2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid

Base Information

• Chemical Name: 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid
• CAS No.: 890152-41-7
• Molecular Formula: C₁₇H₃₃NO₉
• Molecular Weight: 395.45
• Mol file: 890152-41-7.mol

Synonyms:

Chemical Property of 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid

Chemical Property:

• Boiling Point: 526.2±50.0 °C(Predicted)
• Density: 1.136±0.06 g/cm3(Predicted)

Purity/Quality:

98%,99%, ^*data from raw suppliers

2-[2-[2-[2-[2-[2-[(2-methylpropan-2-yl)oxycarbonylamino]ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]aceticacid 95%+ ^*data from reagent suppliers

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

• Description: t-Boc-N-amido-PEG5-CH2CO2H is a PEG linker containing a terminal carboxylic acid and Boc-protected amino group. The hydrophilic PEG spacer increases solubility in aqueous media. The terminal carboxylic acid can react with primary amine groups in the presence of activators (e.g. EDC, or HATU) to form a stable amide bond. The Boc group can be deprotected under mild acidic conditions to form the free amine.
• Uses: This heterobifunctional, PEGylated crosslinker features a carboxylic acid at one end and Boc-protected amino group at the other, which can be deprotected with mildly acidic conditions. The hydrophillic PEG linker facilitates solubility in biological applications. BocNH-PEG5-acid can be used for bioconjugation or as a building block for synthesis of small molecules, conjugates of small molecules and/or biomolecules, or other tool compounds for chemical biology and medicinal chemistry that require ligation. Examples of applications include its synthetic incorporation into antibody-drug conjugates or proteolysis-targeting chimeras (PROTAC? molecules) for targeted protein degradation.

Technology Process of 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid

There total 15 articles about 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 97.8%

C18H35NO9 → 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid (890152-41-7)

Guidance literature:

With lithium hydroxide monohydrate; water; In tetrahydrofuran; at 20 - 25 ℃; for 12h; Inert atmosphere;

Reference yield:

ethyl 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetate → 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid (890152-41-7)

Guidance literature:

With water; lithium hydroxide; In tetrahydrofuran; methanol; at 20 ℃; for 0.5h;

Reference yield:

2-[2-[2-[2-(2-azidoethoxy)ethoxy]ethoxy]ethoxy]ethanol (86770-68-5) → 2-[2-[2-[2-[2-[2-(tert-butoxycarbonylamino)ethoxy]ethoxy]ethoxy]ethoxy]ethoxy]acetic acid (890152-41-7)

Guidance literature:

Multi-step reaction with 5 steps

1: hydrogen; 5%-palladium/activated carbon / ethanol / 48 h / 20 °C / 775.74 Torr

2: sodium hydrogencarbonate / water; acetonitrile / 12 h / 25 °C

3: hydrogen; 10% palladium hydroxide on charcoal / ethyl acetate / 16 h / 20 °C / 775.74 Torr

4: dichloromethane / 17 h / 20 °C

5: water; lithium hydroxide / tetrahydrofuran; methanol / 0.5 h / 20 °C

With 10% palladium hydroxide on charcoal; 5%-palladium/activated carbon; water; hydrogen; sodium hydrogencarbonate; lithium hydroxide; In tetrahydrofuran; methanol; ethanol; dichloromethane; water; ethyl acetate; acetonitrile;

upstream raw materials:

2-[2-[2-[2-(2-hydroxyethoxy)ethoxy]ethoxy]ethoxy]ethyl 4-methylbenzenesulfonate

Pentaethylene glycol

2-[2-[2-[2-(2-azidoethoxy)ethoxy]ethoxy]ethoxy]ethanol

2-[2-[2-[2-(2-aminoethoxy)ethoxy]ethoxy]ethoxy]ethanol
