(3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz₂-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one

Base Information

• Chemical Name: (3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz₂-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one
• CAS No.: 1241096-36-5
• Molecular Formula: C₄₅H₅₄N₆O₇
• Molecular Weight: 790.96
• Mol file: 1241096-36-5.mol

Synonyms:(3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz₂-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one

Chemical Property of (3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz₂-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of (3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz₂-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one

There total 10 articles about (3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz₂-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 59.0%

(3R,5S)-5-(N-Boc-aminomethyl)-3-(N-Cbz-3-aminopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one (1185841-66-0) + N,N'-dicarboxybenzyloxy-N''-trifluoromethanesulfonylguanidine → (3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz2-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one (1241096-36-5)

Guidance literature:

(3R,5S)-5-(N-Boc-aminomethyl)-3-(N-Cbz-3-aminopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one; With hydrogen; 1% Pd/C; In methanol;

N,N'-dicarboxybenzyloxy-N''-trifluoromethanesulfonylguanidine; With triethylamine; In dichloromethane;

Reference yield:

C28H40N4O3 (1185841-74-0) + N,N'-dicarboxybenzyloxy-N''-trifluoromethanesulfonylguanidine → (3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz2-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one (1241096-36-5)

Guidance literature:

With triethylamine; In dichloromethane;

Reference yield:

2,2-Diphenylethylamine (3963-62-0) → (3R,5S)-5-(N-Boc-aminomethyl)-3-(N,N'-Cbz2-3-guanidinopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one (1241096-36-5)

Guidance literature:

Multi-step reaction with 6 steps

1.1: dichloromethane / 2 h / 20 °C

3.1: sodium tris(acetoxy)borohydride / dichloromethane / 24 h

4.1: 1,3-dimethylbarbituric acid / tetrakis(triphenylphosphine) palladium⁽⁰⁾ / dichloromethane / sealed

4.2: 0.5 h

5.1: hydrogen / palladium on activated charcoal / methanol / 1551.49 Torr

6.1: triethylamine / dichloromethane

With 1,3-dimethylbarbituric acid; hydrogen; sodium tris(acetoxy)borohydride; triethylamine; tetrakis(triphenylphosphine) palladium⁽⁰⁾; palladium on activated charcoal; In methanol; dichloromethane;

upstream raw materials:

(3R,5S)-5-(N-Boc-aminomethyl)-3-(N-Cbz-3-aminopropyl)-1-(2,2-diphenylethyl)-1,4-diazepan-2-one

C₂₈H₄₀N₄O₃

BOC-glycine

2,2-Diphenylethylamine
