(R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine

Base Information

• Chemical Name: (R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine
• CAS No.: 1147862-52-9
• Molecular Formula: C₅₀H₇₅N₃O₁₂
• Molecular Weight: 910.158
• Mol file: 1147862-52-9.mol

Synonyms:(R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine

Chemical Property of (R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of (R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine

There total 1 articles about (R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 65.0%

bromoacetic acid tert-butyl ester (5292-43-3) + (R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-amino-6-methylperhydro-1,4-diazepine (1147862-50-7) → (R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine (1147862-52-9)

Guidance literature:

bromoacetic acid tert-butyl ester; (R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-amino-6-methylperhydro-1,4-diazepine; With potassium carbonate; In acetonitrile; at 0 - 20 ℃;

With sodium sulfate; In acetonitrile; Reflux;

DOI:10.1039/b818445c

Reference yield:

(R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-bis(tert-butoxycarbonylmethyl)amino-6-methylperhydro-1,4-diazepine (1147862-52-9) → C34H43N3O12

Guidance literature:

With trifluoroacetic acid; In dichloromethane; at 20 ℃; for 24h;

DOI:10.1039/b818445c

upstream raw materials:

bromoacetic acid tert-butyl ester

(R,R)-1,4-bis(1'-tert-butoxycarbonyl-3'-benzyloxycarbonylpropyl)-6-amino-6-methylperhydro-1,4-diazepine
