Molecules 2016, 21, 8
4 of 6
˝
solid. The solution was cooled to 5 C and the precipitated solid was filtered and washed with water to
20
give M8 (5.90 g, 99%) as a white solid, rαsD
=
´
40.7 (c = 0.4, H2O), ESI/MS: 360.15 [M + H]+, 1H-NMR
(300 MHz, methanol-d4, see Supplementary Materials)
δ 8.34 (d, J = 5.0 Hz, 2H), 7.27 (t, J = 2.1 Hz, 1H),
7.15–6.99 (m, 2H), 6.52 (dt, J = 7.5, 1.8 Hz, 1H), 6.00 (d, J = 6.3 Hz, 1H), 4.77 (dd, J = 6.3, 5.1 Hz, 1H),
4.34 (dd, J = 5.1, 2.6 Hz, 1H), 4.19 (q, J = 2.6 Hz, 1H), 3.90 (dd, J = 12.6, 2.6 Hz, 1H), 3.76 (dd, J = 12.5,
2.8 Hz, 1H). 13C-NMR (100 MHz, methanol-d4)
δ 161.6, 156.5, 155.8, 152.5, 151.9, 144.8, 143.9, 133.1,
115.6, 114.4, 111.6, 93.9, 90.7, 78.1, 75.2, 66.0.
3.3. Synthesis of N6-(3-O-Sulfophenyl) Adenosine (M5)
Chlorosulfonic acid (300
µL, 4.6 mmol) was added dropwise (carefully!) into a stirred solution of
WS070117 (130 mg, 0.27 mmol) in dry pyridine (3 mL) at 0 ˝C under N2. The solution was warmed
to room temperature and stirred for 12 h. Na2CO3 (aq, 0.5 M, 20 mL) was then added to adjust the
pH to 10. The reaction mixture was stirred for another 12 h at room temperature, and the solvent was
removed in vacuo and the remaining solid was purified by Sephadex LH-20 chromatography eluting
20
with water to give M5 (78 mg, 66.3%) as a white solid, rαsD
=
´
33.5 (c = 0.15, H2O), ESI/MS: 440.10
[M + H]+, 1H-NMR (300 MHz, D2O, see Supplementary Materials)
δ
8.28 (s, 1H), 8.21 (s, 1H), 7.50 (t,
J = 3.8 Hz, 1H), 7.40 (t, J = 5.7 Hz, 2H), 7.10 (p, J = 7.7 Hz, 1H), 6.03 (dd, J = 5.9, 2.6 Hz, 1H), 4.76–4.67
(m, 1H), 4.41 (dd, J = 5.4, 3.7 Hz, 1H), 4.28 (dq, J = 6.2, 3.4 Hz, 1H), 3.93 (dd, J = 12.9, 2.94 Hz, 1H), 3.83
(dd, J = 12.9, 3.7 Hz, 1H). 13C-NMR (100 MHz, D2O)
δ180.2, 152.0, 151.5, 148.4, 140.9, 138.6, 130.1, 120.1,
117.7, 115.4, 88.5, 85.8, 73.9, 70.7, 68.0, 61.5.
3.4. Synthesis of N6-(3-Hydroxyphenyl) Adenine (M7)
Concentrated hydrochloric acid (5 mL) was added into a stirred solution of WS070117 (4.85 g,
10 mmol) in 95% ethanol (100 mL). The reaction was refluxed for 1 h and then cooled to room
temperature. The precipitated solid was filtered and washed with water to give M7 (2.1 g, 92.5%) as
a white solid, ESI/MS: 228.05 [M + H]+, 1H-NMR (300 MHz, DMSO-d6, see Supplementary Materials)
δ
11.22 (s, 1H), 9.61 (brs, 1H), 8.74 (s, 1H), 8.70 (s, 1H), 7.42 (s, 1H), 7.31 (d, J = 10.4 Hz, 1H), 7.20 (t,
J = 8.0 Hz, 1H), 6.62 (d, J = 8.0 Hz, 1H). 13C-NMR (100 MHz, DMSO-d6)
δ 158.3, 150.0, 148.9, 148.8,
143.8, 139.1, 130.1, 113.3, 112.6, 112.6, 109.0.
3.5. Synthesis of 8-Hydroxy-N6-(3-hydroxy-phenyl) Adenine (M6)
N,N1-Carbonyldiimidazole (CDI, 1.6 g, 10 mmol) was added into a stirred solution of
4,5-diamino-6-chloropyrimidine ( , 0.76 g, 5.23 mmol) in 1,4-dioxane. The reaction mixture was
refluxed for 6 h and then cooled to room temperature. The precipitated solid was filtered and washed
with water to give 8-hydroxy-6-chloroadenine ( , 700 mg). Concentrated hydrochloric acid (1 mL)
was then added into a stirred solution of intermediate (0.7 g, 4.12 mmol) and 3-aminophenol (0.7 g,
2
3
3
˝
6.42 mmol) in ethanol (20 mL) in a sealed tube, which was irradiated in a microwave reactor at 120 C
for 4 h and then cooled to room temperature. The precipitating solid was filtered and washed with
water to give M6 (0.9g, 70%) as a white solid, ESI/MS: 244.07 [M + H]+, 1H-NMR (400 MHz, DMSO-d6,
see Supplementary Materials)
δ 11.69 (s, 1H), 10.80 (s, 1H), 9.43 (s, 1H), 8.25 (s, 1H), 7.33 (s, 1H),
7.22–7.10 (m, 2H), 6.48 (d, J = 4.0 Hz, 1H). 13C-NMR (100 MHz, DMSO-d6)
δ 158.2, 152.9, 149.5, 148.1,
142.5, 140.9, 129.9, 110.8, 110.2, 107.1, 106.3.
3.6. Synthesis of 8-Hydroxy-N6-(3-O-sulfophenyl) Adenine (M3)
SO3 Pyr complex (9.54 g, 60 mmol) was added into a stirred solution of M6 (2.27 g, 9.3 mmol) in
¨
pyridine (50 mL) and DMF (50 mL) at room temperature. After 24 h, acetone (200 mL) was added and
the precipitated solid was filtered and washed with water to give M3 (2.01 g, 67.2%) as a white solid,
1H-NMR (300 MHz, DMSO-d6)
δ 8.84 (s), 8.20 (s, 1H), 7.61 (dd, J = 8.2, 2.3 Hz, 1H), 7.51 (dd, J = 2.3,
2.2 Hz, 1H), 7.18 (dd, J = 8.2 Hz, 1H), 6.77 (dd, J = 8.2, 2.2 Hz, 1H). 13C-NMR (100 MHz, DMSO-d6)
δ 154.3, 153.5, 150.7, 149.4, 142.4, 141.2, 129.3, 114.5, 114.7, 111.4, 106.3.
