Novel C(6) Modified Baicalein Derivatives
J. Agric. Food Chem., Vol. 56, No. 8, 2008 2839
Scheme 1. Synthesis of Alkoxy Derivatives of Baicalein
ꢀ-amyloid-induced apoptosis in neuronal cells through their
antioxidative properties (12). Some chemicals containing a
terpenoid moiety (group) were reported to have antioxidative
activities (12).
Many human diseases are related to the overproduction of
ROS in living cells. ROS overproduction has been reported to
induce lipid peroxidation, protein and enzyme oxidation, and
DNA damage, which can lead to serious cellular damage such
as mutations, death, and carcinogenesis (13). Moreover, aging,
neurodegeneration, diabetes mellitus, hypertension, and inflam-
matory diseases were also reported to be directly related to ROS
formation inside individual cells (14). Superoxide can be
produced in mitochondrial electron transfer chain or during
phagocytosis and can lead to other cellular reactions to produce
H2O2, hydroxyl radical, and/or lipid peroxide. These ROS can
cause intense cellular damage. Chemical compounds with the
capacity of inhibiting the intracellular oxidative stresses caused
by ROS were often considered to have potential in disease
prevention.
Several studies have demonstrated that ROS generation by
activated monocytes is especially important to exhibit leukocyte-
endothelium interactions in the vascular dysfunction mechanism
(15). Monocytes’ differentiation into macrophages was possibly
triggered by unquenched ROS, which might contribute to
increased inflammatory response such as increased cycloxyge-
nase-2 activity within atheromata (16). It had been reported that
LDL oxidation might play a crucial role in early atherogenesis.
The process of LDL oxidation appears to occur in all major
cells within the arterial wall. Therefore, decreasing the intra-
cellular oxidative stress by baicalein and its derivatives in
monocytes may prevent the formation of monocyte-derived
macrophages; atherogenesis can thus be prevented or minimized.
There are few studies illustrating that baicalein with a
terpenoid moiety is able to increase ROS scavenging activity
and thus decrease intracellular oxidative stresses. In this study,
we synthesized and evaluated a few new baicalein derivatives
that have a substitution at position 6 of the A ring with three
terpenoid groups: prenyl, geranyl, and farnesyl. Our results
indicated that baicalein derivatives with terpenoid groups on
the A ring of the flavones would greatly increase the ROS
scavenging activity and decrease the relative intracellular
oxidative stresses in various ROS-treated human monocyte
THP-1 cells.
NMR. Purity tests of baicalein derivatives were performed by HPLC
equipped with a 280 nm detector and a LiChroCART RP-18e column
(4.6 mm i.d. × 250 mm). The mobile phase was composed of MeOH/
H2O (0.05% TFA) (90:10), and the flow rate was 1.0 mL/min. The
purity of all compounds was >98%.
Bai-C5 (5,6-Dihydroxy-7-prenoxyflavone). Bai-C5 was obtained
as a yellow needle crystal: mp 164-165 °C; 1H NMR (400 MHz,
DMSO-d6) δ 12.47 (s, 1H, C5-OH), 8.69 (s, 1H, C7-OH), 8.06 (dd, J
) 8.0, 1.2 Hz, 2H, H2′, H6′), 7.59-7.54 (m, 3H, H3′, H4′, H5′), 6.96
(s, 1H, H3), 6.95 (s, 1H, H8), 5.50 (dd, J ) 8.0, 6.4 Hz, 1H), 4.67 (d,
J ) 6.4 Hz, 2H), 1.77 (s, 3H, CH3), 1.74 (s, 3H, CH3); 13C NMR (100
MHz, DMSO-d6) δ 181.97, 162.84, 153.55, 149.47, 145.89, 137.57,
131.76, 130.66, 130.05, 128.94, 126.13, 119.11, 105.06, 104.54, 92.07,
65.72, 25.54, 18.18.
Bai-C10 (5,6-Dihydroxy-7-geranoxyflavone). Bai-C10 was ob-
tained as a yellow powder: mp 121-124 °C; 1H NMR (400 MHz,
DMSO-d6) δ 12.47 (s, 1H, C5-OH), 8.70 (s, 1H, C7-OH), 8.06 (dd, J
) 8.0, 1.2 Hz, 2H, H2′, H6′), 7.59-7.54 (m, 3H, H3′, H4′, H5′), 6.97
(s, 1H, H3), 6.94 (s, 1H, H8), 5.49 (t, J ) 5.6 Hz, 1H), 5.05 (m, 1H),
4.70 (d, J ) 6.4 Hz, 2H), 2.07 (m, 4H), 1.77 (s, 3H, CH3), 1.64 (s, 3H,
CH3), 1.56 (s, 3H, CH3); 13C NMR (100 MHz, DMSO-d6) δ 181.97,
162.84, 153.48, 149.44, 145.88, 140.49, 131.77, 130.86, 130.66, 130.10,
128.94, 126.12, 123.54, 118.95, 105.07, 104.54, 93.74, 92.17, 65.79,
25.78, 25.46, 17.63, 16.51.
Bai-C15 (5,6-Dihydroxy-7-farnesoxyflavone). Bai-C15 was ob-
tained as a yellow powder: mp 103-104 °C; 1H NMR (400 MHz,
DMSO-d6) δ 12.47 (s, 1H, C5-OH), 8.71 (s, 1H, C7-OH), 8.05 (dd, J
) 8.0, 1.6 Hz, 2H, H2′, H6′), 7.60-7.54 (m, 3H, H3′, H4′, H5′), 6.96
(s, 1H, H3), 6.92 (s, 1H, H8), 5.48 (t, J ) 6.2 Hz, 1H), 5.05 (t, J ) 6.2
Hz, 1H), 4.96 (t, J ) 6.8 Hz, 1H), 4.71 (d, J ) 6.4 Hz, 2H), 2.06 (m,
4H), 1.93 (m, 2H), 1.85 (m, 2H), 1.75 (s, 3H, CH3), 1.61 (s, 3H, CH3),
1.56 (s, 3H, CH3), 1.49 (s, 3H, CH3); 13C NMR (100 MHz, DMSO-d6)
δ 182.00, 162.86, 153.46, 149.45, 145.90, 140.52, 134.53, 131.79,
130.68, 130.47, 130.14, 128.97, 126.12, 123.87, 123.32, 119.04, 105.09,
104.54, 92.15, 65.76, 26.20, 25.66, 25.54, 17.59, 16.56, 15.89.
ABTS•+ Decoloration Assay. The antioxidative activity was
measured by the ability of hydrogen-donating antioxidants to scavenge
the ABTS•+ radical cation using a previously reported method (18).
The ABTS•+ radical cation was prepared by mixing a 7 mM ABTS
stock solution with 2.45 mM potassium persulfate (1:1, v/v) and leaving
the mixture for 12–16 h until the reaction was complete and absorbance
was stable. The ABTS•+ solution was diluted in phosphate buffer (PBS)
to an absorbance of 0.70 ( 0.02 at 734 nm for measurement. The
photometric assay was conducted in 1.9 mL of the ABTS•+ solution
and 0.1 mL of baicalein and its derivatives dissolved in an ethanol
solution and mixed for 6 min. Measurements were taken immediately
at 734 nm. The percentage inhibition (expressed as percent decrease
of absorbance at 734 nm) is calculated as a function of concentration
of baicalein derivatives and of Trolox for the standard reference data.
All experiments were carried out in triplicates. The IC50 value was
defined as the concentration that causes a 50% decrease of ABTS•+
radical cation.
MATERIALS AND METHODS
Extraction and Isolation of Baicalein from S. baicalensis Georgi.
Dried S. baicalensis roots were cut into small pieces, immersed, and
extracted with a 10 times volume of acetone twice at room temperature
for 2 weeks. Acetone extracts were concentrated and subjected to
column chromatography on silica gel (7.5 cm i.d. × 30 cm) eluted
with CHCl3 and CHCl3/MeOH (10:1) to yield two fractions. The CHCl3/
MeOH (10:1) eluent was subjected to chromatography on silica gel (3
cm i.d. × 20 cm) and eluted with CH2Cl2/acetone (9:1) to yield baicalein
(2.30 g).
Baicalein (5,6,7-trihydroxyflavone). Baicalein was obtained as a
yellow powder: mp 272-273 °C. [lit. (17) 268-271 °C]; 1H NMR
(400 MHz, DMSO-d6) δ 12.62 (s, 1H, C5-OH), 10.63 (s, 1H, C6-OH),
8.83 (s, 1H, C7-OH), 8.03 (d, J ) 7.2 Hz, 2H, H2′, H6′), 7.61-7.54
(m, 3H, H3′, H4′, H5′), 6.91 (s, 1H, H3), 6.62 (s, 1H, H8).
Chemistry. A series of 6-substituted baicalein derivatives were
synthesized and evaluated by alkylation using alkyl bromide (including
prenyl, geranyl, and farnesyl bromides) with anhydrous potassium
carbonate in anhydrous acetone reflux for 4 h. The synthetic procedure
and reaction conditions for all investigated compounds are shown in
Scheme 1. The synthesized compounds were purified by flash silica
gel column chromatography and the structures based on 1H and 13C
Cell Line and Reagents. The human acute monocytic leukemia cell
line THP-1 was obtained from the American type Culture Collection
(Manassa, VA). Hydroethidine (HE) and chloromethylflourescein
diacetate (CMF-DA) were acquired from Molecular Probes (Eugene,
OR). Propidium iodide (PI), 2′,7′-dichlorodihydrofluorescein diacetate
(DCFH-DA), RPMI-1640 medium, menadione, H2O2, cumene hydro-
peroxide, and other chemicals were purchased from Sigma Chemical
Co. (St. Louis, MO).
Cell Culture and Treatment. The basal medium for the THP-1
cell line was cultured in RPMI-1640 medium supplemented with 10%
