(10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester

Base Information

• Chemical Name: (10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester
• CAS No.: 487005-46-9
• Molecular Formula: C₂₂H₁₈N₄O₂S₂
• Molecular Weight: 434.543
• Mol file: 487005-46-9.mol

Synonyms:(10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester

Chemical Property of (10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of (10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester

There total 2 articles about (10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 74.0%

chloroacetic acid ethyl ester (105-39-5) + 4-methyl-2-phenylpyrrolo[1'',2'':1',6']pyrazino[2',3':4,5]thieno[2,3-d]pyrimidine-9(10H)-thione (487005-44-7) → (10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester (487005-46-9)

Guidance literature:

With sodium acetate; In ethanol; for 2h; Heating;

DOI:10.1080/10426500210243

Reference yield:

4-methyl-2-phenylpyrrolo[1'',2'':1',6']pyrazino[2',3':4,5]thieno[2,3-d]pyrimidine-9(10H)-one (487005-43-6) → (10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester (487005-46-9)

Guidance literature:

Multi-step reaction with 2 steps

1: 66 percent / P₂S₅; pyridine / 5 h / Heating

2: 74 percent / NaOAc*3H₂O / ethanol / 2 h / Heating

With pyridine; tetraphosphorus decasulfide; sodium acetate; In ethanol;

DOI:10.1080/10426500210243

Reference yield: 71.0%

(10-methyl-8-phenyl-6-thia-5,7,9,10c-tetraaza-cyclopenta[c]fluoren-4-ylsulfanyl)-acetic acid ethyl ester (487005-46-9) → 9-hydrazino-4-methyl-2-phenylpyrrolo[1'',2'':1',6']pyrazino[2',3':4,5]thieno[2,3-d]pyrimidine (487005-49-2)

Guidance literature:

With hydrazine hydrate; for 3h; Heating;

DOI:10.1080/10426500210243

upstream raw materials:

chloroacetic acid ethyl ester

4-methyl-2-phenylpyrrolo[1'',2'':1',6']pyrazino[2',3':4,5]thieno[2,3-d]pyrimidine-9(10H)-thione

4-methyl-2-phenylpyrrolo[1'',2'':1',6']pyrazino[2',3':4,5]thieno[2,3-d]pyrimidine-9(10H)-one

Downstream raw materials:

9-hydrazino-4-methyl-2-phenylpyrrolo[1'',2'':1',6']pyrazino[2',3':4,5]thieno[2,3-d]pyrimidine
