Synthesis and Fluorescence Properties
of a Pyridomethene-BF2 Complex
Yasuhiro Kubota,*,† Toshihiro Tsuzuki,† Kazumasa Funabiki,† Masahiro Ebihara,‡
and Masaki Matsui*,†
Department of Materials Science and Technology, Faculty of Engineering, Gifu
UniVersity, Yanagido, Gifu 501-1193, Japan, and Department of Chemistry, Faculty of
Engineering, Gifu UniVersity, Yanagido, Gifu 501-1193, Japan
kubota@gifu-u.ac.jp; matsuim@gifu-u.ac.jp
Received July 13, 2010
ABSTRACT
A fluorescent dye, the pyridomethene-BF2 complex, has been synthesized. Although pyridomethenes did not exhibit fluorescence,
pyridomethene-BF2 complexes exhibited fluorescence both in solution and in the solid state. The trifluoromethyl-substituted BF2 complex
formed a J-aggregate and showed the highest fluorescence quantum yield in the solid state among all pyridomethene-BF2 com-
plexes.
Borondipyrromethene (BODIPY) dyes1,2 are well-known
fluorescent dyes with high fluorescence quantum yields, high
extinction coefficients, sharp absorption and fluorescence
emission spectra, and high photo- and chemical stability.
Owing to these excellent characteristics, BODIPY dyes have
a wide range of applications. They can be used in chemosen-
sors,3 in biolabels,4 as sensitizers for dye-sensitized solar cells,5
and as donor materials for bulk heterojunction solar cells,6 as
well as in photodynamic therapy.7 However, most BODIPY
dyes have defects such as very small Stokes shifts (5-20 nm,
in most cases) and high planarity.8 These defects cause the self-
quenching of BODIPY dyes in the solid state. Therefore, most
BODIPY dyes hardly fluoresce in the solid state.9
(3) (a) Mo´cza´r, I.; Huszthy, P.; Maidics, Z.; Ka´da´r, M.; To´th, K.
Tetrahedron 2009, 65, 8250. (b) Guliyev, R.; Buyukcakir, O.; Sozmen, F.;
Bozdemir, O. A. Tetrahedron Lett. 2009, 50, 5139. (c) Sekiya, M.;
Umezawa, K.; Sato, A.; Citterio, D.; Suzuki, K. Chem. Commun. 2009,
3047. (d) Sun, Z. N.; Wang, H. L.; Liu, F. Q.; Chen, Y.; Kwong, P.; Tam,
H.; Yang, D. Org. Lett. 2009, 11, 1887. (e) Lee, H. Y.; Bae, D. R.; Park,
J. C.; Song, H.; Han, W. S.; Jung, J. H. Angew. Chem., Int. Ed. 2009, 48,
1239. (f) Coskun, A.; Akkaya, E. U. J. Am. Chem. Soc. 2005, 127, 10464.
(g) Atilgan, S.; Ozdemir, T.; Akkaya, E. U. Org. Lett. 2008, 10, 4065. (h)
Guliyev, R.; Coskun, A.; Akkaya, E. U. J. Am. Chem. Soc. 2009, 131, 9007.
(4) (a) Gonc¸alves, M. S. T. Chem. ReV. 2009, 109, 190. (b) Wang, D.;
Fan, J.; Gao, X.; Wang, B.; Sun, S.; Peng, X. J. Org. Chem. 2009, 74,
7675.
† Department of Materials Science and Technology.
‡ Department of Chemistry.
(1) (a) Loudet, A.; Burgess, K. Chem. ReV. 2007, 107, 4891. (b) Ulrich,
G.; Ziessel, R.; Harriman, A. Angew. Chem., Int. Ed. 2008, 47, 1184
.
(2) (a) Tram, K.; Yan, H.; Jenkins, H. A.; Vassiliev, S.; Bruce, D. Dyes
Pigm. 2009, 82, 392. (b) Arroyo, I. J.; Hu, R.; Merino, G.; Tang, B. Z.;
Pen˜a-Cabrera, E. J. Org. Chem. 2009, 74, 5719. (c) Schmitt, A.; Hinkeldey,
(5) (a) Ertan-Ela, S.; Yilmaz, M. D.; Icli, B.; Dede, Y.; Icli, S.; Akkaya,
E. U. Org. Lett. 2008, 10, 3299. (b) Hattori, S.; Ohkubo, K.; Urano, Y.;
Sunahara, H.; Nagano, T.; Wada, Y.; Tkachenko, N. V.; Lemmetyinen,
H.; Fukuzumi, S. J. Phys. Chem. B 2005, 109, 15368.
B.; Wild, M.; Jung, G. J. Fluoresc. 2009, 19, 755
.
10.1021/ol101612z  2010 American Chemical Society
Published on Web 08/20/2010

On the other hand, fluorescent boron complexes excluding
BODIPY dyes have attracted considerable attention in recent
times.10 A pyridomethene-BF2 complex is an analogue of
a BODIPY dye. To the best of our knowledge, some
papers11 and some patents12 have been published on the
pyridomethene-BF2 complex. However, the fluorescence
properties of the complex have not been investigated in detail.
In the present paper, we not only describe a convenient
method for synthesizing the pyridomethene-BF2 complex
but also present its fluorescence properties.
BODIPY dyes are synthesized by the reaction of py-
rromethene (dipyrrin)13 with trifluoroborane. Therefore, it
was supposed that pyridomethene would be a good precursor
to the pyridomethene-BF2 complex. Pyridomethene is an
enamine tautomer of bis(2-pyridyl)methane (Figure S1,
Supporting Information (SI)). Because of the aromatic
stability of the pyridine ring, pyridomethene mostly exists
in the imine form, i.e., bis(2-pyridyl)methane.14 However,
several reports have described the synthesis of meso-cyano-
substituted pyridomethene derivertives.15 The findings of
these reports indicate that the introduction of a cyano group
at the meso position is an effective way to stabilize the
pyridomethene structure. Our DFT calculations support these
experimental results (Figure S2, SI). We chose meso-cyano-
substituted pyridomethene derivatives as the precursor
because they are easy to obtain and they enable the retention
of the pyridomethene structure.
meso-Cyano-substituted pyridomethene 1 was obtained by
the reaction of 2-(cyanomethyl)pyridine with 2-bromopyri-
dine (Scheme S1, SI).15b The pyridomethene structure of 1
1
was confirmed by the H NMR signal at δ 16.3 (brs, 1H,
D2O exchangeable, NH) and 13C NMR signal at δ 68.2
(s, meso-carbon atom) (Figures S3, S4, SI). The observed
1
symmetrical H and 13C NMR spectra indicate that the rate
of interconversion between 1 and 1′ is faster than the NMR
time scale (Figure S5, SI). The rapid interconversion between
1 and 1′ can be attributed to an imine-enamine tautomerism
and/or a direct hydrogen shift between two nitrogen atoms
in the vinamidine conjugate system. A similar symmetric
property in the NMR spectrum was reported for another
pentacyclic amidine (vinamidine).16
The reaction of 1 with boron trifluoride diethyl ether
complex in the presence of triethylamine yielded the
pyridomethene-BF2 complex 5 (Scheme 1). The structure
(6) (a) Rousseau, T.; Cravino, A.; Bura, T.; Ulrich, G.; Ziessel, R.;
Roncali, J. Chem. Commun. 2009, 1673. (b) Rousseau, T.; Cravino, A.;
Bura, T.; Ulrich, G.; Ziessel, R.; Roncali, J. J. Mater. Chem. 2009, 19,
2298.
(7) (a) Ozlem, S.; Akkaya, E. U. J. Am. Chem. Soc. 2009, 131, 48. (b)
Erbas, S.; Gorgulu, A.; Kocakusakogullaric, M.; Akkaya, E. U. Chem.
Commun. 2009, 4956. (c) Atilgan, S.; Ekmekci, Z.; Dogan, A. L.; Guc, D.;
Akkaya, E. U. Chem. Commun. 2006, 4398. (d) Gorman, A.; Killoran, J.;
O’Shea, C.; Kenna, T.; Gallagher, W. M.; O’Shea, D. F. J. Am. Chem.
Soc. 2004, 126, 10619.
(8) Small Stokes shift causes the reabsorption of its own fluorescence,
so the fluorescence intensity was decreased. High planarity leads to
increasing intermolecular interactions which cause concentration quench-
ing.
Scheme 1. Synthesis of Pyridomethene-BF2 Complexes
