bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)]

Base Information

• Chemical Name: bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)]
• CAS No.: 1314641-99-0
• Molecular Formula: C₇₆H₅₈N₈Zn₂
• Molecular Weight: 1214.13
• Mol file: 1314641-99-0.mol

Synonyms:bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)]

Chemical Property of bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)]

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)]

There total 2 articles about bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)] which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 82.0%

(5-hexyl-10,20-diphenylporphyrinato)zinc(II) (1314641-98-9) → bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)] (1314641-99-0)

Guidance literature:

With DDQ; Sc(OTf)3; In tetrahydrofuran; toluene; Zn porphyrinate in toluene heated to 50°C; then DDQ and Sc(OTf)3 in dry toluene added, stirred for 3 h; THF added; stirred for 60 min; react. mixt. filtered through silica gel; solvent removed under reduced pressure; residue purified by column chromy. (CH2Cl2/CH3OH = 50:1);

DOI:10.1515/znb-2011-0601

Reference yield: 42.0%

(5-hexyl-10,20-diphenylporphyrinato)zinc(II) (1314641-98-9) → bis[(5-hexyl-10,20-diphenylporphyrin-15-ylato)zinc(II)] (1314641-97-8) + bis[(5-hexyl-10,20-diphenylporphyrin-13,15,17-triylato)zinc(II)] (1314641-99-0)

Guidance literature:

With 2,3-dicyano-5,6-dichloro-p-benzoquinone; scandium tris(trifluoromethanesulfonate); In toluene; at 50 ℃; for 3h;

DOI:10.1002/ejoc.201201622

upstream raw materials:

(5-hexyl-10,20-diphenylporphyrinato)zinc(II)
