regarding the processing and mechanical properties of this material
are in active progress and the results will be presented in our future
articles.
Acknowledgements
This work is financially supported by the National High Tech-
nology Research and Development Programme of China (863
program) with the project No. 2007AA03Z561. We would like to
express our sincere thanks to Dr. Guodong Li of Jilin University for
his kind assistance in Electron Paramagnetic Resonance (EPR)
measurement.
Fig. 12. Schematic illustrations of the cross-link reaction process.
According to the FT-IR spectrum of the polymer (Fig. 3), an
obvious decrease in the amide C]O peak at 1644 cmꢃ1 after curing
is observed, which coincides with our inference. Therefore it can be
concluded that the origin of R1 and R2 is the amide C]O group.
Combined with EPR analysis it is reasonable that R1 are COꢁ free
radicals, and R2 are Cꢁ free radicals. The cross-linking reaction
mechanism is suggested as below.
References
[1] Schuster M, de Araujo CC, Atanasov V, Andersen HT, Kreuer KD, Maier J.
Macromolecules 2009;42:3129e37.
[2] Naffakh M, Marco C, Gomez MA, Gomez-Herrero J, Jimenez I. J Phys Chem B
2009;113:10104e11.
[3] Jeon IY, Lee HJ, Choi YS, Tan LS, Baek JB. Macromolecules 2008;41:7423e32.
[4] Naffakh M, Marco C, Gomez MA, Gomez-Herrero J, Jimenez I. J Phys Chem B
2009;113:7107e15.
[5] Zou H, Wang K, Zhang Q, Fu Q. Polymer 2006;47:7821e6.
[6] Naffakh M, Marco C, Gomez MA, Gomez-Herrero J, Jimenez I. J Phys Chem B
2008;112:14819e28.
[7] Sasanuma Y, Hayashi Y, Matoba H, Touma I, Ohta H, Sawanobori M, et al.
Macromolecules 2002;35:8216e26.
[8] Guo YL, Bradshaw RD. Polymer 2009;50:4048e55.
[9] Zhang RC, Xu Y, Lu A, Cheng KM, Huang YG, Li ZM. Polymer 2008;49:2604e13.
[10] Feller LM, Cerritelli S, Textor M, Hubbell JA, Tosatti SGP. Macromolecules
2005;38:10503e10.
[11] Yang J. CN1935874.
[12] Barique MA, Wu LB, Takimoto N, Kidena K, Ohira A. J Phys Chem B 2009;113:
15921e7.
3.5. Possible reaction mechanism of cross-link
Based on the research hereinbefore, the thermal cross-link
behavior of p-PASSA could be explained by the following mechanism.
The double bonds of amide C]O are opened when they are
subject to thermal curing in air, and two kinds of free radicals,
Cꢁ and COꢁ, are produced consequently. With the effect of O2, most
Cꢁ are transformed into COꢁ free radicals, which causes the higher
concentration of R1 than R2. The cross-linking network was formed
afterward which was induced by these two kinds of free radicals.
The cross-linking reaction type belongs to conventional radical
cross-link reaction, and the reaction process is shown in Fig. 12.
[13] Xia LG, Li AJ, Wang WQ, Yin Q, Lin H, Zhao YB. J Power Sources 2008;178:
363e7.
[14] Huang J, Baird DG, McGrath JE. J Power Sources 2005;150:110e9.
[15] Mighri F, Huneault MA, Champagne MF. Polym Eng Sci 2004;44(9):1755e65.
[16] Tanthapanichakoon W, Furuuchi M, Nitta KH, Hata M, Endoh S, Otani Y. Polym
Degrad Stab 2006;91:1637e44.
4. Conclusions
[17] Hawkins RT. Macromolecules 1976;9(2):189e94.
[18] Scobbo JJ, Hwang CR. Polym Eng Sci 1994;34(23):1744e9.
[19] Gies AP, Geibel JF, Hercules DM. Macromolecules 2010;43:952e67.
[20] Gies AP, Geibel JF, Hercules DM. Macromolecules 2010;43:943e51.
[21] Perng LH. Polym Degrad Stab 2000;69:323e32.
[22] Wang HD, Yang J, Long SR, Wang XJ, Yang Z, Li GX. Polym Degrad Stab 2004;
83:1637e44.
An amorphous p-PASSA was synthesized via low temperature
solution polycondensation. The polymer with high glass-transition
temperature (259 ꢀC) and thermal stability suggests a potential use
in heat-resistant materials.
We have demonstrated, for the first time, the thermal cross-link
behavior of the polymer at 260 ꢀC in air condition. The results
showed that the formation of cross-link network enhanced the Tg
from 259.17 ꢀC to 268.89 ꢀC, and the 1% weight loss temperature of
the polymer increased remarkably from 243.75 ꢀC to 345.87 ꢀC.
Two kinds of free radicals, COꢁ and Cꢁ, existed in the polymer, and
concentration of the former was much higher than that of the latter.
These two kinds of free radicals were responsible for the inter-
molecular cross-linking behavior. The cross-linking type was
attributed to conventional radical cross-link reaction, and the
reaction mechanism was also suggested.
[23] Liu J, Zhang G, Long SR, Wang XJ, Yang J. J Macromol Sci Part B Physics 2010;
49(2):229e35.
[24] Lakshmi RTSM, Vyas MK, Brar AS, Varma IK. Eur Polym J 2006;42:1423e32.
[25] Song Z, Baker WE. J Polym Sci Part A Polym Chem 1992;30:1589e600.
[26] Semsarzadeh MA, Poursorkhabi V. Polym Degrad Stab 2009;94:1860e6.
[27] Wang LX, Wang FS, Zhang JP, Wang RS, Soczka-Guth T, Mullen K. Synthetic
Met 1999;101:320.
[28] Poojari Y, Clarson SJ. Macromolecules 2010;43:4616e22.
[29] Niemela S, Leppanen J, Sundholm F. Polymer 1996;37(18):4155e65.
[30] Iseki T, Narisawa M, Katase Y, Oka K, Dohmaru T, Okamura K. Chem Mater
2001;13:4163e9.
[31] Mukherjee I, Drake K, Berke-Schlessel D, Lelkes PI, Yeh JM, Wei Y. Macro-
molecules 2010;43:3277e85.
[32] Bhadra S, Khastgir D. Polym Degrad Stab 2007;92:1824e32.
[33] Niu YM, Wang GB, Zhang SX, Na Y, Jiang ZH. Polym Int 2005;54:180e4.
[34] Hill DJ, Choi B- K. Polym Int 1999;48:956.
This cross-linkable polymer represents a new class of super engi-
neering plastic with great thermal stability. Further investigations
