4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester

Base Information

• Chemical Name: 4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester
• CAS No.: 1027598-25-9
• Molecular Formula: C₃₄H₄₃Cl₂N₅O₆S
• Molecular Weight: 720.717
• Mol file: 1027598-25-9.mol

Synonyms:4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester

Chemical Property of 4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of 4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester

There total 6 articles about 4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield:

4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carboxylic acid (928851-49-4) + 1-t-Butoxycarbonylpiperazine (57260-71-6) → 4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester (1027598-25-9)

Guidance literature:

With benzotriazol-1-ol; dicyclohexyl-carbodiimide; In N,N-dimethyl-formamide; at 20 ℃;

DOI:10.1021/jm061143k

Reference yield:

3-bromomethyl-2,4-dichlorobenzenesulphonyl chloride (188440-21-3) → 4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester (1027598-25-9)

Guidance literature:

Multi-step reaction with 5 steps

1.1: trimethylsilyl chloride; N,O-bis-trimethylsilylacetamide / tetrahydrofuran / 2 h / Heating

1.2: tetrahydrofuran

1.3: NaBr / acetone; dimethylformamide / 20 °C

2.1: LiOH / acetonitrile / 1.5 h / 20 °C

2.2: acetonitrile; dimethylformamide / 20 °C

3.1: HCl / dioxane / 2 h / 20 °C

4.1: NaCNBH₃ polystyrene resin / methanol; H₂O / 20 °C

5.1: 1-hydroxybenzotriazole; DCC / dimethylformamide / 20 °C

With hydrogenchloride; lithium hydroxide; chloro-trimethyl-silane; N,O-bis-(trimethylsilyl)-acetamide; NaCNBH₃ polystyrene resin; benzotriazol-1-ol; dicyclohexyl-carbodiimide; In tetrahydrofuran; 1,4-dioxane; methanol; water; N,N-dimethyl-formamide; acetonitrile;

DOI:10.1021/jm061143k

Reference yield:

4-(3-bromomethyl)-2,4-dichloro-phenylsulfonamido-1-(tert-butoxycarbonyl)piperidine-4-carboxylic acid (1026484-91-2) → 4-{4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carbonyl}-piperazine-1-carboxylic acid tert-butyl ester (1027598-25-9)

Guidance literature:

Multi-step reaction with 4 steps

1.1: LiOH / acetonitrile / 1.5 h / 20 °C

1.2: acetonitrile; dimethylformamide / 20 °C

2.1: HCl / dioxane / 2 h / 20 °C

3.1: NaCNBH₃ polystyrene resin / methanol; H₂O / 20 °C

4.1: 1-hydroxybenzotriazole; DCC / dimethylformamide / 20 °C

With hydrogenchloride; lithium hydroxide; NaCNBH₃ polystyrene resin; benzotriazol-1-ol; dicyclohexyl-carbodiimide; In 1,4-dioxane; methanol; water; N,N-dimethyl-formamide; acetonitrile;

DOI:10.1021/jm061143k

upstream raw materials:

4-[2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-benzenesulfonylamino]-1-methyl-piperidine-4-carboxylic acid

1-t-Butoxycarbonylpiperazine

3-bromomethyl-2,4-dichlorobenzenesulphonyl chloride

4-(3-bromomethyl)-2,4-dichloro-phenylsulfonamido-1-(tert-butoxycarbonyl)piperidine-4-carboxylic acid

Downstream raw materials:

2,4-dichloro-3-(2,4-dimethyl-quinolin-8-yloxymethyl)-N-[1-methyl-4-(piperazine-1-carbonyl)-piperidin-4-yl]-benzenesufonamide
