9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione

Base Information

• Chemical Name: 9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione
• CAS No.: 1616924-42-5
• Molecular Formula: C₃₀H₃₅N₃O₃
• Molecular Weight: 485.626
• Mol file: 1616924-42-5.mol

Synonyms:9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione

Chemical Property of 9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of 9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione

There total 16 articles about 9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 43.0%

5-benzyloxy-6-hydroxy-2-(1-phenylcyclohexylmethyl)pyrimidine-4-carboxylic acid (2-hydroxyethyl)isopropylamide (1616924-41-4) → 9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione (1616924-42-5)

Guidance literature:

With triphenylphosphine; diethylazodicarboxylate; In dichloromethane; at 20 ℃; for 2h;

Reference yield:

5-benzyloxy-6-hydroxy-2-(1-phenylcyclohexylmethyl)pyrimidine-4-carboxylic acid (1616924-39-0) → 9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione (1616924-42-5)

Guidance literature:

Multi-step reaction with 3 steps

1: 2,4,6-tripropyl-1,3,5,2,4,6-trioxatriphosphinane-2,4,6-trioxide; N-ethyl-N,N-diisopropylamine / tetrahydrofuran; ethyl acetate / 4 h / 65 °C

2: hydrogenchloride / tetrahydrofuran; water / 1.5 h / 20 °C

3: triphenylphosphine; diethylazodicarboxylate / dichloromethane / 2 h / 20 °C

With hydrogenchloride; 2,4,6-tripropyl-1,3,5,2,4,6-trioxatriphosphinane-2,4,6-trioxide; N-ethyl-N,N-diisopropylamine; triphenylphosphine; diethylazodicarboxylate; In tetrahydrofuran; dichloromethane; water; ethyl acetate;

Reference yield:

5-benzyloxy-6-hydroxy-2-(1-phenylcyclohexylmethyl)pyrimidine-4-carboxylic acid [2-(tert-butyldimethylsilanyloxy)ethyl]isopropylamide (1616924-40-3) → 9-benzyloxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione (1616924-42-5)

Guidance literature:

Multi-step reaction with 2 steps

1: hydrogenchloride / tetrahydrofuran; water / 1.5 h / 20 °C

2: triphenylphosphine; diethylazodicarboxylate / dichloromethane / 2 h / 20 °C

With hydrogenchloride; triphenylphosphine; diethylazodicarboxylate; In tetrahydrofuran; dichloromethane; water;

upstream raw materials:

5-benzyloxy-6-hydroxy-2-(1-phenylcyclohexylmethyl)pyrimidine-4-carboxylic acid tert-butyl ester

5-benzyloxy-6-hydroxy-2-(1-phenylcyclohexylmethyl)pyrimidine-4-carboxylic acid

5-benzyloxy-6-hydroxy-2-(1-phenylcyclohexylmethyl)pyrimidine-4-carboxylic acid [2-(tert-butyldimethylsilanyloxy)ethyl]isopropylamide

benzyloxyacetic acid

Downstream raw materials:

9-hydroxy-2-isopropyl-6-(1-phenylcyclohexylmethyl)-3,4-dihydro-2H-pyrazino[1,2-c]pyrimidine-1,8-dione
