Turning on Fluorescent Emission from
C-Alkylation on Quinoxaline Derivatives
Ho-Jin Son, Won-Sik Han, Kyung-Ryang Wee, Dae-Hwan Yoo, Jong-Ho Lee,
Soon-Nam Kwon, Jaejung Ko,* and Sang Ook Kang*
Department of Materials Chemistry, Sejong Campus, Korea UniVersity,
Chochiwon, Chung-Nam 339-700, South Korea
sangok@korea.ac.kr
Received October 2, 2008
ABSTRACT
Reduction on imine moiety (CdN) of quinoxalines by alkyl-/aryllithiums led to a geometrical change on the quinoxaline ring, thereby perturbing
the electronic structure to turn on fluorescence emission. Such a structural change resulted in interrupted cyclic-ring systems with electron-
donating amine (sp3-type) and electron-accepting imine (sp2-type) units bridged by a phenylene unit. Through either alkylation or arylation, a
highly polarized electron donor-electron acceptor bipolar system was established in a single molecule with dramatically enhanced PL efficiency
(up to 60%).
Since the discovery of organic light emitting diodes (OLEDs)
by Tang1 and Burroughes,2 there has been substantial effort
aimed at developing highly efficient electroluminescent (EL)
materials. In particular, small molecules with a built-in
donor-acceptor architecture have currently attracted con-
siderable attention as the key emissive elements due to their
good properties such as bipolar charge (electron and hole)
transport and high PL efficiency.3,4 As representative ex-
amples, many groups have reported several electron donor-
acceptor (ED-EA) conjugated compounds as emissive OLED
materials, which are combined with triarylamine,4 carbazole,5
fluorene,4c and phenoxazine/-thiazine6 as a donor and oxa-
diazole,4,7 benzothiadiazole,8 diarylboron,3 and phenylquino-
line9 as an acceptor. Recently an electro-deficient quinoxaline
moiety has been actively used as the acceptor to obtain high-
efficiency bipolar luminescent materials due to its great
diversity of tunable electronic properties resulting from ligand
substitution, where the systematic alteration is mainly car-
ried out by incorporating electron-donating groups to the
2,3-5b,10 or 5,8-position11 of the quinoxaline moiety.
(6) (a) Lai, R. Y.; Fabrizio, E. F.; Lu, L.; Jenekhe, S. A.; Bard, A. J.
J. Am. Chem. Soc. 2001, 123, 9112. (b) Zhu, Y.; Kulkarni, A. P.; Jenekhe,
S. A. Chem. Mater. 2005, 17, 5225.
(1) Tang, C. W.; VanSlyke, S. A. Appl. Phys. Lett. 1987, 51, 913.
(2) Burroughes, J. H.; Bradley, D. D. C.; Brown, A. R.; Marks, R. N.;
Mackay, K.; Friend, R. H.; Burns, P. L.; Homes, A. B. Nature 1990, 347,
539.
(7) Thomas, K. R. J.; Lin, J. T.; Tao, Y.-T.; Chuen, C.-H. Chem. Mater.
2002, 14, 3852
.
(8) Thomas, K. R. J.; Lin, J. T.; Velusamy, M.; Tao, Y.-T.; Chuen, C.-
H. AdV. Funct. Mater. 2005, 15, 231.
(3) (a) Shirota, Y.; Kinoshita, M.; Noda, T.; Okumoto, K.; Ohara, T.
J. Am. Chem. Soc. 2000, 122, 11021. (b) Doi, H.; Kinoshita, M.; Okumoto,
(9) (a) Agrawal, A. K.; Jenekhe, S. A. Macromolecules 1993, 26, 895.
(b) Zhang, X.; Shetty, A. S.; Jenekhe, S. A. Macromolecules 1999, 32,
7422. (c) Jenekhe, S. A.; Zhang, X.; Chen, X. L. Chem. Mater. 1997, 9,
409.
K.; Shirota, Y. Chem. Mater. 2003, 15, 1080
.
(4) (a) Hamada, Y.; Adachi, C.; Tsutsui, T.; Saito, S. Jpn. J. Appl. Phys.
1992, 31, 1812. (b) Tamoto, N.; Adachi, C.; Nagai, K. Chem. Mater. 1997,
9, 1077. (c) Antoniadis, H.; Inbasekaran, M.; Woo, E. P. Appl. Phys. Lett.
(10) (a) Chen, C.-T.; Lin, J.-S.; Moturn, M. V. R. K.; Lin, Y.-W.; Yi,
W.; Tao, Y.-T.; Chien, C.-H. Chem. Commun. 2005, 3980. (b) Thomas,
K. R. J.; Velusamy, M.; Lin, J. T.; Chuen, C.-H.; Tao, Y.-T. Chem. Mater.
2005, 17, 1860. (c) Kulkarni, A. P.; Zhu, Y.; Babel, A.; Wu, P.-T.; Jenekhe,
1998, 73, 3055
.
(5) (a) Zhu, W.; Hu, M.; Yao, R.; Tian, H. J. Photochem. Photobiol., A
2003, 154, 169. (b) Thomas, K. R. J.; Lin, J. T.; Tao, Y.-T.; Chuen, C. H.
J. Mater. Chem. 2002, 12, 3516.
S. A. Chem. Mater. 2008, 20, 4212
.
10.1021/ol802287k CCC: $40.75
Published on Web 10/31/2008
2008 American Chemical Society

This study examined new types of quinoxaline-based
bipolar systems as a part of an ongoing study into the
development of highly emissive materials based on the
concepts of ED-EA. In general, it has been noted that
reactions of organolithium such as n-butyllithium with
pyridine led ultimately to 2-butylated products, and the
subsequent hydrolysis produced 2-butyl-1,2-dihydropyridine
with efficient change of the sp2-type nitrogen center (EA)
into a sp3-type nitrogen (ED).12 Given the fact that nucleo-
philic addition adjacent to the electro-negative element (e.g.,
nitrogen) in the conjugated ring is possible, such a reaction
can also be applied to the quinoxaline system. Indeed, when
the addition reaction was carried out by reacting quinoxaline
with an alkyl/aryllithium reagent, the expected alkyl/aryl-
added products were produced in high yields (60-81%).
With this reaction scheme in hand, a series of 2-alkyl/arylated
quinoxaline compounds 2-butyl-2,3-diarylX-1H-quinoxaline
(2) and 2-arylX-2,3-diphenyl-1H-quinoxaline (3) were pro-
duced, where the 2,3-postion of the products was altered by
the para-substituted aryl-X groups (X ) F, H, OMe, and
NMe2). Through this substitution, efficient ED-EA-type
materials were produced, turning on fluorescent emission
with the red-shifed PL emission (∼510 nm).
a reaction of 1b (1 equiv) and LiArX (1.1 equiv) para-
substituted with X ) NMe2, OMe, H, and F. In all cases,
the products were isolated by flash chromatography in good
yields (60-81%). Single crystals were obtained by recrys-
tallization of the compounds from the solution of CH2Cl2/
hexane (v/v ) 1/2).
X-ray analysis of 3d was carried out to establish the
structure of the 2-alkyl/arylated quinoxaline compounds. As
shown in Figure 1, the geometrical change derived from the
2,3-Disubstituted quinoxalines (1) were prepared by
Suzuki-Miyaura coupling reaction13 or condensation of
o-phenylenediamine and 1,2-substituted dicarbonyl
compounds.14From the reaction of 1 with n-butyllithium and
Figure 1. X-ray crystal structure of 3d.
substitution of the 4-dimethylaminophenyl unit efficiently
produced a pseudotetrahedral geometry different from that
found in general quinoxaline derivatives, confirming the
addition of the 2-aryl group on quinoxaline derivatives. As
shown in Table S2 in Supporting Information, four bond
angles around the 2-carbon center authenticated a typical
tetrahedral geometry having values in the ranges of
110.4(1)-113.0(1)°. Saturation of the N(1)-C(2) double
bond (1.475(2) Å) by aryl and hydrogen groups induced a
structural transformation from planar to bridge-headed
geometry with an interrupted cyclic-ring system, where the
electron-donating amine (sp3-type) and electron-accepting
imine (sp2-type) units are conjugated by phenylene unit. A
subsequent electron density difference might result in a
significant change in the electronic structure of quinoxaline
derivatives.
Scheme 1
.
Synthesis of 2-Alkyl/Arylated Quinoxaline
Compounds 2 and 3
The UV-visible absorption and fluorescence spectra of 1
and 2 were measured in chloroform, and the data is
summarized in Table 1. A substantial structural change in
the core luminescence unit was expected on the basis of the
characteristic changes in absorption and emission spectra.
Upon C-alkyl/arylation of the quinoxaline CdN functional
group, the symmetrical quinoxaline fused ring system
transformed into a puckered interrupted ring to create the
unsymmetrical structures observed in 2 and 3. This perturbed
ring is believed to be the origin of the photoluminescence
turn-on.
