Stabilizing unusual conformations in small peptides and glucopeptides using a
hydroxylated cyclobutane amino acid†
Alberto Ferna´ndez-Tejada, Francisco Corzana,* Jesu´s H. Busto, Alberto Avenoza and Jesu´s M. Peregrina*
Received 7th April 2009, Accepted 1st May 2009
First published as an Advance Article on the web 8th June 2009
DOI: 10.1039/b907091p
The synthesis and the conformational study in the solid state and in aqueous solution of a peptide and
a glucopeptide containing the non-natural (1S,2S)-1-amino-2-hydroxycyclobutanecarboxylic acid
(c4Ser) residue are reported. This is the first example of a glycopeptide containing a carbohydrate
moiety linked to an underlying non-natural amino acid residue. The conformational analysis in
solution combines NOEs and coupling constants data with Molecular Dynamics (MD) simulations
with time-averaged restraints. The study reveals that the c4Ser-Ala-Ala diamide peptide shows a
conformation of two consecutive b-turn type III structures (the basic structural element of a 310 helix).
However, none of the turns observed in the peptide are present in the derived glucopeptide. The
influence of the carbohydrate moiety on the peptide backbone can be explained by means of the
existence of two simultaneous hydrogen bonds, between the endocyclic oxygen of the glucose and two
amidic protons of the peptide. In addition, the non-natural residue favors the existence of an unusual
high energy conformation for the glycosidic linkage, the so-called anti-f conformation.
acids,8 show that these molecules can stabilize conformations
Introduction
present in naturally occurring molecules or exhibit some atypical
Small natural peptides are in general conformationally flexible and
conformations. This feature could be a powerful tool to design and
are therefore not suitable to study or control secondary peptide
modulate the conformational space of the different synthesized
structures. Taking into account that one attractive approach
glycopeptides.
to restrict peptide conformation involves the incorporation of
quaternary a-amino acids in the peptidic chain,1 the synthesis
With the intention of expanding our novel small systems,
we herein report the synthesis and the conformational anal-
of a,a-disubstituted a-amino acids has been the concern of many
synthetic organic chemists.2 Therefore, with the aim of increasing
the possibilities in terms of producing modified peptides with new
properties or functions, the synthesis and conformational study
of peptides containing non-natural amino acids is still undergoing
continual advancement and optimization. It is well-known, for
instance, that the Ca tetrasubstitution in small homopeptides
favours the stabilization of 310 or a-helixes.3 Additionally, in
short peptides, a,a-disubstituted a-amino acids stabilize turn
structures,4 which have received particular attention because they
play an important role in proteins from both structural and
functional points of view.5 On this basis, and in order to modify
the active conformation of a peptide, several artificial turns have
been reported in the past.6
ysis in aqueous solution of peptide 1 and its corresponding
b-O-glucopeptide 2 (Fig. 1). In addition, the structures found
in solution are compared to that obtained in the solid state for
peptide 1. It is important to emphasize that, to the best of our
knowledge, this is the first synthesized glycopeptide reported to
date that incorporates a non-natural amino acid at the underlying
residue.
To go one step further, and taking into account the important
role that glycopeptides play in fundamental biological processes,7
we are working on the design of novel glycopeptides that incorpo-
rate non-natural amino acids in their structures. Our preliminary
results, carried out on the simplest non-natural glycosylated amino
Departamento de Qu´ımica, Universidad de La Rioja, Grupo de S´ıntesis
Qu´ımica de La Rioja, UA-CSIC, 26006, Logron˜o, Spain. E-mail:
jesusmanuel.peregrina@unirioja.es; Fax: +34 941 299621
† Electronic supplementary information (ESI) available: NMR spectra for
n
all new compounds, full assignment of protons and JH,H couplings for
compound 2, sections of the 800 ms 2D NOESY spectra (400 MHz) in
H2O/D2O (9:1) for compound 2 and X-ray diffraction structure for com-
pound 9. CCDC reference number 716958. For ESI and crystallographic
data in CIF or other electronic format see DOI: 10.1039/b907091p
Fig. 1 Compounds studied in this work.
This journal is
The Royal Society of Chemistry 2009
Org. Biomol. Chem., 2009, 7, 2885–2893 | 2885
©

View Article Online
MeONa/MeOH to give the glycopeptide 2 with a moderate overall
yield (Scheme 2).
Results and discussion
Synthesis
The synthesis of peptide 1 was started from the commercially
available N-Boc-Ala derivative 3. This compound was treated
with MeNH2·HCl and N,N,N¢,N¢-tetramethyl-O-(benzotriazol-
1-yl)uronium tetrafluoroborate (TBTU) as a coupling agent in
the presence of diisopropylethylamine (DIEA) as a base to give
the amide 4. Removal of the Boc group and the subsequent
treatment of the resulting amine 5 with an additional equivalent
of compound 3 gave the dipeptide 6. This compound was
firstly treated with trifluoroacetic acid (TFA) and then with the
racemic mixture of cyclobutane derivative 8, which was previously
synthesized by our group,2 to give a mixture of protected
peptides 9 and 10. The purification of compound 9 by column
chromatography on silica gel and hydrogenolysis of the benzyl
group with hydrogen in the presence of Pd/C as a catalyst gave
the desired peptide 1 (Scheme 1). Single crystals suitable for
X-ray analysis were obtained for compound 1, which allowed us
to determine the relative stereochemistry. Knowing the absolute S
configuration of two of the stereogenic centers allowed the con-
figuration of stereogenic centers in the cyclobutane ring also to be
deduced as S.
Solid state structure of peptide 1
The atom numeration and the labels of the different torsional
angles of compounds 1 and 2 are shown in Fig. 2.
Some important conclusions can be drawn with respect to
the solid state (Fig. 3 and Supporting Information†). Firstly,
a conformation consisting of two consecutive b-turns type III,
slightly deviating from an ideal 310 helix structure, was obtained in
the solid state for compound 1. The torsion angles (f,y) shown in
Fig. 3 resemble the typical values for a b-turn type III (-60◦, -30◦
and -60◦, -30◦). The structure is stabilized by two intramolecular
˚
hydrogen bonds (with N–H ◊ ◊ ◊ O distances of 2.02 and 2.06 A,
respectively and N–H ◊ ◊ ◊ O angles of 166◦ and 161◦, respectively).
A similar structure has been recently found for a tripeptide
containing a tetrahydrofuran Ca-tetrasubstituted amino acid.4
Secondly, the cyclobutane ring adopts only one conformation,
with a pucker angle q equal to -28.3◦. In addition, the substituent
at carbon Cb occupies an equatorial position. This result is in
accordance with the crystal structure of different cyclobutane
derivatives previously studied in the solid state.10
The corresponding model glycopeptide 2 was obtained follow-
ing the modified conditions of the Koenigs–Knorr glycosylation.9
The treatment of peptide 1 with 2,3,4,6-tetra-O-benzoyl-a-D-
glucopyranosyl bromide in the presence of AgTfO gave derivative
11. The hydroxyl groups of this compound were deprotected using
Conformational preferences of peptide 1 in aqueous solution
The conformational preferences of the tripeptide 1 were examined
with experimentally restrained MD simulations using a protocol11
Scheme 1 Synthesis of peptide diamide 1.
This journal is
2886 | Org. Biomol. Chem., 2009, 7, 2885–2893
The Royal Society of Chemistry 2009
©

View Article Online
Scheme 2 Synthesis of glucopeptide diamide 2.
Fig. 2 Molecular structure of glucopeptide 2, showing the atom numer-
ation and the most relevant torsional angles. Letter ‘s’ makes reference
to the carbohydrate moiety. The blue and green numbers make reference
to the numeration of the NH and methyl groups, respectively. The same
numbering and labels were used for peptide 1 (a). The pucker angle q
of the cyclobutane ring is defined as the acute angle between the planes
Ca-Cb-Cd and Cb-Cg-Cd (b).
Fig. 3 Some geometrical features of the crystal structure of peptide 1.
Heteroatoms are shown in color; blue for the nitrogen atom and red for
oxygen atom. Thermal ellipsoids drawn at the 50% probability level.
and NH3–NH4 NOEs (characteristic of folded ones), shown in
Fig. 4, suggests the coexistence of both conformations in aqueous
solution for the two alanine residues of peptide 1. On the other
hand, the medium NOE observed between NH1 and NH2 suggests
an important population of a helix-like conformation for the
cyclobutane residue.12
similar to that recently applied by our group on different model
glycopeptides.
NMR data. In a first step, full assignment of the protons of
compounds 1 and 2 was carried out using COSY and HSQC
experiments and it is given in Table 1 and in the Supporting
Information (Table S1†). Selective 1D-NOESY experiments in
D2O (25 ◦C, pH = 5.2) and 2D-NOESY experiments in H2O/D2O
(9/1) (25 ◦C, pH = 4.84) were then carried out (see Experimental
Section).
The next step was to experimentally determine some proton-
proton distances relevant to the conformational analysis. The
distances involving NH protons were semi-quantitatively deter-
mined by integrating the volume of the corresponding cross-peaks
in the 2D NOESY spectrum. Additionally, some proton-proton
distances were obtained from the corresponding NOE build-
up curves13 (see Supporting Information†). On the other hand,
3JNH,Ha coupling constants were measured from the splitting of the
resonance signals in the 1D spectrum. All these experimentally
The medium-strong Ha2–NH3, Ha3–NH4 (typical of extended
conformations), Ha2–NH2, and Ha3–NH3, as well as NH2–NH3
This journal is
The Royal Society of Chemistry 2009
Org. Biomol. Chem., 2009, 7, 2885–2893 | 2887
©
