5-[(4-Chlorophenyl)hydrazinylidene]-1,3-dimethyl-1,3-diazinane-2,4,6-trione

Base Information

• Chemical Name: 5-[(4-Chlorophenyl)hydrazinylidene]-1,3-dimethyl-1,3-diazinane-2,4,6-trione
• CAS No.: 30201-40-2
• Molecular Formula: C₁₂H₁₁ClN₄O₃
• Molecular Weight: 294.697
• NSC Number: 134365
• DSSTox Substance ID: DTXSID60419194
• Mol file: 30201-40-2.mol

Synonyms:30201-40-2;5-[(4-chlorophenyl)hydrazinylidene]-1,3-dimethyl-1,3-diazinane-2,4,6-trione;NSC134365;DTXSID60419194;AKOS003613023;NSC-134365;5-(2-(4-chlorophenyl)hydrazono)-1,3-dimethylpyrimidine-2,4,6(1h,3h,5h)-trione

Chemical Property of 5-[(4-Chlorophenyl)hydrazinylidene]-1,3-dimethyl-1,3-diazinane-2,4,6-trione

Chemical Property:

• Vapor Pressure: 1.29E-06mmHg at 25°C
• Boiling Point: 400.2°Cat760mmHg
• Flash Point: 195.8°C
• Density: 1.47g/cm³
• XLogP3: 1.9
• Hydrogen Bond Donor Count: 1
• Hydrogen Bond Acceptor Count: 5
• Rotatable Bond Count: 2
• Exact Mass: 294.0519679
• Heavy Atom Count: 20
• Complexity: 483

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

SDS file from LookChem

Useful:

• Canonical SMILES: CN1C(=C(C(=O)N(C1=O)C)N=NC2=CC=C(C=C2)Cl)O

Technology Process of 5-[(4-Chlorophenyl)hydrazinylidene]-1,3-dimethyl-1,3-diazinane-2,4,6-trione

There total 2 articles about 5-[(4-Chlorophenyl)hydrazinylidene]-1,3-dimethyl-1,3-diazinane-2,4,6-trione which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 65.0%

6-amino-1,3-dimethyl-5-[(4-chlorophenyl)diazenyl]uracil (63351-22-4) → 1,3-dimethyl-5-(p-chlorophenylazo)barbituric acid (30201-40-2)

Guidance literature:

With hydrogenchloride; water; for 4h; Reflux;

DOI:10.1002/jccs.201600007

Reference yield:

→ 1,3-dimethyl-5-(p-chlorophenylazo)barbituric acid (30201-40-2)

Guidance literature:

1,3-Dimethylbarbitursaeure, 4-Chlorbenzoldiazoniumchlorid;

DOI:10.1002/jps.2600591139

upstream raw materials:

6-amino-1,3-dimethyl-5-[(4-chlorophenyl)diazenyl]uracil
