tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate

Base Information

• Chemical Name: tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate
• CAS No.: 1201673-40-6
• Molecular Formula: C₂₆H₃₅F₂N₅O₂
• Molecular Weight: 487.593
• Mol file: 1201673-40-6.mol

Synonyms:tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate

Chemical Property of tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate

There total 7 articles about tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield:

cyclohexyl-(4-trimethylstannanylpyridin-2-yl)amine (1201674-98-7) + 4-(6-chloro-4-difluoromethylpyridin-2-yl)piperazine-1-carboxylic acid tert-butyl ester (1201675-02-6) → tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate (1201673-40-6)

Guidance literature:

With cesium fluoride; bis(tri-t-butylphosphine)palladium⁽⁰⁾; In 1,4-dioxane; at 100 ℃; for 5h; Inert atmosphere;

Reference yield:

2,6-dichloropyridine-4-carbaldehyde (113293-70-2) → tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate (1201673-40-6)

Guidance literature:

Multi-step reaction with 3 steps

1: diethylamino-sulfur trifluoride / dichloromethane / -78 - 20 °C / Inert atmosphere

2: triethylamine / 1,4-dioxane / 48 h / 90 °C

3: cesium fluoride / bis(tri-t-butylphosphine)palladium⁽⁰⁾ / 1,4-dioxane / 5 h / 100 °C / Inert atmosphere

With diethylamino-sulfur trifluoride; triethylamine; cesium fluoride; bis(tri-t-butylphosphine)palladium⁽⁰⁾; In 1,4-dioxane; dichloromethane;

Reference yield:

2,6-dichloro-4-(difluoromethyl) pyridine (1201675-01-5) → tert-butyl 4-(2'-(cyclohexylamino)-4-(difluoromethyl)-2,4'-bipyridin-6-yl)piperazine-1-carboxylate (1201673-40-6)

Guidance literature:

Multi-step reaction with 2 steps

1: triethylamine / 1,4-dioxane / 48 h / 90 °C

2: cesium fluoride / bis(tri-t-butylphosphine)palladium⁽⁰⁾ / 1,4-dioxane / 5 h / 100 °C / Inert atmosphere

With triethylamine; cesium fluoride; bis(tri-t-butylphosphine)palladium⁽⁰⁾; In 1,4-dioxane;

upstream raw materials:

cyclohexyl-(4-trimethylstannanylpyridin-2-yl)amine

4-(6-chloro-4-difluoromethylpyridin-2-yl)piperazine-1-carboxylic acid tert-butyl ester

2-cyclohexylamino-4-iodopyridine

2,6-dichloropyridine-4-carbaldehyde

Downstream raw materials:

cyclohexyl-(4-difluoromethyl-6-piperazin-1-yl[2,4']bipyridinyl-2'-yl)amine
