 27
294
295
Fig.4. Fluorescence intensity (at 580 nm) of L1 upon the addition of 20 µM Hg2+ in the presence
296
297
of 20µM background metal ions in CH3CN/H2O (1/1, v/v) (λex = 500 nm).

Page 17 of 27
298
299
Fig.5(a). The fluorescence intensity (at 580 nm) of compound L1 (20 µM) as a function of the
300
301
Hg2+ concentration in CH3CN/H2O(1:1, v/v) solution (λex = 500 nm, slit = 3 nm)

Page 18 of 27
302
303
Fig.5(b). Linear relationship of L1 (20 µM) in CH3CN/H2O (1:1,v/v) upon addition of different
amounts of Hg2+ ions.
304
305

Page 19 of 27
306
307
Fig.6. Benesi–Hildebrand plot (λex = 500 nm) of L1, assuming 1:1 stoichiometry for association
308
309
between L1 and Hg2+ in the solutions.

Page 20 of 27
310
311
Fig.7. Fluorescence spectra of L1 (20 µM) in CH3CN/H2O (1:1,v/v) with the presence of 10 equiv.
312
313
of various metal ions (λex =500 nm).

Page 21 of 27
314
315
Fig. 8. Effects of time on the reaction of Hg2+ with L1
316

Page 22 of 27
317
318
Fig.9. Fluorescence decay curves of L1 and L1 + Hg2+ in solutions obtained at λex =500 nm.
319

Page 23 of 27
320
321
Fig. 10. Photographs of the test kits with L1 for detecting Hg2+ in(CH3CN/H2O = 1:1, v/v) solution
with different concentrations:(1) 0; (2) 1.0 × 10-5M; (3) 1.0 × 10-4M; (4) 1.0 × 10-3M;(5)1.0 ×
10-2M;(6)1.0 × 10-1M.
322
323
324

Page 24 of 27
325
326
Fig.11. Laser confocal scanning microscopy experiments of EC109 cells:（a）Bright-field
transmission image.（b）Cells with 10ꢀM solution of L1 in CH3CN–H2O (1:1, v/v) for 30 min at
25 ◦C.(c)The staining EC109 cells exposed to L1 (10ꢀM) for 30 min and then to a CH3CN–H2O
(1:1, v/v) solution of Hg2+ (10ꢀM) for 30 min.
327
328
329
330

Page 25 of 27
331
332
Fig.12. Fluorescence intensity (at 580 nm) of L1 (20 µM) to Hg2+ in CH3CN/H2O (1:1,v/v)
solutions (1) blue line: 10 µM L1 only; (2) red line: 20 µM L2 with 10 equiv. Hg2+; (3) green line:
20 µM L1 with 10 equiv. Hg2+ and then addition of 30 equiv. EDTA; (4) black line: 10 µM L1with
10 equiv. Hg2+ and 30 equiv. EDTA then addition of 10 equiv. Hg2+ (λex = 500 nm).
333
334
335
336

Page 26 of 27
O
O
R
N
Hg2+
N
N
N
R
N
O
N
N
O
N
L7
−Η2Ο
COOH
N
O
N
337
338
339
Fig.13. Possible sensing mechanism of L1~6 with Hg2+

Page 27 of 27
340
341
Fig.14. Theoretical molding of the absorption of L1 without and with Hg2+ at the TDDFT level.
