R. Gꢁmez Arrayꢀs, J. C. Carretero and J. Hernꢀndez-Toribio
this complex the high steric congestion imposed by the tert-
butyl group linked to the sulfur atom in close proximity to
the copper center hinders the approach of the N-(8-quino-
lyl)sulfonyl imine from the Re C-a enolate face of the azo-
methine. Thus, the approach of I from the more accessible
Si C-a enolate face to the N-sulfonyl imine could explain
the high stereoselectivity attained in the formation of the
a,b-diamino esters with (2S) configuration in both the syn-
and anti-configured a,b-diamino acid derivatives. As a work-
ing hypothesis, the diastereoselectivity switch from anti
(when using aldimine-derived glycinate esters as pronucleo-
philes) to syn (in the case of ketimine-derived glycinates)
could be explained invoking steric interactions during the
approach of the imine to the enolate I (intermediates II).
For instance, the reaction with aldimine pronucleophiles
(R1 =H) is assumed to proceed more favourably via the in-
termediate IIa, which accounts for the observed anti-(2S,3S)
configuration in the Mannich adducts. The Re face approach
of the N-sulfonyl aldimine minimizes the steric repulsion be-
tween its bulky N-sulfonyl substituent and the glycinate
imine group (R1 =H, Scheme 3). In contrast, the presence of
a bulky N-diarylmethylene group (R1 =Ar) in the ketimine
pronucleophile would disfavor IIa because of its severe
steric repulsion with the N-(8-quinolyl)sulfonyl group, thus
forcing the imine to approach from its Si face via the inter-
mediate IIb that would account for the formation of the
syn-(2S,3R)-adducts.
In summary, a diastereoselectivity switch from anti- to
syn- has been devised in the catalytic asymmetric direct
Mannich reaction of glycine derivatives with N-(8-quinolyl)-
sulfonyl imines by tuning the steric and electronic properties
of the glycine imine. a,b-Diamino acids of syn-configuration
are produced with glycinate esters derived from electron-de-
ficient benzophenone-type ketimines, in contrast to aldi-
mine-derived pronucleophiles that lead to anti-configured
products. The Fesulphos–CuI catalyst is crucial for achieving
high asymmetric induction. The selective orthogonal N-de-
protection of the resulting a,b-diamino ester adducts can be
effected under mild conditions in good yields.
Acknowledgements
This work was supported by the Ministerio de Ciencia e Innovaciꢁn
(MICINN, project CTQ2006-01121). J.H.T. thanks the MICINN for a
predoctoral fellowship.
Keywords: copper catalysis · diastereoselectivity · glycine ·
Mannich reaction
[1] For a comprehensive review on synthetic approaches and biological
significance of a,b-diamino acids, see: A. Viso, R. Fernꢀndez de
[2] For recent reviews on catalytic asymmetric Mannich reaction: a) A.
kade, L. J. C. vanHemert, P. J. L. M. Quaedflieg, F. P. J. T. Rutjes,
[3] For a recent review on the synthesis of a,b-amino acids via catalytic
asymmetric direct Mannich reaction, see: R. Gꢁmez Arrayꢀs, J. C.
Carretero, Chem. Soc. Rev. 2009, 38, 1940.
[4] a) L. Bernardi, A. S. Gothelf, R. G. Hazell, K. A. Jørgensen, J. Org.
H. Mihara, A. Kuramochi, T. Ohshima, M. Shibasaki, Chem. Asian
J. 2007, 2, 794; f) G. A. Cutting, N. E. Stainforth, M. P. John, G.
14088; h) S. Kobayashi, R. Yazaki, K. Seki, Y. Yamashita, Angew.
X. Yan, Q. Peng, Q. Li, K. Zhang, J. Yao, X.-L. Hou, Y.-D. Wu, J.
R. Li, X. Tian, X.-F. Xiong, J.-G. Deng, Y.-C. Chen, Chem. Eur. J.
[7] For the aza-Henry reaction between a-nitro acetates and a-imino
[8] J. Hernꢀndez-Toribio, R. Gꢁmez Arrayꢀs, J. C. Carretero, J. Am.
Chem. Soc. 2008, 130, 16150.
Experimental Section
Representative procedure for the synthesis of syn-a,b-diamino acid deriv-
atives: Reaction of tert-butylglycinate 4,4’-dicholorobenzophenone Schiff
base (2d) with N-benzylidene-N-[(8-quinolyl)sulfonyl]imine (3 f) to
afford (2S,3R)-tert-butyl 2-[(bis(4-chlorophenyl)methylene)amino]-3-
phenyl-3-[(8-quinolyl)-sulfonylamino]propanoate (16): To a solution of
[9] For other recent applications of commercially available Fesulphos
ligand in asymmetric catalysis, see: a) O. Garcꢂa MancheÇo, R.
Gꢁmez Arrayꢀs, J. Adrio, J. C. Carretero, J. Org. Chem. 2007, 72,
7832; b) A. Salvador Gonzꢀlez, M. Rogrꢂguez Rivero, R. Gꢁmez
Arrayꢀs, J. C. Carretero, Org. Lett. 2008, 10, 4335; c) A. Lꢁpez-
Perez, J. Adrio, J. C. Carretero, J. Am. Chem. Soc. 2008, 130, 10084;
d) S. Filipone, E. E. Maroto, A. Martꢂn-Domenech, M. Suarez, N.
Martꢂn, Nat. Chem. 2009, 1, 578.
[10] For previous applications of N-(8-quinolyl)sulfonyl imines in asym-
metric catalysis: a) J. Esquivias, R. Gꢁmez Arrayꢀs, J. C. Carretero,
H. Sugimoto, H. Sano, M. Hattori, N. Shibata, T. Toru, Chem. Eur.
imines: c) H. Morimoto, G. Lu, N. Aoyama, S. Matsunaga, M. Shiba-
Fesulphos ligand (R)-1 (1.9 mg, 0.005 mmol) and CuACTHNUTRGNE(UNG CH3CN)4PF6
(2.3 mg, 0.005 mmol), in THF (0.5 mL) at À208C, were successively
added a solution of 2d (36.4 mg, 0.1 mmol) in THF (1.0 mL), Et3N
(1.4 mL, 0.01 mmol) and a solution of 3 f (32.6 mg, 0.11 mmol) in THF
(1.0 mL). The mixture was stirred at À208C for 3 h before it was filtered
through Celite and the filtrate concentrated to dryness. The residue was
1
analyzed by H NMR to determine the diastereomeric ratio and then pu-
rified by flash chromatography (n-hexane/EtOAc 3:1) to afford 16 as a
white solid (58.1 mg, 88%, syn/anti 97:3). M.p. 98–998C. See Supporting
Information for spectroscopic data.
