ABSTRACT: MoS2 is a two-dimensional material that is
gaining prominence due to its unique electronic and chemical
properties. Here, we demonstrate ligand conjugation of chemi-
cally exfoliated MoS2 using thiol chemistry. Using this meth-
od, we modulate the zeta-potential and colloidal stability of
MoS2 sheets through ligand designs, thus enabling its usage as
a selective artificial protein receptor for β-galactosidase. The
facile thiol functionalization route opens the door for surface
modifications of solution processable MoS2 sheets.
The recent excitement over two dimensional atomically-
layered materials has been fueled in large part by desires to
exploit their low-dimensional properties, which can be distinct
from their bulk counter-parts. One of these emerging materi-
als, MoS2, has received a fair share of attention due to its ap-
plicability in areas ranging from catalysis1 and electronics2-5 to
biomedicine.6 Nevertheless, to fully harness the capabilities of
Figure 1. Structural models illustrating ligand conjugation
of ce-MoS2 sheets.
such new materials, ligand conjugations were often necessity.
For example, it is typically a crucial step for solution pro-
sheets by thiol-terminated ligands (Figure 1, Supplemental
Information S1-5). This was used to conveniently tune ce-
MoS2 and its biomolecular interactions. This route opens
pathways for making solution processable MoS2 with tunable
colloidal properties and can potentially facilitate improve-
ments in its processing.
cessing, which enables the usage of nanoparticles as functional
assembly blocks in bio-imaging,7 electronics,8 sensing,9 and
photovoltaics.10 Previously, attempts to functionalize MoS2
have been limited to bulk-like materials characterized by hy-
drophobic cleavage planes.11,12 Specifically, Tremel and
coworkers13 have modified hydrophobic MoS2 particles using
nickel-nitrilotriacetic acid chelation.13 However, colloidal sur-
face modification of water dispersible, chemically exfoliated
MoS2 (ce-MoS2) sheets has not been demonstrated.
In this report, the as-made ce-MoS2was first purified using
exhaustive dialysis (7 days under continuous water flow). Sur-
vey of the material using X-Ray Diffraction (XRD) showed
primary peak at 2θ = 14, thus indicating absence of mixed
lithium phase (Figure 2a).3,21 This was confirmed using Induc-
tive Coupled Plasma-Mass Spectrometry (ICP-MS), which
showed molecular ratios of samples obtained through dialysis
to contain more than ten-fold less Li than the typical centrifu-
gation purification process (vide infra). Atomic Force Micros-
copy (AFM) revealed sheets with average diameters of 0.7ꢀm,
and average thicknesses between ~0.8 and 1.5 nm, consistent
with reported values of monolayers.22 Additionally, the inter-
nal edges mentioned previously become are visible (Figure 2b,
S6).18 Transmission Electron Microscopy (TEM) Selective
Area Diffraction (SAD) showed six-fold symmetrical diffrac-
tion spots (2H phase) with additional points in between those
diffraction points (1T phase, Figure S7). This is consistent
with previous reports by Dungey, et al,17 for ce-MoS2, thus
indicating a mixed 1T and 2H material. Separately, Dynamic
To obtain large quantities of single-layer MoS2 sheets, solu-
tion based exfoliation methods are often used. Most typically,
this involves chemical exfoliation using lithium intercalation,
which can produce single layer MoS2 sheets in scalable quanti-
ties.14-16 In this method, lithium is inserted between MoS2 lay-
ers and then reacted with water to produce hydrogen gas at the
interface. This, in combination with ultrasoncation, then ena-
bles the high yield production of water dispersible ce-MoS2
sheets.14 Due to the violent nature of this reaction however,
MoS2’s crystal structure becomes deformed,3,17 and internal
edges (tears, pinholes and defects) can become visible.18 Pre-
vious work has suggested these edge sites to possess higher
molecular affinities,19 with theoretical suggestions of thiol
edge absorption.20 It is thus possible that ce-MoS2, which pos-
sesses defects in both internal edges and perimeter edges, may
be amenable to thiol ligand modifications. As this has not been
explicitly demonstrated, we show conjugation of ce-MoS2
